IBM Security Hardware 򔻐򗗠򙳰
Disk Drive Assembly Replacement Instructions
This document helps you to complete the following tasks:
vRemove a failed disk drive and replace it with a new disk drive
vVerify that the new disk drive is working correctly
Important: Before you proceed with these instructions, review the IBM Systems Safety Notices provided in
the IBM Media Terms and Conditions CD that is included with your appliance model.
Note: The illustrations in this document might differ slightly from your appliance model.
Supported appliances
The following table lists the appliance models that are supported by the instructions in this document:
Replacing a disk drive assembly
Before you begin
You must have the applicable replacement disk drive assembly before you can remove and replace the
failed disk drive assembly.
Identifying the disk drive assembly
The front panel of the appliance contains the disk drive assembly, as highlighted in yellow in Figure 1.
Figure 1. Location of the disk drive assembly on the front of the appliance
Product Model IBM®Part Number
IBM Security Network Protection XGS 3100 97Y0977
XGS 4100 97Y0823
XGS 5100 97Y0612
IBM Security SiteProtector™System SP 4001 97Y1346

Procedure
Complete the following steps to replace a failed disk drive assembly:
1. Turn off the appliance by pressing the power button on the front of the appliance.
2. Unplug all of the power cords that are attached to the appliance.
3. Press the release button on the left of the disk drive assembly to release the assembly lock.
4. Pull the drive handle lever to the right to pull the disk drive assembly from the drive bay, as shown
in Figure 2.
5. Place the new disk drive assembly in the drive bay.
6. Push the disk drive assembly into the drive bay until the lever locks into place.
Figure 2. Removing the disk drive assembly from the drive bay
2

What to do next
Turn on the appliance and reimage the appliance.
Important: You must reimage the appliance after you replace the drive in the appliance. If you do not
reimage the appliance, the appliance might become inoperable.
Reference: The steps for reimaging an appliance are documented in the following guides:
vFor the IBM Security Access Manager appliance, see the Getting Started instructions on the IBM
Knowledge Center at http://www.ibm.com/support/knowledgecenter/SSPREK/welcome. To access
the Getting Started instructions for supported versions of the Access Manager appliance, select the
product of interest on the left navigation pane of the IBM Security Access Manager welcome page.
vFor the IBM Security Network Protection appliance, see the Getting Started instructions on the IBM
Knowledge Center at http://www.ibm.com/support/knowledgecenter/SSHLHV/welcome. To access
the Getting Started instructions for supported versions of the Network Protection appliance, select the
product of interest on the left navigation pane of the IBM Security Network Protection welcome page.
vFor the IBM Security SiteProtector System appliance, see the Getting Started instructions on the IBM
Knowledge Center at http://www.ibm.com/support/knowledgecenter/SSETBF/welcome. To access
the Getting Started instructions for supported versions of the SiteProtector System appliance, select the
product of interest on the left navigation pane of the IBM Security SiteProtector System welcome page.
