IDEAL Touch User manual

USER GUIDE
Wireless room thermostat
with hot water control
(DHW & single zone CH)
Logic Heat H / Logic Max Heat H / Logic System S /
Logic Max System S / Vogue System / Vogue Max System

2

3
Contents
Introduction......................................................................................................................4
Ideal Touch kit contents .............................................................................................. 5
Thermostat location guidelines................................................................................ 5
Features.............................................................................................................................6
Operating modes (auto/on/o)...............................................................................6
Using the Ideal Touch thermostat ........................................................................... 7
Setting the time..............................................................................................................8
Setting the date..............................................................................................................9
Changing central heating schedule ...................................................................... 10
Review the central heating schedule.....................................................................13
Override central heating ........................................................................................... 14
Cancel override central heating ..............................................................................16
Central heating boost..................................................................................................17
Changing hot water schedule ..................................................................................18
Review the hot water schedule ............................................................................. 20
Override hot water .......................................................................................................21
Cancel hot water override ........................................................................................23
Ideal relay transceiver ................................................................................................24
Glossary ...........................................................................................................................25
Default times..................................................................................................................26
Troubleshooting............................................................................................................26
Battery replacement...................................................................................................28
Warranty..........................................................................................................................29

Introduction
Welcome to the Ideal Touch heat
and system. This guide will help you
control both your central heating
and hot water using your Ideal Touch
Thermostat.
A quick start guide, installation
guide and FAQ’s can be found at
www.idealboilers.com.
The Ideal Touch heat and system must
be installed by a competent person.

5
Ideal Touch kit contents
A. Touch thermostat
B. Mounting bracket cover
C. Mounting bracket
D. Desktop stand
E. Ideal relay transceiver
F. Batteries (AA)
G. Screws and plugs
H. Instructions
I. SAP registration label
Thermostat location guidelines
In-between the Ideal relay transceiver and the Touch thermostat there must be:
• Less than 20 metres
• No more than a total of 3 walls and ceilings
• No large metallic objects (e.g. American fridge/freezer)
• No large mirrors or windows
• No walls running along the RF path
The Touch thermostat must not be within 1 metre of a wifi booster / router and
should not be placed near draughts, in direct sunlight or near heat sources.
You will see the Ideal relay transceiver installed in your home, usually near your hot
water cylinder. This should only be opened and worked on by a qualified electrician.
A B C
EFGHI
D
IDEAL BOILERS LTD
Model Name:
Model Qualifier:
Touch (Single Zone)
ErP Class V or ErP Class VI
I certify that this boiler is connected to a weather
compensation control as indicated:
Touch enhanced load compensator (Class V)
Touch enhanced load compensator & OS2 weather
compensator temperature sensor (Class VI)
These products are compatible with the boiler and
provide compensation control that has been
permanently enabled. The boiler has been
commissioned in accordance with the manufacturer
instructions which have been supplied to the
householder. The central heating temperature control
knob should normally be set in the mid-position.
Signed: Date:
UIN 217679 A01
Installation guide
Wireless room thermostat
with hot water control
(DHW & single zone CH)
Logic Heat H / Logic System S / Vogue System

6
Tap here to
change the
central heating
operating mode
(from auto to
continuously on to
continuously o)
Tap here to
change the hot
water operating
mode (from auto
to continuously
on to continuously
o)
Features
• Simple user Interface
• Rotating outer wheel
• Summer/winter time (GMT/BST)
automatically updated
• 7 day control of heating
• 7 day control of hot water
• Delivers maximum boiler operating
eciency
• Boost
• Tap to wake
• Up to 6 programmable ON/OFF
periods for heating and hot water
every day.
Operating modes (auto/on/o)
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
Auto Your heating will run as set by
your schedule
Your hot water will run as set by
your schedule
On
Heating is constantly on, use outer
wheel to adjust temperature
Hot water is constantly on
O Heating is constantly o Hot water is constantly o

7
Using the Ideal Touch thermostat
If central heating is timed on or continuously on, the target room temperature can be
adjusted by rotating the outer plastic wheel of the device.
If central heating is timed o then central heating can be activated by rotating the
outer wheel until the desired room temperature is shown (Boost).
Rotate to boost
room temperature
Tap to change
heating
operating mode
Flame symbol
indicates
heating on
Heating schedule
indicated by blue
tappets
Actual room
temperature
Target room
temperature
Actual room
temperature
Tap to change
hot water
operating mode
Tap to access
main menu
Flame symbol
indicates hot
water on
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
Note. Only heating schedule shown.
For hot water schedule refer to “Review the hot water schedule”.

8
Setting the time
Tap screen to wake up.
Press MENU.
Press HELP & SETTINGS.
Press CHANGE TIME.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Set system time
DONE
00 00
BACK
SETTINGS MENU
CHANGE
DAT E
CHANGE
TIME
HELP &
SUPPORT
OPTIMISATION
MODE
?
Set the time using the up and down
arrows.
Press DONE.
4

9
Tap screen to wake up.
Press MENU.
Press HELP & SETTINGS.
Press CHANGE DATE.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Set system date
DONE
18 04 18
BACK
SETTINGS MENU
CHANGE
DAT E
CHANGE
TIME
HELP &
SUPPORT
OPTIMISATION
MODE
?
Set the date using the up and down
arrows.
Press DONE.
4
Setting the date

10
Changing central heating schedule
Tap screen to wake up.
Press MENU.
The Ideal Touch thermostat comes pre-programmed with a default heating
schedule which can be easily altered and/or reviewed.
Press HEATING SCHEDULE.
Press MODIFY.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Select days to set
NEXT
MON
BACK
TUE WED
THU FRI MON SUNSAT
BACK
HEATING
SCHEDULE
MODIFY REVIEW
Press the days you would like to set.
Press NEXT.
4

11
Set ON time for period 1
DONE
05 00
BACK
Changing central heating schedule
Set the ON time using the up and
down arrows.
Press DONE.
Set the OFF time using the up and
down arrows.
Press DONE.
Set the temperature using the + and
- buttons.
Press DONE.
5
6
7
Set OFF time for period 1
DONE
08 00
BACK
YESNO
MON TUE WED THU FRI SAT SUN
Heating period 1 Set
Would you like to Modify
the second heating period
Set temperature for period 1
DONE
20 0
BACK
To add another ON period, press
YES. If not press NO.
8

12
Changing central heating schedule
Press DONE.
9
Heating schedule set
07:30
12:00
15:00
19:30
08:30
14:00
17:30
22:45
18.5
19.5
20.5
19.5
>
>
>
>
MON TUE WED THU FRI SAT SUN
DONE

13
NEXT
Heating schedule set
07:30
12:00
15:00
19:30
08:30
14:00
17:30
22:45
18.5
19.5
20.5
19.5
>
>
>
>
Sunday BACK
EDIT
Review the central heating schedule
Tap screen to wake up.
Press MENU.
Press HEATING SCHEDULE.
Press REVIEW.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
To change the schedule press EDIT.
To see the next day press NEXT. To
exit press EXIT or press NEXT on
Sunday’s schedule.
4
BACK
HEATING
SCHEDULE
MODIFY REVIEW

14
Override central heating
Tap screen to wake up.
Press MENU.
Press OVERRIDE HEATING.
Press the desired option.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Set the time required using the up
and down arrows.
Press DONE.
4
What would you like to do? BACK
KEEP HEATING OFF UNTIL ...
TURN HEATING ON UNTIL ...
Keep heating on until...
DONE
05 00
BACK
Overriding the central heating will set your heating on or o until the time you specify.

15
Override central heating
Press DONE. Note that the override
period will be shown by blue
tappets.
5
Override set
Your heating will be on
until 09:00
DONE

16
Cancel override central heating
Tap screen to wake up.
Press MENU.
Press CANCEL OVERRIDE.
Press the desired option.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
CANCEL
OVERRIDE
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Press DONE.
4
Heating override cancelled
DONE
Are you sure you would like to
cancel the override setting?
NO YES
!

17
Tap screen to wake up.
Rotate the outer wheel until your
desired target temperature is
reached.
The display will now show the target
temperature.
1
2
3
Central heating boost
Boosting the central heating will keep the heating at your desired target temperature
until the next heating on period. Once the next heating on period is reached the
Touch thermostat will revert back to the times and temperatures set in your schedule
period. If you require heating for a timed period please use the override function.
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
Target Room Temperature
23 0
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
R
o
t
a
t
e

18
Changing hot water schedule
Tap screen to wake up.
Press MENU.
The Ideal Touch thermostat comes pre-programmed with a default hot water
schedule which can be easily altered and/or reviewed.
Press HOT WATER SCHEDULE.
Press MODIFY.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
Select days to set
NEXT
MON
BACK
TUE WED
THU FRI MON SUNSAT
BACK
HOT WATER
SCHEDULE
MODIFY REVIEW
Press on the days you would like
to set.
Press NEXT.
4

19
Set ON time for period 1
DONE
05 00
BACK
Changing hot water schedule
Set the ON time using the up and
down arrows.
Press DONE.
Set the OFF time using the up and
down arrows.
Press DONE.
To modify the 2nd period press YES.
Once ON / OFF times are set for
the 2nd period, press YES to add
another period.
If no additional periods are required,
press NO.
5
6
7
Set OFF time for period 1
DONE
08 00
BACK
MON TUE WED THU FRI SAT SUN
Hot water schedule set
06:00
16:00
08:00
22:00
>
>
DONE
Hot water period set
Would you like to Modify
the second hot water period
NO YES
Press DONE.
8

20
NEXT
Hot water schedule set
05:00
14:00
18:00
08:00
16:00
20:00
>
>
>
Sunday BACK
EDIT
Review the hot water schedule
Tap screen to wake up.
Press MENU.
Press HOT WATER SCHEDULE.
Press REVIEW.
1
2
3
O
On
Auto
TARGET
Zone: 1
ROOM TEMP
21 .5
22 .5
º
º
O
On
Auto
WED 06:58
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23 0
BACK
MAIN MENU
OVERRIDE
HEATING
HEATING
SCHEDULE
OVERRIDE
HOT WATER
HOT WATER
SCHEDULE
HELP & SETTINGS
?
To change the schedule press EDIT.
To see the next day press NEXT. To
exit press BACK or press NEXT on
Sunday’s schedule.
4
BACK
HEATING
SCHEDULE
MODIFY REVIEW
