HyperX HX-HSCF-BK/AM User manual

User Manual
HyperX Cloud Flight Headset
Find the language and latest documentation for your HyperX Cloud Flight Headset here.
HyperX Cloud Flight Headset Installation Guide
Simplied Chinese .....
Traditional Chinese ....
............For instructions in English
. . . . . . . . . . . . . . . . . . Para instrucciones en Español
.........Für Anleitungen in Deutsch
. . . . . . . . . . . . . . . . . . Pour des instructions en Français
. . . . . . . . . . . . . . . . . . Per le istruzioni in Italiano
............Por as instruções em Português
. . . . . . . . . . . . . . . . . . Instrukcje w jezyku Polskim
. . . . . . . . . . . . . . . . . . Для инструкции на Pусском
. . . . . . . . . . . . . . . . . . Turkce talimatlar icin
. . . . . . . . . . . . . . . . . . Japanese
. . . . . . . . . . . . . . . . . . Korean
. . . . . . . . . . . . . . . . . . Thai
. . . . . . . . . . . . . . . . . . Vietnamese

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 1 of 14
HyperX Cloud Flight Headset
Part Numbers:
HX-HSCF-BK/AM
HX-HSCF-BK/AS
HX-HSCF-BK/EE
HX-HSCF-BK/EM

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 2 of 14
TABLE OF CONTENTS
Overview ..................................................................................................................................3
Headset charging .....................................................................................................................2
Headset power button ..............................................................................................................3
Headset connection (PC) .........................................................................................................4
Headset Windows configuration...............................................................................................2
Headset connection and configuration (PS4™& PS4™Pro) ..................................................16
Headset status beep tone indicators......................................................................................17
Headset ear cup LED mode...................................................................................................18
Headset pairing ......................................................................................................................19
Headset connection (wired) ...................................................................................................20
Headset specifications ...........................................................................................................21

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 3 of 14
Overview
A. Headset
B. Volume wheel
C. Microphone port
D. USB charge port
E. Analog headphone port
F. Power button
G. Mic mute button
H. Detachable microphone
I. USB charge cable
J. 3.5mm headphone cable
K. Wireless adapter
L. Wireless pairing button
M. Wireless status light

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 2 of 14
Headset charging
It is recommended to fully charge the headset before first use.
When the charge cable is connected the ear cup LED will indicate the status.
Ear Cup LED
Charge status
Breathing
Charging
Off
Charging complete
Charging the headset

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 3 of 14
Headset power button
The power button has multiple functions.
To power on the headset, hold down the power button for 3 seconds until you hear a beep.
To power off the headset, hold down the power button for 3 seconds until you hear a beep.
With the headset powered on short press the power button to cycle through the ear cup LED
modes. The supported LED modes are solid (default), breathing and off.
Power button usage

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 4 of 14
Headset connection (PC)
To use the headset wirelessly on your PC:
1. Connect the wireless adapter to a USB port on your PC. The wireless adapter status light will blink,
indicating it is waiting for connection.
2. Press the power button on the headset for 3 seconds to power on.
3. When the wireless adapter status light is solid and the headset ear cup LED is solid, the headset is
connected.
Note: If it is your first time using the headset you may need to set the headset as the default input and
output device.
Wireless connection to PC

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 2 of 14
Headset Windows configuration
If it is your first time using the headset you may need to set the headset as the default input
and output device.
1. Right-click the speaker icon in the
task tray and select ‘Playback
Devices’.
2. Right-click on ‘Cloud Flight
Wireless Headset’ and select ‘Set
as Default Device’.

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 9 of 14
3. Click on the ‘Recording’ tab, then
right-click ‘Cloud Flight Wireless
Headset’and select ‘Set as
Default Device’.
The Cloud Flight Wireless Headset is
now ready to use.

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 16 of 14
Headset connection and configuration (PS4™& PS4™Pro)
To use the headset wirelessly with PlayStation™4 (PS4™)
1. Turn on your PS4™game console
2. Connect the wireless adapter to a USB port on your PS4™. The wireless adapter status light will
blink, indicating it is waiting for connection.
3. Press the power button on the headset for 3 seconds to power on.
4. When the wireless adapter status light is solid and the headset ear cup LED is solid, the headset is
connected.
Connecting to PS4™
Once the ‘Cloud Flight Wireless Headset’ device is detected configure the PS4™ Audio
Devices using the steps below:
1. Navigate to the Settings Menu and select it.
2. Highlight the ‘Devices’ menu option and select it.
3. Scroll down to ‘Audio Devices’ and select it.
4. Set ‘Input Device’ to HyperX Cloud Flight Wireless Headset.
5. Set ‘Output Device’ to HyperX Cloud Flight Wireless Headset.
6. Choose ‘Output to Headphones’ and select ‘All Audio.’

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 17 of 14
Headset status beep tone indicators
The headset will emit beep tones to indicate status for power, microphone mute, volume and
remaining battery charge.
Headset status
Beep tone indicator
Power on
One tone (high)
power off
Two tones (high to low)
Microphone mute
Two tones (high)
Microphone active
One tone (high)
Reaching maximum volume
Three tones (high)
Reaching minimum volume
Three tones (low)
20% battery remaining
Two tones (mid)
10% battery remaining
Three tones (mid)
5% battery remaining
Five tones (mid, low, mid, low, mid)

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 18 of 14
Headset ear cup LED mode
The power button on the ear cup is used to change the ear cup LED mode.
With the headset powered on short press the power button to cycle through the ear cup LED
modes. The supported LED modes are solid (default), breathing and LED off.
Changing LED mode

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 19 of 14
Headset pairing
The headset and USB wireless adapter comes paired and ready to use from the factory. If the
headset loses pairing it can be re-paired manually using the steps below (It is recommended to
contact technical support prior to re-pairing to determine if this is necessary)
1. Turn off the headset.
2. Long press the power button for 10 seconds to enter the pairing mode.
3. The headset ear cup LED will be fast blinking.
4. Plug the USB wireless adapter to a PC.
5. Use a small pin to press the small button on the back side of the USB wireless adapter.
6. The USB wireless adapter LED will be fast blinking.
7. When the LED on the USB wireless adapter and the headset ear cup is solid, pairing is
completed.

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 20 of 14
Headset connection (wired)
The headset can be used as a wired headphone with the included 3.5mm audio cable. To use
the headset in wired headphone mode:
1. Connect the 3.5mm headphone cable to the headphone port on the headset
2. Plug the 3.5mm headphone cable into your device
Note: The microphone and volume wheel are not functional in this configuration.
Using as a wired headphone

Document No. 480HX-HSCF001.X01
HyperX Cloud Flight Headset
Page 21 of 14
Headset specifications
Headphone
Driver: Dynamic, 50mm with neodymium magnets
Type: Circumaural, Closed back
Frequency response:
Wireless: 20Hz–20,000Hz
Analog: 15Hz–23,000Hz
Impedance: 32 Ω
Sound pressure level: 106dBSPL/mW at 1kHz
T.H.D.: < 2%
Weight: 300g
Weight with mic: 315g
Cable length and type: USB charge cable (1m) + Detachable 3.5mm headphone cable (1.3m)
Microphone
Element: Electret condenser microphone
Polar pattern: Noise-cancelling
Frequency response: 100Hz-7,000 Hz
Sensitivity: -45dBV (0dB=1V/Pa,1kHz)
Battery life*
30 hours - LED off
18 hours - Breathing LED
13 hours - Solid LED
Wireless Range**
2.4 GHz
Up to 20 meters
*Tested at 50% headphone volume
**Wireless range may vary due to environmental conditions

Document No. 480HX-HSCF001.X01
Audífonos HyperX Cloud Flight
Página 1 de 15
Audífonos HyperX Cloud Flight
Números de parte:
HX-HSCF-BK/AM
HX-HSCF-BK/AS
HX-HSCF-BK/EE
HX-HSCF-BK/EM

Document No. 480HX-HSCF001.X01
Audífonos HyperX Cloud Flight
Página 2 de 15
TABLA DE CONTENIDO
Resumen............................................................................................................................................................... 3
Carga de audífonos .............................................................................................................................................. 2
Botón de Encendido de los audífonos .................................................................................................................. 3
Conexión de audífonos (PC)................................................................................................................................. 4
Configuración de Windows para micrófonos ........................................................................................................ 2
Conexión y configuración de los audífonos (PS4™& PS4™Pro)........................................................................ 16
Pitidos indicadores del estado de los audífonos................................................................................................. 18
Modo LED de las orejeras................................................................................................................................... 19
Conexión de los audífonos ................................................................................................................................. 20
Conexión de audífonos (con cable) .................................................................................................................... 21
Especificaciones de los audífonos...................................................................................................................... 22!

Document No. 480HX-HSCF001.X01
Audífonos HyperX Cloud Flight
Página 3 de 15
Resumen
A. Audífonos
B. Rueda de volumen
C. Puerto del micrófono
D. Puerto de carga USB
E. Puerto analógico para audífonos
F. Botón de Encendido
G. Botón de Silenciar micrófono
H. Micrófono desmontable
I. Cable de carga USB
J. Cable para audífonos de 3,5mm
K. Adaptador inalámbrico
L. Botón de adaptador inalámbrico
M. Luz de estado inalámbrico

Document No. 480HX-HSCF001.X01
Audífonos HyperX Cloud Flight
Página 2 de 15
Carga de audífonos
Se recomienda cargar totalmente los audífonos después del primer uso.
Cuando el cable de carga está conectado, el LED de las orejeras indica el estado.
LED de las orejeras
Estado de carga
Respiración
Carga
Apagado
Carga completa
Cargando los audífonos

Document No. 480HX-HSCF001.X01
Audífonos HyperX Cloud Flight
Página 3 de 15
Botón de Encendido de los audífonos
El botón de encendido tiene funciones múltiples.
Para encender los audífonos, mantén presionado el botón de encendido durante 3 segundos
hasta que escuches un pitido.
Para apagar los audífonos, mantén presionado el botón de encendido durante 3 segundos
hasta que escuches un pitido.
Con los audífonos encendidos, presiona rápidamente el botón de encendido para cambiar de
un modo de LED a otro. Los modos LED compatibles son Sólido (predeterminado),
Respiración y Apagado
Uso del botón de Encendido
