Hytronik HBHC25 Quick guide

Installation and Instruction Manual
HBHC25 / HBIR29-20190718-A1
EMC standard (EMC)
Safety standard (LVD)
Certification
EN55015, EN61000
Semko, CB, CE , EMC, RED, RCM
EN60669,AS/NZS60669
RED EN300328, EN301489
Safety and EMC
Operation temperature
Ta: - 20° C~ + 50° C
Environment
IP20
IP rating
Master Sensor HBHC25
1. Technical Specifications
Slave Sensor HBIR29
Input Characteristics
Stand-by power
Operating voltage
<1W
220~240VAC 50/60Hz
IP20RED
Max.7 dBm
2.4 GHz - 2.483 GHz
Operation frequency
Transmission power
Range (Typical ) *
15~30m
Bluetooth Transceiver
5m (maximum)
360°
Detection range
Detection angle
Mounting height
(O x H) 10m x 3m
PIR Sensor Data
20s
Warm-up Period
Output Characteristics
DALI Channel 1
30mA, Max. 15 LED drivers DALI Channel 2
50mA, Max. 25 LED drivers
Suitable for DALI DT8 LED drivers
7 dBm
2.4 GHz - 2.483 GHz
Operation frequency
Transmission power
Range (Typical indoor)
Protocol
15~30m
Bluetooth Transceiver
4 Wireless Mesh
Stand-by power
Input Characteristics
Operating voltage
<1W
20s
Warming-up
220~240VAC 50/60Hz
Switched power
Max. 40 devices, 80mA
Please refer to placement guidance provided later in this
document .
EMC standard (EMC)
Safety standard (LVD)
Certification
EN55015, EN61000, EN61547
Semko, CB, CE , EMC, LVD, RCM
EN60669-1, EN60669-2-1
RED EN300328, EN301489
Safety and EMC
Sensor Data
360O
5m (maximum)
PIR detectionSensor principle
Detection range (Max.)
Detection angle
Mounting height
(O x H) 10m x 3m
Operation temperature Ta: -10
O
C~ +50
O
C
Environment
IP20
IP rating
Human Centric Lighting System with Wireless Communication - HBHC25 / HBIR29
Part 1: Master Sensor HBHC25 & Slave Sensor HBIR29

HBHC25 / HBIR29-20190718-A1
75.2
78
70.5
62
1. Ceiling (drill hole65mm)
2. Carefully prise off the cable clamps.
3. Make connections to the pluggable
terminal blocks.
4. Insert plug connectorsand secure using
the provided cableclamps, then clip
terminal covers to the base.
5. Fitdetection blind (if required) and
desired lens.
6. Clip fascia to body.
7. Bend back springs and insert into ceiling.
4
5
2
3
1
65mm
* Install lens as required
1 2
* Install blind as required
A B
7
21
6
3. Wire Preparation
Pluggable screw terminal. It is recommended to make
connections to the terminal before fitting to the sensor.
0.75 - 2.5mm
8mm
(min 6mm, max 11mm)
2. Dimensions (mm)

HBHC25 / HBIR29-20190718-A1
Wiring Diagram
Note: DALI output & terminal P1 / P2 of HBIR29 are disabled in HCL system.
HBHC25HBIR29
DA DA
LN
Bluetooth
Max.15pcs
Max.25pcs
DA DA
LED Driver
LED
- + L N
DA DA
LED Driver
LED
- + L N
DA DA
LED Driver
LED
- + L N
DA DA
LED Driver
LED
- + L N
DA1
DA2
L
N
P3 P2 P1 NL
P1 P2
To maximise the bluetooth transmission range in every direction, the following considerations should be taken into account when situating the control base in the
luminaire:
4. Installation and Placement Notes
Smart Phone to Device RangeDevice to Device Placement
Strong signal sources such as WiFi routers
and microwave ovens will affect the range
Concrete walls
metals, and other
building materials
will reduce the range
Device placement may offer up to 30m communication distance.
However, we recommend for indoor applications that device
placements should be no further apart than 15m.
6-10m ＞10m
Notes:
The range for which a smart phone can communicate with the
lighting points will vary from model to model and is dependant
on its c apability.
Placement of the antenna within the luminaire will also effect
the smart phone communication range and may appear
different for each luminaire variant.
Finally, other environmental factors (as per opposite) will
influence the ultimate achievable range of communication
between smart phone and luminaire device.

HBHC25 / HBIR29-20190718-A1
Two channels of self-powered DALI output are available on HBHC25 for connection of two groups of LED drivers. Each group can be set to support different circadian
rhythm profiles on the App.Please note that both channels share the same control settings sent from the occupancy sensor and photocell.
Dual DALI Output Control
4
25
15
DALI channel
DALI PSU Channel 1 (max 50mA)
DALI PSU Channel 2 (max 30mA)
System Capacity
HBHC25 includes 2 channels
total 80mA max. DALI PSU
DT8 Driver = 2mA
3
Transceiver Nodes
Communication between the master sensor HBHC25, extender sensor HBIR29 and wall panel HBP01is performed wirelessly.This not only reduces system wiring
complexity and costs, it is also beneficial in that the DALI power supply resources can be dedicated to the DALI DT8 LED drivers, such Hytronik HHC2045 and HHC2050L.
Commissioning and programming of the system is via the Hytronik APP using a enabled smart device using Android or iOS operating systems.Please refer to
our App user guide for more details.
Three push terminals (P1, P2,P3) are available on the HBHC25 master sensor for end-users to switch on/off or change the light brightness and colour
temperature of the two DALI channels temporarily. The settings will revert to the automatic timing profile (circadian rhythm mode) after sensor time-out.
* Long push on P1: adjust the hold-time light brightness of DALI channel 1;
Short push (<1s) on P1: on/off function
* Long push on P2: adjust the hold-time light brightness of DALI channel 2;
Short push (<1s) on P2: on/off function
* Long push on P3: cycles through colour tuning on both channels.
Short push (<1s) on P3: resume automatic circadiam rhythm mode.
Manual Override (Push Function)
5
*Note:
The push inputs are fixed by hardware
and are not configurable in the app.
Controlled light output brightness colour appearance can enhance a user’s day-to-day mood, wellbeing, productivity and attention levels. The user can select and
customize the biodynamic lighting curve with pre-programmed colour (CCT) and brightness (LUX) control which automatically changes according to the time of the day.
Circadian Rhythm Lighting
1
1
Time sustainability: Each Hytronik circadian rhythm sensor or touch panel can keep the time runing for up to 2 weeks (sensor) or 1month (panel) during power failure.
The built-in photocell performs the function of reading the natural daylight, and maintaining the lux level by calculating how much artificial light is needed according to
the target lux level required by the profile preset.
Daylight Harvest and Lux Off Function
2
HHC2045 and HHC2050L are specially designed to work with the Hytronik Human Centric sensors. Dual channel tunable white LED driver for accurate white balance
and intensity control.
LED Current Selection (HHC2045) Loading and In-rush Current
HHC2045 & HHC2050L
Pulse Time
Inrush Current (Imax.)
36 μs
53A
37Type B
Number of Drivers
16A Circuit Breaker HHC2045 & HHC2050L
Warning: Please make
sure the correct current
is selected before
starting the driver!
1050mA
900mA
700mA
500mA
1200mA
350mA
LED Current (HHC2050L)
Single current 1.05A
5. Functions
Part 2: . Hytronik Tunable White LED Drivers for Human Centric Lighting System

HBHC25 / HBIR29-20190718-A1
Wire Preparation
Solid or Stranded wire type 0.75 - 1.5mm
2
.
To make or release the wire from the terminal, use a
screwdriver to push down the button.
0.75-1.5
8mm
Conversion table for max. quantites of drivers on other types of Miniature Circuit Breaker
C
C
C
C
C
10A
13A
16A
20A
25A
104%
135%
170%
208%
260%
B
B
B
B
B
16A
10A
13A
20A
25A
63%
81%
125%
156%
MCB Type Rating Relative number of drivers MCB Type Rating Relative number of drivers
100% (see table above)
* Environmental factors (such as temperature) will also influence the maximum number of the drivers. Please refer to the MCB
manufactures datasheet for loading and derating factors.
Load distribution
Each channel can supply the maximum load and white balance can be controlled as such:
HHC2045
Colour Temperature Cool White Neutral White Warm White
Power Distribution CH1=45W, CH2=0W
CH1=50W, CH2=0W
CH1=22.5W, CH2=22.5W
CH1=25W, CH2=25W
CH1=0W, CH2=45W
CH1=0W, CH2=50WPower Distribution
HHC2050L
Dual Output Control
CH1 = Cool white LED array
CH2 = Warm white LED array.
HHC2045
Additional cap for stand alone installation
185
Dimensions and Terminals
23
com
RJ12
LED current selection
CH2 --
+
--
+
CH1
Switch-Dim
N
L
com
4.1
79.2
3.9
126
129.4
140.7
Note: Connecting a sensor
antenna will disable the
com input on the driver.

Technical Data
220~240VAC 50/60Hz
0.22~0.2A(HHC2045); 0.3-0.25A(HHC2050L)
0.95
85%
Input→Output : 3000VAC
< 0.25mA
Mains Voltage
Mains Current
Power Factor
Max. Efficiency
Dielectric Strength
Leakage Current
Input
Power/Current/
Voltage Range (HHC2045)
Output power handling
Output channel function
Ripple Current
Uout Max.
Turn-on Time
Operation Temp.
Case Temp. (Max.)
IP Rating
EMC standard
Safety standard
Certifications
Channel 1 (CH1) + Channel 2 (CH2) = 45W (HHC2045) / 50W (HHC2050L) max.
CH1 = Cool white CH2 = Warm White
<3%
75V(HHC2045); 70V(HHC2050L)
< 0.5s
Ta: -20~+50℃
80℃
IP20
EN55015, EN61547, EN61000-3-2, EN61000-3-3
EN61347-1,EN62493,EN61347-2-13
CB, CE , EMC, RCM
Output
Environment
Safety
and EMC
20W/350mA/10~56V
45W/900mA/10~50V
28W/500mA/10~56V
42W/1050mA/10~40V
40W/700mA/10~56V
40W/1200mA/10~34V
Power/Current/ Voltage 50W/1.05A/12-48V (HHC2050L)
RED standard EN300328, EN301489-1, EN301489-17
HHC2050L
com
com
NL
Switch-Dim
Sensor-Dim(RJ12)
CH2
CH1
414
4.2
36.5
424
φ4.2
21
414
4.2
φ4.2
Dual Output Control
CH1 = Cool white LED array
CH2 = Warm white LED array.
Note: Connecting a sensor
antenna will disable the
com input on the driver.
HBHC25 / HBIR29-20190718-A1

HBHC25 / HBIR29-20190718-A1
With the bluetooth module built in, the touch panel can be grouped with the master sensor HBHC25 and slave sensor HBIR29.
The end-user can:
1. Turn off/on the lights for a certain time
2. Select the circadiam rhythm profiles (office/classroom or healthcare)
3. Temporarily dim up or down the light brightness
4. Temporarily adjust the colour temperature of the lights
5. Select suitable scene programmed on the App for different applications
Please note that these over-ride functions are available under occupancy conditions. When the sensor times out, the automatic circadian rhythm profile will be resumed. 4 Scenes
may be set up for 1-touch recall of comfort or activity settings.
Part 3: Bluetooth Touch Panel HBP01
Ta: 0OC ~ +50OC
20% ~ 90%
IP20
Operation temperature
Relative humidity
Environment
IP rating
Technical Data
Dimensions and Terminals Wiring Diagram
0.75 - 4mm
8mm
Rising clamp terminal.
To make or release the wire from the terminal, use a screwdriver
to push down the button.
35.6
12.1
86
86
N
N
HBP01
L
L
Operation frequency
Transmission power
Range (Typical indoor)
Protocol
Bluetooth Transceiver
7 dBm
2.4 GHz - 2.483 GHz
15~30m
4 Wireless Mesh
Input Characteristics
Operating voltage
Stand-by power
With night light
<1W
220~240VAC 50/60Hz
0.35W
EMC standard (EMC)
Safety standard (LVD)
Certification
Safety and EMC
EN55015, EN61000, EN61547
Semko, CB, CE , EMC, RED, RCM
EN60669,AS/NZS60669
Wire Preparation
