Chapter 1. BladeCenter S chassis power modules
A minimum of two power modules must be installed in power module bays 1 and
2 on the rear of the BladeCenter S chassis. Additional power modules, if installed,
are installed in power module bays 3 and 4.
© Copyright IBM Corp. 2007, 2013 1

Power modules
The BladeCenter S system supports up to four autoranging power modules that
are capable of supporting either 110 V ac or 220 V ac.
Power module
AC power LED
DC power LED
Fault LED
There are two types of power modules. These power modules are identical except
for the power cord connector; one power module has a C14 connector and the
other power module has a C20 connector. Both types of power modules can be
installed in the same chassis.
Table 1. Power modules used in the BladeCenter S system
Power module with C14 connector
C14 connector
Power module with C20 connector
C20 connector
Within the BladeCenter S chassis, all power supplies are combined into a single
power domain, which distributes power to each of the blade servers and modules
through the system midplane.
2BladeCenter S Types 7779 and 8886: Power Modules

You must install a minimum of two power modules. If you install only two power
modules, install them in power module bays 1 and 2 (the top and bottom power
module bays on the right as you face the rear of the BladeCenter S chassis).
Note: You must install all four power modules if you are using both disk storage
modules.
If you disengage or remove all devices from the front of the BladeCenter S chassis
(media tray, blade servers, and disk storage modules), the power modules will be
disabled.
Indicators and controls
There are three LEDs on each power module:
AC power
Lit (green). Power is being supplied to the power module.
DC power
Lit (green). Power is being supplied from the power module to the
BladeCenter S chassis midplane.
Fault Lit (amber). There is a fault with the power module.
Note: Before unplugging the AC power cord from the power module or
removing the power module from the BladeCenter S chassis, verify that the
capacity of the remaining power modules are sufficient to meet the
minimum power requirements for all components in the BladeCenter S
chassis. You can view power status and requirements through the
advanced management module.
For information on accessing and using the advanced management
module, see the Advanced Management Module User's Guide.
1. Verify that the power modules are properly connected to an AC power
source. All power modules in the BladeCenter S chassis must be
connected to the same power input voltage (either 110 V ac or 220 V
ac). Do not mix power input voltages.
2. Unplug the AC power cord from the power module and plug it in
again.
3. Reseat the power supply.
4. Swap the AC power cord with a power cord that is known to be
working.
5. Move the power module to another power module bay in the
BladeCenter S chassis.
Chapter 1. BladeCenter S chassis power modules 3

4BladeCenter S Types 7779 and 8886: Power Modules

Chapter 2. Installation guidelines
Before you remove or replace a component, read the following information.
vRead Safety and “Handling static-sensitive devices” on page 6. This information
will help you work safely.
vObserve good housekeeping in the area where you are working. Place removed
covers and other parts in a safe place.
vYou do not have to disconnect the BladeCenter S system from power to install or
replace any of the hot-swap modules. You must shut down the operating system
and turn off a hot-swap blade server before you remove it, but you do not have
to remove power from the BladeCenter S system itself.
vDo not attempt to lift an object that you think is too heavy for you. If you have
to lift a heavy object, observe the following precautions:
– Make sure that you stand safely without slipping.
– Distribute the weight of the object equally between your feet.
– Use a slow lifting force. Never move suddenly or twist when you lift a heavy
object.
– To avoid straining the muscles in your back, lift by standing or by pushing
up with your leg muscles.
vMake sure that you have an adequate number of properly grounded electrical
outlets for the BladeCenter S system.
vBack up all important data before you make changes to disk drives.
vHave a small flat-blade screwdriver available.
vOrange on a component or an orange label on or near a component indicates
that the component may be hot-swapped, which means that you can remove or
install the component while the BladeCenter S system is running. (Orange can
also indicate touch points on hot-swap components.) See the instructions for
removing or installing a specific hot-swap component for any additional
procedures that you might have to perform before you remove or install the
component.
vBlue on a component indicates touch points, where you can grip the component
to remove it from or install it in the BladeCenter S chassis, open or close a latch,
and so on.
System reliability guidelines
To help ensure proper system cooling and system reliability, make sure the
following requirements are met.
vEach of the module bays on the front and rear of the BladeCenter S chassis has
either a module or a module bay filler installed in it.
vEach of the blade bays on the front of the BladeCenter S chassis has either a
blade server or a blade bay filler installed in it.
vEach of the disk storage module bays has a disk storage module or disk storage
module filler installed in it. If a disk storage module is installed, each of the
drive bays has a hard disk drive or a hard disk drive bay filler installed in it.
vEach of the drive bays in a blade server storage expansion option has either a
hot-swap drive or a filler panel installed.
vYou have followed the cabling instructions that come with optional adapters.
© Copyright IBM Corp. 2007, 2013 5

vCables for the optional modules are routed correctly.
vA failed fan module is replaced as soon as possible.
Handling static-sensitive devices
Make sure that you read these guidelines before handing static-sensitive devices.
Attention: Static electricity can damage the BladeCenter S chassis and other
electronic devices. To avoid damage, keep static-sensitive devices in their
static-protective packages until you are ready to install them.
To reduce the possibility of electrostatic discharge, observe the following
precautions:
vLimit your movement. Movement can cause static electricity to build up around
you.
vThe use of a grounding system is recommended. For example, wear an
electrostatic-discharge wrist strap, if one is available.
vHandle the device carefully, holding it by its edges or its frame.
vDo not touch solder joints, pins, or exposed circuitry.
vDo not leave the device where others can handle and damage it.
vWhile the device is still in its static-protective package, touch it to an unpainted
metal part of the BladeCenter S chassis or rack for at least 2 seconds. This drains
static electricity from the package and from your body.
vRemove the device from its package and install it immediately without setting
down the device. If it is necessary to set down the device, put it back into its
static-protective package.
vTake additional care when you handle devices during cold weather. Heating
reduces indoor humidity and increases static electricity.
6BladeCenter S Types 7779 and 8886: Power Modules

Chapter 3. Installing a power module
You can install a power module while the BladeCenter S system is powered on. To
install it, open the release handle, slide the power module into the power module
bay, and close the release handle.
Notes:
vMake sure the power cord is not connected to the power module when installing
the power module in a BladeCenter S chassis.
vOn the rear of the power module, there is a plastic strain-relief tie that should
not be removed.
Power module
fillers
Power module 3
Power module 4
1. Open the release handle (rotate the handle down).
2. Slide the module into the power module bay until it stops.
3. Close the release handle (rotate the handle up).
4. Plug in the power cable.
5. Fasten the plastic retention tie.
© Copyright IBM Corp. 2007, 2013 7

8BladeCenter S Types 7779 and 8886: Power Modules

Chapter 4. Removing a power module
You can remove a power module while the BladeCenter S system is powered on.
To remove it, open the release handle and slide the power module out of the
power module bay.
Attention:
vTo maintain proper system cooling, do not operate the BladeCenter S system
without a power module or power module filler in each power module bay.
Install a power module or filler within one minute of the removal of a power
module.
vIf you are removing a functioning power module, make sure that power LEDs
on the remaining power modules are lit and the power management policy you
have chosen supports the removal of the power module. If not, shut down the
operating systems and turn off all of the blade servers, before you proceed. (See
the documentation that comes with the blade server for instructions for shutting
down the blade server operating system and turning off the blade server.)
Power module 3
Power module 4
Release handle
(open)
1. Disconnect the power cable.
2. Open the release handle (rotate the handle down).
3. Slide the power module out of the power module bay.
4. If you are instructed to return the power module, follow all packaging
instructions, and use any packaging materials for shipping that are supplied to
you.
© Copyright IBM Corp. 2007, 2013 9

10 BladeCenter S Types 7779 and 8886: Power Modules

Appendix A. Power cords
This section describes the power cords that are available for the C14 and C20
power modules.
Power cords - C14 power module
Several power cords are available for use with the C14 power module (CRU part
number 39Y7403), depending on the location in the world where the cord will be
used.
The following table lists the PDU power cord CRU part numbers.
Table 2. PDU power cords
CRU part
number Description
39M5508 2.0m, 13A/125-10A/250V, C13 to IEC 320-C14 Rack Power Cable
39M5509 2.8m, 13A/125-10A/250V, C13 to IEC 320-C14 Rack Power Cable
39M5510 4.3m, 13A/125-10A/250V, C13 to IEC 320-C14 Rack Power Cable
39M5392 2.8m, 15A/125-10A/250V, C13 to IEC 320-C20 Rack Power Cable
The following table lists the power cord CRU part numbers.
Table 3. Power cords
Country CRU part number Description
Argentina 39M5067 1.8m, 10A/220V, C13 to IRAM 2073
39M5068 2.8m, 10A/220V, C13 to IRAM 2073
39M5069 4.3m, 10A/220V, C13 to IRAM 2073
Australia / New
Zealand
39M5101 1.8m, 10A/230V, C13 to AS/NZS 3112
39M5102 2.8m, 10A/230V, C13 to AS/NZS 3112
39M5103 4.3m, 10A/230V, C13 to AS/NZS 3112
Brazil 39M5239 1.8m, 10A/220V, C13 to NBR 6147
39M5240 2.8m, 10A/220V, C13 to NBR 6147
39M5241 4.3m, 10A/220V, C13 to NBR 6147
China 39M5205 1.8m, 10A/220V, C13 to GB 2099.1
39M5206 2.8m, 10A/220V, C13 to GB 2099.1
39M5207 4.3m, 10A/220V, C13 to GB 2099.1
Denmark 39M5129 1.8m, 10A/230V, C13 to DK2-5a
39M5130 2.8m, 10A/230V, C13 to DK2-5a
39M5131 4.3m, 10A/230V, C13 to DK2-5a
Europe 39M5122 1.8m, 10A/230V, C13 to CEE7-VII
39M5123 2.8m, 10A/230V, C13 to CEE7-VII
39M5124 4.3m, 10A/230V, C13 to CEE7-VII
© Copyright IBM Corp. 2007, 2013 11

Table 3. Power cords (continued)
Country CRU part number Description
India 39M5225 1.8m, 10A/240V, C13 to IS 6538
39M5226 2.8m, 10A/240V, C13 to IS 6538
39M5227 4.3m, 10A/240V, C13 to IS 6538
Israel 39M5171 1.8m, 10A/230V, C13 to SI 32
39M5172 2.8m, 10A/230V, C13 to SI 32
39M5173 4.3m, 10A/230V, C13 to SI 32
Italy 39M5164 1.8m, 10A/230V, C13 to CEI 23-16
39M5165 2.8m, 10A/230V, C13 to CEI 23-16
39M5166 4.3m, 10A/230V, C13 to CEI 23-16
Japan 39M5185 1.8m, 12A/200V, C13 to JIS C-8303
39M5186 2.8m, 12A/200V, C13 to JIS C-8303
39M5187 4.3m, 12A/200V, C13 to JIS C-8303
39M5198 1.8m, 12A/100V, C13 to JIS C-8303
39M5199 2.8m, 12A/100V, C13 to JIS C-8303
39M5200 4.3m, 12A/100V, C13 to JIS C-8303
Korea 39M5218 1.8m, 12A/250V, C13 to KSC 8305
39M5219 2.8m, 12A/250V, C13 to KSC 8305
39M5220 4.3m, 12A/250V, C13 to KSC 8305
South Africa 39M5143 1.8m, 10A/230V, C13 to SABS 164
39M5144 2.8m, 10A/230V, C13 to SABS 164
39M5145 4.3m, 10A/230V, C13 to SABS 164
Switzerland 39M5157 1.8m, 10A/230V, C13 to SEV 1011
39M5158 2.8m, 10A/230V, C13 to SEV 1011
39M5159 4.3m, 10A/230V, C13 to SEV 1011
Taiwan 39M5253 1.8m, 10A/250V, C13 to CNS 10917-3
39M5254 2.8m, 10A/250V, C13 to CNS 10917-3
39M5255 4,3m, 10A/250V, C13 to CNS 10917-3
39M5462 1.8m, 13A/125V, C13 to CNS 10917-3
39M5463 2.8m, 13A/125V, C13 to CNS 10917-3
39M5464 4.3m, 13A/125V, C13 to CNS 10917-3
United Kingdom 39M5150 1.8m, 10A/230V, C13 to BS 1363/A
39M5151 2.8m, 10A/230V, C13 to BS 1363/A
39M5152 4.3m, 10A/230V, C13 to BS 1363/A
United States 39M5094 1.8m, 10A/208V, C13 to NEMA 6-15P
39M5095 2.8m, 10A/208V, C13 to NEMA 6-15P
39M5096 4.3m, 10A/208V, C13 to NEMA 6-15P
39M5511 1.8m, 13A/120V, C13 to NEMA 5-15P
39M5512 2.8m, 13A/120V, C13 to NEMA 5-15P
39M5513 4.3m, 13A/120V, C13 to NEMA 5-15P
12 BladeCenter S Types 7779 and 8886: Power Modules

Power cords - C20 power module
Several power cords are available for use with the C20 power module (CRU part
number 39Y7367), depending on the location in the world where the cord will be
used.
The following table lists the PDU power cord CRU part numbers.
Table 4. PDU power cords
CRU part
number Description
39M5388 2.0m, 16A/100-250V, C19 to IEC 320-C20 Rack Power Cable
39M5389 2.5m, 16A/100-240V, C19 to IEC 320-C20 Rack Power Cable
The following table lists the power cord CRU part numbers.
Table 5. Power cords
Country CRU part number Description
Argentina 39M5341 1.8m, 16A/220V, C19 to IRAM 2073
39M5342 2.5m, 16A/220V, C19 to IRAM 2073
39M5343 4.3m, 16A/220V, C19 to IRAM 2073
Australia / New
Zealand
39M5329 1.8m, 15A/230V, C19 to AS/NZS 3112
39M5330 2.5m, 15A/230V, C19 to AS/NZS 3112
39M5331 4.3m, 15A/230V, C19 to AS/NZS 3112
Brazil 39M5349 1.8m, 15A/125V, C19 to NBR 6147
39M5350 2.5m, 15A/125V, C19 to NBR 6147
39M5351 4.3m, 15A/125V, C19 to NBR 6147
39M5357 1.8m, 16A/220V, C19 to NBR 6147
39M5358 2.5m, 16A/220V, C19 to NBR 6147
39M5359 4.3m, 16A/220V, C19 to NBR 6147
China 39M5353 1.8m, 16A/220V, C19 to GB 2099.1
39M5354 2.5m, 16A/220V, C19 to GB 2099.1
39M5355 4.3m, 16A/220V, C19 to GB 2099.1
Denmark 39M5321 1.8m, 16A/230V, C19 to IEC 309-P+N+G
39M5322 2.5m, 16A/230V, C19 to IEC 309-P+N+G
39M5323 4.3m, 16A/230V, C19 to IEC 309-P+N+G
Europe 39M5281 1.8m, 16A/230V, C19 to CEE7-VII
39M5282 2.5m, 16A/230V, C19 to CEE7-VII
39M5283 4.3m, 16A/230V, C19 to CEE7-VII
India 39M5444 1.8m, 16A/240V, C19 to IS 6538
39M5396 2.5m, 16A/240V, C19 to IS 6538
39M5397 4.3m, 16A/240V, C19 to IS 6538
Israel 39M5309 1.8m, 16A/230V, C19 to SI 32
39M5310 2.5m, 16A/230V, C19 to SI 32
39M5311 4.3m, 16A/230V, C19 to SI 32
Appendix A. Power cords 13

Table 5. Power cords (continued)
Country CRU part number Description
Italy 39M5297 1.8m, 16A/230V, C19 to CEI 23-16
39M5298 2.5m, 16A/230V, C19 to CEI 23-16
39M5299 4.3m, 16A/230V, C19 to CEI 23-16
Japan 39M5333 1.8m, 15A/200V, C19 to JIS C-8303
39M5334 2.5m, 15A/200V, C19 to JIS C-8303
39M5335 4.3m, 15A/200V, C19 to JIS C-8303
39M5337 1.8m, 15A/100V, C19 to JIS C-8303
39M5338 2.5m, 15A/100V, C19 to JIS C-8303
39M5339 4.3m, 15A/100V, C19 to JIS C-8303
Korea 39M5345 1.8m, 15A/250V, C19 to KSC 8305
39M5346 2.5m, 15A/250V, C19 to KSC 8305
39M5347 2.5m, 15A/250V, C19 to KSC 8305
South Africa 39M5289 4.3m, 15A/250V, C19 to KSC 8305
39M5290 2.5m, 16A/230V, C19 to SABS 164
39M5291 4.3m, 16A/230V, C19 to SABS 164
Switzerland 39M5440 1.8m, 16A/230V, C19 to SEV 1011
39M5441 2.5m, 16A/230V, C19 to SEV 1011
39M5442 4.3m, 16A/230V, C19 to SEV 1011
Taiwan 39M5361 1.8m, 16A/125V, C19 to CNS 10917-3
39M5362 2.5m, 16A/125V, C19 to CNS 10917-3
39M5363 4.3m, 16A/125V, C19 to CNS 10917-3
39M5365 1.8m, 16A/250V, C19 to CNS 10917-3
39M5366 2.5m, 16A/250V, C19 to CNS 10917-3
39M5367 4.3m, 16A/250V, C19 to CNS 10917-3
United Kingdom 39M5293 1.8m, 13A/230V, C19 to BS 1363/A
39M5294 2.5m, 13A/230V, C19 to BS 1363/A
39M5295 4.3m, 13A/230V, C19 to BS 1363/A
United States 39M5257 1.8m, 15A/120V, C19 to NEMA 5-15P
39M5258 2.5m, 15A/120V, C19 to NEMA 5-15P
39M5259 4.3m, 15A/120V, C19 to NEMA 5-15P
39M5261 1.8m, 15A/208V, C19 to NEMA 6-15P
39M5262 2.5m, 15A/208V, C19 to NEMA 6-15P
39M5263 4.3m, 15A/208V, C19 to NEMA 6-15P
39M5270 2.5m, 16A/120V, C19 to NEMA L5-20P
39M5271 4.3m, 16A/120V, C19 to NEMA L5-20P
39M5278 2.5m, 16A/208V, C19 to NEMA L6-20P
39M5279 4.3m, 16A/208V, C19 to NEMA L6-20P
14 BladeCenter S Types 7779 and 8886: Power Modules
