PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 i
User’s Manual
PBSW-090T
Intel® Braswell Processor
Compact Panel PC with 9” Resistive Touch Screen
PBSW-090T-8A-E8-4G
PBSW-090T-8A-N7-4G
PBSW-090T-8A-N6-4G
PBSW-090T-P8A-E8-4G
PBSW-090T-P8A-N7-4G
PBSW-090T-P8A-N6-4G
(Revision 1.3A)

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 i
REVISION
DATE VERSION DESCRIPTION
2020/07/24 Version 1.0A New Release
2020/11/19 Version 1.1A Correct HSUART Port information.
2020/12/10 Version 1.2A Remove out 5Aversion.
2021/08/26 Version 1.3A Add Projected Capacitive Touch Solution.
2022/01/05 Version 1.4A Correct part numbers for PCAP Solution.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 ii
COPYRIGHT
The information in this manual is subject to change without notice for continuous
improvement in the product. All rights are reserved. The manufacturer assumes no
responsibility for any inaccuracies that may be contained in this document, and
makes no commitment to update or to keep current the information contained in this
manual.
No part of this manual may be reproduced, copied, translated or transmitted, in whole
or in part, in any form or by any means without the prior written permission of the
ICOP Technology Inc.
Copyright 2022 ICOP Technology Inc.
Manual # IUMPBSW090T-01 Ver.1.4A Jan, 2022
TRADEMARKS ACKNOWLEDGMENT
Intel® Apollo Lake is the registered trademark of Intel Corporation. Other brand
names or product names appearing in this document are the properties and
registered trademarks of their respective owners. All names mentioned herewith are
served for identification purpose only.
For more detailed information or if you are interested in other ICOP products, please
visit our official websites at:
Global: www.icop.com.tw
USA: www.icoptech.com
Japan: www.icop.co.jp
Europe: www.icoptech.eu
China: www.icop.com.cn
For technical support or drivers download, please visit our websites at:
https://www.icop.com.tw/resource_entrance
This Manual is for the PBSW-090T series.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 iii
SAFETY INFORMATION
Read these Safety instructions carefully.
Please carry the unit with both hands, handle carefully.
Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
Do not expose your Panel PC to rain or moisture in order to prevent shock and
fire hazard.
Power Input voltage +12~36VDC (Version 8A).
Operating temperature between 0~+50°C (+32~+140°F) for standard, and
optional for -20~+60°C (-4~+158°F).
Keep PBSW-090T away from humidity.
When a M.2 2242 SATA SSD storage is the main operating system storage,
please turn off power before inserting or removing. Do not open the cabinet to
avoid electrical shock. Refer to your nearest dealer for qualified personnel
servicing.
Never touch un-insulated terminals or wire unless your power adaptor is
disconnected.
Locate your Panel PC as close as possible to the socket outline for easy access
and to avoid force caused by entangling of your arms with surrounding cables
from the Panel PC.
USB connectors are not supplied with Limited Power Sources.
If the equipment is not used for a long time, disconnect it from the power source
to avoid damage by transient overvoltage.
WARNING!
DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS (ENCASING)
OF THIS PRODUCT. PLEASE CONTACT YOUR DEALER FOR SERVICING FROM
QUALIFIED TECHNICIAN.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 iv
Content
Content.............................................................................................................................iv
Ch. 1 General Information................................................................................................1
1.1 Product Description ................................................................................................2
1.2 Product Specifications............................................................................................3
1.3 Inspection standard for TFT-LCD Panel..................................................................5
1.4 Product Dimensions................................................................................................9
1.5 Mounting Instruction .............................................................................................11
1.6 Ordering Information.............................................................................................13
Ch. 2 System Installation................................................................................................15
2.1 CPU Board Outline...............................................................................................16
2.2 Connector Summary.............................................................................................17
2.3 Connector Pin Assignments..................................................................................18
2.4 External I/O Overview......................................................................................20
2.5 External I/O Pin Assignment.................................................................................21
Ch. 3 Hardware Installation............................................................................................22
3.1 Installing the M.2 2242 SATA................................................................................23
3.2 Installing the Mini-PCIe Module............................................................................27
3.3 Installing the Micro SIM Card (Must have 3G/4G Mini-PCIe Module in advance).30
Ch. 4 Drivers and BIOS Instruction ................................................................................33
4.1 Operating System Support and Drivers................................................................34
4.2 BIOS Hot Key .......................................................................................................35
4.3 BIOS Boot Mode Select........................................................................................36
4.4 Intel Internal HSUART Setup in BIOS and Driver Install in Windows....................37
4.5 BIOS Load Default Setting....................................................................................43
Warranty.........................................................................................................................44

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 1
Ch. 1
General Information
1.1 Product Description
1.2 Product Specifications
1.3 Inspection standard for TFT-LCD Panel
1.4 Product Dimensions
1.5 Mounting Instruction
1.6 Ordering Information

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 2
1.1 Product Description
ICOP Technology Inc. is proudly going to release a brand new Panel PC, which
offers fanless design, low power consumption, and IP65 front panel. The PBSW-090T is
powered by Intel® Braswell Atom x5-E8000 / Pentium N3710 / Celeron N3160 processor,
and 4GB DDR3L onboard that handles processing more efficiently and provides faster
performance. The project capacity touch panel with LED backlight TFT LCD increases
operation convenience and visibility in outdoor environments. The ultra-compact and thin
exterior design is perfect for the present demanding embedded and productive
applications.
The new PBSW-090T inherited PBSW series’ smooth appearance and ultra-texture
aluminum exterior design to make your industrial applications look more stylish. The
versatile I/O ports, IP65 front panel, GIGA high-speed Ethernet etc. can fulfill fundamental
functions. Our consistent advantages feature stable performance, extended working
temperature support, low power consumption and fanless design. The expandable
customize I/O ports can be accommodated connectivity requirements to industrial machine
platforms and industrial automation equipment’s needs.
The PBSW-090T supports Win7 (64-bit), Windows Embedded 7, Windows 10 (64-bit),
Windows 10 IoT and Linux to meet ready-to-market demand and provide competitive
advantages for customers.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 3
1.2 Product Specifications
CPU BOARD SPECIFICATIONS
CPU
Intel® x5-E8000 (Quad core 1.04GHz; Burst 2.00GHz)
Intel® N3710 (Quad core 1.60GHz; Burst 2.56GHz)
Intel® N3160 (Quad core 1.60GHz; Burst 2.24GHz)
Cache
L2: 2MB Cache
BIOS
AMI BIOS
Memory
4GB DDR3L Onboard
Display
Intel® HD Graphics
LAN
Integrated 10/100/1000Mbps Ethernet x 1
Audio
HD Audio-Realtek ALC262VD CODEC
Internal Drives
M.2 Slot Support (M-Key, SATA Interface, 2242)
Expansion
MiniPCIe Slot x1, Micro SIM Card Holder x1
I/O
HSUART x 1
USB3.0 x 2
RJ45 x 1
Audio-Out x 1
MECHANICAL & ENVIRONMENT
Power Requirement
8A: +12 ~ 36VDC Power Input
Power Consumption
12W (Typical for x5-E8000 without I/O)
Operating Temperature
0~+50°C (+32~+140°F) /
-20~+60°C (-4~+158°F; Optional)
Storage Temperature
-30~+80°C (-22~ +176°F)
Operating Humidity
0% ~ 90% Relative Humidity, Non-Condensing
Dimensions
236.6x146x35mm (9.31"x5.75"x1.38")
Weight
880g

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 4
Protection
IP65 Front Panel
Certification
CE / FCC / VCCI / Vibration/ Shock
LCD SPECIFICATIONS
Display Type
9” WSVGATFT LCD
Backlight Unit
LED
Display Resolution
1024(W) x 600(H)
Brightness (cd/m2)
300 nits
Contrast Ratio
500 : 1
Display Color
262,144
Active Area (mm)
196.61 (W) x 114.15 (H)
Viewing Angle
Vertical 120o, Horizontal 140o
Backlight Lifetime
20,000 hrs
TOUCHSCREEN
Type1
Analog Resistive (Standard)
Resolution
Continuous
Transmittance
80%
Controller
USB interface
Software Driver
Linux, Win7, WES7, Win10, Win10 IoT
Durability
1 million
Type2
Projected Capacitive Touch Screen (Optional)
Resolution
25ppi (Min.)
Transparency
86% ± 2%
Accuracy
Within 2.5mm each target
Surface Hardness
≧7H (Pressure：0.5N/45°)

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 5
1.3 Inspection standard for TFT-LCD Panel
DEFECT TYPE
LIMIT
Note
VISUAL
DEFECT
INTERNAL
SPOT
φ＜0.15mm
Ignore
Note1
0.15mm≦φ≦0.5mm
N≦4
0.5mm＜φ
N=0
FIBER
0.03mm<W≦0.1mm, L≦5mm
N≦3
Note1
1.0mm＜W, 1.5mm＜L
N=0
POLARIZER
BUBBLE
φ＜0.15mm
Ignore
Note1
0.15mm≦φ≦0.5mm
N≦2
0.5mm＜φ
N=0
Mura
It’ OK if mura is slight visible through 6%ND filter
ELECTRICA
L DEFECT
BRIGHT DOT
A Grade
B Grade
C Area
O Area
Total
C Area
O Area
Total
Note3
N≦0
N≦2
N≦2
N≦2
N≦3
N≦5
Note2
DARK DOT
N≦2
N≦3
N≦3
N≦3
N≦5
N≦8
TOTAL DOT
N≦4
N≦5
N≦6
N≦8
Note2
TWO ADJACENT DOT
N≦0
N≦1 pair
N≦1 pair
N≦1 pair
N≦1 pair
N≦1 pair
Note4
THREE OR MORE
ADJACENT DOT
NOT ALLOWED
LINE DEFECT
NOT ALLOWED
(1) One pixel consists of 3 sub-pixels, including R, G, and B dot. (Sub-pixel = Dot)
(2) Little bright Dot acceptitable under 6% ND-Filter.
(3) If require G0 grand (Total dot N≦0), please contact region sales.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 6
[ Note 1 ] W: Width[mm]; L: Length[mm]; N: Number; φ: Average Diameter.
(a) White / Black Spot (b) Polarizer Bubble
[ Note 2 ] Bright dot is defined through 6% transmission ND Filter as following.
[ Note 3 ] Display area
C Area: Center of display area O Area: Outer of display area

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 7
[ Note 4 ] Judge the defect dot and the adjacent dot as following. Allow below (as A, B, C and
D status) adjacent defect dots, including bright and dark adjacent dot.And they will be counted
2 defect dots in total quantity.
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
RDefect Dot
Adjacent Dot
A
B
C
D
The defects that are not defined above and considered to be problem shall be reviewed
and discussed by both parties.
Defects on the Black Matrix, out of Display area, are not considered as a defect or counted.
[Note 5]
According to the technical information from LCD manufacturer, the image retention may
happen on LCD display if the static image is kept for a period of time without any change. ICOP
will suggest customers not to have static image on LCD for over 4 hours without any image
movement and also enable screensaver to avoid image sticking issue if LCD displays need to be
kept on for a long time.
Some Image retention issue will disappear when LCD display is turned off for a period of time,
but some image retention may be not reversible when LCD encounters screen burn.
The following is LCD manufacturer’s test result for customers’ reference.
TEST ITEMS
CONDITIONS
NOTE
High Temperature Operation
70℃;240hrs
High Temperature Storage
80℃; 240hrs
High Temperature High
Humidity Operation
60℃; 90%RH ;240hrs
No condensation
Low Temperature Operation
-20℃; 240hrs
Backlight unit always
turn on
Low Temperature Storage
-30℃; 240hrs
Thermal Shock
–30℃(0.5hr) ~
80℃(0.5hr) ; 200 Cycles
Image Sticking
25℃; 4hrs
Note 5-1
MTBF
20,000Hrs

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 8
Note 5-1
1. Condition of Image Sticking test：25 ℃± 2 ℃.
2. Operation with test pattern sustained for 4 hrs, then change to gray pattern immediately.
3. After 5 mins, the mura must be disappeared completely.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 9
1.4 Product Dimensions

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 10

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 11
1.5 Mounting Instruction
Panel Mounting
Cut a mounting hole in the panel. (Refer to PBSW‐090T Dimensions on page 10) (Note 1)
Check and remove the twelve M3 screws in a diagonal pattern as image below if necessary.
Place PBSW‐090T face‐down on a clean, flat surface.
Slide the panel cutout around the back of PBSW‐090T, until the panel rests directly on the
gasket. Make sure the screw holes align with the screw holes on PBSW‐090T.
The screw size is M3*L (L=wall thickness + 6.0mm) (Note 2)
Insert all twelve M3 screws into the screw holes. (Note 2)
Finger-tighten the M3 screws. Finish tightening the M3 screws in a diagonal pattern using an M3
screw driver (see the image as below); maximum torque 1.18Nm (12 kgf‐cm).

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 12
Note 1:
It is strongly recommended that a professional machine shop cut the mounting hole
in the panel.
Note 2:
The length for all twelve M3 screws will be according to the thickness of mounting panel. For
example: The length of standard M3 screws for PBSW‐090T is 6mm. If the thickness of your
mounting panel is 3mm and washer thickness is 1mm, you have to use 10mm M3 screw.

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 13
1.6 Ordering Information
Product
Code
LCD
Size
DC-Input Type
CPU
Type
RAM
Wide
Temp.
PBSW
090T
8A (DC12~36V)
P8A (PCAP w/DC12-36V)
E8
N7
N6
4G
I (Wide
Temp.)
1. Product Code：
PBSW：PBSW Series。
2. LCD Size：
090T：9” LCD Panel。
3. DC-Input Type :
8A：Audio Line-out and Support DC12~36V Power Input。
P8A：PCAP Touch Panel with Audio Line-out and Support DC12~36V Power Input。
4. CPU Type:
E8：Intel Braswell Atom x5-E8000 Processor with Resistive Touch。
N7：Intel Braswell Pentium N3710 Processor with Resistive Touch。
N6：Intel Braswell Celeron N3160 Processor with Resistive Touch。
5. RAM：
4G：4GB。
6. Wide Temp.：
I：Support Wide Temp. -20~+60℃。(Optional)
(Standard version doesn’t need to show this item.)

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 14
PART NUMBER
DESCRIPTION
PBSW-090T-8A-E8-4G
9" Panel PC w/Intel Braswell x5-E8000/4GB DRAM
/2U/Giga LAN/1S/RTP/DC12~36V Power Input
PBSW-090T-8A-N7-4G
9" Panel PC w/Intel Braswell N3710/4GB DRAM
/2U/Giga LAN/1S/RTP/DC12~36V Power Input
PBSW-090T-8A-N6-4G
9" Panel PC w/Intel Braswell N3160/4GB DRAM
/2U/Giga LAN/1S/RTP/DC12~36V Power Input
PBSW-090T-P8A-E8-4G
9" Panel PC w/Intel Braswell x5-E8000/4GB DRAM
/2U/Giga LAN/1S/PCAP/DC12~36V Power Input
PBSW-090T-P8A-N7-4G
9" Panel PC w/Intel Braswell N3710/4GB DRAM
/2U/Giga LAN/1S/PCAP/DC12~36V Power Input
PBSW-090T-P8A-N6-4G
9" Panel PC w/Intel Braswell N3160/4GB DRAM
/2U/Giga LAN/1S/PCAP/DC12~36V Power Input
WLAN KIT (Optional)
MINIPCIE-WLAN-159H (or 161H) x1
CASE-H2F-MINIPCIE x1
WIRELESS-ANTENNA-157 x1
WIRELESS-CABLE-UFL x1

PBSW-090T User’s Manual IUMPBSW090T-01 Ver.1.4A Jan, 2022 15
Ch. 2
System Installation
2.1 CPU Board Outline
2.2 Connector Summary
2.3 Connector Pin Assignments
2.4 External I/O Overview
2.5 External I/O Pin Assignment
