IEI Technology ITG-100AI User manual

ITG-100AI Embedded System
Page i
User Manual
,
MODEL:
ITG-100AI
Fanless Embedded System with Intel® Atom™ x5-E3930,
VGA , GbE, Two RS-232/422/485,
Two USB 3.0 and RoHS Compliant
Rev. 1.00 – October 2, 2019

ITG-100AI Embedded System
Page ii
Revision
Date Version Changes
October 2, 2019 1.00 Initial release

ITG-100AI Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

ITG-100AI Embedded System
Page iv
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

ITG-100AI Embedded System
Page v
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 2
1.3 TECHNICAL SPECIFICATIONS ...................................................................................... 3
1.4 SIDE PANEL ................................................................................................................ 4
1.5 FRONT PANEL ............................................................................................................. 5
1.6 PHYSICAL DIMENSIONS .............................................................................................. 6
2 UNPACKING ................................................................................................................. 7
2.1 UNPACKING................................................................................................................ 8
2.2 PACKING LIST............................................................................................................. 8
3 INSTALLATION ......................................................................................................... 10
3.1 ANTI-S TAT I C PRECAUTIONS .......................................................................................11
3.2 INSTALLATION PRECAUTIONS ....................................................................................11
3.3 BOTTOM COVER REMOVAL AND RE-INSTALLATION.................................................. 12
3.4 SO-DIMM INSTALLATION ....................................................................................... 13
3.5 WIRELESS LAN MODULE INSTALLATION (OPTIONAL) ............................................. 15
3.6 RS-232/422/485 SERIAL PORT CONNECTION ........................................................... 17
3.6.1 DB-9 RS-232/422/485 Serial Port Connection................................................ 17
3.6.2 RJ-45 RS-232/422/485 Serial Port Connection............................................... 18
3.7 AT / AT X MODE SELECTION...................................................................................... 21
3.7.1 AT Power Mode................................................................................................ 21
3.7.2 ATX Power Mode ............................................................................................. 22
3.8 MOUNTING THE SYSTEM .......................................................................................... 22
3.9 POWERING ON/OFF THE SYSTEM ............................................................................. 24
3.10 RESET THE SYSTEM ................................................................................................ 24
4 BIOS .............................................................................................................................. 25
4.1 INTRODUCTION......................................................................................................... 26
4.1.1 Starting Setup................................................................................................... 26

ITG-100AI Embedded System
Page vi
4.1.2 Using Setup ...................................................................................................... 26
4.1.3 Getting Help..................................................................................................... 27
4.1.4 Unable to Reboot after Configuration Changes .............................................. 27
4.1.5 BIOS Menu Bar................................................................................................ 27
4.2 MAIN........................................................................................................................ 28
4.3 ADVANCED ............................................................................................................... 29
4.3.1 ACPI Settings ................................................................................................... 30
4.3.2 F81866 Super IO Configuration ...................................................................... 31
4.3.2.1 Serial Port n Configuration ....................................................................... 31
4.3.3 Hardware Monitor ........................................................................................... 33
4.3.4 RTC Wake Settings ........................................................................................... 34
4.3.5 Serial Port Console Redirection ...................................................................... 36
4.3.5.1 Console Redirection Settings.................................................................... 36
4.3.6 CPU Configuration.......................................................................................... 39
4.3.7 USB Configuration........................................................................................... 40
4.3.8 iEi Feature........................................................................................................ 41
4.3.9 SATA Configuration ......................................................................................... 42
4.4 CHIPSET ................................................................................................................... 43
4.4.1 North Bridge Configuration............................................................................. 44
4.4.1.1 Intel IGD Configuration............................................................................ 44
4.4.2 Southbridge Configuration .............................................................................. 46
4.4.2.1 PCI Express Configuration ....................................................................... 47
4.4.2.2 SCC Configuration.................................................................................... 48
4.5 SECURITY ................................................................................................................. 49
4.6 BOOT........................................................................................................................ 50
4.7 EXIT ......................................................................................................................... 52
5 SOFTWARE INSTALLATION .................................................................................. 54
5.1 AVAILABLE DRIVERS ................................................................................................ 55
5.1.1 Driver Download ............................................................................................. 55
5.2 OPENVINO™ TOOLKIT INSTALLATION.................................................................... 57
A REGULATORY COMPLIANCE .............................................................................. 58
B SAFETY PRECAUTIONS ......................................................................................... 63
B.1 SAFETY PRECAUTIONS............................................................................................. 64

ITG-100AI Embedded System
Page vii
B.1.1 General Safety Precautions ............................................................................. 64
B.1.2 Anti-static Precautions .................................................................................... 65
B.1.3 Product Disposal ............................................................................................. 66
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 67
B.2.1 Maintenance and Cleaning.............................................................................. 67
B.2.2 Cleaning Tools ................................................................................................. 67
C BIOS MENU OPTIONS ............................................................................................. 69
D TERMINOLOGY ....................................................................................................... 72
E HAZARDOUS MATERIALS DISCLOSURE ......................................................... 76

ITG-100AI Embedded System
Page viii
List of Figures
Figure 1-1: ITG-100AI .....................................................................................................................2
Figure 1-2: ITG-100AI Side Panel ..................................................................................................4
Figure 1-3: ITG-100AI Front Panel.................................................................................................5
Figure 1-4: Physical Dimensions (mm) ........................................................................................6
Figure 3-1: Bottom Cover Retention Screws .............................................................................12
Figure 3-2: Bottom Cover Installation ........................................................................................13
Figure 3-3: SO-DIMM Socket .......................................................................................................14
Figure 3-4: SO-DIMM Installation ................................................................................................14
Figure 3-5: Accelerator Card Retention Screws........................................................................15
Figure 3-6: WLAN M.2 Card Slot Location .................................................................................16
Figure 3-7: Inserting the WLAN Card into the Slot at an Angle ...............................................16
Figure 3-8: Securing the WLAN Card .........................................................................................17
Figure 3-9: Serial Device Connector...........................................................................................18
Figure 3-10: DB-9 RS-232/422/485 Serial Port Connector ........................................................18
Figure 3-11: Serial Device Connector.........................................................................................19
Figure 3-12: RJ-45 RS-232/422/485 Serial Port Connector.......................................................19
Figure 3-13: DB-9 RS-232/422/485 Connector Pinout Location ...............................................20
Figure 3-14: AT/ATX Switch Location.........................................................................................21
Figure 3-15: Mounting the DIN Rail.............................................................................................23
Figure 3-16: Mounting to DIN Rail...............................................................................................23
Figure 3-17: Power Button Location...........................................................................................24
Figure 3-18: Reset Button Location............................................................................................24
Figure 5-1: IEI Resource Download Center................................................................................55

ITG-100AI Embedded System
Page ix
List of Tables
Table 1-1: Technical Specifications..............................................................................................4
Table 2-1: Package List Contents .................................................................................................9
Table 3-1: RJ-45 RS-232/422/485 Serial Port Pinouts ...............................................................19
Table 3-2: DB-9 RS-232/422/485 Connector Pinouts.................................................................20
Table 4-1: BIOS Navigation Keys ................................................................................................27

ITG-100AI Embedded System
Page x
BIOS Menus
BIOS Menu 1: Main .......................................................................................................................28
BIOS Menu 2: Advanced ..............................................................................................................29
BIOS Menu 3: ACPI Configuration ..............................................................................................30
BIOS Menu 4: Super IO Configuration........................................................................................31
BIOS Menu 5: Serial Port 1 Configuration Menu .......................................................................31
BIOS Menu 6: Hardware Monitor.................................................................................................34
BIOS Menu 7: RTC Wake Settings ..............................................................................................35
BIOS Menu 8: Serial Port Console Redirection .........................................................................36
BIOS Menu 9: Console Redirection Settings.............................................................................37
BIOS Menu 10: CPU Configuration .............................................................................................39
BIOS Menu 11: USB Configuration .............................................................................................40
BIOS Menu 12: iEi Feature...........................................................................................................41
BIOS Menu 13: IDE Configuration...............................................................................................42
BIOS Menu 14: Chipset ................................................................................................................43
BIOS Menu 15: Northbridge Chipset Configuration..................................................................44
BIOS Menu 16: Integrated Graphics ...........................................................................................45
BIOS Menu 17: Southbridge Chipset Configuration .................................................................46
BIOS Menu 18: PCI Express Configuration ...............................................................................47
BIOS Menu 19: PCI Express Configuration ...............................................................................48
BIOS Menu 20: Security ...............................................................................................................49
BIOS Menu 21: Boot .....................................................................................................................50
BIOS Menu 22:Exit........................................................................................................................52

ITG-100AI Embedded System
Page 1
Chapter
1
1 Introduction

ITG-100AI Embedded System
Page 2
1.1 Overview
Figure 1-1: ITG-100AI
The ITG-100AI embedded system is a fanless system with one VGA port for display. It
accepts an Intel® Atom™ x5-E3930 processor and supports one 204-pin DDR3L
SO-DIMM module pre-installed with 8 GB memory. Two RS-232/422/485 serial ports
and two USB 3.1 GEN 1 ports ensure simplified connectivity to a variety of external
peripheral devices.
1.2 Features
The ITG-100AI features are listed below:
Intel® Atom™ x5-E3930 1.3GHz (up to 1.8 GHz)
Two GbE LAN ports
Two RS-232/422/485
M.2 A-key slot for expansion
Pre-installed Mustang-MPCIE-MX2 , 2 x Intel Myriad X
VPU for AI deep learning workload consolidation

ITG-100AI Embedded System
Page 3
1.3 Technical Specifications
The ITG-100AI technical specifications are listed in Table 1-1.
Model Name ITG-100AI
AI Accelerator Mustang-MPCIE-MX2
Chassis
Color Blue & Silver
Dimensions (WxDxH) 137 x 102.8 x 50 (mm)
System Fan Fanless
Chassis Construction Extruded aluminum alloy
Motherboard
CPU Intel® Atom™ x5-E3930 1.3 GHz (up to 1.8GHz, dual-core, TDP=6.5W)
Chipset SoC
System Memory 1x 204-pin DDR3L SO-DIMM slot pre-installed with 8 GB memory
Storage
SATADOM Pre-installed 128GB
eMMC 1 x eMMC 5.0 support (up to 32GB optional)
Micro SD 1 x Micro SD Slot
I/O Interfaces
USB 3.1 Gen 1 (5Gb/s) 2 x USB 3.1 GEN 1 ports
Ethernet 2 x RJ-45 PCIe GbE by I211-AT controller
COM Port 2 x RS-232/422/485 (DB-9/RJ45)
Display 1 x VGA
Resolution Up to 1920x1080@60Hz
Wireless 1 x 802.11a/b/g/n/ac (optional)
Others 1 x Power Button, 1 x Reset Button, 1 x AT/ATX Switch,
1 x LED for HDD (Yellow),1 x LED for Power (Green)
Expansions

ITG-100AI Embedded System
Page 4
M.2 1 x M.2 2230 (A key, PCIe by 1, USB2.0)
Power
Power Input 2-pin terminal block: 9~36V DC-in
Reliability
Mounting DIN-rail
Operating Temperature -20°C ~ 50°C with air flow, 10% ~ 95%, non-condensing
Storage Temperature -20°C ~ 70°C with air flow, 10% ~ 90%, non-condensing
Operating Shock Half-sine wave shock 5G, 11ms, 100 shocks per axis, IEC68-2-27
Operating Vibration MIL-STD-810G 514.6C-1
Safety / EMC CE/FCC
Watchdog Timer Programmable 1~255 sec/min
OS
Supported OS Win10/Linux Ubuntu 16.04 LTS
Table 1-1: Technical Specifications
1.4 Side Panel
The side panel of the ITG-100AI has the following features (Figure 1-2):
1 x 9~36V DC IN
1 x VGA connector
Figure 1-2: ITG-100AI Side Panel

ITG-100AI Embedded System
Page 5
1.5 Front Panel
The front panel of the ITG-100AI has the following features (Figure 1-3):
1 x AT/ATX Switch
1 x HDD LED
1 x Power button
1 x Power LED
1 x Reset button
2 x RJ-45 LAN connectors
2 x RS-232/422/485 serial port connectors (DB-9/RJ45)
2 x USB 3.1 GEN 1 connectors
Figure 1-3: ITG-100AI Front Panel

ITG-100AI Embedded System
Page 6
1.6 Physical Dimensions
The physical dimensions of the ITG-100AI are shown below:
Figure 1-4: Physical Dimensions (mm)

ITG-100AI Embedded System
Page 7
Chapter
2
2 Unpacking

ITG-100AI Embedded System
Page 8
2.1 Unpacking
To unpack the embedded system, follow the steps below:
Step 1: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
external (second) box.
Step 2: Open the external (second) box.
Step 3: Use box cutters, a knife or a sharp pair of scissors that seals the top side of the
internal (first) box.
Step 4: Lift the system out of the boxes.
Step 5: Remove both polystyrene ends, one from each side.
Step 6: Make sure all the components listed in the packing list are present.
2.2 Packing List
NOTE:
If some of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the ITG-100AI
from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [e-mail].
The ITG-100AI is shipped with the following components:
Quantity Item and Part Number Image
1 ITG-100AI

ITG-100AI Embedded System
Page 9
Quantity Item and Part Number Image
1 Adapter
(P/N: 63040-010036-210-RS)
1 Power cord
1 Power cable
(P/N: 32102-045700-100-RS)
1 1 x RJ-45 to DB-9 COM port cable
1 Mounting Bracket
3 Screws (M3*6) for DIN mount
Table 2-1: Package List Contents

ITG-100AI Embedded System
Page 10
Chapter
3
3 Installation
