IBM ThinkPad X22 User manual

Part Number: 46P5768
Setup Guide
ThinkPad X22
Thank you for purchasing the IBM ThinkPad X22 computer. Match the items on this list with the items in the box. If any
item is missing or damaged, please contact your place of purchase.
hComputer
hAC adapter
hMiscellaneous parts
vTrackPoint
®
caps
hBattery pack
hTelephone cable
hPower cord
hBooks
vService & Troubleshooting Guide
vSetup Guide
vManual Package for Microsoft
®
Windows
Notes:
1. Some models may contain additional items that are not listed.
2. Recovery CD components are available on your drive in a
dedicated recovery partition. A recovery CD is not shipped with
this package.
© Copyright IBM Corp. 2001 1

Setting up your computer
Connecting to a power source
1. Insert the battery pack into the battery compartment located
at the rear of the computer:
1. Switch the battery lock 1 to the unlocked
position.
2. Insert the battery pack into the battery compartment.2
Note: Depending on the battery option you ordered,
your battery may appear different from the figure.
3. Switch the battery lock 1 to the locked
position.
1
2
2
2. Connect the ac adapter to the computer’s power jack (at the
rear of the computer) in the order shown.
1
3
2
2

Turning on the system
1. Open the computer display.
Slide the latches 1 and open the display2. Then position
the display so that it is convenient for viewing.
2
1
1
2. Press the power switch.
3

Using the TrackPoint
The TrackPoint
®
is a unique device for moving the cursor on the
screen. You can perform all mouse operations with the TrackPoint. The
left and right click buttons function like the left and right click buttons
of a mouse.
To move the cursor, use the red-tipped pointer at the center of the
keyboard. Press gently with your left or right index finger in the
direction you want to move the cursor. To select and drag an object,
press and hold one of the click buttons with either thumb as required
by your software.
Click means to press the left click button once. Double-click means to
press the left click button twice within 1 second.
For more information about the TrackPoint, TrackPoint, press the
ThinkPad button to open Access ThinkPad, your on-board help
system.
Cursor
Center button
Left click button Right click button
Pointer
4

Using the volume control
You can adjust the sound level produced by the built-in speakers by using the following three buttons:
vVolume down
vVolume up:
vMute:
–If the sound is muted when you turn off the computer, it remains muted when you turn the computer on again.
–To turn on the sound, press the Volume up or Volume down button.
When you press one of these buttons, the volume indicator appears on the screen for a few seconds. For more details on volume
control, see the on-board help system, Access ThinkPad.
Setting up Windows
Your computer comes with a Microsoft
®
Windows operating system. After turning on your computer, follow the instructions on the
screen to set up the operating system. This procedure takes approximately 10 minutes, and your computer restarts several times.
5

Finding inf ormation with Access ThinkPad
Your computer features the unique ThinkPad Button.
Whenever you have a question about your computer, or wish to view
IBM web sites, simply press the ThinkPad button to open Access
ThinkPad.
Access ThinkPad is the comprehensive, on-board help and information
center for your computer. It travels with you, eliminating the need to
carry reference manuals.
Find information about your ThinkPad computer and its features by
using the Quick Search or clicking one of the topics shown. Click one
of the Internet buttons for direct access to help and support, tips from
other mobile users, and information about accessories, software, and
upgrades.
6

Service and support information
Getting help around the world
International Warranty Service (IWS) is available for customers
who are moving products or traveling to countries where their
product (as identified by the 4–digit machine type) is sold and
service delivery methods of the country providing the service will
be in effect. IBM reserves the right to change or modify its service
delivery methods by country at any time without notice. Service
procedures differ by country, and some service and parts may not
be available in all countries because of the laws of that particular
country. In some countries, fees may apply to service provided
on-site in remote locations.
To register, call one of the following IWS Offices:
Southeast Asia, Australia, New
Zealand, and Hong Kong:
61-2-9354-4171
Canada, Latin America, and the
U.S.:
1-800-497-7426
or 248-740-1215
Europe, Middle East, and Africa: 44-1475-893638
Japan, Korea, China (except
Hong Kong), and Taiwan:
81-46–273-7598
The IWS office will issue an International Warranty Service
Certificate, which you can use wherever IBM or IBM resellers sell
and service this product.
7
