Features and specifications
The following table provides a summary of the features and specifications for your
server.
Microprocessor:
vIntel
®
Itanium
®
2 900 MHz or
higher, depending on server model
v1.5 MB (minimum) Level-3 cache
v200 MHz front-side bus (FSB), at
two data transfers per cycle,
yielding a 400 MHz system bus
(minimum)
vSupport for up to four
microprocessors
vXceL4
™
Server Accelerator Cache:
64 MB
Active Memory
™
:
vMinimum: 1 GB
vMaximum: 40 GB
vType: 2-way interleaved PC2100,
ECC DDR SDRAM, registered
DIMMs only
vSupports 512 MB, 1 GB, and 2 GB
dual inline memory modules
(DIMMs)
Drives standard:
DVD/CD-RW: IDE
Expansion bays:
vTwo removable media bays (one
DVD/CD-RW preinstalled)
vSupports up to two internal
Ultra320 SCSI hard disk drives
Active
™
PCI-X expansion slots:
Six 64-bit Active PCI-X expansion
slots:
vTwo 66 MHz PCI-X slots
vTwo 100 MHZ PCI-X slots
vTwo 133 MHZ PCI-X slots
Cooling:
Four hot-swap fans
vTwo 150 mm x 51 mm fans
vTwo 150 mm x 38 mm fans
Acoustical noise emissions:
vDeclared sound power, idle: 6.5
bels
vDeclared sound power, operating:
6.5 bels
vBystander sound pressure, idle: 49
dBa
vBystander sound pressure,
operating: 49 dBa
Power supply:
Two power supplies: 550 watts at
100-127 V ac or 1050 watts at
200-240 V ac (hot-swappable and
redundant at 200-240 V ac only)
Video:
vIntegrated ATI RageXL video
vPCI bus interface
vCompatible with SVGA
v8 MB SDRAM video memory
Size (4 U):
vHeight: 17.8 cm (7 inches, 4 U)
vDepth: 69.85 cm (27.5 inches)
vWidth: 48.3 cm (19 inches)
vMaximum weight: 38.6 kg (85 lb),
depending on your configuration
Integrated functions:
vBroadcom 5704 10/100/1000 dual
port Ethernet controller
vLight Path Diagnostics
™
vOne external and one internal
Ultra320 SCSI port (dual-channel
integrated controller with RAID
capabilities)
vRemote Supervisor Adapter
(service processor)
– ASM interconnect
(peer-to-peer) port
– Ethernet port
– Serial port
vIDE controller
vRXE Management Port
vRXE Expansion Ports
vThree USB ports
vSCSI ports
vSerial port
vWake on LAN
®
Environment:
vAir temperature:
– Server on: 10° to 35°C (50.0°
to 95.0°F). Altitude: 0 to 914 m
(2998.7 ft)
– Server on: 10° to 32°C (50.0°
to 89.6°F). Altitude: 0 to 2133
m (6998.0 ft)
– Server off: -40° to 60°C (-104°
to 140°F). Maximum altitude:
2133 m (6998.0 ft)
vHumidity:
– Server on: 8% to 80%
– Server off: 5% to 100%
Heat output:
Approximate heat output in British
thermal units (Btu) per hour
vMinimum configuration: 854 Btu (250
watts)
vMaximum configuration: 2646 Btu
(775 watts)
Electrical input:
vSine-wave input (50-60 Hz) required
vInput voltage low range:
– Minimum: 100 V ac
– Maximum: 127 V ac
vInput voltage high range:
– Minimum: 200 V ac
– Maximum: 240 V ac
vInput kilovolt-amperes (kVA)
approximately:
– Minimum: 0.250 kVA
– Maximum: 1.3 kVA
Notes:
1. Power consumption and heat
output vary depending on the
number and type of optional
features installed and the
power-management optional
features in use.
2. These levels were measured in
controlled acoustical
environments according to the
procedures specified by the
American National Standards
Institute (ANSI) S12.10 and ISO
7779 and are reported in
accordance with ISO 9296.
Actual sound-pressure levels in a
given location might exceed the
average values stated because
of room reflections and other
nearby noise sources. The
declared sound-power levels
indicate an upper limit, below
which a large number of
computers will operate.
4xSeries 450: Installation Guide
