IB Connect Duplo Troubleshooting guide

installation guide
user manual
organizedconnection
HOME
DUPLO
conexiónorganizada

1 - 2
user manual
12
04
Once the screws have been inserted in the wall,
you can screw in the duplo kit. To do this, position
the duplo kit so that the holes in the wall line
up with the anchor holes in the profile. Once
the screw heads pass through the anchor holes,
move the profile to one side so that when the
screw is tightened, it sits on the narrow part of
the profile anchor hole.
user manual
01
02
WALL MOUNT
Insert a flathead screwdriver in the slots on the
side of the covers indicated in the diagram to
lever them off.
.
After marking them, drill the holes. Then insert
the rawlplugs in the holes made. The next step
is to screw the screws inside the rawlplugs
without fully tightening them.
Once you have removed the covers, you can
access the inside of the profile. Mark the centre
of the holes in order to later fix it to the wall.
The holes where the profile will be fixed are
indicated in diagram 2.
Now connect it to the power supply.
For any queries related to the product, contact:
[email protected]
06
03
1
2
Now you must place the cover on the anchor
system and connection system.
DetailAanchor for fixing our Orgatech vertebra
system, accessory compatible with Duplo Home
(not included)
A
Detail A
05
Detail A
Detail A
