Hyundai Veloster User manual

J3EUJ03
(영어 | 미국) 디오디오2
J3MS7-DA000
Veloster
Car Multimedia System | User's Manual

1
[ The functions and services described in this guide are subject to change without prior notice for performance improvement. If the
system software is updated, the screenshots in this guide may appear different than the actual images on the system.
[ The functions and services described in this guide may differ from those provided in your vehicle. For precise information related to
your vehicle, refer to the owner's manual or catalog of your vehicle.
[ The design and specification of the system may change without prior notice for performance improvement.
[ This multimedia system contains open source software, including without limitation, software distributed and/or modified under the
GNU General Public license, Version 2, June 1991, and the GNU lesser General Public License, Version 2.1, February 1999.
For additional information and to obtain related materials including without limitation, the previous referred to licenses and software,
please contact us at [email protected]

2
Available information for users
Car Multimedia System
User's Manual
This guide introduces your system's functions and explains how to use them. To
use your system correctly and safely, read this guide before using the system.
Car Multimedia System
Quick Reference Guide
This guide combines key information into a quick reference. Use this guide to
refer to descriptions and instructions more quickly and easily.
Quick Guide This guide is the help built into the system. You can access basic information on
how to control the system and a brief description of major functions directly on
the system screen.
• How to access the guide: On the Home screen, touch All Menus >Quick
Guide.
For safety, this quick guide will not be displayed while the vehicle is moving.
Park your vehicle in a safe location before accessing the quick guide.

3
Symbols used in this guide
Warning Indicates important information related to user safety. Failure to follow warnings may
result in death or serious personal injury.
Caution Indicates important information related to user safety. Failure to follow cautions may result
in personal injury, or damage or malfunction your vehicle.
Note Indicates helpful information for convenient use.
*if equipped Indicates descriptions for optional features.
This guide covers all specifications, including all trim models and optional specifications. It
may include descriptions for features that are not equipped in your vehicle.

4
For safety, follow the instructions below. Failure to do so may
increase the risk of a traffic accident, which may result in death
or personal injury.
Ü About driving
Do not operate the system while driving.
• Driving while distracted may result in a loss of vehicle control, potentially
leading to an accident, severe personal injury, or death. The driver’s
primary responsibility is the safe and legal operation of a vehicle, and any
handheld devices, equipment, or vehicle systems which divert the driver’s
attention from this responsibility should never be used during operation
of the vehicle.
Avoid watching the screen while driving.
• Driving while distracted may lead to a traffic accident.
• Stop your vehicle in a safe location before using functions that require
multiple operations.
Stop your vehicle first before using your mobile phone.
• Using a mobile phone while driving may lead to a traffic accident.
• If necessary, use the Bluetooth Handsfree feature to make calls and keep
the call as short as possible.
Keep the volume low enough to hear external sounds.
• Driving without the ability to hear external sounds may lead to a traffic
accident.
• Listening to a loud volume for a long time may cause hearing damage.
Ü About handling the system
Do not disassemble or modify the system.
• Doing so may result in an accident, fire, or electric shock.
Do not allow liquids or foreign substances to enter the
system.
• Liquids or foreign substances may cause noxious fumes, a fire, or a
system malfunction.
Stop using the system if it malfunctions, such as no audio
output or display.
• If you continue using the system when it is malfunctioning, it may lead to
a fire, electric shock, or system failure.
Û Note
If you experience any problems with the system, contact your
place of purchase or dealer.
Safety warnings

5
Safety cautions
For safety, follow the instructions below. Failure to do so may
result in personal injury or damage to the system.
Ý About operating the system
Use the system with the engine running.
• Using the system for a long time when the engine is stopped may
discharge the battery.
Do not install unapproved products.
• Using unapproved products may cause an error while using the system.
• System errors caused by installing unapproved products are not covered
under the warranty.
Ý About handling the system
Do not apply excessive force to the system.
• Excessive pressure on the screen may damage the LCD panel or the
touch panel.
When cleaning the screen or button panel, make sure to
stop the engine and use a soft, dry cloth.
• Wiping the screen or buttons with a rough cloth or using solvents
(alcohol, benzene, paint thinner, etc.) may scratch or chemically damage
the surface.
If you attach a liquid-type air freshener to the fan louver,
the surface of the louver may become deformed due to the
flowing air.
Û Note
If you experience any problems with the system, contact your
place of purchase or dealer.

6
HYUNDAI VEHICLE OWNER PRIVACY POLICY
Your Hyundai vehicle may be equipped with technologies and
services that use information collected, generated, recorded
or stored by the vehicle. Hyundai has created a Vehicle Owner
Privacy Policy to explain how these technologies and services
collect use and share this information.
You may read our Vehicle Owner Privacy Policy on the
Hyundaiusa.com website at:
https://www.hyundaiusa.com/owner-privacy-policy.aspx
If you would like to receive a hard copy of our Vehicle Owner
Privacy Policy, please contact our Customer Connect Center at:
Hyundai Customer Care
P.O. Box 20850
Fountain Valley, CA 92728
800-633-5151
[email protected]
Hyundai’s Customer Connect Center representatives are
available Monday through Friday, between the hours of 5:00
AM and 7:00 PM PST and Saturday and Sunday between 6:30
AM and 3:00 PM PST (English).
For Customer Connect Center assistance in Spanish or Korean,
representatives are available Monday through Friday between
6:30 AM and 3:00 PM PST.

7
1
System overview
Component names and functions 1-2
Turning the system on or off 1-5
Controlling the touch screen 1-7
Getting to know the Home screen 1-8
Getting to know the rear view screen 1-9
Using the climate control system (*if equipped) 1-10
2
Useful features
Setting up My Menu 2-2
Editing My Menu 2-2
Using Voice Memo 2-2
Using phone projection 2-3
Connecting your iPhone via Apple CarPlay 2-4
Connecting your Android smartphone via Android Auto 2-6
3
Radio
Turning on the radio 3-2
Changing the radio mode 3-2
Scanning for available radio stations 3-3
Searching for radio stations 3-3
Saving radio stations 3-4
Listening to saved radio stations 3-4
4
Media player
Using the media player 4-2
Controlling the media player 4-3
Using the USB mode 4-5
Listening to music 4-5
Using the iPod mode 4-7
Using the AUX mode 4-10
Contents

8
5
Bluetooth
Connecting Bluetooth devices 5-2
Pairing devices with your system 5-2
Connecting a paired device 5-4
Disconnecting a device 5-5
Deleting paired devices 5-5
Using a Bluetooth audio device 5-6
Using a Bluetooth phone 5-7
Making a call 5-8
Answering calls 5-11
Using options during a call 5-12
Setting up your favorites list 5-13
6
Settings
Setting sounds 6-2
Setting the system sound 6-2
Turning the touch sound on or off 6-3
Setting the system screen 6-3
Setting the Home screen 6-4
Setting the screen saver 6-4
Setting Bluetooth 6-5
Setting the system environments 6-5
Setting the display language 6-5
Setting the time and date 6-6
Setting the keyboard 6-6
Setting the custom button 6-6
Setting advanced options 6-7
Viewing system information 6-7
7
Troubleshooting
Solutions 7-2
Sound and display 7-2
USB playback 7-4
iPod/iPhone playback 7-5
AUX mode 7-6
Bluetooth connection 7-7
Phone projection 7-8
System operation 7-9
8
Appendix
System status icons 8-2
FAQ 8-3
System specifications 8-7
Important information 8-11
Index 8-13

1
System overview
Component names and functions
Turning the system on or off
Controlling the touch screen
Getting to know the Home screen
Getting to know the rear view screen
Using the climate control system (*if equipped)

1-2
Component names and functions
Control panel
Note: Depending on vehicle models and specifications, the illustration above may differ from the product's actual
appearance and layout.
a Reset button
b POWER button/VOL knob
• Press to turn AV (radio/media) on or off.
• Press and hold to turn off the screen and the sound.
• Turn to the left or right to adjust the system sound volume.
c RADIO button
• Press to turn on the radio. While listening to the radio, press to
change the radio mode.
d SEEK/TRACK button
• While using an AV function, change the station/track/file
(except for the AUX mode).
• While listening to the radio, press and hold to search for a
station.
• While playing media, press and hold to rewind or fast forward
(except for the AUX and Bluetooth audio modes).
e Custom button ( )
• Press to use a custom function.
1
3 4 5
2

1-3
f MEDIA button
• Press to play content from a media storage device.
• If you have multiple media storage devices, select one from the
media selection window.
g HOME button
• Press to access the Home screen.
h PHONE button
• Press to start connecting a mobile phone via Bluetooth.
• After a Bluetooth phone connection is made, press to access
your call history.
i SETUP button
• Press to access the settings screen.
j TUNE knob/FILE knob/ENTER button
• While listening to the radio, turn to adjust the frequency or
change the station.
• While playing media, turn to search for a track/file.
• During a search, press to select the current track/file.
Note: Depending on vehicle models and specifications, the illustration above may differ from the product's actual
appearance and layout.
6 7 8 9
10

1-4
Note: Depending on vehicle models and specifications, the illustration above may differ from the product's actual
appearance and layout.
a Voice recognition button ( )
• Press to start voice recognition of a connected smartphone via phone projection.
• Press and hold to end voice recognition.
b MODE button
• Press to switch between AV (radio/media) modes.
• Press and hold to turn AV (radio/media) on or off.
c Volume lever (VOL +/VOL -)/Mute button ( )
• Push up or down to adjust the volume.
• Press to mute or unmute the system.
• While playing media, press to pause or resume playback (except for the iPod
mode).
d Up/Down lever ( / )
• While using an AV function, change the station/track/file (except for the AUX
mode).
• While listening to the radio, push and hold to search for a station.
• While playing media, push and hold to rewind or fast forward (except for the AUX
and Bluetooth audio modes).
e Call/Answer button ( )
• Press to start connecting a mobile phone via Bluetooth.
• After a Bluetooth phone connection is made, press to access your call history.
Press and hold to dial the most recent phone number. When a call comes in,
press to answer the call.
• During a call, press to switch between the active call and the held call. Press and
hold to switch the call between the system and the mobile phone.
f Call end button ( )
1
1
34
56
1
2
Steering wheel remote control

1-5
Turning the system on or off
1 To turn on the system, start the engine.
2 When the safety warning appears, read it and
touch Confirm.
• To change the display language, touch Language.
• If you do not want to use the system while driving, you
can turn off the screen and the sound by pressing and
holding the [POWER]button on the control panel. To use
the system again, press the [POWER]button.

1-6
• If you turn on your system without starting the engine, a
battery warning will appear. Once the engine starts, the
battery warning will disappear.
Û Note
To avoid having audio play at an excessive volume when you
start the engine, adjust the volume level before stopping the
engine. You can also set the system to decrease the volume
level automatically. On the Home screen, touch All Menus >
Setup >Sound >Priority and activate the Start-up Volume
Limit option.
The system turns off when you stop the engine (ACC Off).
• When you turn back on the system, the previous mode and
settings will remain intact.
Ü Warning
• Some functions may be disabled for safety reasons while
the vehicle is moving. They work only when the vehicle
stops. Park your vehicle in a safe location before using any
of them.
• Stop using the system if it malfunctions, such as no audio
output or display. If you continue using the system when
it is malfunctioning, it may lead to a fire, electric shock, or
system failure.
Ý Caution
• You can turn on the system when the key ignition switch is
placed in the "ACC" or "ON" position. Using the system for
an extended period without the engine running drains the
battery. If you plan on using the system for a long time,
start the engine.

1-7
Touch
Touch an object lightly and lift your finger. You can perform
a function or select an option.
Touch and hold
Touch an object and hold it for at least one second without
lifting your finger. You can rewind or fast forward media by
touching and holding an appropriate button.
Controlling the touch screen
Your system is equipped with a touch screen. You can perform
various functions via touch inputs.
Ý Caution
• Do not apply excessive pressure to the touch screen or
touch it with a pointed object. Doing so may damage the
touch screen.
• Do not let any electrically conductive material contact the
touch screen. A shock from static electricity may cause the
system or the touch screen to malfunction.
Û Note
If you wear regular gloves, you will not be able to control the
touch screen. Remove your gloves or wear gloves designed for
use with a touch screen.

1-8
Getting to know the Home
screen
From the Home screen, you can access various functions.
a
c
e f g h
b
d
a Current time and date
b System status icons >See p.8-2 "System status icons."
c AV information. Touch to activate the corresponding AV
mode in full screen.
d Connection information. The connection status and
function icons are displayed.
e Access the All Menus screen.
f Access the My Menu screen. >See p.2-2 "Setting up My
Menu."
Drag
Touch and hold an object, drag it, and then drop it on a
new location. You can move the selected object to another
location or skip ahead or replay part of a song.
Swipe
Swipe the screen lightly in an appropriate direction. This is
an easy way to scroll through a menu or list quickly.

1-9
• Driving direction lines (yellow) ab
These lines show the directions of the vehicle according to
the steering angle.
• Neutral direction lines (blue) c
These lines indicate your vehicle's expected path with
the steering wheel in the neutral position. It can help you
determine whether the vehicle is in the correct position in
a parking space and prevent you from parking too close to
the next vehicle.
• Crash warning lines (red) d
These lines are to prevent a collision.
Ü Warning
When backing up, make sure to follow the guidelines below:
• Before entering your vehicle, always check the area behind
your vehicle.
• Do not solely rely on the rear view camera when backing
up. Always ensure that it is safe to back up by checking
behind you and looking in the rearview mirrors.
• Always back up slowly and stop immediately if you suspect
that a person, especially a child, might be behind you.
g Run applications and view the quick guide.
h Access the settings screen.
Û Note
To move to the Home screen from another screen, touch .
Getting to know the rear view
screen
When you put the transmission shift lever in the "R" (Reverse)
position while the engine is running, the system screen will
automatically display what is behind you.
The rear view and the parking guides provide a safer
experience when you park your vehicle.
c
d
a
b

1-10
Using the climate control
system (*if equipped)
You can check the current status of the climate control system
via the system screen.
On your vehicle, press the [CLIMATE]button.
• For more information on how to use the climate control
system, refer to the owner's manual of your vehicle.
a
b
e
c
f
d
a Exterior temperature
b Interior temperature
c Air direction
d Air volume
e AUTO mode activated
f Air conditioner turned on
Ý Caution
The distance shown in the rear view screen may differ from the
actual distance. For safety, be sure to visually check the rear,
left, and right sides of your vehicle.
Û Note
• The rear view screen remains active while you are backing
up. When you move the transmission shift lever to any
position other than the "R" (Reverse) position after backing
up, the rear view screen will be deactivated and the system
will display the previous screen automatically.
• As you steer your vehicle, the parking guides change
accordingly to indicate your vehicle's path.
• Depending on vehicle models, the steering-interactive
parking guides may not be supported.
• If an object comes too close to your vehicle as you are
backing up, a warning beep will sound. To prevent an
accident that might result if you do not hear the beep, you
can set the system to decrease the volume level of any
media playing automatically when the vehicle is in reverse.
On the Home screen, touch All Menus >Setup >Sound >
Priority >Back-up Warning Priority.
