Hyundai H-AR18-07H/I Guide

RU
Электрический
кондиционер воздуха
сплит-система
Руководство по эксплуатации
Гарантийный талон
EN
Electric air conditioner
Split system
Instruction manual
Warranty card
Модели / Models
Внутрениий блок
Indoor unit
Наружный блок
Outdoor unit
H-AR18-07H/I
H-AR18-09H/I
H-AR18-12H/I
H-AR18-18H/I
H-AR18-24H/I
H-AR18-07H/O
H-AR18-09H/O
H-AR18-12H/O
H-AR18-18H/O
H-AR18-24H/O
www.hyundai-home.ru

2Electric air conditioner (split system)
EN
Contents
1. Important information
2. Safeguards
3. Specifi cations
4. Appliance description
5. Delivery set
6. Appliance control
Control panel for indoor unit
Remote control board
7. Operating modes
8. Maintenance
9. Recycling, lifetime, warranty period
10. Transportation and storage
Dear Customer!
Thank you for a shrewd choice and purchase of Hyundai portable electric air
conditioner. It will serve you for a long time.
1. IMPORTANT INFORMATION
The appliance is designed for air cooling in domestic premises. The
manufacturer reserves the right to introduce changes in design, confi guration
and processing of the article with a view to improve its properties without
any prior notifi cation of customers. There may be some misprints in text and
digital notations of the present manual.
If aſt er reading of this manual you have any questions concerning work
and operation of the appliance, please, refer to a shop assistant or to a
specialized service center for further explanations.
The article has a label with all the needed technical data and other useful
information about the appliance. Use the appliance only for its intended
purpose indicated in this manual.
2
3
4
6
7
7
7
8
9
10
11
11

3
Electric air conditioner (split system)
EN
2. SAFEGUARDS
1. Don’t try to install the conditioner by yourself. Call for a qualifi ed
installation specialist.
2. While using the air conditioner, it is necessary to observe several
precautions. Incorrect operation due to ignoring of precautions may
result in personal injury of a user and other people, as well as in
damaging of their property.
3. The electric appliance should be under observation while operated,
especially if there are any children near it.
4. Don’t pass your fi ngers or foreign objects through an air outlet grille of
indoor and outdoor units, since it may result in a trauma caused by a
revolving fan.
5. Don’t let children turn the conditioner on by themselves. Children may
turn the conditioner on only under the care of adults.
6. Don’t try to repair the conditioner by yourself. Internal units of the
conditioner carry a voltage and it is life-threatening! For repair of the
appliance refer to an authorized service center.
7. Don’t use the appliance if it is faulty, or if it was dropped or damaged.
8. Don’t open a front panel of the appliance during its work.
9. Don’t dismantle and modify the appliance.
10. Unplug the conditioner immediately, if it emits strange odours or smoke.
11. Don’t splash and pour water and other liquids on the conditioner.
12. Always unplug the conditioner during a thunderstorm.
13. Always unplug the conditioner, when it is not used.
14. Before cleaning and maintenance of the conditioner unplug it. Cleaning
and maintenance should be performed in accordance with instructions of
this manual.
15. To ensure the eff ective work of the conditioner, operate it in environment
described in the present manual.
16. Don’t use dangerous chemicals for cleaning of the appliance and don’t let
them on the appliance.
17. When removing an air fi lter, don’t touch metal parts of the appliance.
18. To avoid overheating and risk of fl ash fi re, as well as damage of internal
electric network, don’t change the length of a power cord and don’t
connect the appliance via extension cords.
19. To avoid electrical hazards, damaged power cord must be changed only at
authorized service centers qualifi ed professionals.
20. To avoid risk of electric shock, do not place the power cord near a heater
and fl ammable or combustible substances.
21. Do not start or stop the unit by connecting or disconnecting electrical
power.
22. Don’t press the buttons of the remote control board by anything but your
fi ngers.
23. Don’t use the appliance for purposes not intended by this user manual.

4Electric air conditioner (split system)
EN
3. SPECIFICATIONS
Tab.1
Indoor unit
Outdoor unit Units H-AR18-07H/I H-AR18-07H/O H-AR18-09H/I H-AR18-09H/O
Capacity (cooling) BTU (W) 7404 (2170) 9165 (2682)
Capacity (heating) BTU (W) 7745 (2270) 9335 (2736)
Rated power consumption (cooling/
heating) W/W 665/617 835/752
Power source V/Hz 220~/50 220~/50
Amperage (cooling/heating) А/А 2,89/2,68 3,63/3,27
Air consumption (indoor unit/outdoor
unit) m³/h/ m³/h 420/1100 450/1600
Noise level (indoor unit) dB 33/29/27/24 33/30/27/24
Noise level (outdoor unit) dB 48 50
Ingress Protection Rating (indoor unit/
outdoor unit) - IPX0/IPX4 IPX0/IPX4
Refrigerant - R410A R410A
Energy efficiency (cooling/heating) - A/A A/A
IEC protection class (indoor unit/outdoor
unit) - I/I I/I
Refrigerant piping (Liquid side / Gas side) inch 1/4 & 3/8 1/4 & 3/8
Max. refrigerant pipe length m 10 10
Maximum difference in level m 7 7
Operating temperature range (cooling) °C 16-47 16-47
Operating temperature range (heating) °C 0-32 0-32
Filling of Freon g 500 640
Net/gross weight (indoor unit) kg/kg 8/9,65 8,5/10,15
Net/gross weight (outdoor unit) kg/kg 21,5/24 25/27,65
Net dimensions (indoor unit/outdoor
unit) mm/mm 700×285×188/ 663×254×421 700×285×188/ 660×500×240
Packing dimensions (indoor unit/
outdoor unit) mm/mm 770×355×272/ 770×478×338 770×355×272/ 780×570×345
Distance between brackets (outdoor unit) mm 430 500

5
Electric air conditioner (split system)
EN
The technical parameters can be changed without compromising product
quality.
H-AR18-12H/I
H-AR18-12H/O H-AR18-18H/I H-AR18-18H/O H-AR18-24H/I H-AR18-24H/O
12590 (3690) 19762 (5792) 25460 (7462)
12931 (3790) 20329 (5958) 26259 (7696)
1151/1017 1805/1647 2325/2127
220~/50 220~/50 220~/50
5,0/4,42 7,85/7,16 10,11/9,25
560/1750 850/2200 1050/2900
36/33/30/27 38/35/32/29 40/37/34/31
52 54 55
IPX0/IPX4 IPX0/IPX4 IPX0/IPX4
R410A R410A R410A
A/A A/A A/A
I/I I/I I/I
1/4 & 3/8 1/4 & 4/8 1/4 & 5/8
12 20 20
7 10 13
16-47 16-47 16-47
0-32 0-32 0-32
660 1150 1500
10/11,8 11/13,3 15/17,3
25/27,9 38/41,7 44/48,2
800×300×197/
660×500×240 850×300×198/ 795×525×290 970×315×235/ 825×655×310
870×370×282/
780×570×345 885×355×255/ 920×400×620 1047×385×317/ 945×725×435
500 545 540

6Electric air conditioner (split system)
EN
The conditioner consists of indoor and outdoor units connected by pipelines.
The conditioner may be controlled from a remote control board or from an
indoor unit control panel.
1. Conditioner unit for indoor installation.
2. Front panel.
3. Air fi lter.
4-5. Blinds (defl ectors) for distribution of treated air.
6. Copper tube of gas (freon). Connecting line.*
7. Condensate drain pipe.*
8. Air-intake grille of the outdoor unit.
9. Button power (auto).
10.Hidden display.
* not supplied
Fig. 1
6
7
8
1
2
3
4
5
4. APPLIANCE DESCRIPTION
9
10

7
Electric air conditioner (split system)
EN
5. DELIVERY SET
Complete set of air conditioner (split system) includes:
Conditioner unit for indoor installation -1 piece
Conditioner unit for outdoor installation -1 piece
Remote control board -1 piece
Batteries for remote control board - 2 pcs.
User manual -1 piece
Warranty card -1 piece
Packing of indoor-installation unit -1 piece
Packing of outdoor-installation unit -1 piece
6. DEVICE CONTROL
Emergency operation
If the remote controller is lost or broken, use force switch button to operate
the air conditioner.
If this button is pushed with the unit OFF, the air conditioner will operate in
Auto mode.
If this button is pushed with the unit ON, the air conditioner will stop running.
Emergency operation
1. Use “SWING” button on the remote controller to adjust the airfl ow direc-
tion. Refer to the operation manual of the remote controller for detail.
2. For models without “SWING” function, the fi ns has to be moved manually.
NOTЕ!
Move the fi ns before the unit is in operation, or your fi nger
might be injured. Never place your hand into the air inlet or
outlet when the air conditioner is in operation.
Your device is equipped with a function for connecting an addi-
tional module, for controlling the air conditioner via Wi-Fi.
Wi-Fi control works only aſt er connecting an additional module
(sold separately).
You may fi nd detailed instructions for installing the module in
the air conditioner and for confi guring the soſt ware into user’s
manual for the Wi-Fi module.

8Electric air conditioner (split system)
EN
1. POWER
Turns the air conditioning on / off .
2. MODE
Selecting the operating mode: AUTO -
COOLING - DRYING - HEATING - VEN-
TILATION.
3. SPEED
Selection of the ventilation speed ac-
cording to the scheme: LOW - MEDIUM -
HIGH - AUTO.
Note: AUTO air speed is not available
in ventilation mode.
4,5. Buttons up, down
The «up» button (4) - the temperature
will rise by 1 °C. The «down» button
(5) - the temperature will drop by 1 °C.
The temperature setting range is from
16 °C (60 °F) to 32 °C (90 °F).
6. SWING - Horizontal rotation mode
(in this model the function is not
provided)
Fig. 2
Controlling the direction of the airfl ow horizontally. Press this button to acti-
vate leſt / right in the SWING mode and re-set the SWING mode.
7. SWING (Vertical rotation mode)
Controlling the direction of the airfl ow along the vertical. Press this button to
activate up / down in the «SWING» mode and re-set the «SWING» mode.
8. TURBO mode
Automatic operation of maximum cooling (in cooling mode) or maximum
heating (in heating mode).
9. TIMER
Setting the on/off time of the air conditioner by timer
10. iFAVOR
Return the device to the user’s previous personal settings (option is not
supplied in this model).
11. iFEEL
Click this button to display temperature settings in the control panel for a
comfortable temperature, and press again to adjust the pre-set temperature.
Remote control
3
7
10
13
16
4
2
6
8
15
14
11
12
9
5
1

9
Electric air conditioner (split system)
EN
12. HEALTH
Activating the ionization function (option is not supplied in this model).
13. SLEEP
Enabling the «SLEEP» mode from which the device will be released aſt er 10
hours and will reboot to the previous state.
14. iCLEAN
Click it and the device will be cleaned auromatically of dust and will increase the
effi ciency of cooling and heating. «ICLEAN» mode works for about 30 minutes.
15. ANTI-FUNGUS
Starting the automatic drying mode of the indoor unit.
16. DISPLAY
Press this button to turn on/off the display.
7. OPERATING MODES
Automatic operation mode
1. Press the «MODE» button, select the automatic operation mode.
2. By pressing the «SPEED» button, you can select the fan speed from LOW,
MID, HIGH, AUTO.
3. Press the «ON/OFF» button, the air-conditioner starts to operate.
4. Press the «ON/OFF» button again, the air-conditioner stops.
Note: In the fan operation mode, the temperature settings is non-eff ective.
Cooling/Heating operation mode
1. Press the «MODE» button, select the Cooling or Heating operation mode.
2. By pressing the « » or « » button, you can set the temperature range
from 16 ℃ (60 ℉) ~ 32 ℃ (90 ℉), the display changes as you touch the button.
3. By pressing the «SPEED» button, you can select the fan speed from LOW,
MID, HIGH, AUTO.
4. Press the «ON/OFF» button, the air-conditioner starts to operate.
5. Press the «ON/OFF» button again, the air-conditioner stops.
Note: The fan operation mode has no heating function.
Fan operation mode
1. Press the «MODE» button, select the fan operation mode.
2. By pressing the «SPEED» button, you can select the fan speed from LOW,
MID, HIGH.
3. Press the «ON/OFF» button, the air-conditioner starts to operate.
4. Press the «ON/OFF» button again, the air-conditioner stops.
Note: In the fan operation mode, the temperature settings is non-eff ective.

10 Electric air conditioner (split system)
EN
Drying operation mode
1. Press the «MODE» button, select the drying operation mode.
2. Press the «ON/OFF» button, the air-conditioner starts to operate.
3. Press the «ON/OFF» button again, the air-conditioner stops.
Backlight function (for remote controllers with such function only)
The remote controller has a backlight which can be turned on by pressing
any button for the convenience of operation in darkness. The backlight will be
automatically turned off if there is no operation within 10 seconds.
8. MAINTENANCE
Before cleaning unplug the conditioner.
Cleaning of the indoor unit and remote control board:
• Indoor unit and remote control board should be cleaned with a dry soſt cloth.
• If the indoor unit is too unclean, moisten the cloth with cold water.
• In order to avoid the damage of paint or details of the conditioner, do not
clean it with brushes and do not leave them on the surface of indoor unit.
• In order to avoid the damage of surface or deformation of the conditioner
details, do not clean it with petrol, solvents, cleaning powders or other
chemically active substances.
Before a sustained interruption in the conditioner work:
• Turn the conditioner on for several hours in the FAN mode. It will allow you
to dry its inner cavities.
• Unplug the conditioner.
• Remove the batteries from the remote control board.
Cheks before starting:
• Make sure that an air fi lter is installed.
• Make sure that air inlet and outlet grilles of the outdoor unit are not
blocked by foreign objects.
Cleaning of air fi lter.
• Air fi lter cleans the air entering the conditioner from dust and foreign particles.
If the fi lter is contaminated, the conditioner capacity decreases sharply.
• If the conditioner is operated permanently, the fi lter should be cleaned
once per two weeks.
• If the conditioner is installed in a room with dusty atmosphere, then the air
fi lter should be cleaned more oſt en.
• To remove the fi lter, open the indoor unit panel.
• Remove air fi lters. Clean the fi lter with a vacuum cleaner or rinse it in clean
water. If the fi lter is contaminated heavily, clean it with a soſt brush and
wash in diluted washing solution, then dry it in a cool place.
