i-team i-mop Lite User manual

i-mopLite
Auto scrubber for hard floor surfaces
User manual
i-team Professional b.v.
Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands
Telephone: [phone]
Email: [e-mail]
Internet: www.i-teamglobal.com

2
Original user manual, written in the English Language
Future Cleaning Technologies B.V.
Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands
Telephone: [phone]
Email: [e-mail]
Internet: www.i-teamglobal.com
Model: I-GUM GAS VERSION
Date: 09/04/2020
Product code: K.1.IMOPLT.FCT.1100C
Version: v.1.0

3
Preface
Thank you for choosing the i-mop® Lite, the auto scrubber that cleans faster, cleaner, safer, greener,
and is better for everyone. The i-mop Lite's compact design allows you to clean right to the edge and
under obstacles, minimizing manual scrubbing. The battery operated i-mop Lite is equipped with two
counter-rotating brushes that provide a deep scrub and a great cleaning result. The i-mop Lite
significantly reduces the amount of water and chemicals needed which both leads to a greener result
and reduces the risk of slippery floors.
Please read this manual carefully for important information and operating instructions before using
the i-mop Lite. Save this manual for future reference. This i-mop Lite will provide excellent
performance. The best results will be obtained when the i-mop Lite is:
•Regularly maintained per the i-mop Lite preventive maintenance instructions in this manual.
•Operated with reasonable care and caution.
•Maintained with manufacturer-supplied parts.
When this manual refers to “the manufacturer”, this means Future Cleaning Technologies B.V., an
affiliate company of i-team in Eindhoven, the Netherlands. When this manual mentions “the
partner”, this refers to your local i-team resell and support service partner.
Purpose of the user manual
The purpose of the user manual is to provide the user with information in such a way that during the
life of the i-mop Lite the machine is used correctly, efficiently and safely, even in the event of
reasonably foreseeable misuse, as described in section 1.2 of this manual.
The user manual contains instructions regarding:
•Personal operator safety
•Intended and non-intended use of the i-mop Lite
•Instructions for daily use
•Maintenance instructions
•Storage conditions
•Disposal of the i-mop Lite
These instructions must be considered to avoid risks that could lead to physical and/or material
damage.
Target audience
This user manual is intended for operators of the i-mop Lite and their supervisors, as well as partners
and importers.
Operators of the i-mop Lite
The i-mop Lite may only be operated by a person who has correctly read and understood the
instructions in this manual, or is trained by an experienced operator who has read and understood
the instructions in this manual.

4
Reading guide
The following symbols and terms are used throughout this manual to alert the reader to
safety issues and important information:
Symbol
Term
Explanation
WARNING
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to injuries of the
operator or bystanders and light and/or moderate
damage to the product or the environment.
CAUTION
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to light and / or
moderate damage to the product or the environment.
ATTENTION
Indicates a liability situation, where the
manufacturer or its partners and affiliates cannot
be held accountable for damages caused by non-
compliance.
STRONG MAGNET
Indicates the machine contains strong magnets. These
can cause pacemakers to stop working or cause
electronic data to be damaged, such as information
stored on access passes.
PACEMAKER
Indicates operators and maintenance crew wearing
pacemakers should keep a minimal distance of 6 in / 15
cm. In this specific case operators may not use the
machine as a backpack.
BATTERIES
Indicates a battery-operated machine, batteries must
be charged according to the instructions in the separate
class I battery charger user manual. Batteries must be
disposed of according to your local laws and
regulations.
SLIPPERY SURFACE
Indicates the machine can cause floors to become
slippery. In the workplace, it is advised to place slippery
surface signs in these areas.

5
Content
Preface .................................................................................................................................................................... 3
Purpose of the user manual.................................................................................................................................... 3
Target audience ...................................................................................................................................................... 3
Operators of the i-mop Lite .................................................................................................................................... 3
Reading guide.......................................................................................................................................................... 4
1Introduction.................................................................................................................................................... 7
1.1 Intended use of the product.................................................................................................................. 7
1.2 Non-intended use of the product.......................................................................................................... 8
1.3 Lifespan.................................................................................................................................................. 8
1.4 Modifications......................................................................................................................................... 8
1.5 Specifications......................................................................................................................................... 9
1.6 Warranty.............................................................................................................................................. 10
1.7 Identification ....................................................................................................................................... 10
2Description ................................................................................................................................................... 11
3Safety............................................................................................................................................................ 12
3.1 General safety instructions.................................................................................................................. 12
3.1.1 Sweep before scrub......................................................................................................................... 12
3.1.2 Brush condition ............................................................................................................................... 12
3.1.3 Machine orientation........................................................................................................................ 12
3.1.4 Strong magnets ............................................................................................................................... 12
3.1.5 Battery............................................................................................................................................. 12
3.2 Risks during operation......................................................................................................................... 13
3.2.1 Dress safely ..................................................................................................................................... 13
3.2.2 Mark the job site ............................................................................................................................. 13
3.2.3 Careful when parking ...................................................................................................................... 13
3.3 Risks after operation............................................................................................................................ 13
3.3.1 Remove battery............................................................................................................................... 13
3.3.2 Machine orientation........................................................................................................................ 13
4Transport and storage.................................................................................................................................. 14
4.1 General ................................................................................................................................................ 14
4.2 Park position........................................................................................................................................ 14
4.3 Transport outside ................................................................................................................................ 15
4.4 Transport in a vehicle .......................................................................................................................... 16
5Assembly and installation............................................................................................................................. 17
5.1 Unboxing.............................................................................................................................................. 17
5.2 Assembly.............................................................................................................................................. 18
5.2.1 Charge the battery .......................................................................................................................... 18

6
5.2.2 Attach the brushes .......................................................................................................................... 18
5.2.3 Attach the squeegee ....................................................................................................................... 19
5.2.4 Install cleaning solution tank........................................................................................................... 19
5.2.5 Install recovery tank........................................................................................................................ 20
6Operation ..................................................................................................................................................... 21
6.1 Before you start................................................................................................................................... 21
6.1.1 Insert the battery ............................................................................................................................ 21
6.1.2 Fill the cleaning solution tank ......................................................................................................... 22
6.2 Operation procedure........................................................................................................................... 22
6.2.1 Walking to the job site .................................................................................................................... 22
6.2.2 At the job site.................................................................................................................................. 23
6.2.3 ECO mode........................................................................................................................................ 26
6.2.4 Turn off the i-mop® Lite .................................................................................................................. 26
6.2.5 Emptying tanks................................................................................................................................ 26
6.3 Cleaning and storage ........................................................................................................................... 27
6.3.1 Flush the system.............................................................................................................................. 27
6.3.2 Cleaning the tanks........................................................................................................................... 27
6.3.3 Clean the filter................................................................................................................................. 28
6.3.4 Remove the battery ........................................................................................................................ 28
6.3.5 Check the brushes and squeegee.................................................................................................... 29
6.3.6 Store in an upright position............................................................................................................. 29
7Maintenance ................................................................................................................................................ 30
7.1 Brush replacement .............................................................................................................................. 30
7.2 Squeegee replacement........................................................................................................................ 31
7.2.1 Detach the squeegee....................................................................................................................... 31
7.2.2 Flip/replace the squeegee blade..................................................................................................... 31
7.2.3 Attach the squeegee ....................................................................................................................... 32
7.3 Replace vacuum hose .......................................................................................................................... 32
7.4 Recommended additional cleaning ..................................................................................................... 32
7.5 Recommended service time ................................................................................................................ 32
7.6 Accessories .......................................................................................................................................... 33
8Troubleshooting ........................................................................................................................................... 34
9Decommissioning and disposal .................................................................................................................... 35
10 Attachments................................................................................................................................................. 36
10.1 CE Certificate ....................................................................................................................................... 36

7
1Introduction
The i-mop® Lite is an easy and safe machine to use. This manual helps you to get started and explains
the operation and maintenance procedure. You will be pleasantly surprised by the fast and effective
use of the battery operated i-mop Lite. The batteries must be fully charged before use. Please refer
to the user manual of the class I battery charger for correct procedure.
This manual is intended for those who work with the i-mop Lite and/or perform daily maintenance.
The manual must be read in full before the first actions. This manual describes the correct method of
use, safety measures, maintenance and transport.
The manufacturer continuously improves all their products based on user experience and feedback.
Any deviations between the texts and/or images from the manual and your i-mop Lite can therefore
arise from the difference in model or from possible changes due to continuous development and
innovation.
1.1 Intended use of the product
The i-mop Lite is a specialized machine for
scrubbing hard floor surfaces. You can use any
type of water-based scrubbing detergent.
The fluid tank, brushes and squeegee come in
HACCP color coded versions (blue, green, red,
yellow and orange). All three items are easily
replaced. This allows you to use different
cleaning solutions, —for instance, when you
move from the food preparing area to the
restaurant. ALWAYS use the same color for fluid
tank, brush and squeegee.
Figure 1

8
1.2 Non-intended use of the product
WARNING
Non-intended use can have consequences for the safety of operators and bystanders
and will void the warranty on the product.
•NEVER operate the i-mop® Lite near flammable dusts, liquids or vapors.
•NEVER operate the i-mop Lite when flammable or poisonous liquids like gasoline, oil, acids, or
other volatile substances are on the floor.
•DO NOT fill the i-mop Lite with any flammable detergent. ONLY use the water-based cleaning
solutions.
•DO NOT use water that exceeds 113° F/45° C. Using water above this temperature will void the
tank warranty.
•DO NOT use cleaning solutions with pH below 3 or above 11 in order to prevent damage to
sensitive components.
•DO NOT use the i-mop Lite outdoors or on uneven surfaces.
•DO NOT operate this i-mop Lite over electrical floor outlets in order to avoid electrical shock.
•NO RIDERS! Do not carry passengers on top of the i-mop Lite.
•DO NOT use the i-mop Lite as stepladder or platform.
•DO NOT store the i-mop Lite outside in order to avoid damage to electronic components.
•ONLY use manufacturer-supplied parts for maintenance.
•KEEP AWAY from children! The i-mop Lite is a professional cleaning machine to be used by trained
adults only.
1.3 Lifespan
Each i-mop® Lite is guaranteed to operate for at least 2000 hours. The wear on brushes and
squeegee heavily depends on the roughness of the surface. They need to be checked regularly.
CAUTION
To ensure proper and safe operation throughout the life of the i-mop Lite, the machine
must be checked every 300 hours by an authorized i-team partner.
1.4 Modifications
It is not permitted to make modifications to the design of the i-mop Lite without consultation and
permission from the manufacturer. This affects the warranty, see section 1.6.

9
1.5 Specifications
Product size:
120 x 43 x 38 cm
Product size in park position:
120 x 43 x 34 cm
Weight (including Battery):
12.5 kg
Li-on battery:
DC (18V, 12.48Ah, 250Wh)
Battery capacity:
1 Battery
Operation time of batteries:
45 min
Brush pressure:
13 kg
Brush speed:
500 rpm
Solution tank capacity:
3 L
Recovery tank capacity:
5 L / 3 L recommended max
Vibration:
Amplitude (mm) <= 0.5086
Velocity (m/s) <= 0.0068
Acceleration (m/s2) <= 1.435
Noise level (1m):
68Db
Theoretical performance:
Up to 1400 m2 per hour
Practical performance:
700 - 1000 m2 per hour
Castor wheels:
YES
Power cut off at park position:
NO
Angle power cut off:
YES < 45°
Timer:
NO
Fluid Shortage Warning:
NO
Figure 2

10
1.6 Warranty
The i-mop Lite should be used as intended and described in this manual. Using the i-mop Lite outside
will void the warranty on the product.
1.7 Identification
The ID tag, containing a serial number and
production number, can be found on the bar
behind the wastewater tank.
1. Serial number
2. Production day
3. Production year
Figure 3
