ICP DAS USA M2M-711D Installation guide

TM
M2M-711D
FAQ
Version 1.00

Table of Contents
Q01: If I forget the M2M-711D’s Ethernet IP, how can I set and operate the
M2M-711D by web browser?..........................................................................................3
Q02: Client cannot connect to Server.......................................................................5
Q03: Server and Client can’t establish Com Port connection. .......................8
Q04: Can the M2M-711D operate in both Ad-Hoc and Infrastructure
modes simultaneously?..................................................................................................9
Q05: What to do if M2M-711D does not work in AP mode? .......................... 10
Q06: How to configure M2M-711D in Ad-Hoc mode and connect it by a PC?
................................................................................................................................................. 11

FAQ
Q01: If I forget the M2M-711D’s Ethernet IP, how can I
set and operate the M2M-711D by web browser?
A01：
(1) ：Please reset system.
(2) : In Ethernet mode, the Ethernet IP address will show again.
Display Ethernet IP address in Ethernet mode

(3) : In Wi-Fi/Ad Hoc mode, the Ethernet IP address will show again.
(4)：Init M2M-711D reference 2.3. Default value of Ethernet IP address
is 192.168.1.217

Q02: Client cannot connect to Server.
A02: Please follow the following steps to check that the network
configuration is correct.
Step 1: Check IP of Server and Client is the only. The IP is not the same
with the other network device.
Step 2: Please confirm the network configurations are correct. The
configurations include IP Address, Net Mask, Gateway and
DNS Server. If the configurations are all correct, it should
respond to the ping command from PC.
Check IP Config in Ethernet mode

Check IP Config in Wi-Fi mode
Step 3: Please confirm that the following settings are correct.
“Server IP” of Client is the same with “IP Address” of Server.
“Listen Port” of Server and “Communication Port” Client are
the same.
“Client Name” of Server and “Host Name” Client are the
same.

Client’s “Standard Config” page
Server’s “Standard Config” page

Q03: Server and Client can’t establish Com Port
connection.
A3: Please follow the steps to check below.
Step 1: Confirm client’s name is the same as server permission name
list.
Step 2: Confirm comport setting of server and client. Server comport
setting must the same setting as client.
Comport setting of server

Comport setting of client
Step 3: Does the inspection wiring have the question?
Q04: Can the M2M-711D operate in both Ad-Hoc and
Infrastructure modes simultaneously?
A04:
M2M-711D can't operate in both AP and Ad-Hoc modes simultaneously.

Q05: What to do if M2M-711D does not work in AP
mode?
A05:
Follow these steps to check.
We suppose the VxServer IP= 192.168.100.100, M2M-711D Wi-Fi IP=
192.168.200.200, and Wi-Fi Mask=255.255.0.0.
Step1: Let other PC(via the company wireless network) does ping
"192.168.100.100"( VxServer IP).
And let VxServer in PC(via the company wireless network) does ping
"192.168.200.200"( IP of other PC).
The transmission structure as show.
Other PC(IP=192.168.200.200) <==> Wi-Fi AP(company wireless net) <==>
VxServer in PC (IP=192.168.100.100)
Step 2: M2M-711D replaces other PC. The network setting of M2M-711D must
be same the network setting of other PC.
( Note: Server IP must be "192.168.100.100" in “standard config” page of
M2M-711D.)
Step 3: Open VxServer and modify local IP="192.168.100.100". If it does
without any M2M-711D on line, please close the firewall of windows.
If these step does not fix the problem, please contact us.

Q06: How to configure M2M-711D in Ad-Hoc mode and
connect it by a PC?
A06:
Step1: Set Ad Hoc mode in M2M-711D. About Ad Hoc mode setting, please
refer to the manual page 36th "3.3.4 Wireless Config".
We suppose the Server IP= 192.168.100.100, SSID=ICPDAS, Wi-Fi IP=
192.168.200.200, and Wi-Fi Mask=255.255.0.0.
Step2: Let your computer build Ad hoc network with M2M-711D.
Click on the wireless network list of your computer.
As show. And then Click on the "Connect" in ICPDAS wireless network.

Step3: Set network setting of PC. The IP must be "192.168.100.100", the
netmask must be "255.255.0.0".
Step4: Open VxServer and modify local IP="192.168.100.100". If it does
without any M2M-711D on line, please close the firewall of windows.
If these steps does not fix the problem, please contact us.
