IBC BioBolt User manual

BioBolt
Biometric Deadbolt
Installation Manual
BioBolt Biometric Deadbolt
Intelligent Biometric Controls
Installation Manual

This manual assumes that the door has been prepared for a US
standard deadbolt lock. If the door has not been prepared, please
refer to the documentation that came with the door cutting hardware.
Preparing a Standard US Preparation for Lock Installation
With the bolt extended (A), locate the stamped
“UP” in the top back corner of the bolt (B).
Insert the bolt into the prepared hole on the
door being sure that the “UP” arrow is pointed
upwards. Now, ensure that the cross slot (C) is
centered vertically (x-axis) of the hole.
B
C
A
Using the supplied screws, attach the bolt to
the door.
1
BioBolt Biometric Deadbolt
Intelligent Biometric Controls
Installation Manual

Measure the thickness of the door. The
BioBolt often requires the tailpiece that
turns the deadbolt be the trimmed to the
appropriate length for the thickness of the
door.
Adjusting the Tailpiece for the Proper Door Thickness
Identify the amount of the tailpiece that will
need to be trimmed based on the following:
!2 1/4” - 2 ½” = Use Full Tailpiece (A)
!1 3/4” - 2 1/8” = Trim 2 Notches (B)
!1 3/8” - 1 5/8” = Trim 4 Notches (C)
A
C
B
With two pairs of plyers, use one pair (A) to
hold the tailpiece just below necessary
notch (B).
Using the second pair of plyers (C), grab
the upper portion of the tailpiece and slightly
bend the top portion of the tailpiece being
careful NOT TO MOVE THE BOTTOM PAIR
OF PLYERS (A)!!
Continue to slightly bend the tailpiece back
and forth until the top potion of the tailpiece
breaks off at the desired notch (B).
AB
C
2
Before proceeding with final installation:
Fit the front and back lock bodies together on
the door to ensure the tailpiece does not hinder
the flush placement of both bodies to the door.
If there is ANY gap due to the length of the
tailpiece (A), remove one more notch from the
tailpiece and repeat this step until the front and
back lock bodies join without any gap.
WARNING: Forcing the front and back lock
bodies together may damage the internal
motor drive VOIDING THE WARRANTY!!
A
DO NOT FORCE FRONT
AND BACK LOCK
BODIES TOGETHER!
BioBolt Biometric Deadbolt
Intelligent Biometric Controls
Installation Manual

Place the Rubber Gaskets (A) on the rear
potions of the front and back lock bodies.
A small lip should surround the lock bodies.
The potion of the gasket that makes
contact with the door should be smooth
and flat.
Installing the BioBolt on a US Standard Preparation Door
With the gasket attached, place the front lock
body (the side with the scanner) through the
door hole. Be sure to align the tailpiece (A)
vertically through the deadbolt cross slot (E).
Only a small portion, if any, of the tailpiece
should extend through the door width (A).
Also, be sure to pass the Control Cable (B)
through the hole.
With the front lock body held against the door
with the tailpiece aligned vertically (A), verify
that the Motor Drive Coupler (D) is also
aligned vertically.
Now, connect the Control Cable (B) to the
corresponding Control Connector (C) on the
back lock body.
A
B
A
A
B
C
E
D
3
Align the front and back lock bodies so they
are straight on the door. Insert the two bolts
in the corresponding holes and try to thread
them into the front lock body.
Locate the Bolt Direction Switch (A) just under
the batteries. Make sure the Bolt Direction
Switch corresponds with the direction that the
bolt extends (B). In the example to the right,
the bolt extends out of the left side of the door.
Therefore the switch should be moved to the
left as shown by the diagram (C).
A
C
B
