ID-AL My Music Player User manual

My Music Player
My Music Player LE
User Guide
V1.0 - February 22, 2017
© 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
-2- © 2016, Waves System
© Waves System - 2016
The ID-A products are the exclusive manufacturing of Waves System.
Waves System
Impasse de a Ville en Bois
44830 BOUAYE
FRANCE
Sales and information: [phone]
E-mail: [email protected]
Website: www.id-al.com
Technical support: [email protected]
A technical support is also available on our website www.id-al.com.
Information in this user guide is subject to change without notice and does not represent any commitment from Waves System. The
equipment described in this manual is supplied under condition of the terms of license specifying the legal use conditions. This manual
may not be reproduced or used, in whole or in part, in any form and by any means, for other use than private, without the written
permission from Waves System.
ID-A is a trademark of Waves System.

ID-A - My Music Player and My Music Player E - User Guide V1.0
CE Markin
The CE marking is found on the nameplate, at the rear side of the device. It certifies the conformance of the device with the low voltage
CE Directive, according to the EN 55022 standard, and the Electromagnetic Compatibility Directive 61000-4-x.
Directives
The requirements related to the electromagnetic compatibility and low voltages directive are met.
Safety Instructions
Overview
Proper usage conforming to the product intended purpose involves strict compliance with the instructions given in this user guide .
The staff should receive instructions regarding the proper usage of the device.
Only the use of genuine parts ensures perfect safety for the user and correct operation of the device. Moreover, only the accessories
mentioned in the technical documentation or explicitly approved by the manufacturer must be used. If accessories or consumable
products from other brands are used, the manufacturer cannot stand guarantee for the correct and safe operation of the device.
Damages caused through the use of accessories or consumable products from other brands will not entail right to any benefit under the
terms of warranty.
The manufacturer will be liable for the safety, reliability and functioning of the product as long as the assembly, settings, modifications,
extensions, and repairs have been carried out by the manufacturer or a company approved by the manufacturer, and if the device is
used in accordance with the instructions mentioned in this manual.
The player complies with the technical safety standards in force at the date of print of this manual. All rights reserved for the electrical
diagrams, procedures, names, and devices mentioned herein.
Any reproduction of the technical documentation, even partial, without a written authorization from Waves System is prohibited.
General Safety Instructions
This device has been shipped out from our facilities in perfect working condition. In order to preserve these conditions, for safety, and to
avoid any risk of accidental bodily injury, the user must imperatively follow the safety instructions and read the “Caution!” messages
included in this manual.
This device, manufactured by Waves System, has been designed in a way that practically eliminates any risk if it is used in accordance
with its intended purpose. Nevertheless, for the sake of safety, we would like to draw your attention to the following instructions:
When using the device, comply with all local rules and regulations in force. Any modification or conversion of the device automatically
entails loss of the certification. The operation of a modified device is liable to a penalty. In the interests of occupational safety, the
operator and the user are held responsible for complying with the regulations.
Keep the original packing for a possible product reshipment. Also ensure that the packing material is kept out of the reach of children.
Only this original packing ensures optimal protection for the product during transportation. If a product reshipment appears to be
necessary during the guarantee period, Waves System is not liable for any ensuing damages arising during the transportation and
attributable to a defective packing.
This device should be used only by persons whose training or knowledge ensures proper handling.
Before each use, the operator must check that the device is in perfect working condition.
This product must not be used in places where there is a potential explosion risk. Besides, it must neither be used in an environment
favoring combustion nor in a humid or excessively hot or cold location.
The device must be installed in a dry and dust-free area. Do not install the device directly against a wall.
-3- © 2016, Waves System
CAUTION! DO NOT EXPOSE TO MOISTURE OR DUST!
Unplu the power supply cable before any servicin !
FOR YOUR SAFETY, PLEASE READ THE USER’S GUIDE CAREFULLY BEFORE USING YOUR PLAYER.

ID-A - My Music Player and My Music Player E - User Guide V1.0
Safety Instructions a ainst Risks Due to Electric Currents
The device must be connected to a grounded AC power outlet or a European standard outlet installed as per good professional
practices.
Before connecting the device, check that the mains voltage and frequency match the specifications indicated on the mains adapter.
Before powering, check that the device and cables are not damaged. Damaged cables and connections must immediately be replaced.
Never allow the power cords to come in contact with other cables. Handle the mains adapter cable as well as all other cables connected
to the mains with extreme care.
Always connect the power cord to the device first, then to the mains. The power outlet must remain accessible after the installation.
Check the device and its mains adapter cable from time to time. Disconnect the device from the mains when it is no longer used or for
the purpose of maintenance.
Handle the power cord by using only the plug. Never remove the plug by pulling the power cord.
Electrical connections, repairs, and maintenance must be carried out by qualified personnel.
Do not switch the device on or off within a short period of time as this reduces its lifespan.
Terms of Use
This product has been designed for indoor use only.
If this device has been exposed to very high temperature fluctuations (e.g.: after transportation), do not connect it immediately. The
condensation formed inside the device could damage it. Allow the device to reach ambient temperature before connecting it.
Do not shake the device. Avoid sudden movements during its installation or handling.
When selecting the spot for installation of the player, ensure that it is not exposed to a high source of heat, moisture, or dust. There
should not be any cables lying around as they might jeopardize your and others’ safety.
Delivery Details
My Music Player
12 V / 500 mA mains adapter
Infrared remote control
USB cable Type-A to Mini-B
My Music Player LE
12 V / 2 A mains adapter
Infrared remote control
-4- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
Table of Contents
1. Introduction.................................................................................................................................................. 8
2. Features....................................................................................................................................................... 9
3. My Music Player and My Music Player E comparison..............................................................................10
4. Hardware Description................................................................................................................................. 11
4.1. My Music Player................................................................................................................................. 11
4.2. My Music Player E...........................................................................................................................12
4.3. Infrared Remote Control....................................................................................................................12
5. Installation.................................................................................................................................................. 13
5.1. My Music Player................................................................................................................................ 13
5.2. My Music Player E...........................................................................................................................14
6. Before switching on the Player.................................................................................................................. 15
6.1. Main Storage Device (Main Media)....................................................................................................15
. Introduction........................................................................................................................................ 15
. Music Folders (MUSIC)..................................................................................................................... 15
. Playlist Folders (P AY IST)............................................................................................................... 15
. Message and Commercial Folders (SPOT).......................................................................................16
. System Folder (SYSTEM).................................................................................................................16
. Temporary Folder (TMP).................................................................................................................... 17
6.2. External Audio Sources......................................................................................................................17
. Introduction........................................................................................................................................ 17
. Web Radios.......................................................................................................................................17
. Auxiliary Input (My Music Player only)...............................................................................................18
6.3. Alternative Storage Devices (Alternate Media) (My Music Player only).............................................18
6.4. Preparation of Storage Device...........................................................................................................18
6.5. Files and Folders Naming Rules........................................................................................................19
6.6. Organization of Files and Folders onto the Main Storage Device (Main Media)................................19
. Introduction........................................................................................................................................ 19
. MUSIC – Music Folders.....................................................................................................................20
. P AY IST – Playlist Folders..............................................................................................................20
. SPOT – Message and Commercial Folders.......................................................................................21
. SYSTEM – System Management Folder...........................................................................................21
6.7. Organization of Files and Folders onto Alternative Storage Devices (Alternate Media)(My Music
Player only)................................................................................................................................................ 21
7. First Use.................................................................................................................................................... 22
7.1. Requirements.................................................................................................................................... 22
7.2. Preparation........................................................................................................................................ 22
7.3. First boot............................................................................................................................................22
8. Use of the Player.......................................................................................................................................24
8.1. Playback of the Audio Files, Web radios and Other Audio Sources...................................................24
. Playback of a Music Folder (MUSIC).................................................................................................24
. Playback of a Playlist Folder (P AY IST)..........................................................................................25
. Playback of a Messages and Commercials (SPOT)..........................................................................25
. Playback of a Web Radio................................................................................................................... 26
. Switching to the Auxiliary Input of the Player (My Music Player only)................................................26
. Playback of an Alternative Storage Device (Alternate Media) (My Music Player only).......................27
8.2. Playback Command...........................................................................................................................27
. Resuming the Playback (P AY Command).......................................................................................27
. Stopping the Playback (STOP Command).........................................................................................28
. Playing the Next Track or Next Web Radio (NEXT Command).........................................................28
. Playing the Previous Track or Previous Web Radio (PREVIOUS Command)...................................29
8.3. Changing the Main Volume................................................................................................................29
9. Programming the Player............................................................................................................................ 31
9.1. Playback at the Startup (Autoplay)....................................................................................................31
. Introduction........................................................................................................................................ 31
. Setting of the ‘Autoplay’ function........................................................................................................32
-5- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
9.2. Web Radio......................................................................................................................................... 32
. Playing the Web Radios..................................................................................................................... 32
. Operation of the Monitoring Engine of the Web Radios.....................................................................33
. Settings of the Web Radio Stations...................................................................................................34
9.3. Control of the Player with a Timestamped Programming (Scheduler)...............................................34
. Introduction........................................................................................................................................ 34
. Principle............................................................................................................................................. 34
. ist of commands............................................................................................................................... 37
. Creation of a Timestamped Programming File...................................................................................38
. Application of a Timestamped Programming to the Player................................................................38
9.4. Content Management of the Main Storage Device............................................................................38
. Introduction........................................................................................................................................ 38
. Use the Main Media on a Computer..................................................................................................39
. Use the USB Device Connector (My Music Player only)...................................................................40
. Use the Embedded FTP Server.........................................................................................................40
. Use the Embedded Samba Server....................................................................................................42
. Use the Embedded FTP Clients in Synchronization Mode................................................................43
. Use the Embedded FTP Clients in Script Mode.................................................................................44
. Removable Device Storage with Script..............................................................................................46
. Setup the FTP Client Presets............................................................................................................47
9.5. Ethernet Network Connection............................................................................................................49
. Introduction........................................................................................................................................ 49
. Establishing the Wired Connection....................................................................................................50
. Identify the player on the network......................................................................................................50
. Access the Player with Internet..........................................................................................................51
. ittle Ethernet Network Glossary.......................................................................................................53
9.6. Clock of the Player.............................................................................................................................54
. Introduction........................................................................................................................................ 54
. Set the Date and the Time................................................................................................................. 55
. Set the Time Zone............................................................................................................................. 55
. Set Network Time Protocol (NTP) Parameters..................................................................................56
9.7. Settings of the Volumes and Gains of the Player...............................................................................56
. Introduction........................................................................................................................................ 56
. Change the Volumes of the Independent Outputs.............................................................................57
. Change the Gains of the Independent Outputs..................................................................................57
. Change the Volumes of the Audio Sources.......................................................................................58
9.8. Fade In and Fade Out Between the Audio Sources (FADE IN/FADE OUT).......................................58
. Introduction........................................................................................................................................ 58
. Change the Fade In and Fade Out settings.......................................................................................59
9.9. Audio File Encryption......................................................................................................................... 59
9.10. Firmware Update............................................................................................................................. 60
. Introduction........................................................................................................................................ 60
. Select a Method.................................................................................................................................60
. Determinate the Current Firmware Version.......................................................................................60
. Perform the Firmware Update............................................................................................................ 60
9.11. Settings of the Parameters with ‘system.ini’ File..............................................................................62
Appendix A. Characteristics........................................................................................................................... 63
A.I. Interfacing and Connectivity...............................................................................................................63
A.II. Audio File Formats Supported...........................................................................................................63
A.III. Playlist File Formats Supported........................................................................................................63
A.IV. Web Radio Stream Formats Supported............................................................................................63
A.V. Other File Formats Supported...........................................................................................................64
A.VI. Storage Devices...............................................................................................................................64
A.VII. Network........................................................................................................................................... 64
A.VIII. Build-in Clock................................................................................................................................. 64
A.IX. Power Supply................................................................................................................................... 64
A.X. Consumption (12 V supplied)............................................................................................................65
A.XI. Temperatures................................................................................................................................... 65
-6- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
A.XII. Size................................................................................................................................................. 65
A.XIII. Weight............................................................................................................................................ 65
Appendix B. Player Audio Diagram................................................................................................................66
B.I. My Music Player................................................................................................................................. 66
B.II. My Music Player E........................................................................................................................... 66
Appendix C. CD Menus............................................................................................................................... 67
C.I. Usual Displays................................................................................................................................... 67
C.II. Change the Main Volume.................................................................................................................. 68
C.III. Quick aunch Menu to Select an Audio Source...............................................................................68
C.IV. Advanced Menu to Select an Audio Source and Configure the Player.............................................68
Appendix D. Web server................................................................................................................................ 73
D.I. Home Page........................................................................................................................................ 73
D.II. About Page........................................................................................................................................ 74
D.III. og In Page...................................................................................................................................... 75
D.IV. User Page........................................................................................................................................ 75
D.V. Administrator Page............................................................................................................................ 77
D.VI. Date/Time........................................................................................................................................ 80
D.VII. Ethernet Page................................................................................................................................. 81
D.VIII. Web Radio Page............................................................................................................................82
D.IX. FTP Client Page............................................................................................................................... 84
Appendix E. Content Updates by Using Copy Scripts (Script).......................................................................86
E.I. Introduction.........................................................................................................................................86
E.II. [HEADER] Section.............................................................................................................................87
E.III. [COMMANDS] Section..................................................................................................................... 87
E.IV. [COMMENTS] Section.....................................................................................................................89
E.V. Examples........................................................................................................................................... 89
Appendix F. RS-232 Serial ink Protocol.......................................................................................................91
Appendix G. Configuration File (system.ini)...................................................................................................92
Appendix H. System Clock Calibration..........................................................................................................93
H.I. Introduction........................................................................................................................................ 93
H.II. Perform the NTP Calibration.............................................................................................................93
-7- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
1. Introduction
The My Music Player and My Music Player E are standalone background music players that manages
WAV/MP3 files stored on USB or SD flash drives, web radios as well as local audio source. The playback of
a wide quantity of audio files is allowed automatically, without recurrence, according to the ‘Autoplay’ setting,
a timestamped programming or an external event trigger (Web command or RS232 serial command). The
My Music Player and My Music Player E allow various possibilities of update processes, connected or
disconnected.
The My Music Player and the My Music Player E are dedicated to a wide spectrum of playback usages
within public spaces such as retails, malls hotels, waiting rooms, bars, amusement parks, etc.
-8- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
2. Features
•Playback possibilities: A wide variety of playback contexts can be performed,
◦Background music and audio content
◦Messages and commercials
◦Playlist files
◦Web radio streams
◦Extra audio sources (My Music Player only)
Audio and playlist files formats supported are WAV, MP3, encrypted MP3 and M3U.
•Web radio active monitoring: In case the web radio audio stream is broken or lost, a defined local
media audio content is played until the stream is restored to be played again.
•Timestamped programming: The playback of a defined audio source, the start/stop of the playback
and the volume change at a specific time are easy to implement thanks to the built-in clock and the
Scheduler software.
•Smart 'AutoPlay': this setting allows to start automatically the playback of predefined audio source or
timestamped audio programming. This feature is configurable and can be disabled.
•Flash drive devices:
◦The My Music Player E has an external USB host for a usage basic and a cost effective of the
content media support, by connecting a USB flash drive to the external USB host receptacle of
the player.
◦The My Music Player has a complete set of flash drive hosts: External USB host, Internal USB
host, SD/SDHC memory card slot, SATA host (HW V1.0)).
•Audio inputs and outputs: the My Music Player range of players allows to choose the right audio
solution depending on needs.
◦The My Music Player offer an uncompromising and versatile audio I/O set with unbalanced and
balanced line-level stereo audio outputs on RCA and X R connectors, and an unbalanced line-
level stereo audio auxiliary input on RCA connectors.
◦The My Music Player E offer an all-in-one cost effective audio I/O set with an unbalanced line-
level stereo audio outputs on RCA and amplified 2xXXW stereo audio output on terminal blocs.
•Networking: My Music Player and My Music Player E embedded a complete set of Ethernet
services like a Web server, a FTP server, a FTP client, a Samba server or a NTP client to ensure a
flexible and distant control, setting and content updating.
•Flexible content updating: the My Music Player range of players offers multipurpose solution to
update the musics, messages, playlists and timestamped programming depending on the player
location, the connectivity possibilities and the update frequency needs. The players embedded
dedicated functions as scripting, file synchronization, FTP and samba possibilities.
•RS-232 serial link: It is possible to control the My Music Player with a P C, a computer, or a remote
control using a serial link.
-9- © 2016, Waves System

ID-A - My Music Player and My Music Player E - User Guide V1.0
3. My Music Player and My Music Player LE
comparison
Table 1: Comparison between the My Music Player an the My Music Player LE
Function My Music Player E My Music Player
CD display ● ●
Clickable knob ● ●
Transport command buttons 1-2 ●
Infrared sensor ● ●
External USB host ● ●
Internal USB host ●
SD/SDHC memory card slot ●
SATA host (HW V1.0) ●
RCA - Unbalanced line-level stereo audio output ● ●
Terminal blocs - Amplified stereo audio output ●
X R - Balanced professional-level stereo audio output ●
RCA - Auxiliary line-level stereo audio input ●
RJ45 connector ● ●
Terminal blocs - RS-232 serial link ●
Micro USB device ●
On/Off Switch button ●
Mounting screw holes ●
Rack mountable (1/3 of a rack) - metal case ●
Small form design - plastic case ●
Playback MP3 and WAV audo files ● ●
Playback proprietary encrypted MP3 audio files ● ●
Playback M3U playlist ● ●
Web radio ● ●
Smart ’Autoplay’ function ● ●
Timestamped programming ● ●
Embedded Web server ● ●
Embedded FTP server ● ●
Embedded Samba server ● ●
Build-in RTC ● ●
Network time protocol NTP function ● ●
Content update by ‘script’ ● ●
Content update by file synchronization ● ●
Fade In/Out audio transitions ● ●
-10- © 2016, Waves System
