CAP PLUS COVER LAYER: To cover the Cap
Plus cover with a finish that matches the desk
(wood or another material), cut a layer with the
same dimensions shown in figure 5.
Check that the box cover opens perfectly to
90º.
The product is completely installed.
IMPORTANT: If necessary, respect the position
and direction of the wood grain.
Contact adhesive is recommended for securing
the material to the cover (in the case of wood or
another porous material). For materials such
as leather or synthetic leather, do not use
adhesives containing cyanoacrylate. Adhesive
not supplied with the product.
manual de usuario
294 +1
-0
147+0
-0,2
01
02
04
03
Cut an opening in the desk to recess the box
with the measurements specified in figure 1.
IMPORTANT: do not exceed the tolerance
dimensions or the product will not be
installed properly.
Use a Phillips head screwdriver to screw the
tabs that you bent using the screws provided.
The box is completely installed.
Bend the four tabs that are best suited for holding
the box to the desk.
After you have cut the opening, insert the box
through the top of the desk.
For any questions on the profile frame, contact
us at:
[email protected]
1+0,2
-0
282 +0
-0,2
101+0
-0,2
