HYOSUNG MS3 125 User manual

This owner’s manual contains important safety information.
Please read it carefully.
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 1 JINSUN 300DPI 100LPI T

1
This manual should be considered a permanent part of the motorcycle and
should remain with the motorcycle when resold or otherwise transferred to
a new owner or operator. The manual contains important safety informa-
tion and instructions which should be read carefully before operatin the
motorcycle.
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 1 JINSUN 300DPI 100LPI T
COPYRIGHTED

2
All information, illustrations photographs
and specifications contained in this manual
are based on the latest product information
available at the time of publication. Due to
improvements or other changes, there may
be some discrepancies in this manual.
Hyosung reserves the right to make
changes at any time.
Please note that this manual applies to all
specifications for all respective destinations
and explains all e uipments. Therefore,
your model may have different standard
features than shown in this manual.
FOREWORD
THANK YOU for choosing Hyosun
motorcycle. We at Hyosun have
designed, tested and produced these
motorcycles using the most modern tech-
nology available to provide you with much
happy, enjoyable, safe riding. Motorcycling
is one of the most exhilarating sports and
insure your riding enjoyment, you should
become thoroughly familiar with the infor-
mation presented in this Owner's Manual
before riding the motorcycle.
The proper care and maintenance that
your motorcycle re uires are outlined in this
manual.
By following these instructions explicitly
you will insure a long trouble-free operating
life for your motorcycle. Your Hyosung deal-
er has experienced technicians that are
trained to provide your machine with the
best possible service with the right tools and
e uipment.
COPYRIGHT S&T Motors Co., Ltd.
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 2 JINSUN 300DPI 100LPI T
COPYRIGHTED

3
IMPORTANT
BREAK-IN INFORMATION FOR
YOUR MOTORCYCLE
The first 1,600 km (1,000 miles) are the
most important in the life of your motorcycle.
Proper break-in operation during this time
will help ensure maximum life and perfor-
mance from your new motorcycle.
Hyosung parts are manufactured of high
uality materials, and manufactured parts
are finished to close tolerances. Proper
break-in operation allows the machined sur-
faces to polish each other and mate
smoothly.
Motorcycle reliability and performance
depend on special care and restraint exer-
cise during the break-in period. It is espe-
cially important that you avoid operating the
engine in a manner which could expose the
engine parts to excessive heat.
Please refer to the BREAK-IN section for
specific break-in recommendations.
WARNING / CAUTION / NOTE
Please read this manual and follow its
instructions carefully.
To emphasize special information the
words WARNING , CAUTION and
NOTE have special meanings.
Information following these signal words
should be carefully reviewed.
N O T E
This provides special information to
make maintenance easier or impor-
tant instructions clearer.
These instructions point out special
service procedures or precautions
that must be followed to avoid dam-
a in the machine.
CAUTION
The personal safety of the rider may
be involved. Disre ardin this infor-
mation
could result in injury to the rider.
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 3 JINSUN 300DPI 100LPI T
COPYRIGHTED

4
Noise Control System (muffler assembly)
TAMPERING WITH NOISE CONTROL SYSTEM PROHIBITED
Owners are warned that the law may prohibit :
(a) The removal or renderin inoperative by any person other than for the
purpose of maintenance, repair or replacement, of any device or ele-
ment of desi n incorporated into any new vehicle for the purpose of
noise control prior to its any sale or delivery to the ultimate purchaser or
while it is in use ; and
(b) The use of the vehicle after such device or element of desi n has been
removed or rendered inoperative by any person.
MAINTENANCE :
The exhaust system of this motorcycle requires no periodic maintenance.
The en ine should be adjusted to the manufacture’s specifications and the
spark plu should be kept in ood condition. Runnin the en ine with
incorrectly operatin spark plu or misadjusted carburetor may cause per-
manent dama e to the catalyst and to the noise control system.
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 4 JINSUN 300DPI 100LPI T
COPYRIGHTED

5
Motorcycle riding is great fun and an excit-
ing sport. Motorcycle riding also re uires
that some extra precautions be taken to
ensure the safety of the rider and passen-
ger. These precautions are :
Before first use of the
read this owner’s man-
ual carefully to become familiar
with the ’s
features, and safety and mainte-
nance requirements. Review all
instructions, requirements and
warnin s with the riders. Keep the
owner’s manual in the owner’s
manual stora e compartment locat-
ed under the seat.
Before the rider’s first use of the
, make
sure that he / she is familiar with
the location and operation of all
controls, and has been instructed
in the proper operation of the
motorcycle.
For first use of the
, find a level, open ar-
ea for the rider to use to become
familiar with the operation of
controls and the operatin and
handlin characteristics of the
.
WARNING
Before each use, perform daily
inspections with the rider. Specific
items to check are listed in the
INSPECTION BEFORE RIDING sec-
tion on pa e 52 of this owner’s
manual.
Make sure the rider wears a helmet,
eye protection, and protective
clothin ( loves, leather or heavy
cloth pants, lon sleeved shirt or
jacket, boots).
Permit use only by dual rider.
These motorcycles are desi ned
for use only by dual rider.
Do not permit anyone to operate
the under
the influence of alcohol or other
dru s caused by dama e to the
motorcycle or altered handlin
characteristics.
Observe periodic maintenance
requirements your authorized
HYOSUNG dealer is trained and
equipped to perform this service.
Drain asoline from the fuel tank
prior to transportin the
.
Caution the rider and others near
the not to
et close to or touch any movin
parts or any heated areas such as
the en ine and exhaust system.
Do not make any modifications to
the .
Modifications may make the motor-
cycle unsafe or ille al in your state.
Never operate at excessive speed.
Always o at a speed that is proper
for terrain, visibility and operatin
conditions, your skill and experi-
ence.
Never attempt stunts.
WARNING
CONSUMER INFORMATION
SAFE RIDING RECOMMENDATION
FOR MOTORCYCLE RIDERS
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 5 JINSUN 300DPI 100LPI T
COPYRIGHTED

6
Do not run the en ine indoors or
where there is little or no ventila-
tion. Exhaust ases contain carbon
monoxide, a potentially lethal as
that is colorless and odorless.
Never leave the motorcycle run-
nin while unattended, even for a
short time.
WARNING
These motorcycles always come on
the head lamp, position lamp, meter
lamp, tail lamp and license plate lamp
when the i nition switch is turned to
the “ ”(ON) position.
CAUTION
While operatin the
, the rider should keep both feet
on the footrests at all times, or
injuries resultin from accidents.
Movin the rider’s feet from the
footrests reduces the rider’s ability to
control the motorcycle, and could
lead to an accident.
WARNING
Keep both hands on the hand rips at
all times when ridin . Removin your
hands from the hand rips reduces
your ability to control the motorcycle,
and could result in an accident.
WARNING
Always open the throttle radually to
prevent front wheel liftin . Failure to
observe this precaution may result in
loss of control and an accident.
WARNING
WHEN KEEPING FOR LONG PERIOD :
1. Supply the enou h fuel in the fuel
tank.
2. Remove the battery from the motor-
cycle.
CAUTION
The trunk could be heated. Don’t
keep anythin that doesn’t endure
heat.
Don’t keep the fra ile.
Check if it is locked.
The unlockin of trunk could cause
serious accident.
Don’t allow water to et inside the
trunk or it could dama e.
Don’t keep the valuables in the
trunk when leavin unattended.
Loadin limit of front stora e box
: 1.5 k (3.3 lbs)
Loadin limit of personal trunk
: 10 k (22.1 lbs)
Loadin limit of rear carrier
: 5 k (11.0 lbs)
Exceed loadin limit may result in
injury caused by dama e to the
vehicle or altered handlin charac-
teristics.
CAUTION
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 6 JINSUN 300DPI 100LPI T
COPYRIGHTED

7
WEAR A HELMET
RIDING APPAREL
INSPECTION BEFORE RIDING
FAMILIARIZE YOURSELF WITH
THE MOTORCYCLE
KNOW YOUR LIMITS
BE EXTRA SAFETY CONSCIOUS
ON BAD WEATHER DAYS
Motorcycle safety equipment starts
with a quality safety helmet. One of
the most serious injuries that can
happen is a head injury. ALWAYS
wear a properly approved helmet. You
should also wear a suitable eye pro-
tection.
WARNING
Do not operate the i nition switch in
the “ ”(OFF) or “ ”(LOCK) position
or the en ine stop switch in the “ ”
position while drivin at one’s plea-
sure.
WARNING
Loose fancy clothin can be uncom-
fortable and unsafe in terms of ridin
your motorcycle.
Choose ood quality motorcycle rid-
in apparel in terms of ridin your
motorcycle.
WARNING
Review thorou hly the instructions in
the “INSPECTION BEFORE RIDING”
section of this manual. Do not for et
to perform an entire safety inspection
to ensure the safety of the rider and
its passen er.
WARNING
Your ridin skill and mechanical
knowled e from the foundation for
safe ridin practices.
We su est that you practice ridin
your motorcycle in a non-traffic situa-
tion until you are thorou hly familiar
with your machine and its controls.
Remember practice makes perfect.
WARNING
Ride within the boundaries of your
own skill at all times. Knowin these
limits and stayin within them will
help you to avoid accidents.
WARNING
Ridin on bad weather days, especial-
ly wet ones, requires extra caution.
Brakin distances double on a rainy
day. Stay off of the painted surface
marks, manhole covers and reasy
appearin areas as they can be espe-
cially slippery.
Use extreme caution at railway cross-
in s and on metal ratin s and
brid es. Whenever you have a doubt
about road condition, slow down!
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 7 JINSUN 300DPI 100LPI T
COPYRIGHTED

8
There are a great variety of accessories
available to Hyosun owners. Hyosun
can not have direct control over the uality
or suitability of accessories you may wish to
purchase except genuine parts.
The addition of unsuitable accessories
can lead to unsafe operating conditions. It
is not possible for Hyosun to test each
accessory on the market or combinations
of all the available accessories, however,
your dealer can assist you in selecting ual-
ity accessories and installing them correct-
ly.
Use extreme caution when selecting and
installing the accessories for your
Hyosun . We have developed some gen-
eral guidelines which will aid you when
deciding whether, and how to e uip your
motorcycle.
ACCESSORY INSTALLATION AND
PRECAUTION SAFETY TIPS
The most common type of motorcycle
accident occurs when a car travelin
towards a motorcycle turns round
corner in front of the motorcyclist.
Ride defensively.
Wise motorcyclist uses a strate y of
assumin they are invisible to other
drivers, even in broad dayli ht.
Wear bri ht, reflectin clothin .
Do not ride in another driver’s blind
spot.
WARNING
RIDE DEFENSIVELY
Improper accessories or modifica-
tions can make your motorcycle
unsafe and can lead to an accident.
Never modify the motorcycle with
improper or poorly installed acces-
sories. Follow all instructions in this
owner’s manual re ardin acces-
sories and modifications. Use en-
uine Hyosun accessories or equiva-
lent desi ned and tested for your
motorcycle. Consult your Hyosun
dealer if you have any questions.
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 8 JINSUN 300DPI 100LPI T
COPYRIGHTED

9
1. Anytime that additional weight or aero-
dynamic affecting accessories are
installed, they should be mounted as
low as possible, as close to the motor-
cycle and as near the center of gravity
as is feasible. The mounting brackets
and other attachment hardware should
be carefully checked to ensure that it
provides for a rigid, nonmovable
mount. Weak mounts can allow the
shifting of the weight and create a dan-
gerous, unstable condition.
2. Inspect for proper ground clearance
and bank angle. An improperly mount-
ed load could critically reduce these
two safety factors. Also determine that
the loaddoes not interfere with the
operation of the suspension, steering
or other control operations.
3. Accessories fitted to the handlebars or
the front fork area can create serious
stability problems. This extra weight will
cause the motorcycle to be less
responsive to your steering control.
The weight may also cause oscillations
in the front end and lead to instability
problems. Accessories added to the
machine should be as light as possible
and kept to a minimum.
4. The motorcycle may be affected by a
lifting condition or by an instability in
cross winds or when being passed or
passing large vehicles. Improperly
mounted or poorly designed acces-
sories can result in an unsafe riding
condition, therefore caution should be
used when selecting and installing all
accessories.
5. Certain accessories displace the rider
from his or her normal riding position.
This limits the freedom of movement of
the rider and may limit his or her control
ability.
6. Additional electrical accessories may
damage the existing electrical system.
Severe overloads may damage the
wiring harness or create a dangerous
situation due to the loss of electrical
power during the operation of the
motorcycle.
When carrying a load on the motorcycle,
mount it as low as possible and as close as
possible to the machine. An improperly
mounted load can create a high center of
gravity which is very dangerous and makes
the motorcycle difficult to handle. The size
of the loadcan also affect the aerody-
namics and handling of the motorcycle.
Balance the load between the left and
right side of the motorcycle and fasten it
securely.
MODIFICATION
Modification of the motorcycle, or removal
of original e uipment may render the
motorcycle unsafe or illegal.
Obey all applicable e uipment regulations
in your area.
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 9 JINSUN 300DPI 100LPI T
COPYRIGHTED

10
1. SERIAL NUMBER LOCATION  12
2. FUEL , OIL AND COOLANT RECOMMENDATION  13
FUEL
ENGINE OIL
TRANSMISSION OIL
ENGINE COOLANT SOLUTION
3. NAMES OF EACH PARTS 16
4. CONTROLS  19
IGNITION SWITCH
IGNITION KEY
INSTRUMENT PANEL
LEFT HANDLE SWITCHES
RIGHT HANDLE SWITCHES
STAND
5. HOW TO USE  28
HOW TO OPEN THE SEAT
HOW TO USE THE PERSONAL TRUNK
HOW TO OPEN THE FRONT STORAGE BOX
HOW TO USE THE OUTPUT TERMINAL
6. SUPPLY OF GASOLINE , OIL AND COOLANT  31
GASOLINE
ENGINE OIL
TRANSMISSION OIL
ENGINE COOLANT
7. THE PROPER OPERATIONS 41
STARTING THE ENGINE
STARTING OFF
OPERATING THE BRAKE
STOPPING AND PARKING
8. BREAK-IN  51
9. INSPECTION BEFORE RIDING 52
TABLE OF CONTENTS
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 10 JINSUN 300DPI 100LPI T
COPYRIGHTED

11
10. PERIODIC MAINTENANCE  54
11. INSPECTION AND MAINTENANCE 58
TOOL
ENGINE OIL
TRANSMISSION OIL
GASOLINE
FUEL HOSE
COOLANT
RADIATOR
RUBBER CAP OF CABLES
EXHAUST PIPE AND MUFFLER
REAR-VIEW MIRROR
REFLECTOR
BRAKES
TIRES
AIR CLEANER
FRONT AND REAR SUSPENSIONS
CHECKING THE STEERING
CHECKING THE ENGINE PIVOT
SIDE COVER STAY
HELMETBOX INNER COVER
PASSENGER BACKREST
IDLING ADJUSTMENT
ADJUSTING THE THROTTLE CABLE
SPARK PLUG
BATTERY
HEAD LAMP
BULBS
TROUBLESHOOTING
TRANSPORT
CLEANING PROCEDURE
STORAGE PROCEDURE
11. LABEL85
12. SPECIFICATIONS 88
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 11 JINSUN 300DPI 100LPI T
COPYRIGHTED

12
Frame number :
Engine number :
The frame serial number is stamped on
the right downside frame.
The engine serial number is stamped
on the left rearside of the crankcase assem-
bly.
Please write down the numbers in the box
provided below for your future reference.
The frame and/or engine serial numbers
are used to register the motorcycle. They
are also to assist your dealer in terms of
ordering parts or referring to special service
information.
SERIAL NUMBER LOCATION


MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 12 JINSUN 300DPI 100LPI T
COPYRIGHTED

13
F U E L
Use unleaded gasoline with an octane
rating of 91 or higher.
Unleaded gasoline can extend spark plug
life and exhaust components life.
FUEL, OIL AND COOLANT
RECOMMENDATION
When refuelin , always shut the
en ine off and turn the i nition key
to the “ ”OFF) position.
Never refuel near the flames,
sparks and heat sources.
Do not overfill the fuel tank.
Do not fill asoline above the fuel
tank entrance lower end.
WARNING
Spillin asoline can dama e the
painted surfaces.
Be careful not to spill any fuel when
fillin the fuel tank.
Wipe spilled asoline up immediately.
CAUTION
ENGINE OIL
Classification
system
API
SAE
Grade
Over SL
10W/40
Remarks
ENGINE OIL SPECIFICATION
Use the chart to select a viscosity rating
based on temperature range in your area.
Using a premium uality four stroke motor
oil will increase the service life of your
motorcycle.

If a SAE 10W 40 motor oil is not avail-
able, select alternative according to
the following chart.
N O T E
In very cold weather [below - 15

(5

F)], use SAE 5W 30 for good starting
and smooth operation.
ENGINE OIL
Temperature


-30
-22
-20
-4
-10
14
0
32
10
50
20
68
30
86
40
104
20W50
15W40 15W50
10W40 10W50
10W30
5W30
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 13 JINSUN 300DPI 100LPI T
COPYRIGHTED

TRANSMISSION OIL
Use a good uality SAE 10W/40 multi-
grade oil.
Dont mix the unrecommended oil.
It could dama e the en ine.
When refillin the oil, dont allow the
dust to et inside.
Wipe the spilled oil up immediately.
Dont put the patch on the filler cap.
It could disturb the oil to be provided
and dama e the transmission.
WARNING
14
Don’t mix the unrecommended oil.
It could dama e the en ine.
When refillin the oil, don’t allow the
dust to et inside.
Wipe the spilled oil up immediately.
Dont put the patch on the filler cap.
It could disturb the oil to be provided
and dama e the en ine.
WARNING
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 14 JINSUN 300DPI 100LPI T
COPYRIGHTED

ENGINE COOLANT SOLUTION
Use an engine coolant that is compatible
with aluminum radiator, mixed with distilled
water only at a 50 : 50 mixture ratio for
engine coolant solution.
An engine coolant mixture other than
50 : 50 can affect cooling efficiency or rust
inhibiting peformance.
En ine coolant is harmful or fatal if
swallowed or inhaled.
Do not drink anti-freeze or coolant
solution. If swallowed, do induce
vomitin . Immediately contact a poi-
son control center or a physician.
Avoid inhalin mist or hot vapors ; if
inhaled, remove to fresh air. If coolant
ets in eyes, flush eyes with water
and seek medical attention. Wash
thorou hly after handlin . Solution
can be poisonous to animals.
Keep out of the reach of children and
animals.
WARNING
Spilled en ine coolant can dama e
painted surfaces.
Do not spill any fluid when fillin the
radiator. Wipe spilled en ine coolant
up immediately.
CAUTION
WATER FOR MIXING
Use distilled water only.
Water other than distilled water can cor-
rode and clog the aluminum radiator.
N O T E
This 50

mixture will protect the cooling
system from freezing at temperatures
above

31

.
If the motorcycle is to be exposed to
temperature below

31


this mixing
ratio should be increased up to 55

(

40

) or 60

(

55

). The mixing
ratio should not exceed 60

.
ENGINE COOLANT
The engine coolant performs as rust
inhibitor and water pump lubricant as well
as anti-freeze.
Therefore the engine coolant should be
used at all times even though the atmos-
pheric temperature in your area does not
go down to freezing point.
50%
Water
Engine coolant
0.6

0.6

Required amount of water / coolant
Solution capacity (total) 1.2

COOLANT RESERVOIR TANK
Refer to 39 page.
15
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 15 JINSUN 300DPI 100LPI T
COPYRIGHTED

NAMES OF EACH PARTS
Fuel tank cap
Radiator cap
Rear brake lever
Left handle switches
Rear brake fluid reservoir
Instrument panel
Front brake fluid reservoir
Right handle switches
Front brake lever
Throttle grip
Coolant reservoir tank cap
Ignition switch
Front storage box
16
N O T E
“ ”

means the invisable parts.











MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 16 JINSUN 300DPI 100LPI T
COPYRIGHTED

17
Turn signal lamp (Front)
Head lamp (High beam)
Head lamp (Position lamp)
Output terminal
Personal trunk
Seat lock
Passenger backrest
Brake / Tail lamp
Turn signal lamp (Rear)
License plate lamp
Air cleaner
Transmission oil filler cap
Transmission oil level bolt
Transmission oil drain bolt
Passenger footrests
Engine oil drain plug
Center stand
Engine oil filter
Side stand
N O T E
“ ”

means the invisable parts.
















MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 17 JINSUN 300DPI 100LPI T
COPYRIGHTED

18
Muffler
Battery & Fuses
Turn signal lamp (Rear)
Seat
Radiator
Head lamp (Position lamp)
Head lamp (Low beam)
Turn signal lamp (Front)
Passenger footrests
Water pump
Engine oil level gauge
N O T E
“ ”

means the invisable parts.
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 18 JINSUN 300DPI 100LPI T
COPYRIGHTED

19
ON
KEY
LOCK OFF
KEY
STEERING
LOCK
Key number :
These motorcycles come e uipped with
two ignition keys.
Keep the spare key in a safe place.
The ignition switch has three positions :
“ ”(OFF) POSITION
All electrical circuits are cut off.
The engine will not start.
The key can be removed.
“ ”(ON) POSITION
The ignition circuit is completed and the
engine can now start.
The key cannot be removed from the igni-
tion switch in this position.
CONTROLS
IGNITION SWITCH
IGNITION KEY
Turnin the i nition switch to the

(OFF) or

(LOCK) position
while the motorcycle is movin can
be hazardous. Movin the motorcycle
while the steerin is locked can be
hazardous. You could lose your bal-
ance and fall, or you could drop the
motorcycle.
Stop the motorcycle and place it on
the side stand if equipped before
lockin the steerin . Never attempt to
move the motorcycle when the steer-
in is locked.
WARNING

(LOCK) POSITION
To lock the steering, turn the handlebar
all the way to the left.
Turn the key to the “ ”(OFF) position
and push down it to the “ ”(LOCK) posi-
tion and remove the key.
All electrical circuits are disconnected.
MS3¿ „fi‡»` 2007.7.5 4:58 PM ˘ ` 19 JINSUN 300DPI 100LPI T
COPYRIGHTED
