i-team i-mop Lite User manual

i
mop
Lite
Auto scrubber for
floor surfaces
User
manual
i-team Professional b.v.
Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands
Telephone: [phone]
Email: hello@ i-teamglobal.com
Internet: www.i-teamglobal.com

2
FASTER:
Cleans 50% faster than conventional mopping and 20% faster than equal size
scrubber dryers proven by cleaning rates of up to 1300 m2per hour.
CLEANER:
Powerful twin counter-rotating 500 RPM brushes for soil removal proven by
ATP test data, reflecting up to 90% cleaner surfaces.
GREENER:
Takes advantage of every bit of chemical and every drop of water, which is proof
that it reduces environmental impact by over 75%. On average the i-mop®Lite
uses 20% less energy per m2 compared to a typical scrubber dryer.
SAFER:
Cleans and dries floors almost instantly - proven by standardized slip test readings
of 120 or less - significantly reducing slip and fall hazards. The antibacterial tanks
on the i-mop reduces the odors coming from the recovery tank and protects
operators who handle the tank every day. Bacterial reduction in contact with the
tank wall has been certified and tested at ≥99.99% efficacy.
BETTER FOR EVERYONE:
It cleans fast and thoroughly, resulting in a cleaner and healthier environment for
everyone.
Original user manual, written in the English Language
Future Cleaning Technologies B.V.
Hoppenkuil 27b, 5626 DD Eindhoven, The Netherlands
Telephone: [phone]
Email: [e-mail]
Internet: www.i-teamglobal.com
Model: imop® Lite
Date: 04-05-2022
Product code:
Version: v2.0
Model year: 2022

3
Preface
Thank you for choosing the imop®Lite, the auto scrubber that cleans faster, cleaner, safer,
greener, and is better for everyone. The imop Lite's compact design allows you to clean right
to the edge and under obstacles, minimizing manual scrubbing. The battery operated imop
Lite is equipped with two counter-rotating brushes that provide a deep scrub and a great
cleaning result. The imop Lite significantly reduces the amount of water and chemicals
needed which leads to a greener result. It also reduces the risk of slippery floors.
Antibacterial tanks
The tanks on the imop use an antibacterial mix-in to make the plastic safer both inside and
outside. Because it is mixed into the plastic, the effect will last the lifetime of the tank. The
reduction of bacteria reduces the odours coming from the recovery tank and protects
operators who handle the tank every day. Bacterial reduction in contact with the tank wall has
been certified and tested at ≥99.99% efficacy.

4
Purpose of the user manual
The purpose of the user manual is to provide the user with information in such a way that
during the life of the imop®Lite, the machine is used correctly, efficiently and safely, even in
the event of reasonably foreseeable misuse, as described in section 1.2 of this manual.
The user manual contains instructions regarding:
•Personal operator safety
•Intended and non-intended use of the imop Lite
•Instructions for daily use
•Maintenance instructions
•Storage conditions
•Disposal of the imop Lite
These instructions must be considered to avoid risks that could lead to physical and/or
material damage.
Target audience
This user manual is intended for operators of the imop Lite and their supervisors, as well as
partners and importers.
Operators of the imop Lite
The imop Lite may only be operated by a person who has correctly read and understood the
instructions in this manual or is trained by an experienced operator who has read and
understood the instructions in this manual.

5
R eading guide
The following symbols and terms are used throughout this manual to alert the reader to
safety issues and important information:
Symbol
Term
Explanation
WARNING
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to injuries of
the operator or bystanders and light and/or
moderate damage to the product or the
environment.
CAUTION
Indicates a hazardous situation which, if the safety
instructions are not followed, can lead to light and /
or moderate damage to the product or the
environment.
ATTENTION
Indicates a liability situation, where the
manufacturer or its partners and affiliates cannot be
held accountable for damages caused by non-
compliance.
STRONG MAGNET
Indicates that the machine contains strong magnets.
These can cause pacemakers to stop working or
cause electronic data to be damaged, such as
information stored on access passes.
PACEMAKER
Indicates that operators and maintenance crew
wearing pacemakers should keep a minimal
distance of 6 in / 15 cm. In this specific case
operators may not use the machine as a backpack.
BATTERIES
Indicates a battery-operated machine, batteries
must be charged according to the instructions in the
separate class I battery charger user manual.
Batteries must be disposed of according to your
local laws and regulations.
SLIPPERY
SURFACE
Indicates that the machine can cause floors to
become slippery. In the workplace, it is advised to
place slippery surface signs in these areas.

6
Content
Preface .............................................................................................................................................................................................. 3
Purpose of the user manual...................................................................................................................................................... 4
Target audience............................................................................................................................................................................. 4
Operators of the imop Lite ........................................................................................................................................................ 4
Reading guide................................................................................................................................................................................ 5
Content ............................................................................................................................................................................................. 6
1. Introduction........................................................................................................................................................................... 8
1.1. Intended use of the product .................................................................................................................................8
1.2. Non-intended use of the product....................................................................................................................... 9
1.3. Lifespan ........................................................................................................................................................................9
1.4. Modifications .............................................................................................................................................................. 9
1.5. Specifications .......................................................................................................................................................... 10
1.6. Warranty................................................................................................................................................................... 11
1.7. Identification ............................................................................................................................................................ 11
2. Description ..........................................................................................................................................................................12
3. Safety ....................................................................................................................................................................................13
3.1. General safety instructions ................................................................................................................................ 13
3.1.1 Sweep before scrub ................................................................................................................................... 13
3.1.2 Brush condition ............................................................................................................................................ 13
3.1.3 Machine orientation .................................................................................................................................... 13
3.1.4 Antibacterial tanks ...................................................................................................................................... 13
3.1.5 Strong magnets............................................................................................................................................ 13
3.1.6 Battery ............................................................................................................................................................. 13
3.2. Risks during operation......................................................................................................................................... 14
3.2.1 Dress safely ................................................................................................................................................... 14
3.2.2 Mark the job site........................................................................................................................................... 14
3.2.3 Careful when parking................................................................................................................................. 14
3.3. Risks after operation ............................................................................................................................................ 14
3.3.1 Remove battery............................................................................................................................................ 14
3.3.2 Machine orientation .................................................................................................................................... 14
3.3.3 Careful when storing.................................................................................................................................. 14
4. Transport and storage ....................................................................................................................................................15
4.1. General....................................................................................................................................................................... 15
4.2. Store position .......................................................................................................................................................... 15
4.3. Transport outside .................................................................................................................................................. 16
4.4. Transport in a vehicle........................................................................................................................................... 17
5. Assembly and installation .............................................................................................................................................18
5.1. Unboxing................................................................................................................................................................... 18

7
5.2. Assembly .................................................................................................................................................................. 19
5.2.1 Charging the battery .................................................................................................................................. 19
5.2.2 Attaching the brushes ............................................................................................................................... 19
5.2.3 Attaching the squeegee............................................................................................................................ 20
5.2.4 Installing the cleaning solution tank..................................................................................................... 20
5.2.5 Installing the recovery tank...................................................................................................................... 21
6. Operation .............................................................................................................................................................................22
6.1. Before you start...................................................................................................................................................... 22
6.1.1 Inserting the battery ................................................................................................................................... 22
6.1.2 Filling the cleaning solution tank ........................................................................................................... 23
6.2. Operation procedure ............................................................................................................................................ 24
6.2.1 Walking to the job site .............................................................................................................................. 24
6.2.2 At the job site................................................................................................................................................ 25
6.2.3 ECO mode ...................................................................................................................................................... 28
6.2.4 Turning off the imop®Lite........................................................................................................................ 28
6.2.5 Emptying tanks............................................................................................................................................. 28
6.3. Cleaning and storage ........................................................................................................................................... 29
6.3.1 Flushing the system ................................................................................................................................... 29
6.3.2 Cleaning the tanks ...................................................................................................................................... 29
6.3.3 Cleaning the filter ........................................................................................................................................ 29
6.3.4 Removing the battery ................................................................................................................................ 30
6.3.5 Checking the brushes and squeegee .................................................................................................. 30
6.3.6 Store in an upright position ..................................................................................................................... 31
7. Maintenance .......................................................................................................................................................................32
7.1. Brush replacement................................................................................................................................................ 32
7.2. Squeegee replacement........................................................................................................................................ 33
7.2.1 Detaching the squeegee........................................................................................................................... 33
7.2.2 Flipping/replacing the squeegee blade............................................................................................... 33
7.2.3 Attaching the squeegee............................................................................................................................ 34
7.3. Replacing the vacuum hose .............................................................................................................................. 34
7.4. Recommended additional cleaning ................................................................................................................ 34
7.5. Recommended service time .............................................................................................................................. 35
7.6. Accessories.............................................................................................................................................................. 35
8. Troubleshooting ................................................................................................................................................................36
9. Decommissioning and disposal ..................................................................................................................................37
10. Attachments..................................................................................................................................................................38
10.1. CE Certificate...................................................................................................................................................... 38
10.2. Specifications ..................................................................................................................................................... 39
10.3. The i-Story........................................................................................................................................................... 40

8
1. Introduction
The imop®Lite is a safe, user-friendly machine. This manual helps you to get started and
explains the operation and maintenance procedure. You will be pleasantly surprised by the
fast and effective use of the battery operated imop Lite. The batteries must be fully charged
before use. Please see the user manual of the class I battery charger for correct procedure.
This manual is intended for those who work with the imop Lite and/or perform daily
maintenance. The manual must be read fully before the first actions. This manual describes
the correct method of use, safety measures, maintenance and transport.
The manufacturer continuously improves all their products based on user experience and
feedback. Any deviations between the texts and/or images from the manual and your
imop Lite can therefore arise from the difference in model or from possible changes due to
continuous development and innovation.
1.1. Intended use of the product
The imop Lite is a specialized machine for
scrubbing floor surfaces. You can use any type
of water
-based scrubbing detergent.
The fluid tank, brushes and squeegee come in
HACCP color coded versions (blue, green, red,
yellow and orange). All three items
can be
easily replaced. This allows you to use
different cleaning solutions,
— for instance,
when you move from the food preparin
g area
to the restaurant.
Make sure that the color
code for the fluid tank, brush and squeegee
ALWAYS
match each other.
Figure 1

9
1.2. Non-intended use of the product
WARNING
Non-intended use can have consequences for the safety of operators and
bystanders and will void the warranty on the product.
•NEVER operate the imop®Lite near flammable dusts, liquids or vapors.
•NEVER operate the imop Lite when flammable or poisonous liquids like gasoline, oil, acids,
or other volatile substances are on the floor.
•DO NOT fill the imop Lite with any flammable detergent. ONLY use the water-based
cleaning solutions.
•DO NOT use water that exceeds 113°F / 45°C. Using water warmer than this temperature
will void the tank warranty.
•DO NOT use cleaning solutions with a pH level below 3 or above 11 in order to prevent
damage to sensitive components.
•DO NOT use the imop Lite outdoors or on uneven surfaces.
•DO NOT operate this imop Lite over electrical floor outlets in order to avoid electrical
shock.
•NO RIDERS! Do not carry passengers on top of the imop Lite.
•DO NOT use the imop Lite as stepladder or platform.
•DO NOT store the imop Lite outside in order to avoid damage to electronic components.
•ONLY use manufacturer-supplied parts for maintenance.
•KEEP AWAY from children! The imop Lite is a professional cleaning machine to be used
by trained adults only.
1.3. Lifespan
Each imop Lite is guaranteed to operate for at least 2000 hours. The wear on brushes and
squeegee heavily depends on the roughness of the surface. They need to be checked
regularly.
CAUTION
To ensure proper and safe operation throughout the life of the imop Lite, the
machine must be checked by an authorized i-team partner every 500 hours..
1.4. Modifications
It is not permitted to make modifications to the design of the imop Lite without consultation
and permission from the manufacturer. This affects the warranty, see section 1.6 of this
manual.

10
1.5. Specifications
Figure 2
Product size:
120 x 43 x 38 cm
Product size in store position:
120 x 43 x 34 cm
Weight (including Battery):
12.5 kg
Li-on battery:
DC (18V, 12.48Ah, 250Wh)
Battery capacity:
1 Battery
Operation time of batteries:
45 min
Brush pressure:
13 kg
Brush speed:
500 rpm
Solution tank capacity:
3 L
Recovery tank capacity:
5 L / 3 L recommended max
Vibration:
Amplitude (mm) <= 0.5086
Velocity (m/s) <= 0.0068
Acceleration (m/s
2) <= 1.435
Noise level (1m):
68 Db
Theoretical performance:
Up to 1400 m2per hour
Practical performance:
700 - 1000 m2per hour
Castor wheels:
YES
Power cut off at store position:
NO
Angle power cut off:
YES < 32°
Hour counter:
NO
Fluid Shortage Warning:
NO

11
1.6. Warranty
The imop®Lite should be used as intended and described in this manual. Using the
imop Lite outside will void the warranty on the product.
1.7. Identification
The ID tag, containing a serial number and
production number, can be found on the bar
behind the wastewater tank.
1.
Serial number
2.
Production day
3.
Production year
Figure 3

12
2. Description
The compact imop®Lite consists of two main parts:
•The body that contains the motor, cleaning solution tank, recovery tank, handle with
triggers and control panel.
•The scrub deck that contains the brushes and squeegee.
The imop Lite can be folded into a store position; this is recommended for storage.
The imop Lite consists of:
Figure 4
Legend
1. Trigger
2.
Control panel – Brush on
3.
Control panel – Vacuum on
4.
Control panel – High water level
5.
Control panel – Low water level
6.
Vacuum hose
7. Battery
8.
Scrub deck
9.
Squeegee
10.
Recovery tank
11.
Solution tank
12.
Rotating brushes

13
3. Safety
Safety comes first. Therefore, please take your time to read and understand these safety
instructions. Improper use can case cause harm or void the manufacturer’s warranty.
3.1. General safety instructions
3.1.1 Sweep before scrub
Remove loose objects from the floor that can be propelled by the rotating brushes.
3.1.2 Brush condition
Make sure to check the condition of the brush before use. Change the brush only when the
machine is turned off and in a store position.
3.1.3 Machine orientation
Always keep the body of the imop®Lite in an upright position when inserting cleaning fluid or
battery.
3.1.4 Antibacterial tanks
Always keep the antibacterial tanks of the imop Lite out of direct sunlight. This can cause
discoloration.
3.1.5 Strong magnets
CAUTION
Please be aware of the integrated magnets that hold the fluid tanks in place and
on the scrub deck.
WARNING
Operators and maintenance crew wearing pacemakers should keep a minimal
distance of 6 in/15 cm.
3.1.6 Battery
Always use the automatic battery charger provided by the manufacturer.
CAUTION
During normal operation, the 18V battery cause no safety hazard on their own.
Please adhere to the following safety instructions regarding the battery:
•Do not crush, pierce or damage in any way.
•Do not heat or incinerate.
•Do not short-circuit.
•Do not dismantle.
•Keep dry.
•Only charge between 5°C~40°C / 41°F~104°F.
•Only use between 5°C~45°C / 41°F~113°F.

14
3.2. Risks during operation
3.2.1 Dress safely
Do not wear a necktie, scarf, or any loose or dangling clothing or jewelry while operating this
imop®Lite. These can tangle in rotating parts, causing serious injury or death.
3.2.2 Mark the job site
WARNING
During operation the cleaning solution can cause slippery patches on the floor.
Therefore, it is advised to mark the job site to warn passersby.
3.2.3 Careful when parking
Do not park the imop Lite on ramps or slopes. Always park the imop Lite on a level, hard
surface.
3.3. Risks after operation
3.3.1 Remove battery
Remove the battery before executing any cleaning or maintenance task.
3.3.2 Machine orientation
Always keep the body of the imop Lite in an upright position when replacing brushes or
squeegee.
3.3.3 Careful when storing
Do not store the imop Lite on ramps or slopes. Always store the imop Lite on a level, hard
surface. Do not store the imop Lite in park position.

15
4. Transport and storage
4.1. General
CAUTION
Always keep the body of the imop®Lite in an upright position when filling the
cleaning solution tank or inserting the battery.
Before storage or transport, drain the machine and remove the battery after each use.
4.2. Store position
CAUTION
Please be aware of the integrated magnet on the scrub deck.
The store position is the upright vertical position for storage and maintenance tasks.
Figure 5
1. Make sure the vacuum hose (Figure 5, pos 2) is pushed back into the machine so it cannot
get squeezed.
2. Crouch down and hold the handle (Figure 5, pos 1) with one hand while holding the scrub
deck (Figure 5, pos 3) with your other hand.
3. Lift the scrub deck slowly until it stands upright on the front wheels (Figure 5, pos 4).
Guide the body towards the scrub deck until it snaps into a resting position.

16
4.3. Transport outside
Figure 6
When outside:
1. Put the imop®Lite in store position, see section 4.2.
2. Carry the imop Lite with one hand while holding the handle (Figure 6, pos 1) with your
other hand.
CAUTION
The transport wheels are not designed to roll over dirty surfaces, sand can cause
the wheels to block. Lift the imop Lite while moving it from one building to
another.

17
4.4. Transport in a vehicle
The preferred way to transport your
imop
®Lite is in an upright position and safely
secured.
1.
Make sure both tanks are empty.
2.
Put the imop Lite in store position, see
section 4.2.
3.
Remove the batteries.
4.
Lift the imop Lite into the vehicle.
5.
Secure the imop using a tension belt or
another appropriate restraint (Figure 7,
pos 1).
Figure 7
TIP
The i-stand wall mount accessory can be installed in the back of a truck. It allows you to
secure the imop and transport the imop in an upright position. Please contact our sales
department for more information.
The imop Lite is a compact machine and fits in the trunk of your car. Before loading the
imop Lite into your vehicle, make sure both tanks and the battery are removed.
1. Put the imop Lite in store position, see section 4.2.
2. Remove the battery and both tanks.
3. Set the imop Lite into a horizontal position.
4. Prevent the imop Lite from moving around during transport by using a tension belt or
another appropriate restraint.
CAUTION
The seal of the solution and recovery tank can be damaged during transport in
horizontal position. Make sure you remove the tanks before loading the machine
into your car.
Improper use will void the warranty.

18
5. Assembly and installation
The imop®Lite does not require much assembly. Most importantly, you will have to attach the
brushes and squeegee.
5.1. Unboxing
The imop Lite body is packed in a single box. The battery and charger are delivered in a
separate box and can be ordered separately.
Figure 8
1. 1x imop®Lite main body
2.
1x suction filter
3.
1x battery charger manual (when ordered)
4.
1x battery charger (when ordered)
5.
1x battery (when ordered)
6. 1x squeegee assembly
7.
2x brushes
8.
1x recovery tank
9.
1x cleaning solution tank
10.
1x this manual

19
5.2. Assembly
5.2.1 Charging the battery
Charge the battery according to the instructions in the battery charger manual. Make sure the
battery is charged regularly.
5.2.2 Attaching the brushes
Figure 9
To attach the brushes:
1. Put the imop®Lite in store position, see section 4.2.
2. Hold the scrub deck firmly with one hand.
3. Align the left brush (Figure 9, pos 1) with the left motor disk (Figure 9, pos 2). Align the
latches and cut-outs in the brush and motor disk.
4. Push the brush on the motor disk.
5. Turn the left brush clockwise until you see the motor disk turning. The brush is now in
place.
6. Align the right brush with the right motor disk. Align the latches and cut-outs in the brush
and motor disk.
7. Push the brush on the motor disk.
8. Turn the right brush anticlockwise until you see the motor disk turning. The brush is now
in place.

20
5.2.3 Attaching the squeegee
Figure 10
To attach the squeegee:
1. Hold the scrub deck firmly with one hand.
2. Align the pins on the scrub deck (Figure 10, pos 2) with the holes on the squeegee
(Figure 10, pos 1).
3. Push the left side of the squeegee in place.
4. Push the right side of the squeegee in place.
5.2.4 Installing the cleaning solution tank
1. Put the tank (Figure 11, pos 1) on the
imop®Lite with the valve first.
2.
Press the tank downward on the nipple
(Figure 11, pos 3) to open the valve seal.
3.
Push the tank forward into place, the
magnet (Figure 11, pos 2) will lock the
solution tank in place.
Figure 11
