ABOUT HM-133S (for IC-2100 series)
w
e
r
q
!1
y
u
o
i
Mic element
!0
t
Push the key to accessible the first function of keys.
Push the key after FUNCTION SWITCH (!0)to accessible
the second function of keys.
Push the key after DTMF-S (o) to accessible the third
function of keys.
Second Function
Third Function
First Function
qKEYPAD
Push to accessible the first function of keys.
Used for controlling the transceiver, transmitting a DTMF
signals, etc. See back page for function details.
wACTIVITY INDICATOR
Lights red while any key is pushed (except [FUNC] or
[DTMF-S].
Lights red while transmitting.
Lights green while the one-touch PTT function is in use.
eUP/DOWN SWITCHES
➥ Push either switch to change the operating frequency,
memory channel, set mode contents, etc. (pgs. 15, 26)
➥ Push either switch for 1 sec. to start scanning. (p. 37)
rPTT SWITCH
➥ Push for 1 sec. to transmit; release to receive.
➥ Toggles between transmitting and receiving while the
one-touch PTT function is in use. (p. 20)
tVFO/LOCK SWITCH
➥ Push to select VFO mode.
➥Push for 1 sec. to toggle the lock function ON and OFF.
(p. 14)
yMEMORY/CALL SWITCH
➥ Push to select memory mode. (p. 26)
➥ Push for 1 sec. to select call channel. (p. 32)
The supplied microphone HM-133S is redesigned from the HM-98S. The functions
of HM-133S are instructed in this sheet.
Please refer to following information.
uNULL SWITCH [B]
No function.
iFUNCTION SWITCHES (p. 57)
Assign your desired key function from the front panel
switches.
• Default settings are [LOW] for [F-1] ([DUP] when pushed and
held) and [TONE] for [F-2] ([T-SCAN] when pushed and held).
oDTMF MEMORY SELECT SWITCH [DTMF-S]
(pgs. 22, 44, 45)
Push to accessible the third function of keys.
Turns the DTMF encoder ON and OFF.
• When DTMF encoder is activated, function indicator lights green.
• See back page for function details.
!0 FUNCTION SWITCH [FUNC]
Push to accessible the second function of keys.
• Push again to cancel it.
• When accessible the secondary function, function indicator lights
orange.
• See back page for function details.
!1 FUNCTION INDICATOR
➥ Lights orange while [FUNC] is activated—indicates the
second function of switches can be accessed.
➥ Lights green when [DTMF-S] is activated—DTMF sig-
nals can be transmitted with the keypad.
* The number in ( ) indicates the instruction’s page number.

KEY FUNCTION SECONDARY FUNCTION ( +key) OTHER FUNCTIONS
Toggles between opening and closing the
squelch.
Starts and stops scanning. (p. 37)
Starts and stops priority watch. (p. 42)
Selects high output power. (p. 19)
Selects mid output power. (p. 19)
Selects low output power. (p. 19)
Selects –duplex. (p. 21)
Selects +duplex. (p. 21)
Selects simplex. (p. 21)
No primary function.
• Clears a digit before entry. (p. 17)
• Cancels the scan, priority watch or DTMF
memory function. (pgs. 16, 37, 43)
Enters set mode and advances the set mode
selection.
• Sets the keypad for numeral input. (p. 17)
• Decreases the set mode selection order
after entering set mode.
No primary function.
No primary function.
No primary function.
No secondary function.
No secondary function.
Turns the one-touch PTT function ON and
OFF. (p. 20)
No secondary function.
No secondary function.
Turns the DTMF memory encoder function
ON. (p. 44)
Turns the subaudible tone encoder ON.
(p. 21)
Turns the pocket beep function ON.
(p. 46)
Turns the tone squelch function ON.
(p. 46)
While being pushed, transmits a 1750 Hz
tone. (p. 22)
• Writes the VFO contents into the memory
channel or call channel. (pg. 29)
• Advances the memory channel number
when continuously pushed after program-
ming is completed. (p. 28)
DTMF memory OFF.
Turns the subaudible tone encoder, pocket
beep or tone squelch OFF. (pgs. 21, 46, 47)
Mutes the audio. (p. 18)
• Mute function is released when any operation is
performed.
Locks the digit keys on the keypad (including
the A–D, # and Mkeys). (p. 14)
Sends a 1750 Hz tone signal for 0.5 sec.
(p. 22)
After is pushed:
Transmit the appropriate
DTMF code.
(pgs. 22, 45)
Push [0] to [9], [A] to [D]
to transmit the DTMF
memory contents when
the DTMF memory
encoder is activated.
(p. 44)
After is pushed:
Transmit the appropriate
DTMF code. (p. 45)
■Microphone keypad—q
* The number in ( ) indicates the instruction’s page number.
[A] to [D] to transmit the
DTMF memory (p. 44)
A-6146D-1EX
