hylite SLTH030 User manual

Assembly & Fitting Instructions
SLIMLINE GREENHOUSE
& SHED HEATER
WITH BUILT-IN THERMOSTAT

PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE ATTEMPTING TO INSTALL AND OPERATE THIS HEATER
IMPORTANT SAFETY INSTRUCTIONS
WHILST MEETING THE REQUIREMENTS OF BS:EN90335-2-30, THE SURFACE OF THIS TUBULAR HEATER CAN STILL
GET HOT. IT IS THEREFORE RECOMMENDED THAT THE AGED, INFIRM, CHILDREN AND ANIMALS ARE NOT LEFT
UNSUPERVISED IN THE VICINITY OF THE HEATER UNLESS A SUITABLE GUARD IS FITTED.
DUE TO THE HIGH SURFACE TEMPERATURES, IT IS ESSENTIAL THAT COMBUSTIBLE OR FLAMMABLE OBJECTS
SUCH AS FABRICS OR CLOTHING DO NOT COME INTO CONTACT WITH THE HEATER.
IF A TUBULAR HEATER IS TO BE INSTALLED IN A PLACE USED BY THE PUBLIC A WARNING NOTE SHOULD BE
PLACED ADJACENT TO THE HEATER AVISING THAT THE SURFACE IS HOT.
ENSURE THE POWER CORD IS PUSHED FULLY INTO THE POWER SOCKET IN THE HEATER WHEN IN OPERATION.
IF THE CORD IS DAMAGED DISCONTINUE USING THE PRODUCT AND CONTACT THE MANUFACTURER FOR
FURTHER INSTRUCTIONS.
ALWAYS SWITCH THE HEATER OFF AT THE MAINS WHEN NOT IN USE AND ENSURE THE POWER CORD IS NOT IN
CONTACT WITH THE SURFACE OF THE HEATER.
THE HEATER MUST ALWAYS BE POSITIONED HORIZONTALLY USING THE MOUNTING BRACKETS SUPPLIED AND
ALLOWING FREE MOVEMENT OF AIR AROUND THE HEATER. DO NOT COVER THE HEATER AS THIS MAY CAUSE
OVERHEATING.
THE HEATER IS WATER RESISTANT (IP44 RATED) AND IS SUITABLE FOR USE IN LOFTS, GARAGES, UTILITY ROOMS,
AIRING CUPBOARDS, SHEDS, DISPLAY WINDOWS ETC. HOWEVER IT IS NOT WATERPROOF AND SHOULD NOT BE
USED IN ENVIRONMENTS WHERE CONTINUOUS OR EXCESSIVE WATER-SPRAYING MAY OCCUR.
DO NOT USE THE HEATER IN BATHROOMS, SHOWERS OR SWIMMING POOLS.
WHEN USING THE HEATER IN AN AREA WHERE IT MAY COME INTO CONTACT WITH WATER,
AND TO ENSURE IT’S IP44 RATING IS MAINTAINED - ALWAYS ENSURE THAT THE POWER
CABLE HAS THE BLACK FOAM GASKET IN PLACE ON THE CONNECTOR END BEFORE
PLUGGING IT INTO THE SLIMLINE HEATER [FIG.1]
IMPORTANT SAFETY ADVICE
1. INSTALLING THE SLIMLINE ECOHEATER
IMPORTANT: The heater should only be operated in the
horizontal plane, using the mounting brackets provided.
• Dimensions of the heaters are shown in [Fig.2].
Wattage A
55 500mm
90 750mm
120 1000mm
190 1500mm
• Before installing the heater it is recommended that
the power cable is attached by pushing it fully into the
heaters power cable socket [Fig.3].
Assembly & Fitting Instructions
Fig.1
70mm
95mm
A
Fig.2
Fig.3
English

IF FITTING TO A WALL
• Follow minimum clearances below and above the heater as shown in [Fig.4].
• Once a suitable location has been found, screw the two bottom halves of
the bracket to the wall (Fig.5).
• Place the Eco Heater on the brackets and then fasten top part of the
brackets over tube to secure.
DO NOT SWITCH ON THE HEATER UNTIL IT IS SECURED.
FIXING TO A FLOOR OR OPERATING THE HEATER FREESTANDING
• Follow the minimum clearances around the heater as shown in [Fig.6].
• If operating as a freestanding heater, fix brackets along the length of
the heater to adequately support the unit and ensure it is stable.
• Attach rubber boots to the feet of the bracket [Fig.7] to increase stability.
INSTALLING MORE THAN ONE HEATER
• Minimum clearances as shown in [Fig.8] must be observed when the
heater is in use.
• Ensure the power cable is pushed fully into the heaters power socket
before switching power on.
• Turn the thermostat knob in a clockwise direction until it reaches the
maximum setting [Fig.9].
• When the room has reached the desired temperature, turn the
thermostat knob in an anti-clockwise direction just until the appliance
switches off (amber yellow light goes out) and not beyond.
• The temperature will then be regulated and kept at a constant level by
the thermostat.
• The heater is fitted with a safety device which will switch off the heater
in case of accidental overheating (please see safety notes).
• To reset, disconnect the heater from the power source for a few
minutes to allow the unit to cool down.
• Make sure that any causes of overheating, such as obstructions, are
removed and plug the appliance in again.
• DO NOT DIRECTLY EXPOSE TO WATER
PLEASE NOTE: When the heater is switched on for the first time,
small wisps of smoke may drift from the heater. This is a perfectly
normal part of the first time operating procedure and should cease
after the heater has been operating for approximately 5 minutes
2. OPERATION
Fig.7
Fig.4
Wall Mounting
30mm min.
200mm min.
30mm min.
Floor Mounting
Fig.6
Fig.5
Fig.9
50mm
min.
30mm min.
50mm
min.
30mm
min.
175mm
min.
Fig.8
English

English
Hylite tries to improve its products for the benefit of its
customers. For this reason we reserve the right to make
changes to any product at any time without notice.
Please note that this equipment and its components have
no user serviceable parts. If you experience any difficulties
installing this product please call our helpline or write to
F4 Enterprises Limited.
F4 Enterprises Limited
7 Abbey Square, Chester
CH1 2HU, UK
Tel: [phone]
www.f4enterprises.co.uk
