ICOP Technology PPC-090T-PD2N5NG5CGP User manual

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 i
User’s Manual
PPC-090T
DMP Vortex86 DX2 / DX3 Processor
Compact Panel PC with 9” Touchscreen
PPC-090T-D2 Series with DX2 processor
PPC-090T-D3 Series with DX3 processor
(Revision 1.12A)

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 i
REVISION
DATE VERSION DESCRIPTION
2014/1/22 Version 1.0A New Release
2014/3/11 Version 1.1A Add 4.3 Serial Ports Setting (RS232/422/485)
2015/9/15 Version 1.2A Change the SPEC of Section 3.1
1. Add the type with 2GB DRAM solution
2016/1/6 Version 1.3A 2. Correct LED backlight lifetime
3. Doesn't support DOS Touch Driver
1. Change J33~J36 connectors as optional
2016/4/28 Version 1.4A (They are for I/O Extension board.)
2. Add the information of DX3 & extension board.
3. Correct the weight of whole system.
2016/10/19 Version 1.5A 1. Add USB WLAN solution as optional.
2. Add the ordering information of SATA SLIM
storage.
2016/11/05 Version 1.6A Correct 16bit GPIO port on section 5.1.
2016/11/30 Version 1.7A Correct 16bit GPIO port on section 5.2.
2016/12/19 Version 1.8A Specification correction
1. Panel mounting: M3 screws maximum torque
0.44Nm (4.5 kgf‐cm).
2017/04/13 Version 1.9A 2. Add serial number code on section 1.6.
3. Add pin assignment for PoE on RJ45.
4. Add IEE 802.3at standard PoE+ pinout on
section 5.2
5. Specification correction

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 ii
DATE VERSION DESCRIPTION
2018/06/08 Version 1.10A Correct the PoE+ pinout on section 5.2
2019/07/30 Version 1.11A Add section 1.3 [Note 5] instruction
2021/08/31 Version 1.12A Add Projected Capacitive Touch Solution

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 i
COPYRIGHT
The information in this manual is subject to change without notice for
continuous improvement in the product. All rights are reserved. The
manufacturer assumes no responsibility for any inaccuracies that may
be contained in this document, and makes no commitment to update or
to keep current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or
transmitted, in whole or in part, in any form or by any means without the
prior written permission of the ICOP Technology Inc.
Copyright 2021 ICOP Technology Inc.
Manual # IUMPPC090T-01 Ver.1.12A Aug, 2021
TRADEMARKS ACKNOWLEDGMENT
Vortex86DX2and Vortex86DX3are the registered trademark of DMP
Electronics Inc. Other brand names or product names appearing in this
document are the properties and registered trademarks of their
respective owners. All names mentioned herewith are served for
identification purpose only.
For more detailed information or if you are interested in other ICOP
products, please visit our official websites at:
Global: www.icop.com.tw
USA: www.icoptech.com
Japan: www.icop.co.jp
BV: www.icoptech.eu
China: www.icop.com.cn
For technical support or demo images of operating systems download,
please visit our websites at:
ICOP Technical Resource: http://tech.icop.com.tw/
Software Support: http://www.icoptech.net/
This Manual is for the PPC-090T.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 ii
SAFETY INFORMATION
Read these Safety instructions carefully.
Please carry the unit with both hands, handle carefully.
Make sure the voltage of the power source is correct before
connecting the equipment to the power outlet.
Do not expose your Panel PC to rain or moisture in order to prevent
shock and fire hazard.
Input voltage rated +12 ~ 24 VDC
Operating temperature between 0~+50°C (+32~+122°F).
Keep PPC-090T away from humidity.
When a Compact Flash Card or a SATA Slim is the main operating
system storage, please turn off power before inserting or removing.
Do not open the cabinet to avoid electrical shock. Refer to your
nearest dealer for qualified personnel servicing.
Never touch un-insulated terminals or wire unless your power
adaptor is disconnected.
Locate your Panel PC as close as possible to the socket outline for
easy access and to avoid force caused by entangling of your arms
with surrounding cables from the Panel PC.
USB connectors are not supplied with Limited Power Sources.
If the equipment is not used for a long time, disconnect it from the
power source to avoid damage by transient overvoltage.
WARNING!
DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS
(ENCASING) OF THIS PRODUCT. PLEASE CONTACT YOUR DEALER
FOR SERVICING FROM QUALIFIED TECHNICIAN.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 iii
Content
Content ....................................................................................................... iii
Ch. 1 General Information............................................................................1
1.1 Product Description ............................................................................2
1.2 Product Specifications ........................................................................3
1.3 Inspection standard for TFT-LCD Panel..............................................6
1.4 Product Dimensions..........................................................................10
1.5 Panel Mounting Instruction ...............................................................12
1.6 Ordering Information.........................................................................14
Ch. 2 System Installation............................................................................16
2.1 CPU Board Outline...........................................................................17
2.2 Connector Summary.........................................................................18
2.3 Connector Pin Assignments..............................................................19
2.4 External I/O Overview.......................................................................21
2.5 External I/O Pin Assignment.............................................................22
2.6 Watchdog Timer................................................................................23
Ch. 3 Hardware Installation........................................................................24
3.1 Installing the SATASlim....................................................................25
3.2 Installing the Compact Flash.............................................................27
Ch. 4 Driver Installation..............................................................................28
4.1 PPC-090T Development Note ..........................................................30
4.2 BIOS Default Setting.........................................................................31
4.3 Serial Ports Setting (RS232/422/485)...............................................32
Ch. 5 Extension I/O (Optional)....................................................................39
5.1 Extension I/O Overview (Optional)....................................................40
5.2 Extension I/O Pin Assignment (Optional)..........................................41
Warranty.....................................................................................................42

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 1
Ch. 1
General Information
1.1 Product Description
1.2 Product Specifications
1.3 Inspection standard for TFT-LCD Panel
1.4 Product Dimensions
1.5 Mounting Instruction
1.6 Ordering Information

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 2
1.1 Product Description
ICOP Technology Inc. is proudly going to release a brand new Panel PC, which
offers fanless design, low power consumption, and IP65 front panel. The PPC-090T is
powered by DMP’s Vortex86DX2 and DX3 SoCs, the 3rd generation SoCs of Vortex86
family, and dual-channel 1GB / 2GB DDRII (DDDRIII) chipset that handles processing
more efficiently and provides faster performance. The resistive touch panel with LED
backlight TFT LCD increases operation convenience and visibility in outdoor
environments. The ultra-compact and thin exterior design is perfect for the present
demanding embedded and productive applications.
The new PPC-090T inherited PDX/PMX-series’ smooth appearance and ultra-texture
aluminum exterior design to make your industrial applications look more stylish. The
versatile I/O ports, IP65 front panel, 10/100Mps Ethernet, GIGA high-speed Ethernet,
WLAN, etc. can fulfill fundamental functions. Our consistent advantages feature stable
performance, extended working temperature support, low power consumption and fanless
design. The expandable customize I/O ports can be accommodated connectivity
requirements to industrial machine platforms and industrial automation equipment’s needs.
The PPC-090T supports Windows Embedded CE 6.0, Windows Embedded Compact 7,
Windows Embedded Standard 2009, Windows Embedded Standard 7 and Linux to meet
ready-to-market demand and provide competitive advantages for customers.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 3
1.2 Product Specifications
CPU BOARD SPECIFICATIONS
CPU DM&P Vortex86DX2- 933MHz / DX3-1GHz
Cache
DX2: L1:16KB I-Cache, 16KB D-Cache
L2: 256KB Cache
DX3: L1:32KB I-Cache, 32KB D-Cache
L2: 512KB Cache
BIOS AMI BIOS
Memory 512MB/1GB/2GB DDR2(DDR3) onboard
Watchdog Timer Software Programmable from
30.5u to 512 seconds x 2 sets
LAN Integrated 10/100M Ethernet X1
Giga Ethernet (Optional) X1
PoE (Optional) Optional upon 10/100Mbps Ethernet x 1
Support IEEE 802.3AT
Audio HD Audio-Realtek ALC262 CODEC
Internal Drives Compact Flash Type I / II Slot
SATA SLIM, SD Slot (Optional)
I/O
RS-232/422/485 x 2
USB Ports (Ver2.0) x 3
PS/2 KB
Audio-Out
RJ-45 Port x 1
GIGA Ethernet Port X 1 (Optional)
MECHANICAL & ENVIRONMENT
Power Requirement +12 ~ 24VDC
Power Consumption +24VDC@ 1A
Operating Temperature 0~+50°C (+32~+122°F) /

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 4
-20~+60°C (-4~+140°F; DX2 with 800MHz)
Storage Temperature -30~+70°C (-22~ +158°F)
Operating Humidity 0% ~ 90% Relative Humidity, Non-Condensing
Dimensions 242x156.5x44mm (9.68"x6.26"x1.76")
Weight 1.36 Kg
Protection IP65 Front Panel
Certification CE / FCC / VCCI / Vibration / Shock
LCD SPECIFICATIONS
Display Type 9” WSVGATFT LCD
Backlight Unit LED
Display Resolution 1024(W) x 600(H)
Brightness (cd/m2) 300 nits
Contrast Ratio 500 : 1
Display Color 262,144
Pixel Pitch (mm) 190.5 (H) x 189 (V)
Viewing Angle Vertical 120o, Horizontal 140o
Backlight Lifetime 18,000 hrs
TOUCHSCREEN
Type1 Analog Resistive
Resolution Continuous
Transmittance 80%
Controller PS/2 interface
Software Driver Linux, Win CE, Win XP, Win 7,
Windows Embedded Standard
Durability 1 million

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 5
Type2 Projected Capacitive Touch Screen (Optional)
Resolution 25ppi (Min.)
Transparency 86% ± 2%
Accuracy Within 2.5mm each target
Surface Hardness ≧7H (Pressure：0.5N/45°)

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 6
1.3 Inspection standard for TFT-LCD Panel
DEFECT TYPE LIMIT Note
VISUAL
DEFECT INTERNAL
SPOT
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦4
0.5mm＜φN=0
FIBER 0.03mm<W≦0.1mm, L≦5mm N≦3 Note1
1.0mm＜W, 1.5mm＜L N=0
POLARIZER
BUBBLE
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦2
0.5mm＜φN=0
Mura It’ OK if mura is slight visible through 6%ND filter
ELECTRICA
L DEFECT
BRIGHT DOT
A Grade B Grade
C Area O Area Total C Area O Area Total Note3
N≦0 N≦2 N≦2 N≦2 N≦3 N≦5 Note2
DARK DOT N≦2 N≦3 N≦3 N≦3 N≦5 N≦8
TOTAL DOT N≦4 N≦5 N≦6 N≦8 Note2
TWO ADJACENT DOT N≦0 N≦1 pair N≦1 pair N≦1 pair N≦1 pair N≦1 pair Note4
THREE OR MORE
ADJACENT DOT NOT ALLOWED
LINE DEFECT NOT ALLOWED
(1) One pixel consists of 3 sub-pixels, including R, G, and B dot. (Sub-pixel = Dot)
(2) Little bright Dot acceptitable under 6% ND-Filter.
(3) If require G0 grand (Total dot N≦0), please contact region sales.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 7
[ Note 1 ] W: Width[mm]; L: Length[mm]; N: Number; φ: Average Diameter.
(a) White / Black Spot (b) Polarizer Bubble
[ Note 2 ] Bright dot is defined through 6% transmission ND Filter as following.
[ Note 3 ] Display area
C Area: Center of display area O Area: Outer of display area

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 8
[ Note 4 ] Judge the defect dot and the adjacent dot as following. Allow below (as A, B, C and
D status) adjacent defect dots, including bright and dark adjacent dot. And they will be counted
2 defect dots in total quantity.
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
RGＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
RDefect Dot
Adjacent Dot
A
B
C
D
The defects that are not defined above and considered to be problem shall be reviewed
and discussed by both parties.
Defects on the Black Matrix, out of Display area, are not considered as a defect or counted.
[Note 5]
According to the technical information from LCD manufacturer, the image retention may
happen on LCD display if the static image is kept for a period of time without any change. ICOP
will suggest customers not to have static image on LCD for over 4 hours without any image
movement and also enable screensaver to avoid image sticking issue if LCD displays need to be
kept on for a long time.
Some Image retention issue will disappear when LCD display is turned off for a period of time,
but some image retention may be not reversible when LCD encounters screen burn.
The following is LCD manufacturer’s test result for customers’ reference.
TEST ITEMS CONDITIONS NOTE
High Temperature Operation 70℃;240hrs
High Temperature Storage 80℃; 240hrs
High Temperature High
Humidity Operation 60℃; 90%RH ;240hrs No condensation
Low Temperature Operation -20℃; 240hrs Backlight unit always
turn on
Low Temperature Storage -30℃; 240hrs
Thermal Shock –30℃(0.5hr) ~
80℃(0.5hr) ; 200 Cycles
Image Sticking 25℃; 4hrs Note 5-1
MTBF 20,000Hrs

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 9
Note 5-1
1. Condition of Image Sticking test：25 ℃± 2 ℃.
2. Operation with test pattern sustained for 4 hrs, then change to gray pattern immediately.
3. After 5 mins, the mura must be disappeared completely.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 10
1.4 Product Dimensions

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 11

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 12
1.5 Panel Mounting Instruction
1. Cut a mounting hole in the panel. (Refer to PPC‐090T Dimensions on page
11~12.) (Note 1)
2. Check and remove the twelve M3 screws in a diagonal pattern as image below if
necessary.
3. Place PPC‐090T face‐down on a clean, flat surface.
4. Slide the panel cutout around the back of PPC‐090T, until the panel rests
directly on the gasket. Make sure the screw holes align with the screw holes on
PPC‐090T.
5. The screw size is M3*L (L=wall thickness + 6.0mm) (Note 2)
6. Insert all twelve M3 screws into the screw holes. (Note 2)
7. Finger-tighten the M3 screws. Finish tightening the M3 screws in a diagonal
pattern using an M3 screw driver (see the image as below); maximum torque
0.44Nm (4.5 kgf‐cm).

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 13
Note 1:
It is strongly recommended that a professional machine shop cut the mounting hole in
the panel.
Note 2:
The length for all twelve M3 screws will be according to the thickness of mounting
panel. For example: The length of standard M3 screws for PPC-090T is 6mm. If the
thickness of your mounting panel is 3mm and washer thickness is 1mm, you have to
use 10mm M3 screw.

PPC-090T User’s Manual IUMPPC090T-01 Ver.1.12A Aug, 2021 14
1.6 Ordering Information
Product
Code
LCD
Size
CPU Type
CPU Clock
RAM
Flash
onboard
I/O
PPC 090T D2 (DX2)
D3 (DX3)
PD2 (DX2 + 9” PCAP)
PD3 (DX3 + 9” PCAP)
W(800MH)
N(933MHz)
G (1GHz)
D (1GHz with wide
temp.)
3 (512B)
4 (1GB)
5 (2GB)
N (No Flash)
A (256MB)
B (512MB)
C (1GB)
D (2GB)
E (4GB)
GE (GigaLAN)
G7C (GigaLAN + 7 COMs)
G7CP (GigaLAN + 7 COMs + PoE)
G5CG (GigaLAN + 5 COMs + 16bit GPIO)
G5CGP (GigaLAN + 5 COMs + 16bit GPIO + PoE)
7C (7 COMs)
7CP (7 COMs + PoE)
5CG (5 COMs + 16bit GPIO)
5CGP (5 COMs + 16bit GPIO + PoE)
1. Product Code：
PPC：Panel PC Series。
2. LCD Size：
090T：9” LCD Panel。
3. CPU Type：
D2：Vortex86DX2 CPU with Resistive Touch。
D3：Vortex86DX3 CPU with Resistive Touch。
PD2：Vortex86DX2 CPU with PCAP Touch。
PD3：Vortex86DX3 CPU with PCAP Touch。
4. CPU Clock：
3：300MHz。8：800MHz。W：800MHz。N：933M
G：1GHz。D：1GHz with wide temp -20~60℃。(DX3 only)
5. RAM：
3：512MB。4：1GB。5：2GB。
6. Flash Onboard：
N：No Flash。A：256MB。B：512MB。C：1GB。D：2GB。
E：4GB。
7. I/O Code：
GE or G：Giga Ethernet (GbE)。
5C：Total 5 COM ports。(Standard 2 COMs + Extension board -> 3 COMs)
7C：Total 7 COM ports。(Standard 2 COMs + Extension board -> 5 COMs)
G：16bit of GPIO port。(Extension board -> 16bit of GPIO)
P：PoE Function。(Extension board -> PoE)
