ICS Auto Passport User manual

Auto Passport®
with the RFID All-In-One Reader/ Antenna
for the Auto Sentry® Petro
Installation Guide - Version 3.0
November 8, 2019

Auto Passport Installation GuidePage 1 Copyright © Innovative Control Systems, Inc.
Installation Overview
Thank you for purchasing your Auto Passport, the ICS® radio frequency identication system. This document was written for technicians
and electricans installing the Auto Passport. A thorough understanding of electrical wiring, installation, codes, and safety protocols is
required. No prior experience with the Auto Passport is necessary. By reading the information and performing the procedures in this
installation guide, you should be able to install the Auto Passport system-level and communications wiring.
NOTE:The Auto Passport is not a stand-alone system. WashConnect and a connection to an Auto Sentry is required.
System Components
The protective enclosure houses the RFID reader and antenna.
One All-In-One RFID Reader / Antenna Enclosure per lane is
to be installed on an overhead truss or canopy above the lane
near the Auto Sentry Petro so vehicles can drive underneath
it.
The RFID All-In-One Reader/Antenna power and data cable
terminates at the terminal blocks located in the base of Auto
Sentry Petro.
The RFID All-in-One Cable is 35’ in length.
Truss Size Information
Trusses are available in two sizes:
A 95-inch truss to be installed on curbs or raised islands.
A 100-inch truss to be installed on ground-level surfaces.
This guide should be supplied to the electrician prior to the installation of
conduits and wiring to ensure the Auto Passport is installed properly. Faulty
installations are the major cause of system malfunctions. The Auto Passport
must be installed exactly as described in this installation guide to ensure its
reliability and safe operation.
WARNING: Failure to properly install the Auto Passport could result
in serious injury or death and will void the warranty.
Version Considerations
This version 3.0 of the installation guide, released on
November 5, 2019. WashConnect Software version of 1.6.7 or higher.
Site Planning
Careful planning for the layout of the site will help eliminate possible
problems with the start-up of your system and will ensure continued,
reliable system operation. In determining the location stage, keep the
following objectives in mind:
The Auto Passport has been designed to operate in an
outdoor environment.
Figure 1. RFID All-In-One Reader / Antenna Enclosure
Figure 2. Internal view of Enclosure
displaying the RFID Reader Card
Figure 3. RFID All-In-One Cable

Auto Passport Installation GuidePage 2 Copyright © Innovative Control Systems, Inc.
Hardware Specs
The Auto Passport is designed to be located in all types of conditions, cold, wet, or hot.
The unit has been designed to operate in the temperature range of -20° F to120° F (-28 °C to 48 °C).
The RFID Antenna enclosure is mounted on a truss that is bolted to the concrete oor.
Dedicated universal power supply (UPS): 1500VA/865 Watts output capacity.
RFID All-In-One Reader / Antenna Enclosure Equipment Measurements, and Ratings:
Planning for Installation
Prepare to have all the necessary tools and parts.
Ensure Auto Sentry island specications are met.
Ensure permanent connections are performed by a licensed electrician who must comply with the National and Local
recommended standards.
Dimension Amount
Width 10 - 1/2 in / 26.7 cm
Length 30 in / 76.2 cm
Depth 5- 1/2 in / 13.9 cm
Weight 30.0 lbs / 13.6 kg
Operating Temp. Range -20° F to 120° F -28° C to 48° C
Frequency 902.75 – 927.25 MHz
Supply Voltage 24V AC
Max. Current 10 Amps @ 120 V AC
RF Power Max 4 watts EIRP with antenna
Table 1: Auto Passport RFID Reader/Antenna Measurements, and Ratings
Wiring can be contained in rigid PVC conduit or metal conduit.
High-voltage (AC) and low-voltage (DC) must not be combined in a common conduit, junction box, or wire trough.
Power for the Auto Passport and any peripherals must come from the dedicated UPS, as supplied by ICS, and must be
properly grounded.
Check through all shipping containers before disposing of them looking for possible manuals, cables, connectors, etc..
Warning Markings
Technical Support
Innovative Control Systems® provides a phone number for customers and installers for installation questions: 800-246-3469.
!
The symbol on the left is labeled on equipment and hardware
to indicate one should consult accompanying documentation
before proceeding.

Auto Passport Installation GuidePage 3 Copyright © Innovative Control Systems, Inc.
Auto Sentry Petro Island Specications
NOTE 1: The length of the island should be determined by the car wash owner, but ICS recommends that the island be
a minimum of 18’ - 0” in length. This will provide for adequate space for the proper placement of the Auto Sentry and
its gate. If menu signs and other items are to be installed on the island, then it is the car wash owner’s responsibility to
increase the length of the island to accommodate these additional items. See Figure 4.
NOTE #2: ICS highly recommends that the width of the islands be a minimum of 4’- 6” for the safety of the attendants
when servicing. This measurement, along with the proper placement of the Auto Sentry, will prevent the rear of the Auto
Sentry from hanging over into another drive-thru lane and provides ample room for vehicles to pass through the lanes
without striking the rear of an Auto Sentry.
NOTE #3: The height of the island, above the nal nished grade upon which a vehicle will rest, must be 6”. This will
ensure that the Auto Sentry is at the optimum height for customers using the Auto Sentry while seated in their vehicles.
NOTE #4: At the car wash owner’s discretion, the installation of bollards at the entrance end of the island is highly
recommended and will minimize the chances of vehicles striking and damaging an Auto Sentry or Trac gate.
Bollards should be located so that they provide protection to ICS equipment but also oer ample clearance so that the
equipment can be easily installed and maintained.
NOTE #5: Any canopy that is above both the Auto Sentry and the optional Trac Gate must be a minimum of 12’ - 6”
from the base of the gate to the bottom of the canopy to allow the gate to open fully without striking the canopy.
NOTE #7: WARNING: (If optional Gates are installed) Do not install bollards or any equipment within 20”clearance of the
gate housing and gate arm. This is to prevent crushing and allow the gate arm to break away properly.
Figure 4. Auto Sentry Petro Island Specications
14"
16"
5"
8"
8"8"
THE RE SHOU LD BE A MI NIM UM
OF 24 " DI AM ETER O F CLE AR AN CE
FROM THE CENTER OF THE GATE
IN ALL DIREC TIO NS.
1' - 0"
10'- 0"
FOOTPRINT OF
A UT O S EN TR Y
PETRO
2' - 0"
C
L
C
L
C
L
C
L
MINIMALLY 18' - 0"
SEE NOTE #1
4'-6"
SEE NOTE #2
3" DIA. CONCRETE FILLE D
BOLLARD (TYPICAL)
SEE NOTE #3
AUTO SENTRY PETRO ISLAND DETAIL
(TOP VIEW)
TRAFFIC
GAT E
OF TR AVE L
DIRECTION
OF TR AVE L
DIRECTION
NOTE #1: THE LENGTH OF THE ISLAND S HOULD BE DETERMINE D BY THE CAR WASH OWNER, BUT ICS RECOMMENDS T HAT THE ISLAND BE A MINIMUM OF 18 ' - 0" IN LENGTH. THIS WILL
PROVIDE FOR ADEQUATE SPACE FOR THE PROPER PLACEMENT OF THE AUTO SENTRY AND ITS GATE. IF MENU SIGNS AND OTHER ITEMS ARE TO BE INSTALLED ON THE ISL AND, THEN IT IS THE
CAR WASH OWNER S RESPONSIBILITY TO INCREASE THE LENGTH OF THE ISLAND TO ACCOMMODATE THESE ADDITIONAL ITEMS.
NOTE #2: ICS HIGHLY RECOMMENDS THAT THE WIDTH OF THE ISLANDS BE A MINIMUM OF 4'- 6" FOR THE SAFETY OF THE ATTENDANTS WHEN SERVICING. T HIS MEASUREMENT, ALONG WITH
THE PROPER PLACEMENT OF THE AUTO SENTRY, WILL PREVENT THE REAR OF THE AUTO SENTRY F ROM HANGING OVER INTO ANOTHER DRIVE-THRU LANE AND PROVIDES AMPLE ROOM FOR
VEHICLES TO PASS THROUGH THE LANES WITHOUT STRIKING THE REAR OF AN AUT O SENTRY.
NOTE #3: AT THE CAR WASH OWNER S DISCRETION, THE INSTALLATION OF BOLLARDS AT THE ENTRANCE END OF THE ISLAND IS HIGHL Y RECOMMENDED AND WILL MINIMIZE THE CHANCES OF
VEHICLES STRIKING AND DAMAGING AN AUTO SENTRY OR TRAFFIC GATE. BOLLARDS SHOULD BE LOCATED S O THAT THEY PROVIDE PROTECT ION TOICS E QUIPMENT BUT ALSO OFFER AMPLE
CLEARANCE SO THAT THE EQUIPMENT CAN BE EASILY INSTALLED AND MAINTAINED.
THE WHITE SQUARE REPRESENTS THE
OPEN SPACE IN THE BASE OF THE
AUTO SENTRY PETRO WHERE THE
CONDUITS PASS THROUGH.
6- ½ x 6- ½
***THIS DRAWING IS NOT TO SCALE.***
14"
10"
1' 5"
OPTIONAL
RFID TRUSS BASE
FO OTPRINT
C
L
C
L
3'- 9 ½
TRAFFIC GATE
ARM O R BA RR IER
6' - 2 ½
OF PE TRO
OF TRUSS
OF GAT E

Auto Passport Installation GuidePage 4 Copyright © Innovative Control Systems, Inc.
System Wiring
Auto Passport® RFID All-In-One Reader/Antenna Power Requirements
Power for the Auto Passport reader/antenna is supplied by the Auto Sentry Petro.
The Auto Sentry Petro has terminal blocks inside for power termination.
Recommended and Accepted Grounding Methods
The Auto Passport equipment must be properly grounded. Proper system grounding is an extremely important part of the system
installation. Grounds for all devices should be wired to the main service electrical panel ground bus bar which, in turn, should be
grounded to a ground rod. A conduit ground does not provide a sucient ground. It is recommended that the neutral and ground
bus bars be bonded together when it is not prohibited by local codes.
The universal ground symbol identies the grounding terminal
located in the Auto Sentry unit near the terminal blocks.
WARNING: Failure to properly ground the unit could result in unit failure and/or bodily injury. Ground wire must be connected
to the ground terminals.
NOTE:Improper grounding will void equipment warranty.
Wire Gauge and Conduit Size
When planning the orientation of the wiring runs, follow the applicable ICS wiring diagrams and consider the layout of the
components at the site. To determine conduit size needed, see the table below for more information.
Tools Required
You will need to have the following tools:
Table 2: Number of Wires (THHN) in a Given Conduit Size
1/2 3/4 1 1 1/4 1 1/2 2 2 1/2 3
AWG 14 13 24 39 69 94 154 — —
AWG 12 10 18 29 51 70 114 164 —
AWG 10 6 11 18 32 44 73 104 160
AWG 8 3 5 9 16 22 36 51 79
AWG 6 1 2 6 11 15 26 37 57
AWG 4 1 1 4 7 9 16 22 35
AWG 3 1 1 3 6 8 13 19 29
AWG 2 1 1 3 5 7 11 16 25
AWG 1 1 1 1 3 5 8 12 18

Auto Passport Installation GuidePage 5 Copyright © Innovative Control Systems, Inc.
Conduit Detail (Triple Lane)
AUTO SENTRY LANE
CONDUIT DETAIL
THI S DR AWING I S ONLY IN TENDED TO SHOW TH E C ONDUIT
REQUIREMENTS F OR THE AUTO SE NTRY ISL ANDS IN DETAIL.
THI S DRAWING I S NOT T O SCALE.
LANE #1
A UT O
SE N TR Y
ISLAND
3/4 "
CO NDUIT
LANE #2
A UT O
SE N TR Y
ISLAND
1/2" C ONDUIT STUBBED
OUT TO CONNE CT WI TH
GATE CLOSING LOOP
1/2" CONDUIT STUBBED OUT
TO CONNECT WITH GATE
CLOSING LOOP
1/2" C ONDUIT STUBBED OUT TO
CONNECT WITH THE MERGE LOOP.
THE ME RGE LOOP SHOULD BE RUN
TO THE TRAFFIC GATE IN LANE #1.
1" C ONDUIT TO SITE
MAIN SERVICE
ELECTRICAL PANEL
NOTE: EN S UR E TH AT A L L C ON D UI T S
RUNNING TOTHEGATES ARE TIGHTLY
BUNDLED T OGETHER AS THE OPENING
IN THE BASE OF THE GATE IS ONLY 3- ¼
INCHES IN DIAMETER.
LOW VOLTAGE CONDUIT
HIGH VOLTAGE CONDUIT
3/4 "
CONDUIT
RFID
TRUSS
BAS E
1" C ONDUIT S
RFID
TRUSS
BAS E
LANE #3
A UT O
SE N TR Y
ISLAND
3/4 "
CONDUIT
1/2" C ONDUIT STUBBED OUT
TO CONNECT WITH GATE
CLOSING LOOP
1" CONDUIT
1/ 2" C ONDUI T
CONNECTING THE
TWO GATES
RFID
TRUSS
B AS E
(9) - 1" C ONDUIT S:
• THREE POWER CONDUITS GOING TO
THE POWER DISTRIBUT ION BOX
WHICH POWERS THE AUTO SENTRY.
• THREE POWER CONDUITS GOING
BACK TO THE MAIN SE RVICE
ELECTRIC PANEL WHICH POWE RS
THE HEAT EXCHANGERS.
• THREE CONDUI TS FOR LOW
VOLTAGE GOING TO T HE LO W
VOTLAGE JUNCTION BOX.
½CONDUIT STUB OUTS FOR
CONNECTION T O LO OPS
Figure 5. Triple Lane Example Conduit Layout
RFID Wiring Layout
The wiring layout is the same for one, two, three, or four lanes. There is one cable that houses ve wires and they
connect from the RFID All-in-One Reader / Antenna back to its corresponding Auto Sentry Petro. See Figure 6.
ICS SUPPLIED
35' SPECIAL CABLE
RFID WIRING
TRIPLE LANE LAYOUT
AUTO SENTRY PETRO
LANE #1
RFID READE R /
ANTENNA
LANE #3
RFID READE R /
ANTENNA
LANE #2
RFID READE R /
ANTENNA
RFID WIRING PLAN
TERMINATE THE CABLE FROM THE RFID ALL-IN-ONE RFID READER/ ANTENNA
ENCLOSURE TO THE RIGHT-SIDE OF THE TERMINAL BLOCKS INSIDE THE AUTO
SENTRY P ETRO HEAD A S FOLLOWS:
BLACK ALL IN ONE CABLE ALL (5) WIRES ARE LABELED:
POWER WIRES
ATTACH WIRE MARKED 24V(+) TO THE ORANGE TERMINAL BLOCK (24+)
ATTA CH WIRE MARKED 24 V(-) TO THE BLACK TERMINAL BLOCK (24-)
DATA WIRES
ATTACH WIRE MARKED TX TO THE ORANGE TERMINAL BLOCK (TX)
ATTACH WIRE MARKED RX TO THE YELLOW TERMINAL BLOCK (RX)
ATTACH WIRE MARKED GROUND TO THE WHITE TERMINAL BLOCK (GD)
THERE WILL BE THREE ALL-
IN-ONE RFID READER/
ANTENNAS WITH 35' LEADS
THAT TERMINATE BACK TO
THEIR OWN AUTO SENTRY
PETRO. THERE WILL BE ( 3)
35' CABLES PROVIDED.
Figure 6. Triple Lane Example RFID Wiring Layout

Auto Passport Installation Guide
Page 6
Copyright © Innovative Control Systems, Inc.
Part Description Parts Included
RFID All-In-One Reader / Antenna Enclosure
NOTE: Colors may vary.
Power and Data Wires
in the RFID All-In-One Cable
Truss and RFID System Installation
NOTE:It is recommended to have 2 people perform the installation of the RFID system.
Tools Required (not supplied by ICS)
1/8” Allen Wrench
Small Flat Head Screw Driver
Hammer Drill
Diagonal Cutting Pliers
Fish Tape
Ladder
Parts Required (not supplied by ICS)
8” or greater UV Cable Ties
1/2” dia. x 6” L Concrete Anchor Bolts
Parts Required (supplied by ICS)
Estimated Completion Time
We estimate that it will take 2 hours to perform this procedure. Keep all hardware organized as you work.

Auto Passport Installation GuidePage 7 Copyright © Innovative Control Systems, Inc.
WARNING: Please have a certied electrician check voltages on the power supply before installing new
components. The voltage should be 24 volts.
Instructions to Power Down the Auto Sentry Petro
WARNING: Failure to turn o the Auto Sentry increases the risk of serious bodily injury or death.
1. On the site server desktop, click on the VNC icon for the Auto Sentry Petro.
2. On the menu bar, click the Windows ag icon.
3. Click the Shutdown button.
4. Wait until the Auto Sentry display goes to a white screen.
5. Open the rear door of the Auto Sentry Petro.
6. Inside the head of the Auto Sentry, turn o the power switch. See Figure 7.
7. The circuit breaker for the Auto Sentry Petro is located in the left side of the Auto Sentry Petro. Turn o the circuit breaker by
Auto Sentry
Petro Power
Switch
(1) 10 Amp Circuit
Breaker (Typical
US install)
Figure 7. Circuit Breaker (US) and Power Switch
(2) 10 Amp Circuit
Breaker (Typical
Canada install for
additional heater)
Auto Sentry Petro Power Switch
Figure 8. Canada Circuit Breakers and Power Switch
pressing the 10A blue button on the breaker until it clicks out. See Figure 7. If Canadian install, there are two 10A circuit breakers
to turn o. See Figure 8.
8. Shut o the electricity by turning o the Auto Sentry Petro breaker inside the ICS® power distribution box. If your site does

Auto Passport Installation Guide
Page 8
Copyright © Innovative Control Systems, Inc.
not have an ICS Power Distribution Box, shut o the electricity by turning o the Auto Sentry Petro breaker inside the Main
Service Electrical Panel.
Truss Base Mounting Location
A UT O S E NTR Y
TRAFFIC
LANE GRADE
RFID LANE FRONT VIEW
THIS DRAWING IS NOT T O S CALE
C
L
C
L
A UT O S EN TR Y
9' - 2"
RFID ANTENNA
ENCLOSURE
CONCRETE ISLAND CONCRETE ISLAND
8' - 5"
7' - 11"
8' - 8"
7' - 11 5/8"
C
L
C
L
RFID
TRUSS
45 ½
NOTE: CONCRETE ISLANDMUST BE 6 INCHESABOVE THE
FI NAL TRAFF IC LANE GRADE. IF NO ISLA ND, PURCHASE 6
INCH RISER FOR OPTIMAL OPERATING HEIGHT.
TRAFFIC
LANE GRADE
0' - 6" 0' - 6"
Figure 10. Truss Base Mounting Location Side View
TRAFFIC LANE
GRADE
0' - 6"
RFID LANE – REAR VIEW
THIS DRAWING IS NOT TO SCALE
CONCRETE ISLAND
NOTE: CONCRETE ISLAND MUST BE 6 INCHES ABOVE THE
FINAL TRAFFIC LANE GRADE
AUTO SENTRY
PETRO
RFID
T RU SS
C
L
C
L
0' - 6"
11"
1' -5"
Figure 9. Truss Base Mounting Location Rear View

Auto Passport Installation GuidePage 9 Copyright © Innovative Control Systems, Inc.
TRUSS-BASE DIMENSIONS
12"
6"
1" 1"
1"
5" 5"
2 1/8"
12"
6"
1"
2 1/2"
2 1/2"
2" 2"
SEE
NOTE #1
SEE
NOTE #1
SEE
NOTE #1
SEE
NOTE #1
SEE
NOTE #1
2 1/8" DIA. HOLE.
SEE NOTE #2
NOTE #1: THE TRUSS-BASE MOUNTING HOLES.
THEY ARE 9/16" IN DIAMETER. USE 1/2” DIA. X 6" L
CONCRETE ANCHOR BOLTS THROUGH EACH OF
THE FIVE MOUNTING HOLES TO SECURE THE BASE
OF THE TRUSS TO THE CONCRETE ISLAND.
THE THREE MOUNTING HOLES THAT ARE ADJACENT
TO THE REAR EDGE OF THE TRUSS BASE SHOULD
ALWAYS BE FURTHEST AWAY FROM THE TRAFFIC
LANE AND THE VEHICLE. THE TWO MOUNTING
HOLES ADJACENT TO THE FRONT EDGE OF THE
TRUSS BASE SHOULD ALWAYS BE CLOSEST TO THE
TRAFFIC LANE AND THE VEHICLE.
NOTE #2: THE TRUSS-BASE CONDUIT HOLE. THIS IS
THE HOLE IN THE TRUSS-BASE THROUGH WHICH
THE CONDUIT CONTAINING THE ANTENNA CABLING
WILL PASS. MINIMALLY, A 1" CONDUIT IS
RECOMMENDED FOR THE ANTENNA CABLING.
FRONT EDGE OF
TRUSS-BASE
REAR EDGE OF
TRUSS-BASE
IN RELATIONSHIP TO TRUSS BASE
DIRECTION OF VEHICLE TRAVEL
Truss Base Mounting Instructions
Figure 11. Truss Base Mounting Specications
Mount truss base 1’5” from the edge of the curb to the center of the truss base.
Mount truss base 45 1/2” from the center of the Auto Sentry Petro to the center of the truss.
1. The three mounting holes that are adjacent to the rear edge of the truss base should always be furthermost away from the
trac lane and the vehicle. The two mounting holes adjacent to the front edge of the truss base should always be closest to
the trac lane and the vehicle. See Figure 11.
2. The center hole in the truss-base is used to pass the RFID all-in-one reader/antenna cable to pass from the conduit up
through the center of the truss to the RFID enclosure. Minimally, a 1”conduit is recommended for the RFID All-in-one cable.
3. Using a hammer drill, secure the base of the truss to the concrete island with 1/2”dia. x 6”L concrete anchor bolts through

Auto Passport Installation Guide
Page 10
Copyright © Innovative Control Systems, Inc.
7' – 11 5/8"
RFID
ANTENNA
ENCLOSURE
C
L
C
L
CENTER LINE OF
RFID UNIT
4' – 7"
2' – 6"
5 3/8"
TRAFFIC LANE
GRADE
0' - 6"
3' – 6 1/2"
7' –11"
8' –5"
RFID LANE – SIDE VIEW
THIS DRAWING IS NOT TO SCALE
CONCRETE ISLAND
6' – 7"
8' –8"
9' –2"
NOTE: CONCRETE ISLAND MUST BE 6 INCHES
ABOVE THE FINAL TRAFFIC LANE GRADE
RFID All-In-One Reader / Antenna Mounting
1. Attach the RFID All-In-One Reader / Antenna enclosure to the truss that is next the Auto Sentry and extends over the lane.
The truss will be shipped with truss brackets and hex
screws. (1/8” Allen key is needed to install but not
supplied by ICS).
2. Mount the center of the enclosure at 3’6-1/2” from the edge of
the curb. See Figure 13.
To ensure the proper angle for the antenna, the enclosure
should be mounted so the top of the enclosure is level.
The antenna is angled inside of the enclosure. The
enclosure will appear to be facing down. See Figure 10,
Figure 12, and Figure 13.
3. Route cable down through the center of the truss. ICS
recommends securing the cable to the truss every 12 inches
with cable ties.
4. Use diagonal cutters to cut excess length o of the cable ties.
IMPORTANT: The enclosure should not be rotated on the truss as
that would move the antenna to a position where it is not designed
to work properly.
Figure 12. RFID Reader/Antenna Enclosure
on the Truss Front View
Figure 13. RFID Enclosure Mounting on the Truss Rear View

Auto Passport Installation GuidePage 11 Copyright © Innovative Control Systems, Inc.
Figure 14. Terminal block inside
Auto Sentry Petro
Figure 15. Wire Termination
5. Open the back door of the Auto Sentry Petro.
6. Using the sh tape, pull the RFID All-In-One Cable through the 1”conduit from the base of the truss to the Auto Sentry Petro.
7. Locate the set of terminal blocks included on the right wall inside the back door as shown in Figure 14.
NOTE:There is a terminal description label to the right of the terminal blocks.
8. The RFID All-In-One reader/antenna cable has (5) wires that connect to the terminal blocks as follows. See Figure 15.
Attach the power wires marked 24VDC(+) and 24VDC(-) from the RFID reader to the bottom terminals of the orange and
black terminal blocks: 24V DC(+) wire to orange terminal block 24V DC(+), and the 24V DC(-) wire to black terminal block
24V DC(-).
Attach the data wires from the RFID reader to the bottom terminals of the orange, yellow, and white terminal blocks: the
wire marked (Tx) to the orange terminal block (Tx), the wire marked (Rx) to the yellow terminal block (Rx), and the wire
marked Ground to the white terminal block (GD).
Instructions to Power On the Auto Sentry Petro
1. After the truss and enclosure are installed, and all the wires are connected as instructed on page 11, reconnect the power to
the ICS power distribution box by turning on the Auto Sentry Petro breaker inside the ICS® power distribution box.
2. Turn on the breaker(s) inside the Auto Sentry Petro by pressing the blue buttons on the breakers until they click in.
3. Inside the Auto Sentry Petro, turn on the power switch to boot the system. See Figure 7 and Figure 8 on page 7.
4. Please contact ICS Technical Support to congure the RFID System: 800-246-3469

Corporate Oce: 81 Highland Avenue, Suite 300, Bethlehem, PA 18017 | Sales: 800.642.9396
Email: [email protected] | icscarwashsystems.com
If you have any questions or concerns, please contact ICS Technical Support: 800-246-3469.
