N2225 and N2226 SAS/SATA HBAs for IBM System x
User’s Guide
IBM P/N: 00FH247

First Edition (April 2014)
© Copyright IBM Corporation 2014.
US Government Users Restricted Rights -- Use, duplication or disclosure restricted by GSA ADP Schedule Contract with
IBM Corp.
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014

- 1 -
Table of Contents
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Table of Contents
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
N2225 and N2226 SAS/SATA HBAs for IBM System x
Hardware User’s Guide . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2 HBA Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.1 N2225 HBA Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 N2226 HBA Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Functional Descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 PCI Express Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 SAS Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Operating System Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5 HBA Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.1 Flash. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.2 LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
5.3 Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.4 Physical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
5.5 Electrical Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5.6 Thermal and Atmospheric Limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6 HBAs Certifications and Safety Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Hardware Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8 Replaceable HBA Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Appendix A: Getting Help and Technical Assistance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
A.1 Before You Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
A.2 Using the Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
A.3 Getting Help and Information from the World Wide Web . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
A.4 Software Service and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
A.5 Hardware Service and Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
A.6 IBM Taiwan Product Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Appendix B: Notices
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
B.1 Trademarks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
B.2 Important Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
B.3 Documentation Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
B.4 Electronic Emission Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

- 2 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Safety
Safety
Bu ürünü kurmadan önce güvenlik bilgilerini okuyun.
Youq mwngz yungh canjbinj neix gaxgonq, itdingh aeu doeg aen
canjbinj soengq cungj vahgangj ancien siusik.

- 3 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Safety

- 4 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Safety

- 5 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Safety
Statement 28:
CAUTION:
The battery is a lithium ion battery. To avoid possible explosion, do not burn the
battery. Exchange it only with the approved part. Recycle or discard the battery
as instructed by local regulations.

- 6 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
Overview
N2225 and N2226 SAS/SATA HBAs for IBM System x
Hardware User’s Guide
1Overview
The N2225 and N2226 SAS/SATA HBAs for IBM® System x® are Serial Attached SCSI (SAS) host bus adapters (HBAs) that
provide high-performance external storage connectivity for servers and workstations. The N2225 HBA provides eight
lanes of 12Gb/s SAS connectivity and is matched with eight lanes of PCIe 3.0 8Gb/s performance. The N2226 HBA
provides sixteen lanes of 12Gb/s SAS connectivity and is matched with eight lanes of PCIe 3.0 8Gb/s performance.
These HBAs are based on the Fusion-MPT™-architected LSI SAS 3008 controller that integrates the latest
enhancements in PCIe 3.0 technology and 12Gb/s SAS technology.
The HBAs have onboard Flash memory for the firmware.
2HBAFeatures
The following sections list the HBAs features.
2.1 N2225 HBA Features
Implements one LSI SAS 3008 eight-port 12Gb/s SAS to PCIe 3.0 controller
Supports eight-lane, full-duplex PCIe 3.0 performance
Supports eight external 12Gb/s SATA+SAS ports
Supports SATA link rates of 3Gb/s and 6Gb/s
Supports SAS link rates of 3Gb/s, 6Gb/s, and 12Gb/s
Provides two x4 external mini-SAS HD connectors (SFF-8644)
Supports passive copper cables
Supports up to 1024 SATA or SAS end devices
Offered with a full-height bracket and a low-profile vented bracket
Provides one heartbeat LED
2.2 N2226 HBA Features
Implements two LSI SAS 3008 eight-port 12Gb/s SAS to PCIe 3.0 controllers
Supports eight-lane, full-duplex PCIe 3.0 performance
Supports sixteen external 12Gb/s SATA+SAS ports
Supports SATA link rates of 3Gb/s and 6Gb/s
Supports SAS link rates of 3Gb/s, 6Gb/s, and 12Gb/s
Provides four x4 external mini-SAS HD connectors (SFF-8644)
Supports passive copper cables
Supports up to 1024 SATA or SAS end devices
Offered with a full-height bracket
Provides two heartbeat LEDs

- 7 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
Functional Descriptions
3 Functional Descriptions
3.1 PCI Express Interface
PCIe is a high-speed standard local bus for point-to-point interfacing of I/O components to the processor and the
memory subsystems in high-end computers and servers. The N2225 HBA uses one LSI SAS 3008 controller chip and
one PCI Express switch to provide high-bandwidth interconnection ability. The N2226 HBA uses two LSI SAS 3008
controller chips and one PCI Express switch to provide high-bandwidth interconnection ability.
Both the HBAs supports eight-lane PCIe performance up to 64Gb/s single direction and 128Gb/s dual direction.
3.2 SAS Interface
The LSI SAS 3008 controller chip contains the SATA+SAS functionality for the HBAs. The following table shows the LSI
SAS 12Gb/s SAS performance.
4 Operating System Support
To check for the latest list of supported operating systems and to download the device drivers for those operating
systems, see http://www.ibm.com/systems/support/.
5HBACharacteristics
5.1 Flash
The N2225 HBA provides one 4-M × 16-bit Flash ROMs to store the firmware and the BIOS. The N2226 HBA provides
two 4-M × 16-bit Flash ROMs to store the firmware and the BIOS.
5.2 LED
The N2225 HBA Heartbeat LED, CR1, blinks green to indicate the HBA is capable of general activity. The N2226 HBA
Heartbeat LEDs, CR3 and CR4, blink green to indicate the HBA is capable of general activity.
Half Duplex Full Duplex
Narrow port (one lane), 1200 MB/s Narrow port (one lane), 2400 MB/s
Wide port (four lanes), 4800 MB/s Wide port (four lanes), 9600 MB/s

- 8 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
HBA Characteristics
5.3 Connectors
PCIe Connector (EC1). The N2226 and N2225 HBAs support a x8 interface. The PCIe host interface connection is
through the edge connector, EC1, which provides connections on both the top (EC1 B) and bottom (EC1 A) of the
board. The signal definitions and pin numbers conform to the PCIe specification.
SATA+SAS Connectors
—N2225 SATA+SAS (J6)– The N2225 HBA supports SATA and SAS connectors through connectors that are
SFF-8644 mini-SAS HD, external connectors. See Figure 1for the connector locations.
—N2226 SATA+SAS (J6, J7) – The N2226 HBA supports SATA and SAS connectors through connectors that are
SFF-8644 mini-SAS HD, external connectors. See Figure 2for the connector locations.
Auxiliary Power Connector (J5). The N2226 HBA provides a 6-pin PCIe power connector.
5.4 Physical Characteristics
5.4.1 N2225 HBA Physical Characteristics
The N2225 SAS HBA is a 6.6-in. × 2.7-in., low-profile board. The component height on the top and bottom of the HBA is
in accordance with the PCIe specification. The following figure shows the HBA board layout.
Figure 1 N2225 SAS/SATA HBA Board Layout
EC1 – PCIe x8 board edge connector
CR1 – Heartbeat LED
J6 – SFF-8644 mini-SAS HD, external, right-angle connectors
5.4.2 N2226 HBA Physical Characteristics
The N2226 SAS HBA is a 6.6-in. × 4.4-in board. The component height on the top and bottom of the HBA is in
accordance with the PCIe specification. The following figure shows the HBA board layout.
/6,6$6
(& B
&5
3RUW
-
3RUW

- 9 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
HBA Characteristics
Figure 2 N2226 SAS/SATA HBA Board Layout
EC1 – PCIe x8 board edge connector
CR3, CR4 – Heartbeat LEDs
J5 – Auxiliary power connector
J6, J7 – SFF-8644 mini-SAS HD, external, right-angle connectors
5.5 Electrical Characteristics
5.5.1 N2225 HBA Electrical Characteristics
The power requirements for the N2225 HBA under normal operation are as follows:
PCIe 12.0 V = 1.07 A
Power values:
—Nominal = 14.5 W
—Worst case = 22.5 W
5.5.2 N2226 HBA Electrical Characteristics
The power requirements for the N2226 HBA under normal operation are as follows:
PCIe 12.0 V = 2.35 A
PCIe 3.3 V = 0.13 A
Power values:
—Nominal = 28.6 W
—Worst case = 35.4 W
5.6 Thermal and Atmospheric Limits
The atmospheric limits for the HBAs are as follows:
Temperature range: 0 °C to 55 °C (32 °F to 131 °F) (dry bulb)
Relative humidity range: 5% to 90% noncondensing
Maximum dew point temperature: 32 °C (89.6 °F)
Minimum airflow
—N2225 HBA:
(& B
3RUW
-
3RUW
3RUW
-
3RUW
-
/6,6$6
/6,6$6
&5
&5

- 10 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
HBAs Certifications and Safety Characteristics
200 linear feet per minute
—N2226 HBA:
220 LFPM at 35 °C inlet temperature
270 LFPM at 45 °C inlet temperature
350 LFPM at 55 °C inlet temperature
The following limits define the storage and transit environment for the HBAs:
Temperature range: –45 °C to +105 °C (–49 °F to +221 °F) (dry bulb)
Relative humidity range: 5% to 90% noncondensing
6 HBAs Certifications and Safety Characteristics
The HBAs meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is marked with the
supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCIe bus slot,
all voltages are less than the SELV 42.4-V limit.
The design and implementation of the HBAs minimize electromagnetic emissions, susceptibility to radio frequency
energy, and the effects of electrostatic discharge.
The HBAs meet the following integrated electromagnetic interference (EMI) compliance labels:
CE mark
CISPR Class B
C-Tick mark
Canadian Compliance Statement
FCC Class B, marked with the FCC Self-Certification logo
Japan VCCI
Korean KCC
Taiwan BSMI
The HBAs meet the following environmental directives:
RoHS
WEEE

- 11 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
Hardware Installation Instructions
7 Hardware Installation Instructions
To install the HBAs, follow these steps:
1. Unpack the HBA and inspect if for damage.If it appears damaged, or if any of the following items are missing,
contact your place of purchase. The HBA is shipped with the following items:
A CD containing an electronic version of this User’s Guide and other related documentation.
IBM Warranty Information
ATTENTION Make a backup of your data before changing your system configuration to avoid the risk of
data loss.

- 12 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
Hardware Installation Instructions
2. Prepare the computer. Turn off the computer, and disconnect the power cord from the rear of the power supply.
3. Remove the cover from the chassis.
4. Check the mounting bracket on the HBA (system-dependent). If required for your system, replace the
full-height mounting bracket that ships on the HBA with the low-profile bracket supplied.
5. Insert the HBA into an available PCIe slot.
a. For N2225 ONLY. Locate an empty x8 PCIe slot. Remove the blank bracket panel on the rear of the computer
that aligns with the empty PCIe slot. Save this bracket screw, if applicable. Align the HBA to a PCIe slot. Press
down gently, but firmly, to seat the HBA correctly in the slot. The following figures show how to insert the
HBA into a PCIe slot.
Figure 3 Install an N2225 HBA in a PCIe Slot
a. For N2226 ONLY. Locate an empty x8 PCIe slot. The N2226 is a high power HBA and must be installed in a
75W slot, or an external power connector cable must be installed from the N2226 to the server. Remove the
blank bracket panel on the rear of the computer that aligns with the empty PCIe slot. Save this bracket screw,
if applicable. Align the HBA to a PCIe slot. Press down gently, but firmly, to seat the HBA correctly in the slot.
The following figures show how to insert the HBA into a PCIe slot.
CAUTION Disconnect the computer from the power supply and from any networks to which you will
install the HBA, or you risk damaging the system or experiencing electrical shock.
NOTE The shape, size, and locations of the components on your HBAs and its bracket might vary from this
illustration. The HBAs require a x8 PCIe slot.
NOTE The shape, size, and locations of the components on your HBAs and its bracket might vary from this
illustration. The HBAs require a x8 PCIe slot.
B
(GJHRI+RVW%RDUG
%LW6ORWV
92QO\
3&,([SUHVV
[6ORW
%LW6ORW
92QO\
%UDFNHW
6FUHZ
3UHVV
+HUH
3UHVV
+HUH
7R'ULYH
(QFORVXUHV
0LQL6$6+'
([WHUQDO
&RQQHFWRUV

- 13 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
N2225 and N2226 SAS/SATA HBAs for IBM System x Hardware User’s Guide
Replaceable HBA Components
Figure 4 Install an N2226 HBA in a PCIe Slot
6. Secure the HBA bracket to the system’s chassis. Install the bracket screw, if applicable, or engage the system
retention mechanism to secure the HBA to the system’s chassis.
7. Replace the cover of the chassis.
8. Connect SAS cables between the HBA and the SAS enclosure that contains SATA or SAS devices. The N2225
HBA has two, SFF-8644, external x4 mini-SAS HD connectors. The N2226 HBA has four SFF-8644, external x4
mini-SAS HD connectors. Use a cable with an external mini-SAS HD connector (SFF-8644) on one end (to connect
to the HBA) and the appropriate connector to attach to the enclosure that contains SAS or SATA devices on the
other end.
9. Replace the cover and any power cords, and power up the system. Replace the chassis’s cover, reconnect any
power cords, and reconnect any network cables. Turn on the power.
The hardware installation of your SAS HBAs is complete.
8 Replaceable HBA Components
The IBM field replaceable unit (FRU) part number for the N2225 HBA is 00AE914.
The IBM field replaceable unit (FRU) part number for the N2226 HBA is 00AE918.
B
(GJHRI+RVW%RDUG
3&,([SUHVV[6ORW
%UDFNHW
6FUHZ
3UHVV
+HUH
3UHVV
+HUH
7R'ULYH
(QFORVXUHV
0LQL6$6+'
([WHUQDO
&RQQHFWRUV

- 14 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Appendix A: Getting Help and Technical Assistance
Before You Call
Appendix A: Getting Help and Technical Assistance
A.1 Before You Call
A.2 Using the Documentation

- 15 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Appendix A: Getting Help and Technical Assistance
Getting Help and Information from the World Wide Web
A.3 Getting Help and Information from the World Wide Web
A.4 Software Service and Support
A.5 Hardware Service and Support
A.6 IBM Taiwan Product Service

- 16 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Appendix B: Notices
Appendix B: Notices

- 17 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Appendix B: Notices
Trademarks
B.1 Trademarks
B.2 Important Notes
IBM, the IBM logo, and ibm.com are trademarks of International
Business Machines Corp., registered in many jurisdictions worldwide.
Other product and service names might be trademarks of IBM or other
companies. A current list of IBM trademarks is available on the web at
"Copyright and trademark information"
at http://www.ibm.com/legal/copytrade.shtml
Adobe and PostScript are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
Cell Broadband Engine is a trademark of Sony Computer Entertainment, Inc., in the
United States, other countries, or both and is used under license
therefrom.
Intel, Intel Xeon, Itanium, and Pentium are trademarks
or registered trademarks of Intel Corporation or its subsidiaries
in the United States and other countries.
Java and all Java-based trademarks and logos are trademarks or registered
trademarks of Oracle and/or its affiliates.
Linux is a registered trademark of Linus
Torvalds in the United States, other countries, or both.
Microsoft, Windows, and Windows NT are trademarks of Microsoft Corporation in
the United States, other countries, or both.
UNIX is a registered trademark of The Open Group in the United States and other countries.
This product is not intended to be connected directly or indirectly by any means
whatsoever to interfaces of public telecommunications networks, nor is it intended
to be used in a public services network.

- 18 -
N2225 and N2226 SAS/SATA HBAs for IBM System x User’s Guide
April 2014
Appendix B: Notices
Documentation Format
B.3 Documentation Format
B.4 Electronic Emission Notices
