Id-al Flash mpx - mp2 User manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

Flash MPX

MANUAL

Firmware 1.2

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

TABLE OF CONTENTS

1 - Safety instructions ......................................................P2

2 - Products information...................................................P4

3 - Introduction.................................................................P5

4 - The MPX player dual drives .......................................P5

5 - Type of Compact Flash and USB flash drive ..............P5

6 - Video file types ...........................................................P6

7 - Audio file types ...........................................................P7

8 - Software conversion for PC user ................................P7

9 - ImToo software converter...........................................P7

10 - For MAC user ...........................................................P8

11 - JPeg picture file........................................................P8

12 - How to loop a video ..................................................P8

13 - How to play video using push button ........................P8

14 - How to create file folder............................................P9

15 - Inputs .......................................................................P9

16 - How to trigger an input .............................................P9

17 - How to jump into (enter) a file folder .........................P9

18 - How to play a file while inside a file folder...............P10

19 - Jump to file folder ...................................................P11

20 - Default mode ..........................................................P12

21 - Dark Screen ...........................................................P13

22 - IDLing with no sound ..............................................P13

23 - How to program......................................................P13

24 - Application examples..............................................P14

25 - Technical specifications..........................................P20

ID-AL products are distribued/manufactured by Waves System

LA VILLE EN BOIS - 44830 BOUAYE - FRANCE

Sales and information: +33 2 40 78 22 44

E-mail : [email protected] - Web site: http://www.id-al.com and www.wsystem.com

Technical support : [email protected]

For a detailed list of the technical support options, we suggest you to visit our site

www.id-al.com.

Information in this manual is subject to change without notice and do not represent any commitment from

Waves System. The equipment described in this manual is supplied under condition of the terms of license

specifying the legal use conditions. This manual can’t be reproduced or used, in whole or in part, in any

form and by any mean, for other use than private, without the written permission from Waves System.

ID-AL is a trademarks of Waves System.

- 1 -

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

WARNING: DO NOT EXPOSE TO MOISTURE AND DUST!

Unplug the power cord before any intervention!

FOR YOUR SAFETY, PLEASE READ CAREFULLY THIS OPERATION MANUAL

BEFORE USING YOUR PLAYER.

1. SAFETY INSTRUCTIONS

1.1 CE marking

The CE marking is on the ID plate, at the back of the product. It means this product complies with the low

voltage CE directive, according the EN 55022 standard, and the EMC directive 61000-4-x.

1.2 Directives

• Electro-magnetic compatibility (EMC) and low voltage directive requirements are satisfied.

1.3 Overview

• The user’s manual forms an integral part of the unit. It must be kept close to the unit. Precise observance

of these instructions is a pre-condition to use the unit for the intended purpose and for its correct operation.

This user’s manual must be passed on to any future purchaser or operator.

The staff would receive instructions concerning the correct use of the product.

•Safety for the operator aswellastrouble-free operation of theunitisonly ensured if useismadeof original

equipment parts. Moreover, use may only be made of those accessories that are specified in the technical

documentation or that have been expressly approved by the manufacturer. The manufacturer cannot

guaranteefor the safety orproperfunctioning of the unitinthe case where accessoriesorconsumablesare

used which are not supplied by the manufacturer.

•Thewarrantydoesn’tcoverdamagescausedbyuseofaccessoriesorconsumableswhicharenotsupplied

by the manufacturer.

•Themanufactureronlyregard himself as beingresponsiblefortheequipmentwithregardtosafety, reliability

and proper functioning if assembly, re-settings, changes or modifications, extensions and repairs have

been carried out by the manufacturer or a company authorized by the manufacturer and if the equipment is

used in conformity with the operating instructions written in this manual.

for electrical diagrams, procedures, mentioned names and equipments.

• No reproduction, in whole or in part, without the written permission from Waves System.

1.4 General safety instructions

This equipment left our facilities in perfect conditions of operation. In order to maintain these conditions, for

safety and to avoid any risk of injury, the user must imperatively follow the safety instructions and read the

´Warning!´notesin this manual. Thisequipmenthasbeen so designed thatanydangeris virtually excluded

provided it is used according to its purpose. However, for safety reasons, we are obliged to point out the

following measures:

- 2 -

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

• When operating this appliance, observe all local rules and enforced regulations! The homologation shall

be invalid if any modification or alteration is made on the appliance. Operating modified appliances may

lead to a penal suit. In the interest of the safety of work, the manager and the operator will be responsible

for respecting the instructions.

• Retain all packing material in case the device must be shipped. Take care that it does not fall into the

hands of children. Only the original packing guarantees optimal safety of the appliance during transport.

Should it be necessary to ship the product during the guarantee period, Waves System will not accept

claims for damage arising during the transport from using incorrect packing material!

• This product is dedicated to broadcasting music. It may only be operated by trained or knowledgeable

personnel who can handle the device correctly.

• Before every use, the operator must check the functional safety and the condition of the appliance and

must be knowledgeable in the operation of the appliance.

• This device must not be used in places with potential explosion risk. Moreover, it must not be used in an

environment favouring combustion neither in a wet or excessively hot or cold place.

1.5 Safety instructions against risks pertaining to electrical current

• The appliance must be connected to a grounded AC power outlet or a correctly wired CEE AC outlet.

•Beforeconnectingthe appliance,verifythatthepower supplyvoltageandfrequencymatchthe specifications

indicated on the appliance.

• Before powering, check that the appliance and the cables are not damaged. Damaged cables and

connections must be immediately replaced.

• Never leave power cords enter in contact with other cables! Handle the power cord and all the cables

connected to a power supply with extreme care.

•Alwaysconnect the power supply last. Checkthatthepowerswitch is ´off’ before connectingtheappliance

to mains supply. The mains outlet must be accessible after installation.

• Always grasp only the plug on the power supply cord. Never pull the cable to unplug.

• Power supply, repairs and maintenance must be done by qualified personnel.

• Do not switch the appliance on and off in short intervals, as this may reduce its life, especially concerning

the hard disk.

1.6 - Conditions of use :

• This product has been designed for indoor use only.

• If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch

it on immediately. The arising condensation water might damage your device. Leave the device switched

off until it has reached room temperature.

• Do not shake the device. Avoid brute force when installing or operating the device.

• When choosing the installation-spot, please make sure that the device is not exposed to extreme heat,

moisture or dust. There should not be any cables lying around, for your own safety and that of bystanders.

- 3 -

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

2. PRODUCT INFORMATION

2.1 Correct usage

The player is designed for automatically broadcasting music, audio, video files.

Correct usage implies observation of the instructions in this manual as well as observing the requirements

concerning installation.

2.2 Incorrect usage

Any other use beyond this is considered as incorrect usage. The manufacturer will not be liable for any

damage resulting from incorrect usage. The operator carries all risks.

2.3 CONTENTS

Flash MPX player

Power supply block

User manual

2.4 INSTALLATION

The apparatus must be set up in a dry and dust-free room.

Do not install the player too close to a wall. To avoid overheating, the ventilation holes must be kept

clear and an air circulation gap must be left above the unit.

2.5 ELECTRICAL CONNECTION

Before use, compare mains voltage with that specified on model plate.

- 4 -

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 5 -

FLASH MPX Manual

INTRODUCTION :

Thempx playeris aself-contained SolidState Mpeg4Video/MP3 Audioplayerhoused

in a small aluminum enclosure. The mpx player utilizes the latest development in

custom design single chip to decode various Mpeg compression systems including

Mpeg4 video, Mpeg4 Audio and Mp3 audio. Mpeg4 video is the latest video

compression that gives similar or better video quality than Mpeg2 video (DVD video)

at less than half the bit rate. The mpx player has two drives, Compact Flash Card and

USBFlashdrive. Ithas16digital input andisconfigured to providea very fastreaction

time so that the video/audio playback is instantaneous. The mpx player is pre-

programmed to play a multi stage interactive multimedia presentation and to support

push buttons and sensors. The mpx player is a solid state device that will give you

years of trouble free operation, superb video quality and at a much lower cost.

THE MPX PLAYER DUAL DRIVES :

The mpx player has two drives. It reads from a Compact Flash card OR USB flash

drive, but not both. The mpx player is a video/audio playback device only, it is not

configuredfordirectconnectionintoaPC.TheUSBportonthempxplayerisconfigured

strictly for reading the USB Flash drive only. It can not communicate with your PC

and/or download files from it.

To copy files into the Compact Flash Card, use a USB card reader and a PC (USB

port) and copy the files into the CF card. To copy files into the USB Flash drive, plug

it directly into the USB port of your PC and copy the files into it.

TYPE of COMPACT FLASH CARD and USB FLASH DRIVE :

If you are using a compact flash card for Audio or Low bit rate Video (under 4 Mbit/

s), you can use any standard Sandisk Compact Flash card. For higher bit rate video

(over 4 Mbit/s) use Sandisk Ultra II Compact Flash card only.

If you are using USB Flash drive use a USB Flash drive with 2.0 interface only. Do

not use USB1.1 interface.

The mpx player reads Compact Flash card and USB Flash drive that uses Windows

(98 to XP) DOS (FAT) format only, not NTSF. Do not format a new drive. However if

you have to format a used drive, format it with DOS (FAT or FAT32) format only (not

NTFS). The USB drive is also called Thumb Drive, Cruiser Mini, Stick Drive or Flash

drive.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 6 -

VIDEO file types:

xxx.mpg (Mpeg2 and Mpeg1):

Flash mpx is optimized to play Mpeg2 video files at up to 9 Mbps. Consider using

Mpeg2 first before using other format.

An Mpeg2 file most likely consists of Mepg2 Video stream and MP2 (Mpeg1 Audio)

audio stream. This file should be readily played by the Flash mpx. If your Mpeg2 file

does not play, then most likely it is not a program Mpeg file. Use the ImToo converter

software to convert it into Mpeg2 program file.

xxx.vob (VOB file from DVD):

A DVD file (vob) most likely consists of Mpeg2 Video stream and MP2 (Mpeg1 Audio)

orAC3 audiostream.If thevobfile playson thempxbut nosound, thenmostlikely the

audioportion is AC3.To playiton theFlashmpx, youhaveto convertthe VOB fileinto

Mpeg2 file using MP2 audio (Mpeg1 audio) stream. Please see ImTOO encoder

software below.

xxx.mp4 MPEG4-10 AVC (h.264):

TheFlash mpxplaysMpeg4-2 ASPvideoonly, itwill notplayMpeg4-10 videosuch as

Mpeg4 iMovie or Mpeg4 Quicktime.

xxx.mp4 MPEG4-2 ASP file with AAC audio.

Almost all xxx.mp4 file that is encoded with Mpeg4-2 ASP contains Mpeg4 video and

AAC audio. This file should be readily played by the Flash mpx, but maximum bit rate

is 4Mbps. This video format is also compatible with I-Pod movie, Nero Digital

(www.nerodigital.com)etc.

xxx.avi MPEG4-2 ASP file:

Mostxxx.avifiles containMpeg4video and MP3audio or PCM16bitaudio. The Flash

mpx will readily play any Mpeg4 AVI file, maximum bit rate is 4 mbps. The Mpeg4

video format is compatible with Divx, AVI, 3IVX etc.

xxx.divx MPEG4-2 ASP file with MP3 audio.

The Flash mpx plays DIVX video (www.divx.com), maximum bit rate is 4Mbps. It will

also play 3IVX and other Mpeg4 encoder that uses MP3 audio.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 7 -

AUDIO file types (in order of audio quality):

The Flash mpx plays:

xxx.wav 16bit PCM audio (CD quality at 44100Hz)

xxx.aac AAC audio (CD quality at 192kbps).

xxx.mp3 MP3 audio (CD quality at 256kbps)

SOFTWARE CONVERSION for PC USER:

For PC user, the easiest way to convert your DVD file (VOB), Mpeg2 file and Mpeg4

(AAC) file is by using the Mpeg4 converter software such as from Divx or ImToo

Mpeg4converter(recommended).ForMACuser,useMpeg4converterthatisavailable

from Apple web site or Divx web site.

ImTOO SOFTWARE CONVERTER (PC USER):

TheImTOOMpeg4 converter software is veryeasyto use and canbepurchased and

downloaded from their website at : www.Imtoo.com. When using the Imtoo Mpeg4

converter software, the setting for the Flash mpx is as follows:

PROFILE:

Set profile to DIVX or AVI.

VIDEO:

Video Codec: Mpeg4

Video size: 640 X 480

Bit Rate: Type in 2000 or 3000 (2 Mbps or 3 Mbps).

Frame rate: Type in a frame rate to match the original frame rate. (25 or 29.97)

AUDIO:

Audio Codec: MP3

Audio bit rate: 192 or 256 Kbps.

Frame rate: 44100 Hz

Note: Youcanalso use the ImTOO softwaretoconvert your VOB file (fromDVD)into

a std Mpeg2 file. To convert without any loss, type in to match the Video bit rate,

Framerateandaudio bit rate. You can also usethissoftware to convert Wav files into

MP3 audio files and AAC audio files.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 8 -

FOR MAC USER:

Convert your video files into Divx using the Divx6 Converter from www.divx.com. Set

the encoder to Home theatre setting.

Maximum bit rate is 3Mbps, audio is MP3 at 192Kbps or 256 Kbps. You can also

download MP4 converter software from the Apple web site.

JPEG PICTURE File:

TheFlashmpx plays anysize Jpeg fileandwill automatically resizeitto fitthescreen.

WhileloopingasingleJpegpicture,it willautomaticallydisplaythepicturecontinuously

without any black screen in between.

Whenplaying aseriesof jpegpictures, thempxplayer willautomatically gointoa slide

mode.In aslide mode,itwill superimposethe newJpeg fileover theonebeing played,

fade out the Jpeg file being played and fade in the new Jpeg file.

HOW TO LOOP a VIDEO (or series of video files, audio files or

Jpeg pictures) AFTER POWERING UP:

NAMING A FILE PLACED AT THE ROOT

For the FLASH MPX player to work correctly, it is strongly recommended to include 6

digits in the file name for all files placed at the root on the memory card. These digits

are used to define the default audio level and the possible volume adjustments.

Digit 1 et 2 : undefined - recommended values 00. These two digits could be used to

determine a sequence, the order in which the player broadcast the files.

Digit 3 et 4 : define the default volume level of the player - between 01 and 16.

Possiblevalues :01to16 (01= minimumvolume,16 =maximumvolume, 08 =default

volume).

000100cheval.mpg : volume of player is set to its minimum

001600chat.mpg : volume of player is set to its maximum

Digit 5 et 6 : define the pitch of volume adjustment when using Vol+ and Vol- inputs.

Possiblevalues: 00 to16.The volume incrementwill be + or- the setting indicatedby

these 2 digits.

00 : no volume setting allowed

01 : adjustment + 1 or - 1 in relation to the default volume level set by digits 3 and 4

08 : adjustment + 8 or - 8 in relation to the default volume level set by digits 3 and 4

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 9 -

16 : adjustment possible on the whole volume range of the player

000800cheval.mpg : volume set at 8 ; no adjustment allowed using inputs Vol+ and

Vol-

000808chat.mpg : volume set at 8 ; possible adjustment + 8 and - 8 using Vol+ et Vol-

000116chat.mpg : volume set to minimum value ; possible adjustment on the whole

volume scale of the player using Vol+ et Vol-

Important : Do not include spaces nor special characters in the file names.

Any file (or files) in the root directory will automatically loop after powering up.

Caution : For the Flash MPX to work correctly, at least ONE file, video, audio or still

frame, must be stored at the root ; the file name must include the 6 digits which will

define the volume level of the player and the scale of adjustment.

HOW TO PLAY VIDEO USING PUSH BUTTON (or audio file or Jpeg

picture)

To play a file using push button, you have to create file folders. You can create up to

96 file folders, however the first 16 file folder are directly related to the 16 input. E.g.:

File folder 01 is for input 1, file folder02 is for input 2 etc.

Upon entering a file folder, the Flash mpx will automatically play the first file. While

playingor after playingthisfile youassignthe 16pushbuttons againtoplay otherfiles

(insidethisfile folder). Toplay the otherfilesinside this filefolder,you havetorename

eachfile byadding6numbersinfrontofthefile name.The functionof these6 numbers

is explained below.

HOW TO CREATE FILE FOLDER :

Create file folder on your PC or MAC and name it using 2 numbers (numerical) only.

Eg: 01, 20, 32 etc.

Maximum number of file folder is 96. File folders 00, 99,98 and 97 are exclusive and

are used for specific instruction only.

File folder that does not have 2 numbers will be ignored.

Example:

File folder 01 is accessible by input 1.

File folder 02 is accessible by input 2.

File folder 08 is accessible by input 8.

File folder 16 is accessible by input 16.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 10 -

INPUTS:

The Flash mpx has 8 input and 1 UP input for a total of 16 input.

HOW to trigger an INPUT:

To trigger input 1 to 8, short it momentarily to ground.

To trigger input 9, short both 1 and UP momentarily to ground.

To trigger input 10, short both 2 and UP momentarily to ground.

To trigger input 16, short both 8 and UP momentarily to ground.

HOW TO JUMP INTO (ENTER) A FILE FOLDER:

Afterpowering up theplayerwill loopallfiles intheroot directory, relayis OFF. Ifthere

is no file in the root directory, then the player will simply idle and wait for an input.

This is the Home position of the mpx player. From this home position you can select

16 input.

From home position, if input#1 is triggered, the mpx player will immediately go to file

folder 01 and plays the first file in that file folder.

From home position, if input#2 is triggered, the mpx player will immediately go to file

folder 02 and plays the first file in that file folder.

From home position, if input#16 is triggered, the mpx player will immediately go to file

folder 16 and plays the first file in that file folder.

HOW TO PLAY A FILE WHILE INSIDE A FILE FOLDER:

After entering a file folder the mpx player will automatically play the first file in that file

folder. While inside a file folder you can set the mpx player to play 16 more files.

For example while playing the first file inside a file folder, if input #1 is triggered then

the mpx player will play the file with a file name that starts with 01. If input #2 is

triggered then the mpx player will play the file with a file name that starts with 02.

After finish playing a file and depending on the file name, the mpx player will read

characters 5 and 6 (file name) and stay or jump into this file folder.

Example: 000122Lion.mp4. After entering this file folder, mpx player will play this file.

After finish playing this file, mpx player will jump to file folder 22.

If the file folder does not exist, the mpx player will go into default mode and returns to

home position.

Below is the definition of the first six numbers of a file name.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 11 -

First and Second number, 16 possibilities + 00:

ASSIGN AN INPUT TO PLAY A FILE NAME,

020101Horse.mp4, this file will play when input 2 is triggered.

030101Lion.mp4, this file will play when input 3 is triggered.

080101Cat.mp4, this file will play when input 8 is triggered.

160101Tiger.mp4, this file will play when input 16 is triggered.

Third number, 2 possibilities:

TURN RELAY ON or OFF while playing a file.

The third number has 2 possibilities number 0 and number 1.

If the number is 1, Relay is ON. (terminal «Busy» and «Com»)

Example:011022cats.mpg

Turn relay ON while playing this file.

If the number is 0, Relay is OFF.

Example:010022cats.mpg

Relay is OFF while playing this file.

Fourth number, 2 possibilities:

INTERRUPT or NO INTERRUPT while playing a file.

The fourth number has 2 playback possibilities number 0 and number 1.

Standard play with interrupt (number is 0).

Example:011022cats.mpg

Abort playback if another input is triggered and immediately play the other file.

Play with no interrupt (number is 1).

Example:011122cats.mpg

Ignore input, no interrupt is allowed while playing this file.

Fifth and Sixth number, 96 possibilities + numbers 00, 99,98 and 97:

JUMP to FILE FOLDER after playing a file.

The fifth and the sixth number refer to a file folder name.

Example:

001022dogs.mp4 after finish playing this file the mpx player will jump to file folder 22.

121118horses.mpg after finishplayingthis filethempx playerwill jump tofile folder 18

091143lion.mp3 after finish playing this file the mpx player will jump to file folder 43

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 12 -

STAY inside a FILE FOLDER after playing a file.

The fifth and the sixth number is the same as the file folder name (where the file

resides).

Example:

Ifthempx playerisinside file folder32 andthen play 220032Cats.jpg, thenafter finish

playing this file the mpx player will stay inside file folder 32 and play the first file again.

Fifth and Sixth number is NUMBER 00:

RETURN TO HOME POSITION after playing a file.

The Fifth and the Sixth number is 00.

Number 00 is for Home position, eg. 011000cats.mpg.

After finish playing 011000cats.mpg, go to home position.

Fifth and Sixth number is NUMBER 99:

STOP after playing a file and WAIT for Input. While waiting show the file menu

on screen.

The Fifth and the Sixth number is 99.

Number 99 is for Stop after playing a file and wait for input. eg. 011099cats.mpg.

After finish playing 011099cats.mpg, Stop after playing this file and wait for another

input.

Fifth and Sixth number is NUMBER 98:

LOOP this file.

The Fifth and the Sixth number is 98.

Number 98 is for Loop playing. eg. 011098cats.mpg.

Loop file 0110998cats.mpg.

Fifth and Sixth number is NUMBER 97:

STOP after playing a file and WAIT for Input. While waiting screen is DARK.

The Fifth and the Sixth number is 97.

Number 97 is for Stop after playing a file and wait for input. eg. 011097cats.mpg.

After finish playing 011097cats.mpg, Stop after playing this file and wait for another

input. While waiting screen is dark.

The Fifth and the Sixth number do not exist in the CF or USB drive.

If the Fifth and the Sixth number do not belong to any file folder name (does not exists

inthe CF),then goto HOMEposition afterfinish playingthis file.E.g: 011045cats.mpg.

Iffilefolder 45 doesnot exist, thenafterplaying this filethempx player willgoto home

position.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 13 -

The first inside a file folder does not have six numbers in front of the file name:

The Flash mpx will play the first file in a file folder even if the file does not have six

numbers.Whileplayingit will disregard other input. Afterplayingitwill return to Home

and loop.

DEFAULT MODE:

In default mode player plays a file to the end with interrupt (standard mode) and relay

is ON except in Home position where Relay is Off.

After playing the file, player will automatically go to Home and loop.

EXAMPLE OF A FILE NAME:

001022dogs.mp4

00 First 2 number is 00, first file in directory. Play it when entering this folder.

1 the third number refers to Relay ON. Turn relay ON while playing this file.

0 the fourth number refers to Interrupt while playing. Abort playback if another input

is triggered and immediately play the other file.

22 the fifth and sixth number is 22, jump to file folder. Jump to file folder 22 after

playing this file.

Example 2 :

120199dogs.mp4

12 the first two numbers is 12. Play this file if input 12 is triggered.

0 the third number refers to Relay OFF. Relay is OFF while playing this file.

1 the fourth number refers to NO Interrupt while playing. Play this file to the end, no

interrupt is allowed.

99 the fifth and sixth number is 99. After playing this file stop and wait for another

input.

Example 3 :

020097Lion.mp4

02 the first two numbers is 02. Play this file if input 02 is triggered.

0 the third number refers to Relay OFF. Relay is OFF while playing this file.

0 the fourth number refers to Interrupt while playing. Stop and play another file if

another input is triggered.

97 the fifth and sixth number is 97. After playing this file stop and wait for another

input. While waiting screen is dark.

DARK SCREEN for mpx player:

Ifyouareusingthempxplayerasavideoplayerandyouwanttoplayadarkscreen,you

can use Black.mpg files or use code 97. These Black files can be downloaded from our

web site. There are several Black.mpg files, the main difference is the length of time.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 14 -

Copy it into the root directory if you want a dark screen after powering up. Copy it into a

filefolder (and add00 intothename) ifyouwant adarkscreen afterenteringa filefolder.

IDLING with no sound:

If you are using the mpx player as an MP3 player only and you want it to idle (no

sound) after powering up simply leave the root directory empty. If you want to idle

after playing a file, you can use any Jpeg file (still picture) from your video camera or

download silent.mp3 files from our web site or use code 99 or code 97.

HOW TO PROGRAM the mpx player:

Tip: Always hook up the video out of the Flash mpx into a monitor. Test your

program’s logic by using mp3 file for the first file inside a file folder.

The mpx player’s operation is determined by the File folder structure and the first six

number of a file name. The easiest way to “program” the mpx player is by creating the

entirefilefolder structure inyour PC first.Aftertesting the logic,thenyou can copythe

entire file folder structure from your PC directly into the CF or USB drive.

Hook up the video out into a monitor. The screen will show info about the content of

the drive and also the content of the file folder. You can download a CF structure

containing MP3 sample sound (ZIP) from our website. The file name is CF-USB.zip.

APPLICATION EXAMPLES:

Example 1: (LOOP MODE)

A video exhibit with continuous playback after powering up. After powering up,

loop a series of video clips to be played continuously all day.

The structure of the CF/USB drive is as follows:

F:\… 000816Main.mpg …. Loop all files after powering up.

Lion.mpg

Explanation: Copy000816Main.mpg andLion.mpg videoclipsintotheroot directory.

After powering up, the mpx player will loop 000816Main.mpg and Lion.mpg.

NOTES:

The above is an example of a video exhibit. For Audio exhibit, replace the video files

with mp3 audio files. For Jpeg slide show, replace the video files with Jpeg files (from

your video camera).

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 15 -

Example 2: (SIMPLE PUSH BUTTON MODE)

A video exhibit with 1 push button. Afterpoweringup, a loopvideo(Main.mpg) will

be played. If push button 1 is triggered a horse video clip will be played. After playing

the video, the player will return to play the loop video (Main.mpg).

The structure of the CF/USB drive is as follows:

F:\… 000816Main.mpg …. Loop this file after powering up.

F:\01\ Horse.mpg … Input 1 plays this file and return home.

Explanation: For the loop video, copy 000816Main.mpg video clip into the root

directory.

Create File Folder 01, prepare the Horse video clip and copy this file to file folder 01.

NOTES:

The above is an example of a video exhibit. For Audio exhibit, replace the video files

with mp3 audio files.

Example 3: (Simple push button mode)

A video exhibit with 4 push button. After poweringup,a loop video(Main.mpg) will

be played. If push button 1 is triggered a horse video clip will be played. After playing

the video, the player will return to play the loop video (Main.mpg). If push button 2 is

triggered a Lion video clip will be played. After playing the video, the player will return

toplay theloopvideo (Main.mpg).Ifpush button3 istriggereda Tigervideo clipwillbe

played.After playingthevideo,theplayer willreturn toplaytheloopvideo (Main.mpg).

If push button 4 is triggered a Cat video clip will be played. After playing the video, the

player will return to play the loop video (Main.mpg)

The structure of the CF/USB drive is as follows:

F:\… 000816Main.mpg …. Loop this file after powering up.

F:\01\ Horse.mpg ... Input 1 plays this file and return home.

F:\02\ Lion.mpg ... Input 2 plays this file and return home.

F:\03\ Tiger.mpg ... Input 3 plays this file and return home.

F:\04\ Cat.mpg ... Input 4 plays this file and return home.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 16 -

Explanation:

For the loop video, copy 000816Main.mpg video clip into the root directory (F:\).

Create File Folder 01,02,03 and 04.

Prepare the Horse, Lion, Tiger and Cat video clips. Copy Horse video clip into File

folder 01. Copy Lion video clip into File folder 02. Copy Tiger video clip into File folder

03. Copy Cat video clip into File folder 04.

EXAMPLES 4 and up are samples for interactive mode.

Avideo exhibit with1 push button. Afterpoweringup,aloopvideo(000816Main.avi)

will be played. If push button 1 is triggered a horse video clip will be played. While

playingno interrupt isallowed.After playingthevideo, the playerwill return toplaythe

loop video (000816Main.avi).

The structure of the CF/USB drive is as follows:

F:\… 000816Main.avi ... Loop this file after powering up.

F:\01\ 000100Horse.avi ... Input 1 plays this file and return home.

Explanation:

For the loop video, copy 000816Main.avi video clip into the root directory (F:\).

Prepare the Horse video clip and rename it as follows:

Horse.avi video clip, add 6 digit numbers. The new name is 000100horse.avi.

Copy this file to file folder 01. Since the first 2 digits is 00, this file will automatically be

played when mpx player is inside file folder 01.

The third digit is 0, relay is OFF while playing this file.

The fourth digit is 1, interrupt is not allowed while playing this file.

The fifth and sixth digit is 00, mpx player will return to home position (00) after playing

this file.

NOTES:

The above is an example of a video exhibit. For Audio exhibit, replace the video files

with mp3 audio files.

Example 5:

A video exhibit with 2 push button and no interrupt while playing. Afterpowering

up, a loop video (000816Main.mp4) will be played. If push button 1 is triggered a

horse video clip will be played. While playing no interrupt is allowed. After playing the

video, the player will return to play the loop video (Main.mp4). If push button 2 is

triggered a lion video clip will be played. While playing no interrupt is allowed. After

playing the video, the player will return to play the loop video (000816Main.mp4).

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 17 -

The structure of the CF/USB drive is as follows:

F:\… 000816Main.avi ... Loop this file after powering up.

F:\01\ 00100Horse.avi ... Input 1 plays this file and return home.

F:\02\ 000100Lion.avi ... Input 2 plays this file and return home.

Example 6:

An Audio exhibit with 2 push button and no interrupt while playing. Exhibit is

silentafter powering up. Afterpoweringup,audioissilent.Ifpushbutton1istriggered

a horse audio will be played. While playing no interrupt is allowed. After playing the

audio, the player will stop and wait. If push button 2 is triggered a lion audio will be

played. While playing no interrupt is allowed. After playing the audio, the player will

stop and wait.

The structure of the CF/USB drive is as follows:

F:\…

F:\01\ 000100Horse.mp3 ... Input 1 plays this file, return home and wait.

F:\02\ 000100Lion.mp3 ... Input 2 plays this file, return home and wait.

Example 7:

A video exhibit with 2 push buttons and switching between the 2 video clips

while playing a video clip. After powering up, a loop video will be played. If push

button 1 is triggered a horse video clip will be played. While playing horse video clip if

push button 2 is triggered, then lion video clip will be played. While playing Lion video

clip, if push button 1 is triggered horse video clip will be played again. After finish

playing the video clip, the loop video will be played again.

The structure of the CF/USB drive is as follows:

F:\… 000816Main.avi ... Loop this file after powering up.

F:\01\ 000098Main.avi ... Automatically loop this file.

010001Horse.avi ... In1 plays this file and stay in folder 01.

020001Lion.avi ... In2 plays this file and stay in folder 01.

ID-AL - FLASH MPX - MP2/3/4 audio/video player - ManualID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

ID-AL - FLASH MPX - MP2/3/4 audio/video player - Manual

® Waves System V 1.2 - 2006

- 18 -

Example 8:

Similar to the 2 push button exhibit, but after powering up screen is dark. Ifpush

button 1 is triggered a horse video clip will be played. While playing horse video clip if

push button 2 is triggered, then lion video clip will be played. While playing Lion video

clip, if push button 1 is triggered horse video clip will be played again. After finish

playing the video clip, screen is dark again.

The structure of the CF/USB drive is as follows:

F:\… 000816Black.mpg ... Loop this file after powering up.

F:\01\ 010097Horse.mpg ... In 1 plays this file and wait while dark.

020097Lion.mpg ... In 2 plays this file and wait while dark.

Example 9:

An exhibit using motion detector (or a push button) to sequentially play a set of

video clips. Themotiondetectorwill playhorse videoclip andafterplayingthescreen

is dark. If the motion detector is triggered again, the lion video clip will be played and

after playing the screen is dark. If the motion detector is triggered again, the cat video

clipwillbeplayedand afterplayingthescreenisdark.If themotiondetectoristriggered

again, the tiger video clip will be played and after playing the screen is dark. If the

motiondetectoristriggered again, it will return to playhorsevideo clip again and after

playing the screen is dark.

The structure of the CF/USB drive is as follows:

F:\… 000816Black.mpg

F:\01\ 000097Black.mpg ... Play this file and wait for input and dark.

010120Horse.mpg ... In 1 plays this file and jump to folder 20.

F:\20\ 000097Black.mpg ... Play this file and wait for input and dark.

010121Lion.mpg ... In 1 plays this file and jump to folder 20.

F:\21\ 000097Black.mpg ... Play this file and wait for input and dark.

010122Cat.mpg ... In 1 plays this file and jump to folder 22.

F:\22\ 000097Black.mpg ... Play this file and wait for input and dark.

010101Tiger.mpg ... In 1 plays this file and return to folder 01.

This manual suits for next models

Table of contents

Other ID-AL MP3 Player manuals

ID-AL

ID-AL AP303 User manual

ID-AL

ID-AL SP603 User manual

ID-AL

ID-AL NanoPlayer box User manual

ID-AL

ID-AL My Music Player User manual

ID-AL

ID-AL My Music Player User manual

Popular MP3 Player manuals by other brands

Samsung

Samsung MCD-SM45 instruction manual

X-Micro

X-Micro XMP3L user manual

IRiver

IRiver E300 user guide

SAL

SAL MP 3000LCD instruction manual

Belkin

Belkin F8Z439ea TuneCast user manual

Transcend

Transcend TS8GMP330W user manual

Sony

Sony NW-MS7 - Memory Stick Walkman operating instructions

Apacer Technology

Apacer Technology AUDIO STENO AU840 user manual

Clas Ohlson

Clas Ohlson KA10 user guide

Sony

Sony Walkman NW-WS413 Help guide

Sony

Sony Walkman NW-S202 Service manual

Numark

Numark NDX 400 quick start guide

Sony

Sony NW-E507 - Network Walkman 1 GB Digital Music... Specifications

Crypto

Crypto MP300 user manual

JOLIKE

JOLIKE M5 user manual

Sony

Sony NW-HD5 Operating Instructions (English) instruction & operation manual

Gogen

Gogen MAXIPREHRAVAC B instruction manual

Sencor

Sencor SFP 1360 user manual

ID-AL FLASH MPX - MP2 User manual

Popular MP3 Player manuals by other brands
