100 SRM 1615 Repairs - General
General
WARNING
DO NOT make repairs or adjustments unless
you have been properly trained and specifi-
callyauthorizedtodoso. Repairsandadjust-
ments that are incorrect can create dangerous
operating conditions.
DO NOT operate a lift truck that needs repairs.
Report the need for repairs to your supervisor
immediately. If repair is necessary, disconnect
the battery and attach a DO NOT OPERATE tag
to the control handle.
This section contains descriptions of the frame com-
ponents, repair procedures, and assembly informa-
tion. These components include the frame weldment,
door, floor plate, and covers. The overhead guard and
base arms are also covered in this section.
Throughout this section, forward will refer to travel
in the direction of the forks, and left and right will be
from the perspective of an operator in the operator
compartment facing the forks. See Figure 1.
A. LEFT
B. RIGHT C. FORWARD
Figure 1. Travel Orientation
Description
The frame is available in two sizes: small chas-
sis and large chassis. The small chassis is used
for the N30ZDR2, N35-40ZRS2, N30ZDRS2, and
N35-40ZR2 unit and uses a smaller drive unit. The
small chassis frame is available with a 368.3 mm
(14.5 in.) or 419.1 mm (16.5 in.) battery com-
partment width. The large chassis is used for the
N35ZDR2 and N45ZR2 unit and uses a larger drive
unit. The large chassis frame is available with a
419.1 mm (16.5 in.), 469.9 mm (18.5 in.), or 546.1 mm
(21.5 in.) battery compartment width.
The frame has mounts for the following parts:
•Mast Assembly
•Steering System Parts
•Electrical System Parts
•Hydraulic System Parts
•Door, Floor Plate, Access Panels, and Covers
The overhead guard fastens to the mast. A rear op-
erator guard leg provides protection for the operator
and unobstructed operation of the lift truck. The op-
erator guard leg fastens between the overhead guard
and the frame. Repair procedures for major compo-
nents that fasten to the frame are in separate sec-
tions. See each section for the system that has the
part to be repaired.
Repairs - General
Repair is seldom required on the frame unless the
truck has been structurally damaged. Most truck re-
pairs involve removing the system parts that attach
to the frame. Refer to the appropriate section for the
system that needs repair. To separate the mast from
the frame, refer to the sections Mast,Repair 4000
SRM 1195 and Reach Carriages 4500 SRM 1196.
To replace the load wheels in the base arms, see the
section Periodic Maintenance 8000 SRM 1617 or
Load Wheels in this section.
The caster wheel assembly is part of the steering
assembly. See the section Steering System 1600
SRM 1610 to replace the caster wheel assembly or
the caster wheels.
To replace the drive wheels or tires, see the section
Periodic Maintenance 8000 SRM 1617.
1

Covers, Panels, and Plates 100 SRM 1615
Covers, Panels, and Plates
FRONT FRAME PANEL (LEFT AND RIGHT)
Remove the screws from the upper and lower ends of
the front frame panel. Pull the lower end of the panel
away from the frame of the lift truck and gently work
up the side of the panel to pull it from the retainer
clips securing the panel to the frame. Pull the top end
tabs out of the operator compartment cover. Repeat
for opposite side as necessary. See Figure 2.
NOTE: On right-side, front frame panels, ensure the
diagnostic connector cap is positioned correctly to al-
low the cover to seat properly.
To install the panel, position the upper end of the
panel partially into the retaining clip on the frame.
Insert the tabs on the upper end of the panel into
the slots in the operator compartment cover. Work
the sides of the panel into the retaining clips until all
areas of the panel are aligned with the frame. Align
the holes in the panel with the mounting brackets
on the frame and loosely install the screws into the
upper end and lower end of the panel. Make certain
the panel is seated correctly against the frame and
tighten the screws to secure in place. See Figure 2.
1. OPERATOR COMPARTMENT COVER
2. FRAME
3. LOWER BRACKET
4. LOWER SCREW
5. FRONT COVER PANEL (LEFT)
6. TABS
7. UPPER BRACKET
8. UPPER SCREW
Figure 2. Front Frame Panel (Left Side)
OPERATOR COMPARTMENT COVER
Remove the front frame panels from the lift truck.
See Front Frame Panel (Left and Right). Remove
the two screws securing the operator cover to the
frame brackets. One is located on the lower right
side of the operator compartment above the opera-
torpresenceswitch. Theotherislocatedbesidethe
overhead guard post mount, at the bottom of the cup
holder. Pull the operator compartment cover up from
the front right corner. Continue pulling the cover up
along the edge of the frame in both directions until
the cover is free from the retaining clips. See Fig-
ure 3. To install, position the cover over the electri-
cal compartment. Align the lip of the cover to the
retaining clips. Press the lip of the cover into the re-
taining clips starting at the overhead guard post and
continue around until completely seated. Align the
holes in cover with the mounting brackets and install
retaining screws as removed. Install the front frame
panels to complete assembly. Refer to Front Frame
Panel (Left and Right).
1. OPERATOR COMPARTMENT COVER
2. RETAINING SCREW
3. FRAME
4. FRONT COVER PANEL (LEFT)
Figure 3. Operator Compartment Cover
2

100 SRM 1615 Load Wheels
DRIVE UNIT COMPARTMENT DOOR
Completely loosen the two socket head capscrews se-
curing the drive unit compartment door closed. The
screws are spring-loaded and are retained to the door
byclips. Pullthedooropenonitshinges. Toclose,
push the door closed and start both socket head cap-
screws loosely into the mounting holes. When both
screws are started, verify that the door seats prop-
erly against the frame and tighten the screws.
DOOR PAD
Open compartment door and remove the seven cap-
screws holding the pad to the door. Lift the pad over
the steering mechanism and remove.
To instal the pad, lower it over the steering mecha-
nism and position it onto the door. Install the seven
socket head capscrews as removed.
OPERATOR BACK PAD
Side-Stance Models
Remove the five socket head capscrews retaining pad
to the adjuster mechanism and remove the pad.
To install, position the back pad onto the adjuster
mechanism and loosely install the five socket head
capscrews as removed. Verify that the back pad seats
properly to the adjuster mechanism and tighten to
secure as removed.
Forward-Stance Models
NOTE: On models with Aft Travel controls, guide
the aft travel control handle wiring harness into/out
of the frame when installing/removing the operator
back pad.
Remove the operator compartment cover to access
the screw securing the front of the operator back pad
to the frame. Remove the two screws securing the
operatorbackpadtotheframeandremovethepad
from the frame.
To install, position the back pad against the frame
as removed. Install the two screws securing pad to
frame as removed, and reinstall the operator com-
partment cover.
OPERATOR FRONT PAD
Remove the operator compartment cover from the lift
truck. See Operator Compartment Cover. Remove
the screws securing the pad brackets to the frame.
Pull the top of the pad away from the frame and then
lift the pad from the lower retaining clips.
To install, position the lower pad brackets into the
retaining clips. Position the upper end of the pad to
the frame. Align the pad bracket holes and install the
screws to secure the pad in place. Install the operator
compartment cover in place.
CASTER WHEEL COVER
Remove the two socket head capscrews on top of the
caster wheel cover and lift cover from the clips secur-
ing it to the frame.
To replace, fit the bottom of the cover into the clips
inside the opening and slide the cover into place. In-
stall two socket head capscrews to secure the top of
the cover in place.
Load Wheels
REMOVE
Slightly raise the base arms and support on blocks as
described in the Periodic Maintenance 8000 SRM
1617. Make sure the base arms and load wheels do
not support any weight.
1. Remove the nut, washers, and axle bolt. See Fig-
ure 4.
2. Remove the load wheels from the hanger brack-
ets.
3. Removetheaxlesleevesandbearingsfromthe
loadwheels. Checkforwearorroughnessas
the bearings are rotated. Replace both bearings
if wear or roughness is noted. Inspect the load
wheels for damage or wear. Replace as necessary.
3

Load Wheels 100 SRM 1615
CAUTION
Use a hammer and a soft punch when removing
bearings to avoid damage to bearings and/or
load wheel.
4. Remove the hanger bracket from the base arms
and inspect thoroughly. Inspect the base arms
thoroughly for damage.
1. AXLE BOLT
2. WASHER
3. HANGER
BRACKETS
4. AXLE SLEEVE
5. BEARING
6. LOAD WHEEL
7. NUT
Figure 4. Load Wheels
INSTALL
WARNING
Cleaning solvents can be flammable and toxic
and can cause skin irritation. Wear protection
when handling solvents and always follow the
recommendations of the manufacturer.
CAUTION
1. Clean all parts with solvent and inspect thor-
oughly. Replace damaged parts as necessary.
2. Apply lithium grease to the pivot contact on the
hanger brackets. Position the hanger brackets
into the base arms and install the load wheels
and axle sleeves into the hanger brackets. See
Figure 5.
1. PIVOT CONTACT
2. HANGER
BRACKET
3. LOAD WHEELS
4. BASE ARM
Figure 5. Hanger Bracket Pivots
CAUTION
The bearings are replaced by pressing on the
outer race of the bearing only. Pressing or tap-
ping on the inner race will damage the bearing.
Use a suitable driver when installing bearings
to avoid damage to bearings and/or load wheel.
Replace bearings in sets to maintain proper
wheel loading and operation.
NOTE: Load wheel assemblies that have axle bolts
equipped with lube fittings use side-shielded bear-
ings and must be greased. Assemblies with axle bolts
not equipped with lube fittings use sealed bearings
and cannot be greased.
3. Install the bearings into the load wheels.
a. Sealed Bearings - Install the bearings into
the load wheel assemblies. Position the axle
sleeve into the assembly. Apply antiseize lu-
bricant to the axle bolt.
b. Side-Shielded Bearings - Install one bear-
ing into the load wheel with the shielded side
facing out. Fill the cavity inside of the load
wheel with grease. Install the other bearing
into the load wheel with the shielded side fac-
ing out. Position the axle sleeve into the as-
sembly.
4. Applygreasetothepivotcontactonthehanger
brackets. Position the hanger brackets into the
base arms and install the load wheels and axle
sleeves into the hanger brackets.
4

100 SRM 1615 Overhead Guard Replacement
5. Install a washer onto the axle bolt. Install the
axle bolt through the hanger brackets, bearings,
and axle sleeve with the threads to the inside of
thebasearms.
6. Install washers and nuts to the axle bolts. Torque
to 68 N•m (50 lbf ft).
NOTE: If axle shafts are equipped with lube fittings,
grease to fill load wheel cavity. Refer to Periodic
Maintenance 8000 SRM 1617 for regularly sched-
uled maintenance procedures.
Overhead Guard Replacement
WARNING
DO NOT weld mounts for lights or accessories
to the overhead guard. The strength of the
overhead guard can be reduced by welding or
heating.
Install lights and accessories or their mounts
with clamps. The strength of the overhead
guard can be reduced if holes are drilled in the
wrong location or are too large. Contact your
lift truck dealer before welding or drilling
holes in any part of the overhead guard.
The overhead guard assembly is heavy. Be sure
that all lifting devices (hoists, cables, chains,
slings, etc.) are suitable and of adequate capac-
itytoliftt
he overhead guard.
The overhead guard assembly consists of the over-
head guard and a support post. See See Figure 6 and
Figure 7. The overhead guard is attached to the mast
with six capscrews (2) and lockwashers (3). The top
of the support post is bolted to the overhead guard.
The bottom ofthepostfitsintoaretainerinthedrive
unit compartment.
5

Overhead Guard Replacement 100 SRM 1615
Figure 6. Overhead Guard (N35ZDR2, N45ZR2, N30ZDR2, N35-40ZR2)
6

100 SRM 1615 Overhead Guard Replacement
Legend for Figure 6
1. OVERHEAD GUARD
2. CAPSCREW
3. LOCKWASHER
4. PLUG (W/O HEAD LAMPS)
5. CAPSCREW
6. CAPSCREW
7. PLUG
8. SUPPORT POST
9. BUSHING
7

Overhead Guard Replacement 100 SRM 1615
Figure 7. Overhead Guard (N30ZDRS2, N35-40ZRS2, N35ZDR2, N45ZR2, N30ZDR2, and
N35-40ZRZ)
8

100 SRM 1615 Overhead Guard Replacement
Legend for Figure 7
1. OVERHEAD GUARD
2. CAPSCREW
3. LOCKWASHER
4. PLUG (W/O HEAD LAMPS)
5. CAPSCREW
6. CAPSCREW
7. SUPPORT POST
8. BUSHING
Thesizeoftheo
verhead guard varies depending
upon the battery compartment size.
REMOVE
Refer to WARNING (above) before performing ser-
vice to any overhead guard components.
1. Attach a suitable lifting device to the overhead
guard.
2. Remove the two capscrews (6) retaining the sup-
port post to the overhead guard. See Figure 7.
Pull the support post out of the retainer in the
lift truck frame. Remove the support post.
3. Remove the six capscrews (2) and lockwashers (3)
retaining the overhead guard to the mast. Lower
the overhead guard to the floor.
INSTALL
Refer to WARNING (above) before performing ser-
vice to any overhead guard components.
1. Attach a suitable lifting device to the overhead
guard.
2. Align the overhead guard with the top of the mast
and install the six capscrews (2) and lockwash-
ers (3). SeeFigure7. Torquethecapscrewsto
149 N•m (110lbfft).
3. Slide the support post into the retainer in the
lift truck frame. Install the two capscrews (6)
retaining the support post to the overhead guard.
FRONT LIGHTS
Two front (head) lights are mounted by their brackets
to the front of the overhead guard.
Bulb Replacement
1. Remove the four screws securing the lens re-
tainer and lens to the assembly. Hold the lens
in place until all screws have been removed
then remove the lens and retainer. Replace as
required. See Figure 8.
1. BRACKET
2. RETAINING CAPSCREW AND NUT
3. SCREW
4. LENS RETAINER
5. LENS
Figure 8. Lens Removal
2. Remove the bulb from the fixture and replace
with new.
CAUTION
Overtightening the screws can break the lens.
3. Position the lens and the retainer to the fixture
and install the four screws.
9

Overhead Guard Replacement 100 SRM 1615
Assembly Replacement
1. Disconnect the wiring harness from the light as-
sembly connector.
2. Remove the nut and washers from the capscrew
securing the headlight assembly to the bracket.
Slide the capscrew from the bracket and remove
the headlight. See Figure 9.
3. Remove the bracket from the overhead guard and
replace, if necessary.
4. Install bracket to overhead guard, if removed.
5. Position the light assembly to the bracket and in-
stall capscrew and attaching hardware. Tighten
slightly to allow for adjustment.
Rear Work and Caution Light
The rear work and caution lights are options that
mount to the overhead guard near the rear of the
truck. Several configurations of these assemblies are
available and connect to the options harness. To re-
pair the light assemblies, perform the following pro-
cedures. Some repairs may not require total disas-
sembly. Perform only the steps necessary to safely
complete the required service. See Figure 10.
The work light is very similar to the front light, ex-
cept for its mounting platform and location. To re-
pair or replace the work light, refer to the instruc-
tions for repairing or replacing the front lights. See
Front Lights.
1. ADJUSTMENT SLOT
2. ADJUSTMENT BOLT
3. OVERHEAD GUARD
4. WIRING HARNESS
5. HEADLIGHT
6. CONNECTOR
7. WIRE CLAMP
8. ATTACHING HARDWARE
Figure 9. Head Light Mounting
10

100 SRM 1615 Overhead Guard Replacement
Caution Light
1. Move the lift truck to a safe, level area and com-
pletely lower the mast. Turn the key switch to
the OFF position and attach a DO NOT OPER-
ATE tag to the control handle. Block the drive
wheel to prevent unexpected movement.
2. Disconnect the battery power cable connector
from the truck connector located on the right side
of the frame. Pull the battery cable connector
handle to separate the battery connector from
the truck connector.
3. Remove the nuts securing the cage to the light
assembly. Remove the cage.
4. Remove the screws and washers securing the
lens globe to the light assembly. Remove the lens
globe.
5. Remove the bulb from the fixture and replace if
necessary.
6. Connect the battery and turn the key switch to
the ON position. Test for proper operation.
7. Position the lens globe to the light assembly. In-
stall screws to secure.
8. Position the cage onto the studs of the light as-
sembly. Install nuts and washers onto studs.
9. Remove blocks from the wheel and return to ser-
vice.
1. CAGE
2. GLOBE
3. STUDS AND NUTS
4. UPPER MOUNTING FLANGE
5. LOWER MOUNTING FLANGE
6. SCREW
7. MOUNTING BRACKET
8. WORK LIGHT WITH ADJUSTABLE BRACKET
9. WORK LIGHT WIRING HARNESS
10. STROBE WIRING HARNESS
Figure 10. Rear and Caution Light
11

Painting Instructions 100 SRM 1615
Painting Instructions
WARNING
Some frames and components are painted with
polyurethane paint. Welding, burning, or other
heat sufficient to cause thermal decomposition
of the paint may release isocyanates. These
chemicals are allergic sensitizers to the skin
and respiratory tract irritants. Overexposure
may occur without odor warning. When heat
must be applied, use good industrial hygiene
practices, including removal of all paint (prime
and finish coats) to the metal around the area
to be heated. Use local ventilation, and/or sup-
plied, air-respiratory protection.
Cleaning solvents may be flammable and/or
toxic and may cause skin irritation. Always
wear proper eye and skin protection.
Always use solvents and paints in an area with
adequate ventilation. DO NOT use solvents or
paints near heat, fire, or electrical equipment
that can make sparks. Follow the paint manu-
facturer’s instructions and precautions.
CAUTION
DO NOT put tape on cylinder rods to protect
from paint. Use a thick layer of multipurpose
grease to protect cylinder rods. Cylinders can
be damaged if operated with tape on the cylin-
der rod.
1. Cleanthesurfacetobepainted. Useasolvent
on surfaces to be painted to remove grease and
oil before sanding. DO NOT use solvent to clean
new paint. Make sure all oil and grease is re-
moved.
2. Use sandpaper to remove the top surface of
paint and rust from the metal. All metal sur-
faces where the paint has been removed to the
bare metal must be primed. Apply primer BE-
FORE applying the paint.
3. Protect all surfaces that will not be painted. DO
NOT paint:
All Plastic Covers
Steering Handle
Dash Display
Control Handles
Labels and Information Plates
Operator Pads
Tires and Load Wheels
Chains and Hoses
Battery Connectors
All Switches
Cylinder Rods
Pumps and Motors
Wiring Harnesses or Connectors
CAUTION
Protect electrical components, wiring, and
electrical contacts from overspray.
4. Paint the surfaces using Hyster approved paints.
Followtheproperpaintschemeforyourlifttruck
model (refer to the Parts Manual for specific in-
formationonpaintforyourlifttruck).
5. Install new safety labels. See Safety Labels Re-
placement.
12

100 SRM 1615 Safety Labels Replacement
Safety Labels Replacement
WARNING
Safety labels are installed on the lift truck to
give information about operation and possible
hazards. It is important that all safety labels
are installed on the lift truck and can be read.
DO NOT add to or modify the lift truck. Any
change to the lift truck, the tires, or its equip-
ment can change the lifting capacity. The lift
truck must be rated as equipped and the name-
plate must show the new capacity rating. Con-
tact your lift truck dealer for a replacement
nameplate.
Cleaning solvents can be flammable and toxic
and can cause skin irritation. When using
cleaning solvents, always follow the recom-
mendations of the manufacturer.
If an adhesive plate or label must be replaced, use
the following procedure to install a new label or plate.
SeeFigure11andFigure12.
1. Clean area with an oil-free cleaner to remove all
oil, grease, and foreign matter. Wipe until com-
pletely dry.
2. Carefully remove only the paper backing from
adhesive. DO NOT touch adhesive surface with
hands or remove front mask from label or plate
face.
3. Exposed adhesive face must be free from all for-
eign matter before positioning label or plate on
surface.
4. Press label or plate down firmly making sure that
all corners are stuck down tight. Make sure that
all air is removed from under the label or plate
and the corners and edges are tight. DO NOT
attempt to move the label or plate once it has
been stuck down.
1. MULTIFUNCTION CONTROL LABEL
2. NAMEPLATE
3. NAMEPLATE COVER
4. RIVET
5. HYDRAULIC FUNCTION DECAL
Figure 11. Operator Compartment Label Placement
13

Safety Labels Replacement 100 SRM 1615
Figure 12. Label Placement
14
