INSTRUCTION MANUAL
UHF TRANSCEIVER
iF4002
VHF TRANSCEIVER
iF3002
Limited functions only
The photo shows the
VHF transceiver.

i
FOREWORD
READ ALL INSTRUCTIONS carefully and completely before
using the transceiver.
SAVE THIS INSTRUCTION MANUAL— This instruction
manual contains important operating instructions for the IC-F3002
VHF TRANSCEIVER and the IC-F4002 UHF TRANSCEIVER.
EXPLICIT DEFINITIONS
WORD DEFINITION
RDANGER! Personal death, serious injury or an explo-
sion may occur.
RWARNING! Personal injury, fire hazard or electric shock
may occur.
CAUTION Equipment damage may occur.
NOTE
If disregarded, inconvenience only. No risk
of personal injury, fire or electric shock.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorpo-
rated (Japan) in Japan, the United States, the United Kingdom, Germany, France,
Spain, Russia, Australia, New Zealand, and/or other countries.

ii
PRECAUTIONS
RDANGER! NEVER short terminals of the battery pack. Also,
current may flow into nearby metal objects such as a key, so be
careful when placing the battery packs (or the transceiver) in hand-
bags, etc. Simply carrying with or placing near metal objects such
as a key, etc. may cause shorting. This may damage not only the
battery pack, but also the transceiver.
RDANGER! Use and charge only specified Icom bat-
tery packs with Icom transceivers or Icom chargers. Only Icom
battery packs are tested and approved for use with Icom transceiv-
ers or charged with Icom chargers. Using third-party or counterfeit
battery packs or chargers may cause smoke, fire, or cause the bat-
tery to burst.
RWARNING! NEVER hold the transceiver so that the antenna
is very close to, or touching exposed parts of the body, especially
the face or eyes, while transmitting. The transceiver will perform
best if the microphone is 5 to 10 cm away from the lips and the
transceiver is vertical.
RWARNING! NEVER operate the transceiver with a headset
or other audio accessories at high volume levels. The continuous
high volume operation may cause a ringing in your ears. If you ex-
perience the ringing, reduce the volume level or discontinue use.
RWARNING! NEVER operate the transceiver while driving a
vehicle. Safe driving requires your full attention—anything less may
result in an accident.
CAUTION: MAKE SURE the flexible antenna, battery pack and
jack cover are securely attached to the transceiver, and that the
antenna and battery pack are dry before attachment. Exposing the
inside of the transceiver to dust or water will result in serious dam-
age to the transceiver.

iii
DO NOT operate the transceiver near unshielded electrical blast-
ing caps or in an explosive atmosphere.
DO NOT push [PTT] when you do not actually intend to transmit.
DO NOT operate or place the transceiver in direct sunlight or in
areas with temperatures below –25°C or above +55°C.
DO NOT modify the transceiver. The specifications may change
and then not comply with the requirements of a corresponded
regulation. The transceiver warranty does not cover any problems
caused by unauthorized modification.
DO NOT use harsh solvents such as benzine or alcohol when
cleaning, as they will damage the transceiver surfaces.
BE CAREFUL! The transceiver will become hot when operating
it continuously for long periods of time.
KEEP the transceiver away from heavy rain, and never immerse
it in the water. The transceiver meets IP54* requirements for dust-
protection and splash resistance. However, once the transceiver
has been dropped, dust-protection and splash resistance cannot
be guaranteed because of possible damage to the transceiver’s
case or the waterproof seal.
* Only when the battery pack/case and jack cover are attached.
Even when the transceiver power is OFF, a slight current still flows in
the circuits. Remove the battery pack from the transceiver when not
using it for a long time. Otherwise, the installed battery pack will be-
come exhausted, and will need to be recharged or replaced.
MAKE SURE to turn OFF the transceiver power before connect-
ing the supplied/optional equipment.
PRECAUTIONS (Continued)

iv
TABLE OF CONTENTS 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
FOREWORD ........................................................................................ i
EXPLICIT DEFINITIONS...................................................................... i
PRECAUTIONS................................................................................... ii
1 ACCESSORIES ......................................................................... 1–4
■Supplied accessories.................................................................. 1
■Accessory attachments .............................................................. 1
2 PANEL DESCRIPTION ............................................................ 5–11
■Front, top and side panels .......................................................... 5
■LED indicator .............................................................................. 7
■Programmable function keys ...................................................... 8
3 BASIC OPERATION .............................................................. 12–22
■Turning power ON..................................................................... 12
■Channel selection ..................................................................... 13
■Call procedure .......................................................................... 14
■Receiving and transmitting ....................................................... 15
■Setting the microphone gain..................................................... 18
■Setting the squelch level........................................................... 19
■Output power level selection..................................................... 20
■Priority A channel selection ...................................................... 20
■MDC 1200 system operation .................................................... 20
■Emergency Call ........................................................................ 21
■Lone Worker Emergency Call................................................... 22
4 BATTERY CHARGING .......................................................... 23–33
■Caution (for the BP-264 ni-mh battery).................................... 23
■Caution (for the BP-265 li-ion battery).................................... 25
■Battery chargers ....................................................................... 28
5 BATTERY CASE .......................................................................... 34
■Optional battery case (BP-263) ................................................ 34
6 OPTIONS ............................................................................... 35–40
■VOX function ............................................................................. 38
7 INFORMATION ............................................................................ 41
■Country code list (ISO 3166-1) ................................................. 41
■Disposal.................................................................................... 41

■Supplied accessories
The following accessories are supplied with the transceiver.
Flexible antenna
(This illustration is for the VHF type.)
Battery pack*
Belt clip Jack cover
(with screws)
Battery charger* Power adapter*
* Not supplied, or the shape is different, depending on the version.
■Accessory attachments
DFlexible antenna
Connect the flexible antenna to the an-
tenna connector.
CAUTION:
• NEVER carry the transceiver by
holding the antenna.
• DO NOT connect the antenna other
than listed on p. 36.
• Transmitting without an antenna
may damage the transceiver.
1
1ACCESSORIES

2
1
ACCESSORIES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
DBelt clip
To attach the belt clip:
➥Slide the belt clip in the direction of the arrow until the belt clip
locks in place, and makes a ‘click’ sound.
Battery pack
Belt clip
To detach the belt clip:
qRemove the battery pack from the transceiver, if it is attached.
(p. 3)
wLift the tab up (q), and slide the belt clip in the direction of the
arrow (w).
w
q
Ta b

3
1ACCESSORIES
DBattery pack/case
To attach the battery pack/case:
q Fit the battery pack/case in the direction of the arrow (q), then
close.
w Hook the latch until it makes a ‘click’ sound (w).
q
Latch
w
Battery pac
k/case
To remove the battery pack/case:
Unhook the latch (e), and lift up the
battery pack/case in the
direction of the arrow (r).
e
r
Be careful! The latch is tightly locked, so use caution when re-
leasing it. DO NOT use your finger nail. Use the edge of a coin or
screwdriver tip to carefully release it.

4
1
ACCESSORIES
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
NEVER remove or attach the battery pack/case when the trans-
ceiver is wet or soiled. This may result in water or dust getting into
the transceiver,
battery pack/case, and may result in them being
damaged.
NOTE: Keep the battery terminals clean. It’s a good idea to
occasionally clean them.
DJack cover
Attach the jack cover when the optional equipment is not used.
To attach the jack cover:
qAttach the jack cover to the
[SP MIC] jack.
wTighten the screws.
To detach the jack cover:
eRemove the screws with a
phillips screwdriver.
rDetach the jack cover to con-
nect the optional equipment.
r
w
w
q
e
e

5
2PANEL DESCRIPTION
■Front, top and side panels
Microphone
Speaker
r
w
e
q
y
u
i
t
LOWER KEY
UPPER KEY
PTT SWITCH
ANTENNA
CONNECTOR
ROTARY
SELECTOR
LED INDICATO
R
VOLUME
CONTROL
SPEAKER-
MICROPHONE
JACK
qROTARY SELECTOR
Rotate to select the pre-programmed memory channels.
wVOLUME CONTROL [VOL]
Rotate to turn the power ON/OFF, and adjust the audio level.

6
2
PANEL DESCRIPTION
eLED INDICATOR (p. 7)
➥Lights red* while transmitting.
*When the optional battery case is attached, the LED indicator
lights orange.
➥Lights green while receiving a signal, or when the squelch is
open.
➥Lights/blinks orange when the matched 2/5-Tone code is re-
ceived, depending on the pre-programming.
rSPEAKER-MICROPHONE JACK [SP MIC]
Connect the optional speaker-microphone or VOX adapter
cable.
tLOWER KEY [Lower]
yUPPER KEY [Upper]
The desired function can be assigned by your dealer. (p. 8)
uPTT SWITCH [PTT]
Push and hold to transmit; release to receive.
iANTENNA CONNECTOR
Connect the antenna.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Jack cover
NOTE: Attach the jack cover
when the optional equipment
is not used. (p. 4)

7
2PANEL DESCRIPTION
■LED indicator
The LED indicator indicates the status of various
parameters of the transceiver as follows;
(Ref.; R=Red, G=Green, O=Orange)
R* R*
TX Low BATT2
R* R* R* R*
O
O O
G G G G
G G
G G G G G G G G
R G R G R G R G R G R G R G R G
R O R O R O R O R O R O R O R O
G
G G
Clone Err
Clone TX/RX
Low BATT1
Low BATT2
Busy
F/S Scan
Call LED Blink
Call LED ON
TX Low BATT1
R*
TX
• TX: Lights Red while transmitting a signal.
• RX: Lights Green while receiving a signal.
• Call LED (ON): Turns ON while receiving a matched 2/5-Tone.
• Call LED (Blink): Blinks while receiving a matched 2/5-Tone.
• Fast/Slow scan: Blinks when the Fast/Slow scan is activated.
• Low Battery 1: You should charge the battery. (blinks slowly)
• Low Battery 2: You must charge the battery. (blinks fast)
• TX low Battery 2: Very Low Battery was detected during TX mode.
• Channel Error: A non-programmed channel is selected.
* Lights (or blinks) orange when the optional battery case is attached.
• TX low Battery 1: Low Battery was detected during TX mode.

8
2
PANEL DESCRIPTION
■Programmable function keys
The following functions can be assigned to the [Upper] and [Lower]
programmable function keys.
Consult your Icom dealer or system operator for details concerning
your transceiver’s programming.
SCAN A
➥Push to start and cancel the scanning operation.
➥When the Power ON scan function is turned ON, push to pause
the scanning operation. The paused scan resumes after the
specified time period has passed.
SCAN B
Push to start and cancel the scanning operation.
If the scan pauses for any reason, except being cancelled by this
key, it will resume after a specified time period has passed.
PRIORITY A CHANNEL, PRIORITY B CHANNEL
Push to select the Priority A or Priority B channel.
PRIORITY A CHANNEL (REWRITE),
PRIORITY B CHANNEL (REWRITE)
➥Push to select the Priority A or Priority B channel.
➥Push and hold [Prio A (Rewrite)] or [Prio B (Rewrite)] for 1 sec.
to assign the operating channel to Priority A or Priority B chan-
nel, respectively.
MEMORY CHANNELS 1, 2, 3, 4
Push to directly select memory channel 1, 2, 3 or 4, if programmed.
Consult your dealer for details.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

9
2PANEL DESCRIPTION
MONITOR, MONITOR (AUDIBLE)
➥Push to turn the CTCSS (DTCS) or 2/5-Tone squelch Mute ON
or OFF.
• Only during LMR operation, push to open any squelch func-
tions, or deactivate any mute functions.
• Only during PMR operation, push to activate one or two of the
following functions* on each channel.
- Push and hold to un-mute the channel (Audible mode).
- Push to mute the channel (Inaudible mode).
- Push to send a ‘reset code’ after the communication is finished.
*Ask your dealer for details.
NOTE: The un-mute condition may automatically return to
the mute condition, after a specified time period.
➥
Depending on the presetting, pushing and holding this key for
1 sec. cancels a scan.
LOCK
Push and hold to electronically lock all programmable keys except
[Moni(Audi)], [Call] (including Call A and Call B), [Emergency],
[Surveillance] and [Lone Worker].
LONE WORKER (p. 22)
➥Push to turn the Lone Worker function OFF.
➥Push and hold to turn the Lone Worker function ON.
• When the Lone Worker function is turned ON, and no operation is
performed for the specified time period, the Emergency function is
automatically turned ON.
HIGH/LOW (p. 20)
Select the transmit output power level temporarily or permanently,
depending on the presetting.
• Ask your dealer for the output power level for each selection.

10
2
PANEL DESCRIPTION
TALK AROUND
➥Push to turn the Talk Around function OFF.
➥Push and hold to turn the Talk Around function ON.
• The Talk Around function equalizes the transmit frequency to the
receive frequency for transceiver-to-transceiver communication.
WIDE/NARROW
➥Push to switch the IF bandwidth to Wide.
• The wide passband width can be selected from 20 or 25 kHz using
the optional cloning software (PMR operation only). Ask your dealer
for details.
➥Push and hold to switch the IF bandwidth to Narrow.
DTMF AUTODIAL
Push to transmit a programmed DTMF code.
CALL, CALL A, CALL B
Push to transmit a 2/5-Tone code.
• Tone call transmission may be necessary before you call another sta-
tion, depending on your signalling system.
• [Call A] and/or [Call B] keys may be available when your system em-
ploys selective ‘Individual/Group’ calls. Ask your dealer which call is
assigned to each key.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20

EMERGENCY
Push and hold for specified time period to transmit an emergency
call.
• The emergency call transmits with beeps, and the LED indicator lights
red.
• The transceiver can transmit an emergency call without the beep
sounding and the LED indicator lighting. Ask your dealer for details.
• If you want to cancel the emergency call, push and hold the key again
before transmitting the call.
• The emergency call is transmitted one time only, or repeatedly until re-
ceiving an acknowledgement signal, or until the power is turned OFF.
When a matched 5-Tone code signal is received, the emergency func-
tion can be cancelled depending on the presetting. (PMR operation
only)
SURVEILLANCE
➥Push to turn the Surveillance function OFF.
➥Push and hold to turn the Surveillance function ON.
• When this function is turned ON, the beep is not heard and the LED
does not light when a signal is received, or a key is pushed.
SIREN
Push and hold for 1 sec. to emit a siren sound.
This function can be used for situations other than an emergency
alert, such as a security alarm for example.
The transceiver emits the siren sound until the power is turned
OFF.
11
2PANEL DESCRIPTION

12
3
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
■Turning power ON
Prior to using the transceiver for the first
time, the battery pack must be fully charged
for optimum life and operation. (p. 23)
➥ Rotate [VOL] to turn power ON.
D Battery type selection
The battery type must be selected according to the battery pack or
case when it is changed, but only the first time it is used.
Check the battery type before you begin the selection procedure.
One to three beep(s) sound in sequence, so you must repeat the
steps until the number of beeps matches your battery type.
For example, if your battery type is a Li-ion battery pack, you must
repeat the procedure until 1 beep is heard.
qSet
[ROTARY SELECTOR] to any
channel other than Channel 16.
w Rotate [VOL] to turn OFF the
transceiver power.
e While holding down [PTT], rotate
[VOL] to turn ON the power.
• You should hold [PTT] until the bat-
tery type confirmation beeps sound.
(It takes approximately 5 seconds;
while holding down [PTT], the count
down beeps sound. After that, the confirmation beeps sound.)
• 1 beep sounds when the Li-ion battery is selected.
• 2 beeps sound when the battery case is selected.
• 3 beeps sound when the Ni-MH battery is selected.
rAfter the beep sounds, release [PTT].
t Repeat steps wto runtil you select the correct battery type.
NOTE: This operation may not be available, depending on the
presetting. Ask your dealer for details.
[VOL]
[VOL]
[PTT]
[ROTARY SELECTOR]

■Channel selection
Several types of channel selecting methods are available. They
may differ, according to your system set up.
To select a desired operating channel, do one of the following.
• Rotate [ROTARY SELECTOR].
• Push one of memory channel keys, [MR-CH 1] to [MR-CH 4].
AUTOMATIC SCAN TYPE:
Selecting a channel is not necessary for this type. When turning the
power ON, the transceiver automatically starts scanning. Scanning
stops when a call is received.
NOTE: If the Move to Priority A channel at Power ON function
(p. 20) is turned ON, the transceiver does not start scanning at
power ON.
13
3BASIC OPERATION

14
3
BASIC OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
■Call procedure
When your system employs tone signalling (excluding CTCSS and
DTCS), the tone call procedure may be necessary prior to voice
transmission.The tone signalling that is employed in the transceiver
may be a selective calling system, which allows you to call only
specific station(s), and prevent unwanted stations from contacting
you.
qSelect a desired TX code channel or 2/5-Tone code, according
to your System Operator’s instructions.
• This may not be necessary, depending on programming.
wPush [Call] (assigned to one of the dealer programmable keys.)
(p. 10)
eAfter transmitting a 2/5-Tone code, the remainder of your com-
munication can be carried out normally.
Selective calling Non-selective calling

15
3BASIC OPERATION
■Receiving and transmitting
CAUTION: Transmitting without an antenna will damage the
transceiver. See p. 1 for antenna attachment.
Receiving:
qRotate [VOL] to turn power ON.
wRotate [ROTARY SELECTOR], or push one of the memory chan-
nel keys, [MR-CH 1] to [MR-CH 4], to select a channel.
eWhen receiving a call, adjust the audio output to a comfortable
listening level.
NOTE: When a matched RX code signal is received, audio from
the microphone is automatically transmitted for a specified time
period.*
* Depending on the presetting. Ask your dealer for details.
Transmitting:
Wait for the channel to become clear to avoid interference.
qWhile pushing and holding [PTT], speak into the microphone at
a normal voice level.
wRelease [PTT] to return to receive.
IMPORTANT: To maximize the readability of your signal;
1. Pause briefly after pushing [PTT].
2.
Hold the microphone 5 to 10 cm from your mouth, then speak
into the microphone at a normal voice level.
