IBASE Technology IB898 User manual

IB898
Intel®AtomTM E3800 SoC Series
3.5” Disk Size SBC
USER’S MANUAL
Version 1.0

ii IB898 User’s Manual
Acknowledgments
AMI BIOS is a trademark of American Megatrends Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Atom are registered trademarks of Intel Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Nuvoton is a registered trademark of Nuvoton Technology
Corporation.
All other product names or trademarks are properties of their
respective owners.

IB898 User’s Manual iii
Table of Contents
Introduction.......................................................1
Product Description.............................................................1
Specifications......................................................................2
Checklist..............................................................................3
Board Dimensions...............................................................4
Installations.......................................................5
Installing the Memory.........................................................6
Setting the Jumpers .............................................................7
Connectors on IB898.........................................................11
BIOS Setup.......................................................21
Drivers Installation......................................35
Intel Chipset Software Installation Utility.........................36
Intel Baytrail Graphics Driver Installation........................37
Realtek High Definition Audio Driver Installation...........38
LAN Drivers Installation...................................................39
Intel Trusted Execution Engine Installation......................40
Intel® USB 3.0 Drivers.....................................................41
Appendix...........................................................42
A. I/O Port Address Map...................................................42
B. Interrupt Request Lines (IRQ)......................................44
C. Digital I/O Sample Code ..............................................45
D. Watchdog Timer Configuration ...................................50

iv IB898 User’s Manual
This page is intentionally left blank.

INTRODUCTION
IB898 User’s Manual 1
Introduction
Product Description
IB898 is a 3.5-inch single board computer based on the Intel®AtomTM
E3800 series processors. It supports One DDR3L SODIMM sockets
for a maximum memory capacity of 4GB.
IB898 features the Intel®Gen7 w/4EUs graphics engines and has both
CRT and DisplayPort video display interface, and 24-bit LVDS dual
channel interface with the use of the NXP PTN3460 device.
Onboard connections are available for two SATAII ports, two COM
ports, one USB 3.0 ports, three USB2.0 ports, audio, three Mini
PCI-e(x1) slots,
IB898 Features:
• Supports AtomTM E3800 series SoC processors
• One DDR3L SO-DIMM, 1066 MHz, Max. 4GB memory
• Integrated graphics for VGA, DP displays
• 2 x SATA II connectors
• 2x COM port connectors
• 1 x Mini-PCIe(x1) slot (w/ USB/mSATA support)
• 2 x Mini-PCIe(x1) slot
• 1x GbE (RJ-45) connectors
• 24-bit dual channel LVDS

INTRODUCTION
2 IB898 User’s Manual
Specifications
Product Name
IB898 [default silk screen model # on PCB is IB898]
Form Factor
3.5” disk size SBC
SoC Type/Speed
Intel® AtomTM DC E3825 /1MB cache/1.33 GHz (IB898-I25)
Intel® AtomTM SC E3815 /512KB cache/1.46 GHz (IB898-I15)
FCBGA1170,Type-3, 25mmx27mm, 22nm,Tj= -40ﾟC to +110ﾟC ;
**All SoC Skus will be on
D-0 stepping
»
BIOS
AMI
BIOS
Memory Intel
®
Atom
TM
SoC integrated memory controller, supports
DDR3L(1.35V) only; 1x DDR3 SO-DIMM socket;
Max. DDR3L-1066@4GB (Non-ECC, Un-buffered)
VGA
Intel® Gen7 w/ 4 EUs graphics engines (Gfx freq @542MHz/792MHz
[Turbo]); Supports DX 11, OGL 3.0, OCL 1.1, OGLES 2.0,
DisplayPort x 1 [Support to 2560x1200@60Hz]
CRT x 1 [Support to 1920x1080@60Hz]
LVDS
24-bit dual channel via NXP PTN3460 thru eDP
[Supports up to 1920x1200@60Hz]
LAN Intel I210IT PCIe Gigabit LAN [9x9mm @64-QFN , -40ﾟC to +85ﾟC]
USB
Intel® AtomTM SoC built-in USB host controller
Support USB 2.0 x 4 ports; USB 3.0 x 1 port,
USB 2.0 Hub x 4 ports (Thru Renesas uPD720115K8)
Serial ATA Ports
Intel® Atom
TM
SoC built-in SATA II controller, supports 2 ports
Audio Intel
®
Atom
TM
SoC built-in HD Audio controller + Realtek ALC269QHD
Codec w/ class-D speaker amplifier(2.3W per channel @ 5V P/S)
[7mm x 7mm @ 48-QFN] ; support 2-channel audio out + amp
LPC I/O Nuvoton NCT5523D [64-pin LQFP, 7x7x1.4mm]
COM #1 (RS232/422/485) [EXAR SP339EER1 x 1 for jumper-less]
COM #2 (RS-232 only)
Hardware Monitor: 2x Thermal inputs; 2x Voltage monitoring
Digital IO
4 in & 4 out
Expansion Slots
Mini PCI-e socket x3 (2x Full-sized + 1x Half-sized, all with USB signal
from USB Hub) **Full-sized MiniPCIe(1x) # 1 support mSATA also **
Edge Connector
DB9 for COM1, DB15 for VGA, DisplayPort, RJ45 for GbE LAN
USB 2.0 vertical connector x 1 (from SoC)
USB 3.0 vertical connector x 1 (from SoC)
Onboard
Header/Connector
2x4 header for front panel (PWR, LED, RESET)
DF11 2x4 header for 2x USB 2.0 (from USB Hub)
DF20 socket connector x2 for 24-bit dual channel LVDS
4-pin box header for backlight/brightness control (PWM mode)
DF11 2x6 box header x1 for Audio; 4-pin box header for speaker
DF11 2x5 box header for COM2
2x5 pin header for LPC (80-port card debugging purpose)
Mini PCI-e(1x) connector x3
SATA connector x2 for SATA device
4-pin power connector x2 (JST type, For SATA device)
2-pin connector 1 for power input
Watchdog Timer
Yes (256 segments, 0, 1, 2…255 sec/min)
Power Connector
12V only DC-in thru onboard 2-pin connector
Others iSMART 3.1 [EuP/ErP ; Auto-scheduler ; Power resume]
Heat-spreader / Heatsink for fanless purpose
Mounting holes for heatsink / heat spreader are at least 5 holes
OS supporting
- Windows 8.1 / Embedded; Windows 7 / Embedded; Linux
RoHS 2.0
/ CE
/FCC/ LVD
Yes / Yes / Yes / Class B
Operating system
-40
ﾟ
C to +85
ﾟ
C
Board Size
102mm x 147mm

INTRODUCTION
IB898 User’s Manual 3
Checklist
Your IB898 package should include the items listed below.
•The IB898 SBC
•This User’s Manual
•1 CD containing chipset drivers and flash memory utility

INTRODUCTION
4 IB898 User’s Manual
Board Dimensions

INSTALLATIONS
IB898 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the IB898 in order to set up a workable system. The topics
covered are:
Installing the Memory ........................................................................... 6
Setting the Jumpers................................................................................ 7
Connectors on IB898........................................................................... 11

INSTALLATIONS
6 IB898 User’s Manual
Installing the Memory
The IB898 board supports one DDR3L memory socket for a maximum
total memory of 4GB in DDR3L memory type.
Installing and Removing Memory Modules
To install the DDR3L modules, locate the memory slot on the board and
perform the following steps:
1. Hold the DDR3L module so that the key of the DDR3L module
aligned with that on the memory slot.
2. Gently push the DDR3L module in an upright position until the
clips of the slot close to hold the DDR3L module in place when the
DDR3L module touches the bottom of the slot.
3. To remove the DDR3L module, press the clips with both hands.
** Channel-A slot must be installed with
memory module for booting up**

INSTALLATIONS
IB898 User’s Manual 7
Setting the Jumpers
Jumpers are used on IB898 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on IB898 and their respective functions.
Jumper Locations on IB898................................................................... 8
JP1: LVDS Panel Power Selection........................................................ 9
JP2: LVDS Panel Brightness Control Selection.................................... 9
JP4: Clear CMOS Contents................................................................. 10
JP5: Clear ME Contents ...................................................................... 10

INSTALLATIONS
8 IB898 User’s Manual
Jumper Locations on IB898

INSTALLATIONS
IB898 User’s Manual 9
JP1: LVDS Panel Power Selection
JP1 Setting Panel Voltage
Pin 1-2
Short/Closed 3.3V (default)
Pin 2-3
Short/Closed 5V
JP2: LVDS Panel Brightness Control Selection
JP2 Brightness Control
(PWM mode)
Open 3.3V
Close 5V(Default)
1 3
1 2

INSTALLATIONS
10 IB898 User’s Manual
JP4: Clear CMOS Contents
JP4 Setting Function
Pin 1-2
Short/Closed Normal
Pin 2-3
Short/Closed Clear CMOS
JP5: Clear ME Contents
JP5 Setting Function
Pin 1-2
Short/Closed Normal
Pin 2-3
Short/Closed
Clear ME
Register
1
3
1
3

INSTALLATIONS
IB898 User’s Manual 11
Connectors on IB898
Connector Locations on IB898............................................................ 12
CN1: USB3.0 Connector..................................................................... 13
CN3: Gigabit LAN Connector............................................................. 13
CN3: Intel® I210IT Connector ........................................................... 13
CN4: USB2.0 Connector..................................................................... 13
CN5: DP Connector............................................................................. 13
CN6: CRT Connector.......................................................................... 13
CN7: DB9 Connector (COM1) ........................................................... 13
J1: Audio Connector............................................................................ 14
J3: Amplifier Connector...................................................................... 14
J4: DDR3L SO-DIMM Sockets .......................................................... 15
J5, J6: LVDS Connectors.................................................................... 15
J5: First Channel LVDS ...................................................................... 15
J6: Second Channel LVDS.................................................................. 15
J7: LCD Backlight Connector ............................................................. 16
J8: SPI Flash Connector (factory use only)......................................... 16
J9: SATAII /share mSATA/ Connectors............................................. 16
J12: SATAII Connectors..................................................................... 17
J10, J11: SATA HDD Power Connectors ........................................... 17
J14: Mini PCIE Connector (share mSATA)........................................ 18
J16: Front Panel Function Connector.................................................. 18
J17: Board Input Power Connector .................................................... 19
J18: COM2/RS232 Serial Port ............................................................ 19
J19: Digital I/O Connector .................................................................. 20
J21: Debug 80 Port Connector (factory use only)............................... 20
J22: USB 2.0 Connector...................................................................... 20

INSTALLATIONS
12 IB898 User’s Manual
Connector Locations on IB898

INSTALLATIONS
IB898 User’s Manual 13
CN1: USB3.0 Connector
CN3: Gigabit LAN Connector
CN3: Intel® I210IT Connector
CN4: USB2.0 Connector
CN5: DP Connector
CN6: CRT Connector
CN7: DB9 Connector (COM1)
Signal Name
Pin #
Pin #
Signal Name
DCD, Data carrier detect
1
6
DSR, Data set ready
RXD, Receive data
2
7
RTS, Request to send
TXD, Transmit data
3
8
CTS, Clear to send
DTR, Data terminal ready
4
9
RI, Ring indicator
GND, ground
5
10
Not Used
COM1 is jumper-less for RS-232, RS-422 and RS-485 and is to be
configured with BIOS Selection.
[
Pin #
Signal Name
RS-232
R2-422
RS-485
1
DCD
TX-
DATA-
2
RX
TX+
DATA+
3
TX
RX+
NC
4
DTR
RX-
NC
5
Ground
Ground
Ground
6
DSR
NC
NC
7
RTS
NC
NC
8
CTS
NC
NC
9
RI
NC
NC
10
NC
NC
NC

INSTALLATIONS
14 IB898 User’s Manual
J1: Audio Connector (DF11-12DP-2DSA)
Signal Name Pin # Pin # Signal Name
LINEOUT R
2
1
LINEOUT L
Ground
4
3
JD FRONT
LINEIN R
6
5
LINEIN L
Ground
8
7
JD LINEIN
MIC-R
10
9
MIC L
Ground
12
11
JD MIC1
J2: MCU Flash Connector (factory use only)
J3: Amplifier Connector (JST B4B-PH-K-S)
Pin # Signal Name
1
OUTL+
2
OUTL-
3
OUTR-
4
OUTR+
1 11
2 12
1 4
1
4

INSTALLATIONS
IB898 User’s Manual 15
J4: DDR3L SO-DIMM Sockets
J5, J6: LVDS Connectors (DF20G-20DP-1V)
J5: First Channel LVDS
J6: Second Channel LVDS
Signal Name
Pin #
Pin #
Signal Name
TX0N
2
1
TX0P
Ground
4
3
Ground
TX1N
6
5
TX1P
Ground
8
7
Ground
TX2N
10
9
TX2P
Ground
12
11
Ground
CLKN
14
13
CLKP
Ground
16
15
Ground
TX3N
18
17
TX3P
Power(1A)
20
19
Power
20 2
19 1
2
20
1
19

INSTALLATIONS
16 IB898 User’s Manual
J7: LCD Backlight Connector (JST B4B-PH-K-S )
Pin #
Signal Name
1
+12V(1A)
2
Backlight Enable
3
Brightness Control
4
Ground
J8: SPI Flash Connector (factory use only)
J9: SATAII /share mSATA/ Connectors
4
1
2 10
1 9
