Icom HM151 User manual
SERVICE
MANUAL
HAND MICROPHONE
S-14526XZ-C1-q
Dec. 2009
INTRODUCTION
This service manual describes the latest service information
for the HM-151 HAND MICROPHONE, at the time of
publication.
ORDERING PARTS
Be sure to include the following four points when ordering
replacement parts:
1. 10-digit Icom part number
2. Component name and informations
3. Equipment model name and unit name
4. Quantity required
<SAMPLE ORDER>
8810009610 Screw FH M2.6 ×6 ZK HM-151
Top cover
10 pieces
Addresses are provided on the inside back cover for your
convenience.
To upgrade quality, all electrical or mechanical parts and internal
circuits are subject to change without notice or obligation.
MODEL NAME VERSION
HM-151
[GEN]
[GEN-02]
[GEN-01]
[EXP]
1. Make sure the problem is internal before disassembling
the speaker microphone.
2. DO NOT open the speaker microphone until the
transceiver is disconnected from its power source.
3. DO NOT force any of the variable components. Turn
them slowly and smoothly.
4. DO NOT short any circuits or electronic parts. An
insulated tuning tool MUST be used for all adjustments.
5. DO NOT keep power ON for a long time when the
speaker microphone is defective.
REPAIR NOTES
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia and/or other countries.
TABLE OF CONTENTS
SECTION 1 PARTS LIST
SECTION 2 MECHANICAL PARTS
SECTION 3 BOARD LAYOUTS
SECTION 4 CIRCUIT DIAGRAMS
1 - 1
SECTION 1
.
PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN UNIT] (For [GEN], [GEN-1])
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
IC1 1140011491 S.IC UPD789071MC-041-5A4-E1-A B 51.1/24.5
IC3 1110006310 S.IC BD5245G-TR B 67.3/34.8
Q1 1530001941 S.TRA 2SC2712-BL(TE85L,F) B 26.1/11
Q2 1590000680 S.TRA DTC114EUA T106 B 21.6/34.8
Q3 1590001330 S.TRA DTA114EUA T106 B 24.7/34.8
Q5 1510000771 S.TRA 2SA1586-GR(TE85L,F) B 54.8/37.8
D1 1790000950 S.ZEN MA8056-M(TX) B 23.1/17
D3 1750000940 S.DIO ISS400 TE61 B 64.7/23.2
D4 1750000940 S.DIO ISS400 TE61 B 64.7/29.2
D6 1750000940 S.DIO ISS400 TE61 B 58.7/20.8
D7 1750000940 S.DIO ISS400 TE61 B 42.8/16.7
D9 1750000940 S.DIO ISS400 TE61 B 34.1/16.3
D10 1750000940 S.DIO ISS400 TE61 B 34.9/17.8
D11 1750000940 S.DIO ISS400 TE61 B 38.8/14.5
D12 1750000940 S.DIO ISS400 TE61 B 55/34.3
D16 1730002280 S.ZEN MA8091-M(TX) B 55.2/14.5
D17 1730002280 S.ZEN MA8091-M(TX) B 48.8/14.5
D18 1730002280 S.ZEN MA8091-M(TX) B 13.1/13.7
X1 6060000860 S.CER PBRC4.91HR30X B 42.6/22.3
L1 6200005051 S.COI NLV25T-330J B 12.3/29
L2 6200005011 S.COI NLV25T-100J B 11/13.9
R2 7030000400 S.RES MCR10EZHJ 1.5K (152) B 24.2/8.3
R3 7030000400 S.RES MCR10EZHJ 1.5K (152) B 41.9/8.3
R4 7030000400 S.RES MCR10EZHJ 1.5K (152) B 57.3/8.2
R5 7030003400 S.RES ERJ3GEYJ 471 V (470) B 28.6/11.2
R6 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 26.8/34.7
R7 7030003620 S.RES ERJ3GEYJ 333 V (33K) B 23.3/36.8
R8 7030003550 S.RES ERJ3GEYJ 822 V (8.2K) B 19.1/33.7
R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 52.3/38.7
R12 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 57/35
R13 7030003490 S.RES ERJ3GEYJ 272 V (2.7K) B 53/35
R14 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 47.2/6.1
R18 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 41.6/33.6
R19 7030003640 S.RES ERJ3GEYJ 473 V (47K) B 38.4/34.5
R22 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 37.9/18.7
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 56.1/18.1
R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 58/18.6
R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7K) B 59.8/18.9
R27 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 68.1/32.5
R35 7030000400 S.RES MCR10EZHJ 1.5K (152) B 69.1/11.9
R36 7030003560 S.RES ERJ3GEYJ 103 V (10K) B 20.5/30.6
R37 7030003460 S.RES ERJ3GEYJ 152 V (1.5K) B 19.1/30.6
R39 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 24.4/5.7
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2K) B 24.4/3
R41 7030003580 S.RES ERJ3GEYJ 153 V (15K) B 17/32.7
R42 7030003860 S.RES ERJ3GE JPW V B 68.4/21.6
R44 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 57.3/22.1
R45 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 53.9/18
R46 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 37.8/15.8
R47 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 37.6/17.1
R48 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 45.3/17.6
R49 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 57.3/26.2
R50 7030003440 S.RES ERJ3GEYJ 102 V (1K) B 58.1/23.4
C1 4030006850 S.CER C1608 JB 1H 471K-T B 52/16.9
C2 4510008500 S.ELE EEE1CA101WP B 35.5/5.8
C5 4030007050 S.CER C1608 CH 1H 220J-T B 14.9/30.4
C9 4030007050 S.CER C1608 CH 1H 220J-T B 20.8/16.8
C10 4030007050 S.CER C1608 CH 1H 220J-T B 19.8/11.6
C11 4030007050 S.CER C1608 CH 1H 220J-T B 17/5.6
C12 4030011600 S.CER C1608 JB 1E 104K-T B 64.9/34.4
C13 4030011600 S.CER C1608 JB 1E 104K-T B 44.3/27.6
C14 4030006900 S.CER C1608 JB 1H 103K-T B 67.5/37.2
C16 4030006860 S.CER C1608 JB 1H 102K-T B 14.7/13.6
C17 4030006880 S.CER C1608 JB 1H 472K-T B 11.7/17.4
C18 4030006880 S.CER C1608 JB 1H 472K-T B 10.4/17.4
C19 4030011600 S.CER C1608 JB 1E 104K-T B 13/25.8
C21 4030011600 S.CER C1608 JB 1E 104K-T B 11.7/25.9
C22 4030011600 S.CER C1608 JB 1E 104K-T B 10.4/28.7
C23 4030011600 S.CER C1608 JB 1E 104K-T B 23.1/14
C24 4030011600 S.CER C1608 JB 1E 104K-T B 67.2/12.1
C25 4030011600 S.CER C1608 JB 1E 104K-T B 25.6/32.2
C26 4030011600 S.CER C1608 JB 1E 104K-T B 44.5/6.1
C27 4030011600 S.CER C1608 JB 1E 104K-T B 51.7/35
C29 4510008540 S.ELE EEE1CA100SR B 26.4/16
C30 4030010210 S.CER C3216 JB 1C 105M-T B 19.8/4.6
C31 4510008540 S.ELE EEE1CA100SR B 28.3/4.9
C32 4030011600 S.CER C1608 JB 1E 104K-T B 55/35.8
J1 6510023110 CON 3008L-8P8C <KIN>
DS1 5010000120 S.LED LN1371G-(TR) T 21.9/11
DS2 5010000120 S.LED LN1371G-(TR) T 21.9/32
DS3 5010000120 S.LED LN1371G-(TR) T 39.3/11
DS4 5010000120 S.LED LN1371G-(TR) T 39.3/32
S.=Surface mount
[MAIN UNIT] (For [GEN], [GEN-1])
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
DS5 5010000120 S.LED LN1371G-(TR) T 55.9/2.5
DS6 5010000120 S.LED LN1371G-(TR) T 56.2/26.8
DS7 5010000120 S.LED LN1371G-(TR) T 71.7/14.8
DS8 5010000120 S.LED LN1371G-(TR) T 72.2/33.8
DS10 5040002890 S.LED SML-310FT T86 T 51.6/5
DS11 5040002620 S.LED SML-311UT T86 T 51.6/38
MC1 7700002850 MIC EM6022P-65B-G <HOR>
S1 2260000980 SWI SKHHLP014A
EP1 6910012350 S.BEA MMZ1608Y 102BT B 10.4/26.1
EP2 6910012350 S.BEA MMZ1608Y 102BT B 14.3/17.4
EP3 6910012350 S.BEA MMZ1608Y 102BT B 13/17.4
EP4 6910012350 S.BEA MMZ1608Y 102BT B 14.7/11
EP5 6910012350 S.BEA MMZ1608Y 102BT B 15/25
1 - 2
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
[MAIN-A UNIT] (For [GEN-02], [EXP])
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
IC1 1140011491 S.IC UPD789071MC-041-5A4-E1-A B 51.1/24.5
IC3 1110006310 S.IC BD5245G-TR B 67.3/34.8
IC6 1130012030 S.IC BR24L02FV-WE2
Q1 1530001820 S.TRA 2SC2412K WT T147 S B 26.1/11
Q2 1590000680 S.TRA DTC114EUA T106 B 21.6/34.8
Q3 1590001330 S.TRA DTA114EUA T106 B 24.7/34.8
Q5 1510000510 S.TRA 2SA1576A T106R B 54.8/37.8
D1 1730002750 S.ZEN UDZSTE-17 5.6B B 23.1/17
D3 1750000940 S.DIO ISS400 TE61 B 64.7/23.2
D4 1750000940 S.DIO ISS400 TE61 B 64.7/29.2
D6 1750000940 S.DIO ISS400 TE61 B 58.7/20.8
D7 1750000940 S.DIO ISS400 TE61 B 42.8/16.7
D9 1750000940 S.DIO ISS400 TE61 B 34.1/16.3
D10 1750000940 S.DIO ISS400 TE61 B 34.9/17.8
D11 1750000940 S.DIO ISS400 TE61 B 38.8/14.5
D12 1750000940 S.DIO ISS400 TE61 B 55/34.3
D16 1730002760 S.ZEN UDZSTE-17 9.1B B 55.2/14.5
D17 1730002760 S.ZEN UDZSTE-17 9.1B B 48.8/14.5
D18 1730002760 S.ZEN UDZSTE-17 9.1B B 13.1/13.7
X1 6060000860 S.CER PBRC4.91HR30X B 42.6/22.3
L1 6200005051 S.COI NLV25T-330J B 12.3/29
L2 6200005011 S.COI NLV25T-100J B 11/13.9
R2 7030000400 S.RES MCR10EZHJ 1.5K (152) B 24.2/8.3
R3 7030000400 S.RES MCR10EZHJ 1.5K (152) B 41.9/8.3
R4 7030000400 S.RES MCR10EZHJ 1.5K (152) B 57.3/8.2
R5 7030012150 S.RES MCR03EZPJ 470 (471) B 28.6/11.2
R6 7030012140 S.RES MCR03EZPJ 33 K (333) B 26.8/34.7
R7 7030012140 S.RES MCR03EZPJ 33 K (333) B 23.3/36.8
R8 7030012180 S.RES MCR03EZPJ 8.2K (822) B 19.1/33.7
R11 7030012100 S.RES MCR03EZPJ 2.2K (222) B 52.3/38.7
R12 7030012120 S.RES MCR03EZPJ 10 K (103) B 57/35
R13 7030012170 S.RES MCR03EZPJ 2.7K (272) B 53/35
R14 7030012110 S.RES MCR03EZPJ 1 K (102) B 47.2/6.1
R18 7030012120 S.RES MCR03EZPJ 10 K (103) B 41.6/33.6
R19 7030012090 S.RES MCR03EZPJ 47 K (473) B 38.4/34.5
R22 7030012080 S.RES MCR03EZPJ 4.7K (472) B 37.9/18.7
R23 7030012080 S.RES MCR03EZPJ 4.7K (472) B 56.1/18.1
R24 7030012080 S.RES MCR03EZPJ 4.7K (472) B 58/18.6
R25 7030012080 S.RES MCR03EZPJ 4.7K (472) B 59.8/18.9
R27 7030012120 S.RES MCR03EZPJ 10 K (103) B 68.1/32.5
R35 7030000400 S.RES MCR10EZHJ 1.5K (152) B 69.1/11.9
R36 7030012120 S.RES MCR03EZPJ 10 K (103) B 20.5/30.6
R37 7030012070 S.RES MCR03EZPJ 1.5K (152) B 19.1/30.6
R39 7030012100 S.RES MCR03EZPJ 2.2K (222) B 24.4/5.7
R40 7030012100 S.RES MCR03EZPJ 2.2K (222) B 24.4/3
R41 7030012190 S.RES MCR03EZPJ 15 K (153) B 17/32.7
R42 7030012050 S.RES MCR03EZPJ JPW (000) B 68.4/21.6
R44 7030012110 S.RES MCR03EZPJ 1 K (102) B 57.3/22.1
R45 7030012110 S.RES MCR03EZPJ 1 K (102) B 53.9/18
R46 7030012110 S.RES MCR03EZPJ 1 K (102) B 37.8/15.8
R47 7030012110 S.RES MCR03EZPJ 1 K (102) B 37.6/17.1
R48 7030012110 S.RES MCR03EZPJ 1 K (102) B 45.3/17.6
R49 7030012110 S.RES MCR03EZPJ 1 K (102) B 57.3/26.2
R50 7030012110 S.RES MCR03EZPJ 1 K (102) B 58.1/23.4
C1 4030006850 S.CER C1608 JB 1H 471K-T B 52/16.9
C2 4510008500 S.ELE EEE1CA101WP B 35.5/5.8
C5 4030007050 S.CER C1608 CH 1H 220J-T B 14.9/30.4
C9 4030007050 S.CER C1608 CH 1H 220J-T B 20.8/16.8
C10 4030007050 S.CER C1608 CH 1H 220J-T B 19.8/11.6
C11 4030007050 S.CER C1608 CH 1H 220J-T B 17/5.6
C12 4030011600 S.CER C1608 JB 1E 104K-T B 64.9/34.4
C13 4030011600 S.CER C1608 JB 1E 104K-T B 44.3/27.6
C14 4030006900 S.CER C1608 JB 1H 103K-T B 67.5/37.2
C16 4030006860 S.CER C1608 JB 1H 102K-T B 14.7/13.6
C17 4030006880 S.CER C1608 JB 1H 472K-T B 11.7/17.4
C18 4030006880 S.CER C1608 JB 1H 472K-T B 10.4/17.4
C19 4030011600 S.CER C1608 JB 1E 104K-T B 13/25.8
C21 4030011600 S.CER C1608 JB 1E 104K-T B 11.7/25.9
C22 4030011600 S.CER C1608 JB 1E 104K-T B 10.4/28.7
C23 4030011600 S.CER C1608 JB 1E 104K-T B 23.1/14
C24 4030011600 S.CER C1608 JB 1E 104K-T B 67.2/12.1
C25 4030011600 S.CER C1608 JB 1E 104K-T B 25.6/32.2
C26 4030011600 S.CER C1608 JB 1E 104K-T B 44.5/6.1
C27 4030011600 S.CER C1608 JB 1E 104K-T B 51.7/35
C29 4510008540 S.ELE EEE1CA100SR B 26.4/16
C30 4030010210 S.CER C3216 JB 1C 105M-T B 19.8/4.6
C31 4510008540 S.ELE EEE1CA100SR B 28.3/4.9
C32 4030011600 S.CER C1608 JB 1E 104K-T B 55/35.8
J1 6510023110 CON 3008L-8P8C <KIN>
DS1 5010000120 S.LED LN1371G-(TR) T 21.9/11
DS2 5010000120 S.LED LN1371G-(TR) T 21.9/32
DS3 5010000120 S.LED LN1371G-(TR) T 39.3/11
DS4 5010000120 S.LED LN1371G-(TR) T 39.3/32
DS5 5010000120 S.LED LN1371G-(TR) T 55.9/2.5
DS6 5010000120 S.LED LN1371G-(TR) T 56.2/26.8
DS7 5010000120 S.LED LN1371G-(TR) T 71.7/14.8
DS8 5010000120 S.LED LN1371G-(TR) T 72.2/33.8
DS10 5040002890 S.LED SML-310FT T86 T 51.6/5
S.=Surface mount
[MAIN-A UNIT] (For [GEN-02], [EXP])
REF PARTS DESCRIPTION M. H/V
NO. NO.
LOCATION
DS11 5040002620 S.LED SML-311UT T86 T 51.6/38
MC1 7700002850 MIC EM6022P-65B-G <HOR>
S1 2260000980 SWI SKHHLP014A
EP1 6910012350 S.BEA MMZ1608Y 102BT B 10.4/26.1
EP2 6910012350 S.BEA MMZ1608Y 102BT B 14.3/17.4
EP3 6910012350 S.BEA MMZ1608Y 102BT B 13/17.4
EP4 6910012350 S.BEA MMZ1608Y 102BT B 14.7/11
EP5 6910012350 S.BEA MMZ1608Y 102BT B 15/25
2 - 1
[CHASSIS PARTS] (For [GEN], [GEN-1])
[CHASSIS-A PARTS] (For [GEN-02], [EXP])
W1 8900011272 OPC-1153B <TJM> 1
MP1 8210021920 2539 FRONT PANEL(C) 1
MP2 8210018840 2539 REAR PANEL 1
MP3 8930057380 2539 PTT BUTTON 1
MP4 8930057390 2539 LED LENS 2
MP5 8930057570 2539 SW RUBBER 1
MP6 8930066540 2539 KEYBOARD(C) 1
MP8 8810009371 PAN HEAD BT M3 X12 NI-ZK3 2
MP9 8810009561 PAN HEAD BT M2 X 6 NI-ZK3 3
W1 8900011272 OPC-1153B <TJM> 1
MP1 8210025520 2539 A-FRONT PANEL(C) 1
MP2 8210025200 2539 A-REAR PANEL 1
MP3 8930077320 2539 A-PTT BUTTON 1
MP4 8930077300 2539 A-LENS 2
MP5 8930057570 2539 SW RUBBER 1
MP6 8930066540 2539 KEYBOARD(C) 1
MP8 8810009371 PAN HEAD BT M3 X12 NI-ZK3 2
MP9 8810009561 PAN HEAD BT M2 X 6 NI-ZK3 3
ORDER
NO.
ORDER
NO.
REF.
NO.
REF.
NO.
DESCRIPTION
DESCRIPTION
QTY.
QTY.
Screw abbreviations BT: Self-tapping
PH: Pan head ZK: Black
[MAIN UNIT] (For [GEN], [GEN-1])
[MAIN-A UNIT] (For [GEN-02], [EXP])
J1 6510023110 CONNECTOR 3008L-8P8C 1
S1 2260000980 SWITCH SKHHLP014A 1
MC1 7700002850 EM6022P-65B-G 1
J1 6510023110 CONNECTOR 3008L-8P8C 1
S1 2260000980 SWITCH SKHHLP014A 1
MC1 7700002850 EM6022P-65B-G 1
ORDER
NO.
ORDER
NO.
REF.
NO.
REF.
NO.
DESCRIPTION
DESCRIPTION
QTY.
QTY.
MP2 (C)
MP8 (C)
MP3 (C)
MP9 (C)
S1 (M)
MP6 (C)
MC1 (M)
J1 (M)
MP4 (C)
MP1 (C)
MP5 (C)
W1 (C)
Unit abbreviations
(C):CHASSIS/CHASSIS-A PARTS
(M): MAIN/MAIN-A UNIT
MAIN/MAIN-A UNIT
31.5
(1 1/4)
61.0
(2 13/32)
104.0
(4 3/32)
54.3
(2 1/8)
Unit: mm (inch)
SECTION 2
.
MECHANICAL PARTS
3 - 1
SECTION 3
.
BOARD LAYOUTS
• MAIN UNIT (For [GEN], [GEN-1])
(TOP VIEW)
• MAIN UNIT (For [GEN], [GEN-1])
(BOTTOM VIEW)
• MAIN-A UNIT (For [GEN-02], [EXP])
(BOTTOM VIEW)
• MAIN-A UNIT (For [GEN-02], [EXP])
(TOP VIEW)
The combination of top side and bottom side of this
page shows the actual configuration of P.C. board.
71
to the IC-7000
MAIN unit J2003
82
J1
M DATA
MIC
PTT
MU/D
E
MICE
M8VSW
M8V
71
to the IC-7000
MAIN unit J2003
82
J1
M DATA
MIC
PTT
MU/D
E
MICE
M8VSW
M8V
PTT
PTT
DS1 DS2
DS3 DS4
DS5 DS6
DS7 DS8
DS10
DS11
MC1
H0
H5H10H15H20H25
H30
H35H40
H45
H50H55H60
H65
H70
H75
H80
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45
DS1 DS2
DS3 DS4
DS5 DS6
DS7 DS8
DS10
DS11
MC1
H0
H5
H10
H15
H20
H25
H30H35H40
H45
H50
H55
H60
H65
H70H75H80
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45
C1
C2
C5
C9
C10
C11
C12
C13
C14
C16
C17
C18
C19
C21
C22
C23
C24
C25
C26
C27
C29
C30
C31
C32
D1
D3
D4
D6
D7 D9
D10
D11
D12
D16
D17
D18
EP1
EP2
EP3
EP4
EP5
IC1
IC3
J1
L1
L2
Q1
Q2
Q3
Q5
R2
R3
R4
R5
R6
R7
R8
R11
R12
R13
R14
R18
R19
R22
R23
R24
R25
R27
R35
R36
R37
R39 R40
R41
R42
R44
R45
R46
R47
R48
R49
R50
S1
X1
3
2
1
B7194
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80
V0V5V10V15V20V25V30V35V40V45
C1
C2
C5
C9
C10
C11
C12
C13
C14
C16
C17
C18
C19
C21
C22
C23
C24
C25
C26
C27
C29
C30
C31
C32
D1
D3
D4
D6
D7 D9
D10
D11
D12
D16
D17
D18
EP1
EP2
EP3
EP4
EP5
IC1
IC3
J1
L1
L2
Q1
Q2
Q3
Q5
R2
R3
R4
R5
R6
R7
R8
R11
R12
R13
R14
R18
R19
R22
R23
R24
R25
R27
R35
R36
R37
R39 R40
R41
R42
R44
R45
R46
R47
R48
R49
R50
S1
X1
3
2
1
B6347B
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80
V0V5V10V15V20V25V30V35V40V45
4 - 1
SECTION 4 VOLTAGE DIAGRAM
S23
C29
C9
S10 S11
S3
J1
1
2
3
4
5
6
7
8
R7
C13
S26S24
C16
C12
S21
S18
DS4
R4
C22
R44
S1
C5
Q5
C18
Q3
MC1
R36
DS3
R39
R23
S19
C10
R24
DS11
D7
D16
IC1
1P10
2P31/BZO90
3VPP
4RESET
5X2
6X1
7VSS
8VDD
9P30/TO90
10 P27/TI80/TO80
11 P26/INTP2/CPT90
12 P25/INTP1
13 P24/INTP0
14 P23/SS20
15 P22/SI120/RXD20 16
P21/SO20/TXD20
17
P20/SCK20/ASCK20
18
P07
19
P06
20
P05
21
P04
22
P03
23
P02
24
P01
25
P00
26
P15
27
P14
28
P13
29
P12
30
P11
S13
C32
DS10
EP2
C31
X1
D4
EP4
DS2
D18
D3
R48
C17
R40
Q1
DS8
C21
R46
EP3
S9
R47
R41
D11
S4
C25
C14
D17
R2
S15
R6
C27
R35
D9
S8
DS7
R8
R25
S20
R5
R18
EP1
S6
C26
S2
S25
R27
DS5
S12
C1
IC3
1VOUT
2VDD
3GND 4
NC
5
CT
S22
S5
R12
R42
R49
S16
R22
C23
C2
S17
R19
D6
EP5
DS6
S14
S7
Q2
R37
C19
R45
R14
C24
D10
J2
1
12
23
34
45
56
6
D1
DS1
C11
R3
R50
L1
L2
C30
MKEY-00
MKEY-01
MKEY-02
MKEY-03
MKEY-04
MKEY-05
MKEY-06
MKEY-07
MKEY-I1
MKEY-I2
MKEY-I3
MKEY-I0
PTT
V/M
MW
LOCK
TUNER/
XFCUP
DN
(1)
(2)
(3)
(4)
(5)
(6)
MODE FIL GENE F-INP
(9)
(8)
(7) (.)
(0)
430
F-2
F-1
M8V
MU/D
M8VSW
PTT
MICE
MIC
E
MDATA
ENT
(CE)
28187
3.5
1.8
14 24 144
10 21 50
CALL
SPCH/
D12
R13
R11
MAIN UNIT (For [GEN], [GEN-1]) MAIN-A UNIT (For [GEN-02], [EXP])
S23
C29
C9
S10 S11
S3
J1
1
2
3
4
5
6
7
8
R7
C13
S26S24
C16
C12
S21
S18
DS4
R4
C22
R44
S1
C5
Q5
C18
Q3
MC1
R36
DS3
R39
R23
S19
C10
R24
DS11
D7
D16
IC1
1P10
2P31/BZO90
3VPP
4RESET
5X2
6X1
7VSS
8VDD
9P30/TO90
10 P27/TI80/TO80
11 P26/INTP2/CPT90
12 P25/INTP1
13 P24/INTP0
14 P23/SS20
15 P22/SI120/RXD20 16
P21/SO20/TXD20
17
P20/SCK20/ASCK20
18
P07
19
P06
20
P05
21
P04
22
P03
23
P02
24
P01
25
P00
26
P15
27
P14
28
P13
29
P12
30
P11
S13
C32
DS10
EP2
C31
X1
D4
EP4
DS2
D18
D3
R48
C17
R40
Q1
DS8
C21
R46
EP3
S9
R47
R41
D11
S4
C25
C14
D17
R2
S15
R6
C27
R35
D9
S8
DS7
R8
R25
S20
R5
R18
EP1
S6
C26
S2
S25
R27
DS5
S12
C1
IC3
1VOUT
*Refer to “PARTS LIST” for component name or value.
2VDD
3GND 4
NC
5
CT
S22
S5
R12
R42
R49
S16
R22
C23
C2
S17
R19
D6
EP5
DS6
S14
S7
Q2
R37
C19
R45
R14
C24
D10
J2
1
12
23
34
45
56
6
D1
DS1
C11
R3
R50
L1
L2
C30
MKEY-00
MKEY-01
MKEY-03
MKEY-04
MKEY-05
MKEY-06
MKEY-07
MKEY-I1
MKEY-I2
MKEY-I3
MKEY-I0
PTT
V/M
MW
LOCK
TUNER/
XFCUP
DN
(1)
(2)
(3)
(4)
(5)
(6)
MODE FIL GENE F-INP
(9)
(8)
(7) (.)
(0)
430
F-2
F-1
M8V
MU/D
M8VSW
PTT
MICE
MIC
E
MDATA
ENT
(CE)
28187
3.5
1.8
14 24 144
10 21 50
CALL
SPCH/
W1
D12
R13
R11
*Refer to “PARTS LIST” for component name or value.
6F No.68, Sec. 1 Cheng-Teh Road, Taipei, Taiwan, R.O.C.
Phone : +886 (02) 2559 1899 Fax : +886 (02) 2559 1874
URL : http://www.asia-icom.com
Zac de la Plaine
1 Rue Brindejonc des Moulinais BP 5804
31505 Toulouse Cedex, France
Phone : +33 (5) 61 36 03 03 Fax : +33 (5) 61 36 03 00
URL : http://www.icom-france.com
Blacksole House, Altira Park, Herne Bay, Kent CT6 6GZ, UK
Phone : +44 (01227) 741741 Fax : +44 (01227) 741742
URL : http://www.icomuk.co.uk
Ctra. Rubi, No. 88 Bajos A 08174, Sant Cugat del Valles, Barcelona, Spain
Phone : +34 (93) 590 26 70 Fax : +34 (93) 589 04 46
URL : http://www.icomspain.com
<Corporate Headquarters>
2380 116th Avenue N.E., Bellevue, WA 98004, U.S.A.
Phone : +1 (425) 454-8155 Fax : +1 (425) 454-1509
URL : http://www.icomamerica.com
<Customer Service>
Phone : +1 (425) 454-7619
Glenwood Centre #150-6165
Highway 17 Delta, B.C., V4K 5B8, Canada
Phone : +1 (604) 952-4266 Fax : +1 (604) 952-0090
URL : http://www.icomcanada.com
Unit 1 / 103 Garden Road, Clayton VIC 3168 Australia
Phone : +61 (03) 9549-7500 Fax : +61 (03) 9549-7505
URL : http://www.icom.net.au
146A Harris Road, East Tamaki,
Auckland, New Zealand
Phone : +64 (09) 274 4062 Fax : +64 (09) 274 4708
URL : http://www.icom.co.nz
10C07, Long silver Mansion, No.88, Yong Ding
Road, Haidian District, Beijing, 100039, China
Phone : +86 (010) 5889 5391/5392/5393
Fax : +86 (010) 5889 5395
URL : http://www.bjicom.com
81-850 Sopot, ul. 3 Maja 54, Poland
Phone : +48 (58) 550 7135 Fax : +48 (58) 551 0484
1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan
Phone : +81 (06) 6793 5302
Fax : +81 (06) 6793 0013
URL : http://www.icom.co.jp/world/index.html
Communication Equipment
Auf der Krautweide 24
65812 Bad Soden am Taunus, Germany
Phone : +49 (6196) 76685-0
Fax : +49 (6196) 76685-50
URL
: http://www.icomeurope.com
E-mail
1-1-32, Kamiminami, Hirano-ku, Osaka 547-0003, Japan S-14526XZ-C1-q
© 2009 Icom Inc.
Table of contents
Other Icom Microphone manuals
