Iconasys LumiPad 360 LightBox Medium Manual

© Iconasys 2013-2018
Iconasys LumiPad 360 LightBox –Medium: Set up Instructions
Inspect package to ensure all parts/accessories are included
*(note images included are from Small size LightBox):
A. 24 x 24”LED Backlight Panel (please be sure to remove protective film)
B. 4 x 24” LED Tower Light (2X) (please be sure to remove protective film)
C. Tower Light Power Adaptors (2X)
D. Velcro Strips (4X)
E. 1X Acrylic Shooting Stand (please be sure to remove protective film)
F. LED Photo Tent (includes power adaptor)
Please contact us should any parts/accessories be missing
Continued on page 2.
A
B
B
C
D
E
F

© Iconasys 2013-2018
Step 1. Build LED Photo Studio:
Build light tent structure using plastic rods and connectors then place tent over
top of the structure. The opening (front shooting hole) should be at the front of
the studio).
Light Tent Frame
With Light Tent Shell on
frame

© Iconasys 2013-2018
Step 2. Attach Velcro to light panels:
Step 3. Place Velcro on inside of studio in corresponding positons to Velcro on
lights.

© Iconasys 2013-2018
Step 4. Holes will need to be punctured in studio walls to run power
cords/adaptors through in the following locations denoted by ‘+’
Step 5. Place light Panels inside the studio and run power cords/adaptors through
holes.

© Iconasys 2013-2018
Step 6.
If not using Turntable:
6a. Place acrylic shooting stand inside. Note, you will want to raise this stand (we
suggest >4”. In this example we use boxes to raise the stand.
If using Turntable:
6b. Place turntable inside in center of the studio (and if purchased 360 acrylic
riser, place on top of turntable).

© Iconasys 2013-2018
Step 7. Power on lights and get started shooting.
