INSTRUCTION MANUAL
VHF FM REPEATER
CY-5300
UHF FM REPEATER
CY-6300

IMPORTANT
READ THIS INSTRUCTION MANUAL
CAREFULLY before attempting to operate
the repeater.
SAVE THIS INSTRUCTION MANUAL– This
manual contains important safety and operating
instructions for the CY FR series.
EXPLICIT DEFINITIONS
WORD DEFINITION
WARNING Personal injury, re hazard or electric
shock may occur.
CAUTION Equipment damage may occur.
NOTE If disregarded, inconvenience only.
No risk of personal injury, re or
electric shock.
PRECAUTION
WARNING HIGH VOLTAGE! NEVER
attach an antenna or internal antenna connector
during transmission. This may result in an
electrical shock or burn.
WARNING HIGH VOLTAGE! NEVER
install the antenna at any place that person touch
the antenna easily during transmission. This may
result in an electrical shock or burn.
NEVER apply AC to the [BATTERY] terminals
on the repeater rear panel. This could cause a
re or damage the repeater.
NEVER apply more than 16 V DC, such as a
24 V battery, to the [BATTERY] terminals on the
repeater rear panel. This could cause a re or
damage the repeater.
NEVER let metal, wire or other objects touch
any internal part or connectors on the rear panel
of the repeater. This may result in an electric
shock.
NEVER expose the repeater to rain, snow or
any liquids.
AVOID using or placing the repeater in areas
with temperatures below –30°C (–22°F) or above
+60°C (+140°F). Be aware that temperatures
on a vehicle’s dashboard can exceed 80°C
(+176°F), resulting in permanent damage to the
repeater if left there for extended periods.
AVOID placing the repeater in excessively dusty
environments or in direct sunlight.
AVOID putting anything on top of the repeater.
This will obstruct airow.
Place the repeater in a secure place to avoid
inadvertent use by children.
BE CAREFUL! The heatsink will become hot
when operating the repeater continuously for long
periods.
BE CAREFUL! If a linear amplier is
connected, set the repeater’s RF output power
to less than the linear amplier’s maximum
input level, otherwise, the linear amplier will be
damaged.
Use Icom microphones only. Other
manufacturer’s microphones have different pin
assignments, and connection to the CY FR series
may damage the repeater.
For U.S.A. only
CAUTION: This repeater is intended for use
as a xed repeater with the antenna located
outdoors on the rooftop or on antenna tower.
The Icom America Systems logo is a trademark
of Icom, Inc.
i

FORWARD
Thank you for purchasing this Icom America
Systems CY FR VHF/UHF repeater. With
proper care, this product should provide you
years of trouble-free operation.
 FEATURES
❍Automatic battery backup and
charging system
A built-in backup system supports automatic
switching to an external battery (13.6 V DC)
if the AC power supply fails.
❍ Other features
- PC programmable
- 19 inch rack mount or desktop.
SUPPLIED ACCESSORIES
The following accessory is supplied with
CY FR series
[AC120V version]
➀AC power cable (OPC-510) ….............……… 1
ii

➊MICROPHONE CONNECTOR
[MIC]
Use Icom microphones only. Other manufacturer’s
microphones have different pin assignments, and
connection to the CY FR series may damage the
repeater.
➀ ➇
1PANEL DESCRIPTION
■ Front Panel
1
➀ +8 V DC output (Max. 15 mA)
➁ Output port for PC programming
➂ AFO
➃ M PTT (Input port for TX control)
➄ Microphone ground
➅ Microphone input
➆ Ground
➇ Input port for PC programming

➊LIGHTED POWER SWITCH [POWER]
Toggles to turn the repeater AC power ON
or OFF. Located on the back panel of the
repeater.
NOTE: Does not effect DC power input.
➋TRANSMIT ANTENNA CONNECTOR [TX/
TX•RX]
➥ Connects a transmit antenna (impedance:
50
Ω) and outputs transmit signals.
➥ When an optional internal duplexer is
installed, this connects the Transmit and
Receive Radios to an antenna.
➥ N Female Connector.
➌ ACCESSORY CONNECTOR [ACC]
Connects to the remote controller.
• See pg. 3 for accessory connector
information.
➍RECEIVE ANTENNA CONNECTOR [RX]
➥ Connects a receive antenna (impedance: 50
Ω) and inputs receiving signals.
➥ When an optional internal duplexer is
installed, do not use this connector.
➥ N Female Connector.
➎AC POWER SOCKET [AC]
Connects the supplied AC power cable to a
120V or 220V AC outlet.
120V or 220V internal jumper selectable.
➏ GROUND TERMINAL [GND]
Ground the repeater through this terminal
to prevent electric shocks, TVI, BCI and other
problems.
➐DC POWER INPUT TERMINALS [BATTERY]
Connects the 12 V storage battery for
the repeater backup when the AC power is
interrupted. These terminals are also used for
DC power operation. Battery is automatically
recharged when AC power is restored.
CAUTION: NEVER short the (+) line of the
DC power cable to repeater’s chassis, when
connecting DC power cable to the [BATTERY]
terminals. Otherwise, there is danger of
electric shock and/or equipment damage.
➑LAN CONNECTOR for ethernet connection
when optional UC-FR5300 controller
installed.
➒BUS CONNECTORS for data communication
among optional UC-FR5300 controllers.
➓ GPS CONNECTOR connects to the optional
GPS antenna.
■ Rear Panel
PANEL DESCRIPTION 1
2
➌➊
➏
➋ ➍ ➎
➐
➑➒

ACC
Pin
No. Pin Name Description Specication
1 NC No connection —
2 TXD Input terminal for serial communication data. —
3 RXD Output terminal for serial communication data. —
4RTS Input terminal for request-to-send data. —
5 CTS Output terminal for clear-to-send data. —
6 NC No connection —
7 GND Serial/digital signal ground —
8 MOD IN Modulator input from an external terminal unit. Input level: 85 mV rms
9 DISC OUT Output terminal for AF signals from the AF detector circuit.
Output level is xed, regardless of the [AF] control setting. Output level: 300 mV rms
10 EXT. D/A Output terminal.
The desired function can be assigned.*
(Default: Null)
—
11 VCC Power supply voltage output Output current: Less than 100 mA
12 N/C No connection —
13 N/C No connection —
14 GND Ground —
15 EXT.I/O 15 A desired function can be assigned.*
(Default: Null) —
16 EXT.I/O 16 A desired function can be assigned.*
(Default: P0 Monitor Output) —
17 EXT.I/O 17 A desired function can be assigned.*
(Default: Busy Output) —
18 EXT.I/O 18 The desired function can be assigned.*
(Default: Null) —
19 EXT.I/O 19 A desired function can be assigned.*
(Default: Null) —
20 N/C No connection —
21 EXT.I/O 21 A desired function can be assigned.*
(Default: Analog Audible Output) —
22 AF OUT The AF detector Output. —
23 EXT.I/O 23 A desired function can be assigned.*
(Default: Mic Mute Output) —
24 EXT.I/O 24 The desired function can be assigned.*
(Default: Null) —
25 EXT.I/O 25 A desired function can be assigned.*
(Default: Null) —
■ Accessory Connector
PANEL DESCRIPTION 1
3
* A desired function can be assigned using the optional programming software CS-FR5300.
[ACC]

2INSTALLATION AND CONNECTIONS
■ Unpacking
After unpacking, immediately report any damage
to the delivering carrier or dealer. Keep the
shipping cartons.
For a description and a diagram of accessory
equipment included with the CY FR series, see
‘Supplied accessories’ of this manual.
■ Selecting a location
Select a location for the repeater that allows
adequate air circulation, free from extreme
heat, cold, or vibrations, and away from TV
sets, TV antenna elements, radios and other
electromagnetic sources.
■ Antenna connection
For radio communications, the antenna is of
critical importance, along with output power and
sensitivity. Select antenna(s), such as a well-
matched 50 Ωantenna, and feedline. 1.5:1 or
better of Voltage Standing Wave Ratio (VSWR)
is recommended for desired band. Of course, the
transmission line should be a coaxial cable.
CAUTION: Protect repeater from lightning
by using a lightning arrestor.
NOTE: There are many publications
covering proper antennas and their
installation. Check with your local dealer for
more information and recommendations.
■ Duplexer
A duplexer is separately required when only
one antenna is used for both transmitting and
receiving. Select a duplexer according to the
transmitting and receiving frequencies. Ask your
Dealer for details.
■ Grounding
To prevent electrical shock, television interference
(TVI), broadcast interference (BCI) and other
problems, ground the transceiver through the
[GND] terminal on the rear panel.
For best results, connect a 2-gauge wire to an
8-foot long earth-sunk copper rod. Make the
distance between the [GND] terminal and ground
as short as possible.
WARNING: NEVER connect the
[GND] terminal to a gas or electric pipe,
since the connection could cause an
explosion or electric shock.
TYPE-N CONNECTOR INSTALLATION EXAMPLE
Slide the nut, at washer, rubber gasket and clamp over the coaxial
cable, then cut the end of the cable evenly.
Strip the cable and fold the braid back over the clamp.
Soft solder the center conductor. Install the center conductor pin and
solder it.
Carefully slide the plug body into place aligning the center conductor
pin on the cable. Tighten the nut onto the plug body.
30 mm ≈ 9⁄8 in 10 mm ≈ 3⁄8 in 1–2 mm ≈ 1⁄16 in
➀
➁
➂
➃
4

■ Required Connections
INSTALLATION AND CONNECTIONS 2
[DC POWER INPUT TERMINAL]
Make sure the back up battery is correctly
connected. Use a cable with following
current capacity. Solder or clamp the cable
plug when connecting the power cable to the
backup battery to prevent voltage drops.
Power cable current capacity: 25 A or more
[TX(TX•RX) ANT] [RX ANT] GROUND
5
NOTE: Must have minimum 20’ vertical separation when using separate antennas.
TX•RX antenna required
for installing an internal
duplexer.

Make sure the AC [POWER] switch is turned
OFF when connecting an AC power cable or a
backup battery (emergency power supply).
The CY FR series can operate with either an AC
or DC input. If AC power is interrupted and there
is an external DC source (emergency power
supply), the Repeater will continue to operate
until the DC source is exhausted.
NOTE: IF turning the Repeater OFF using
the rear panel switch, wait a few seconds
before turning it back ON. Otherwise, Logic
circuits may not sense the transition. The
AC Power switch does not effect the DC
supply. If Repeater is operating on DC, you
must use the power switch(s) on the Radio.
 In AC operation
• Use the supplied AC power cable for
connection to a domestic AC outlet.
• Extension cords should not be used unless
absolutely necessary. Using improper
extension cords could result in re risk.
• An International AC power cable is available.
The internal AC power supply is jumper
selectable between 120Vac and 220Vac .
 In DC operation
CAUTION: Voltages greater than 16 VDC
will damage the repeater. Check the source
voltage before connecting the power cable.
• DO NOT place the backup battery on or near
the repeater. Lead-acid batteries should be
placed at least 5 m (16.4 ft.) away from the
repeater. Use a heavy duty cable to make
the connection and be sure both the positive
(red) and negative (black) terminals are
correctly connected.
• When connecting to the battery, connect
the DC power cable to the repeater rst, then
the positive (red) terminal and negative
(black) terminal to the battery. This is to
prevent an electric shock or circuit damage.
■ Power
INSTALLATION AND CONNECTIONS 2
6
• Remove jumper for 220V operation.
• Install jumper for 120V operation.
WARNING: DANGER OF ELECTRIC
SHOCK. Disconnect AC power before
changing voltage select jumper.
120V/220V Jumper
(-) Negative (black) (+) Positive (red)

3OPTIONAL UNIT INSTALLATION
■ Opening the repeater’s case
Follow the case and cover opening procedures
shown here when an optional unit is installed or
adjustments are required to the internal units, etc.
7
OPTIONAL PRESELECTOROPTIONAL DUPLEXER
➀Remove 3 screws from the top of the repeater, 4 screws from the sides and 4 screws from the
top of the front Panel, then lift up the top cover.
CAUTION: Disconnect theAC power cable
and/or DC power cable from the repeater.
Otherwise, there is danger of electric shock
and/or equipment damage.

4OPERATION
■ Turning power ON
➀ On rear panel, toggle AC Power Switch up to
turn AC power ON.
■ Receiving and transmitting
 Receiving
➀ When receiving a signal, RX indicator turns
ON. No audio is output from the repeater.
A subscriber unit will be required to hear
the audio.
 Transmitting for Local Control
➀ Take the microphone off hook.
➁ Wait for the channel to become clear.
➂ Push and hold [PTT] to transmit, then
speak into the microphone at your normal
voice level.
➃ Release [PTT] to receive.
IMPORTANT:
To maximize the readability of the transmitted
signal:
➀ Pause briey after pushing [PTT].
➁Hold the microphone 1 to 2 inch (2.5 to
5 cm) from your mouth, then speak into
the microphone at a normal voice level.
8

5MAINTENANCE
■ Fuse replacement
If a fuse blows or the repeater stops functioning,
try to nd the source of the problem, and replace
the damaged fuse with a new, rated fuse.
9
CAUTION: DISCONNECT the DC power
cable from the repeater. Otherwise, there is
a danger of electric shock and/or equipment
damage.

6SPECIFICATIONS AND OPTIONS
■ Specications
◆UR-FR5300
GENERAL
Power supply 105-130 VAC 50/60 hz 5A Max
requirement (nominal) 185-250 VAC 50/60 hz
13.6 VDC (nominal) 16.2 Amp Max
Dimensions 480 (W) x 133 (H) x 364 (D) mm;
(Projections not included) 18.90 (W) x 524 (H) x 14.33 (D) in.
Weight: 8.6 kg; 18 lb
10
*Optional Duplexer and Preselector specications not listed.
*All specications are subject to change without notice.
(See UR Service Manual for module specications)

11
■Options
• HM-152 HAND MICROPHONE
• HM-152T DTMF MICROPHONE
Hand microphone with a DTMF keypad
• SM-26 DESKTOP MICROPHONE
• UX-241 GNSS ANTENNA
• Various duplexers and preselectors are available
in both VHF and UHF. Please contact Icom
America Customer Service to find the currently
available options.

MEMO

Count on us!
42960 02/21
©2021 Icom America Inc. The Icom logo is a registered trademark of Icom Inc.
All specications and information is subject to change without notice or obligation.
All other trademarks remain the property of their respective owners.
