IAG Top Feed TGV Housings with New Style Injector Dynamics Fuel Injectors
Corresponds to IAG Part# IAG-AFD-3000, IAG-AFD-3001
Thank you for choosing IAG Performance. Our top feed TGV
housings are CAD modeled and CNC machined to be a direct
fit. In 2015, Injector Dynamics released an updated top feed
fuel injector body and the instructions below explain how to
install their top feed injectors using IAG TGV’s with stock fuel
rails or IAG fuel rails.
Picture above shows the New Injector Dynamics top feed
intector body (left) versus the old ID injector body (right).
IAG TGV / IAG Top Feed Fuel Rails
If using IAG top feed fuel rails, use (x2) 8mm washers under
each fuel rail mounting point (included with our latest fuel
rail kits) as shown in the corresponding images 1a, 1b and 1c.
1a. Shows (x2) M8x20 socket head cap screws, placed
through IAG Fuel Rail mounting points with (x2) 8mm
washers added as spacers to each side.

IAG Performance | 1203 Baltimore Blvd. Westminster, MD 21157 | Ph: 410-840-3555 | www.iagperformance.com
2
1b.
Shows (x2) M8x20 socket head cap screws, placed through IAG Fuel Rail mounting points with (x2) 8mm washers added as spacers
to each side mounted to IAG TGV’s
1c. Shows IAG Fuel Rail to TGV mounting points with (x2) 8mm washers added to each side as spacers. Also illustrates Injector
Dynamic injector fitment.

IAG Performance | 1203 Baltimore Blvd. Westminster, MD 21157 | Ph: 410-840-3555 | www.iagperformance.com
3
IAG TGV / Stock Top Feed Fuel Rails
If you are using the stock fuel rails, use (x1) washer under
each fuel rail mounting point as shown in the corresponding
images 2a, 2b.
2a. Shows (x2) OEM hex head bolts, placed through the OEM
fuel rail mounting points with (x2) 8mm washers added as
spacers to each side.
2b.Shows the OEM fuel rail to IAG TGV mounting points with (x1) 8mm washers added as a spacer per side. Also illustrates Injector
Dynamic injector fitment.
