IBASE Technology MB870 User manual

MB870
Socket 478 Pentium 4
ATI RS300M Mini ITX
USER’S MANUAL
Version 1.0

ii MB870 User’s Manual
Acknowledgments
Award is a registered trademark of Award Software International,
Inc.
PS/2 is a trademark of International Business Machines
Corporation.
Intel and Pentium 4 are registered trademarks of Intel
Corporation.
Microsoft Windows is a registered trademark of Microsoft
Corporation.
Winbond is a registered trademark of Winbond Electronics
Corporation.
All other product names or trademarks are properties of their
respective owners.

MB870 User’s Manual iii
Table of Contents
Introduction .......................................................1
Product Description............................................................. 1
Checklist..............................................................................2
Specifications ......................................................................3
Board Dimensions ...............................................................4
Installations .......................................................5
Installing the CPU ............................................................... 6
Installing the Memory .........................................................7
Setting the Jumpers .............................................................8
Connectors on MB870 ...................................................... 12
Watchdog Timer Configuration ........................................23
Digital I/O Sample Code ................................................... 27
BIOS Setup.......................................................31
Drivers Installation ......................................50
ATI Chipset Software Installation Utility .........................51
Realtek AC97 Codec Audio Driver Installation................ 55
Realtek RTL8100 LAN Drivers Installation ..................... 57
Appendix ...........................................................59
A. I/O Port Address Map................................................... 59
B. Interrupt Request Lines (IRQ)...................................... 60

iv MB870 User’s Manual
This page is intentionally left blank.

INTRODUCTION
MB870 User’s Manual 1
Introduction
Product Description
The MB870 Pentium 4 Mini ITX board incorporates the ATI RS300M
chipset and supports 478-pin Intel Pentium 4 processors of 2GHz and up
to 3.2GHz+ with FSB 800MHz/533MHz/400MHz. MB870 supports the
Pentium 4 processor with 256-KB L2 cache, Pentium 4 processor with
512-KB L2 cache on 0.13 micron process.
The I/O functions are on MB870 integrated onto the IXP150. It supports
the integrated graphics processor (IGP) on the IGP9180. The IGP has
3D, 2D, and video capabilities. The system memory size can be up to
1GB, using the single DDR socket on board. Four USB ports are
supported with the USB 1.1/2.0 standard.
MB870 supports TV out and LVDS with the use of the ATI RS300M
integrated graphics device that accepts two digital graphics input data
streams. One data stream outputs through an LVDS transmitter to an
LCD panel, while the other data stream is encoded for NTSC or PAL TV
and outputs through a 10-bit high speed DAC. The TV encoder device
encodes a graphics signal up to 1024x768 resolution and outputs the
video signals according to NTSC or PAL standards. The LVDS function
supports 18 bit single and dual channel LCD panels.
*The board does not support 24-bit single and dual channel LCD
panels.
The MB870 Mini ITX SBC supports CRT VGA interface as well as TV
out and LVDS interface. Realtek LAN 8100BL supports Ethernet
functionality (10/100Mb). The board also has AC97 6CH audio, 4 COM
ports, UDMA 100, 4 USB ports, two serial ATA ports, watchdog timer
and a PCI slot for expandability. Dimensions of the board are 170mm x
170mm.
This board represents the perfect choice for those who want superior
performance for POS, kiosk, ATM, Web payphone, medical and other
embedded applications.

INTRODUCTION
2MB870 User’s Manual
Checklist
Your MB870 package should include the items listed below.
• The MB870 P4 Mini ITX board
• This User’s Manual
• 1 CD containing chipset drivers and flash memory utility
• Optional cables such as:
• 1 slim FDD Ribbon Cable
• 2 IDE Ribbon Cables (40-pin & 44-pin)
• 1 COM Port Cable
• Serial ATA Cable

INTRODUCTION
MB870 User’s Manual 3
Specifications
Product Name MB870
Form Factor Mini ITX
CPU Type Socket 478 (Intel Pentium 4 / Celeron)
CPU Voltage 0.8375V~1.6V (VRD10)
System Speed 2.0AG~3.2GHz
CPU Operating
Frequency
400/533/800MHz
Green /APM APM1.2
CPU Socket Socket 478
Chipset ATI RS300M Chipset
NB: Mobility IGP9180 868 PIN BGA
SB: IXP150 457 PIN BGA
BIOS Award BIOS, with ACPI Function
Cache 128K/256K/512K Level 2 (CPU integrated)
VGA Mobility IGP9180 embedded, AGP 4X,CRT, TV-out,
LVDS
LAN Realtek RTL8100 10/100Mb LAN controller
Audio IXP150 built-in sound controller + AC97 Codec
ALC655 AC3 5.1 CH. (Line-out, Line-in, Mic)
Memory type 1 x DDR, 2.5V, DDR266/333/400 SDRAM(without
ECC Function) DIMM Module, Max. capacity - 1GB
LPC I/O 1. First I/O : Winbond 83627HF: IrDAx1 Parallel x1,
COM1(RS-232), COM2(RS-232), FDC 1.44MB (Slim type),
Hardware monitor (3 thermal inputs, 8 voltage monitor
inputs, VID0-4 , 1 chassis open detection ,3 fan headers)
2. Secondary I/O: Fintek F81216 support COM3,4 (RS-232)
Keyboard
Controller
Winbond 83627HF built-in
Local bus IDE IXP150 built-in, IDE1 40-pin pitch 2.54mm (Ultra
DMA 33/66/100), IDE2 44-pin pitch 2.0mm
Serial ATA SiI3512, 2 ports
Digital I/O 4 in, 4 out
On board D-type
connector
PS/2 Keyboard/Mouse, VGA(CRT), COM1, Printer,
USBx2, RJ-45, Line-out , Line-in, Mic, TV-out
Power Connector ATX 12V
PCI Slot 1 slot (support 2 bus master)
USB 4 ports, USB 2.0
IrDA (Infrared Ray) Pin header, allows infrared wireless communication.
Watchdog Timer Yes (256 segments, 0,1,2…255. sec/min)
System Voltages +5V, +12V, -12V, 5VSB-5V, 3.3V
Board Size 170 x170mm
Other Features Modem Wakeup, LAN Wakeup

INTRODUCTION
4MB870 User’s Manual
Board Dimensions

INSTALLATIONS
MB870 User’s Manual 5
Installations
This section provides information on how to use the jumpers and
connectors on the MB870 in order to set up a workable system. The
topics covered are:
Installing the CPU ............................................................... 6
Installing the Memory .........................................................7
Setting the Jumpers ............................................................. 8
Connectors on MB870 ...................................................... 12
Watchdog Timer Configuration ........................................23
Digital I/O Sample Code ................................................... 27

INSTALLATIONS
6MB870 User’s Manual
Installing the CPU
The MB870 embedded board supports a Socket 478 processor socket for
Intel Pentium 4 processors.
The Socket 478 processor socket comes with a lever to secure the
processor. Raise this lever to about a 90°angle to allow the insertion of
the processor. Place the processor into the socket by making sure the
notch on the corner of the CPU corresponds with the notch on the inside
of the socket. Once the processor has slide into the socket, return the
lever to the lock position. Refer to the figures below.
After you have installed the processor into the socket, check if the
jumpers for the CPU type and speed are correct.
NOTE: Ensure that the CPU heat sink and the CPU top surface are in
total contact to avoid CPU overheating problem that would
cause your system to hang or be unstable.

INSTALLATIONS
MB870 User’s Manual 7
Installing the Memory
The MB870 embedded board supports one DDR memory sockets for a
maximum total memory of 1GB in DDR memory type. The memory
module capacities supported are 128MB, 256MB, 512MB and 1GB. The
following table lists the supported DDR DIMM configurations. ATI
RS300M supports configurations defined in the JEDEC DDR DIMM
specification only. Non-JEDEC standard DIMMs such as double-sided
x16 DDR SDRAM DIMMs are not supported.
Installing and Removing Memory Modules
To install the DDR modules, locate the memory slot on the embedded
board and perform the following steps:
1. Hold the DDR module so that the key of the DDR module align with
those on the memory slot.
2. Gently push the DDR module in an upright position until the clips of
the slot close to hold the DDR module in place when the DDR module
touches the bottom of the slot.
3. To remove the DDR module, press the clips with both hands.
DDR Module Lock
Lock
Lock Lock

INSTALLATIONS
8MB870 User’s Manual
Setting the Jumpers
Jumpers are used on MB870 to select various settings and features
according to your needs and applications. Contact your supplier if you
have doubts about the best configuration for your needs. The following
lists the connectors on MB870 and their respective functions.
Jumper Locations on MB870.......................................................... 9
Configuring the CPU Frequency .................................................. 10
J24: RTL8100BL LAN Enable/Disable ....................................... 10
JP12: LVDS Panel Power Select .................................................. 10
JP13: Clear CMOS Contents ........................................................ 10
JP8: COM3 RS232 +5V / +12V Power Setting............................ 11
JP7: COM4 RS232 +5V / +12V Power Setting............................ 11
SW1: LVDS Resolution Setting ................................................... 11

INSTALLATIONS
MB870 User’s Manual 9
Jumper Locations on MB870
Jumpers on MB870 ...................................................................Page
Jumper Locations on MB870 ......................................................... 9
Configuring the CPU Frequency.................................................. 10
J24: RTL8100BL LAN Enable/Disable ....................................... 10
JP12: LVDS Panel Power Select.................................................. 10
JP13: Clear CMOS Contents ........................................................ 10
JP8: COM3 RS232 +5V / +12V Power Setting ........................... 11
JP7: COM4 RS232 +5V / +12V Power Setting ........................... 11
SW1: LVDS Resolution Setting................................................... 11

INSTALLATIONS
10 MB870 User’s Manual
Configuring the CPU Frequency
The MB870 embedded board does not provide DIP switches to
configure the processor speed (CPU frequency).
J24: RTL8100BL LAN Enable/Disable
J24 10/100Mb LAN
Enable
Disable
JP12: LVDS Panel Power Select
JP12 LVDS Panel Power
3.3V (default)
5V
JP13: Clear CMOS Contents
Use JP13 to clear the CMOS contents. Note that the ATX-power
connector should be disconnected from the board before clearing
CMOS.
JP13 Setting Function
Pin 1-2
Short/Closed Normal
Pin 2-3
Short/Closed Clear CMOS

INSTALLATIONS
MB870 User’s Manual 11
JP8: COM3 RS232 +5V / +12V Power Setting
Pin # Signal Name JP8 Signal Name Pin #
1 RI +12V 2
3 RI (Default) RI (Default) 4
5 RI +5V 6
COM3 Settings: Pin 1-2 short = +12V, Pin 5-6 short = +5V, Pin 3-4
Standard COM Port
JP7: COM4 RS232 +5V / +12V Power Setting
Pin # Signal Name JP7 Signal Name Pin #
1 RI +12V 2
3 RI (Default) RI (Default) 4
5 RI +5V 6
COM4 Settings: Pin 1-2 short = +12V, Pin 6-5 short = +5V, Pin 3-4
Standard COM Port
SW1: LVDS Resolution Setting
SW1 1 2 3 4
800x600 OF
F
ON ON O
N
1024x768 ON OF
F
ON O
N
1280x1024 OF
F
OF
F
ON O
N
1400x1050 ON ON OF
F
O
N

INSTALLATIONS
12 MB870 User’s Manual
Connectors on MB870
The connectors on MB870 allows you to connect external devices such
as keyboard, floppy disk drives, hard disk drives, printers, etc. The
following table lists the connectors on MB870 and their respective
functions.
Connector Locations on MB870................................................... 13
FDD1: Floppy Drive Connector ................................................... 14
IDE1, IDE2: EIDE Connectors..................................................... 14
J1: ATX 12V/+12V Power Connector ......................................... 15
J2: ATX Power Supply Connector ............................................... 16
J3: PS/2 Keyboard and PS/2 Mouse Connectors.......................... 16
J4: CPU Fan Power Connector ..................................................... 16
J7, J30: System Fan Power Connector.......................................... 17
J8: USB Connector (USB1/USB2)............................................... 17
J9: IrDA Connector ...................................................................... 17
J11: Digital 4-in 4-out I/O Connector........................................... 17
J12: COM1 Serial Port.................................................................. 17
J13: Parallel Port Connector ......................................................... 18
J14: Serial Ports ............................................................................ 19
JP14: Power LED Connector........................................................ 19
J15: VGA CRT connector ............................................................ 19
J16: RJ45 Connector..................................................................... 20
J17, J19: LVDS Connectors (1st channel, 2nd channel) .............. 20
J18, J20: Serial ATA (SATA) Connectors ................................... 20
J21, JP11: TV out Connector (RCA Jack/J21 and 3-pin
Header/JP11) ................................................................................ 20
J22: External Audio Connector .................................................... 21
J23: USB Connector (USB3/USB4)............................................. 21
J25: Panel Inverter Power Connector ........................................... 21
J26: Panel Inverter Power Connector ........................................... 21
J27: CD-In Audio Connector........................................................ 21
J28: System Function Connector .................................................. 22
J29: Line Out, Line In, Mic Connector......................................... 22

INSTALLATIONS
MB870 User’s Manual 13
Connector Locations on MB870
Connector on MB870................................................................................................................Page
FDD1: Floppy Drive Connector .................................................................................................. 14
IDE1, IDE2: EIDE Connectors.................................................................................................... 14
J1: ATX 12V/+12V Power Connector ........................................................................................ 15
J2: ATX Power Supply Connector .............................................................................................. 16
J3: PS/2 Keyboard and PS/2 Mouse Connectors......................................................................... 16
J4: CPU Fan Power Connector .................................................................................................... 16
J7, J30: System Fan Power Connector ........................................................................................ 17
J8: USB Connector (USB1/USB2).............................................................................................. 17
J9: IrDA Connector...................................................................................................................... 17
J11: Digital 4-in 4-out I/O Connector ......................................................................................... 17
J12: COM1 Serial Port................................................................................................................. 17
J13: Parallel Port Connector ........................................................................................................ 18
J14: Serial Ports ........................................................................................................................... 19
JP14: Power LED Connector.......................................................................................................19
J15: VGA CRT connector............................................................................................................ 19
J16: RJ45 Connector.................................................................................................................... 20
J17, J19: LVDS Connectors (1st channel, 2nd channel)............................................................. 20
J18, J20: Serial ATA (SATA) Connectors .................................................................................. 20
J21, JP11: TV out Connector (RCA Jack/J21 and 3-pin Header/JP11)...................................... 20
J22: External Audio Connector ...................................................................................................21
J23: USB Connector (USB3/USB4)............................................................................................ 21
J25: Panel Inverter Power Connector .......................................................................................... 21
J26: Panel Inverter Power Connector .......................................................................................... 21
J27: CD-In Audio Connector....................................................................................................... 21
J28: System Function Connector ................................................................................................. 22
J29: Line Out, Line In, Mic Connector ....................................................................................... 22

INSTALLATIONS
14 MB870 User’s Manual
FDD1: Floppy Drive Connector
FDD1is a slim 26-pin connector and will support up to 2.88MB FDD.
Signal Name Pin # Pin # Signal Name
VCC 1 2 INDEX
VCC 3 4 DRV_SEL
VCC 5 6 DSK_CH
NC 7 8 NC
NC 9 10 MOTOR
DINST 11 12 DIR
NC 13 14 STEP
GND 15 16 WDATA
GND 17 18 WGATE
GND 19 20 TRACK
NC 21 22 WPROT
GND 23 24 RDATA
GND 25 26 SIDE
IDE1, IDE2: EIDE Connectors
IDE1: Primary IDE Connector
Signal Name Pin # Pin # Signal Name
Reset IDE 1 2 Ground
Host data 7 3 4 Host data 8
Host data 6 5 6 Host data 9
Host data 5 7 8 Host data 10
Host data 4 9 10 Host data 11
Host data 3 11 12 Host data 12
Host data 2 13 14 Host data 13
Host data 1 15 16 Host data 14
Host data 0 17 18 Host data 15
Ground 19 20 Protect pin
DRQ0 21 22 Ground
Host IOW 23 24 Ground
Host IOR 25 26 Ground
IOCHRDY 27 28 Host ALE
DACK0 29 30 Ground
IRQ14 31 32 No connect
Address 1 33 34 No connect
Address 0 35 36 Address 2
Chip select 0 37 38 Chip select 1
Activity 39 40 Ground

INSTALLATIONS
MB870 User’s Manual 15
IDE2: Secondary IDE Connector
Signal Name Pin # Pin # Signal Name
Reset IDE 1 2 Ground
Host data 7 3 4 Host data 8
Host data 6 5 6 Host data 9
Host data 5 7 8 Host data 10
Host data 4 9 10 Host data 11
Host data 3 11 12 Host data 12
Host data 2 13 14 Host data 13
Host data 1 15 16 Host data 14
Host data 0 17 18 Host data 15
Ground 19 20 Key
DRQ0 21 22 Ground
Host IOW 23 24 Ground
Host IOR 25 26 Ground
IOCHRDY 27 28 Host ALE
DACK0 29 30 Ground
IRQ14 31 32 No connect
Address 1 33 34 No connect
Address 0 35 36 Address 2
Chip select 0 37 38 Chip select 1
Activity 39 40 Ground
Vcc 41 42 Vcc
Ground 43 44 N.C.
J1: ATX 12V/+12V Power Connector
Pin # Signal Name
1 Ground
2 Ground
3 +12V
4 +12V

INSTALLATIONS
16 MB870 User’s Manual
J2: ATX Power Supply Connector
Signal Name Pin # Pin # Signal Name
3.3V 11 1 3.3V
-12V 12 2 3.3V
Ground 13 3 Ground
PS-ON 14 4 +5V
Ground 15 5 Ground
Ground 16 6 +5V
Ground 17 7 Ground
-5V 18 8 Power good
+5V 19 9 5VSB
+5V 20 10 +12V
11 1
20 10
J3: PS/2 Keyboard and PS/2 Mouse Connectors
PS/2 Mouse
PS/2 Keyboard
Signal Name Keyboard Mouse Signal Name
Keyboard data 1 1 Mouse data
N.C. 2 2 N.C.
GND 3 3 GND
5V 4 4 5V
Keyboard clock 5 5 Mouse clock
N.C. 6 6 N.C.
J4: CPU Fan Power Connector
J4 is a 3-pin header for the CPU fan. The fan must be a 12V fan.
Pin # Signal Name
1 Ground
2 +12V
3 Rotation detection
