IEI Technology TANK-800 User manual

TANK-800 Embedded System
Page i
User Manual
MODEL:
TANK-800
Fanless Embedded System with Intel® Atom™ D525
Dual Core CPU, VGA, Two Gigabit Ethernet, Four USB,
RS-232/422/485, RoHS Compliant
Rev. 1.15 – September 10, 2015

TANK-800 Embedded System
Page ii
Revision
Date Version Changes
September 10, 2015 1.15 Updated memory spec
September 2, 2013 1.14 Updated Section 3.4: System Fan Installation
April 2, 2013 1.13 Added the maximum dimensions of an expansion card in
Section 1.7
February 5, 2013 1.12 Updated the optional system fan P/N
May 10, 2012 1.11 Updated Section 1.7: Backplane Options
December 5, 2011 1.10 Updated Section 2.3: Unpacking Checklist
Updated Section 3.7.9: RJ-45 RS-422/485 Serial Ports
Updated Appendix A: One Key Recovery
November 3, 2011 1.00 Initial release

TANK-800 Embedded System
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

TANK-800 Embedded System
Page iv
WARNING
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions:
(1) this device may not cause harmful interference, and(2) this device must accept any
interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
You are cautioned that any change or modifications to the equipment not expressly
approve by the party responsible for compliance could void your authority to operate
such equipment.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator & your body.

TANK-800 Embedded System
Page v
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

TANK-800 Embedded System
Page vi
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 MODEL VARIATIONS................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 TECHNICAL SPECIFICATIONS ...................................................................................... 4
1.5 CONNECTOR PANEL.................................................................................................... 6
1.6 LED INDICATORS ....................................................................................................... 7
1.7 BACKPLANE OPTIONS ................................................................................................ 8
1.8 DIMENSIONS............................................................................................................. 10
2 UNPACKING................................................................................................................11
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 12
2.2 UNPACKING PRECAUTIONS....................................................................................... 12
2.3 UNPACKING CHECKLIST........................................................................................... 13
3 INSTALLATION ......................................................................................................... 16
3.1 INSTALLATION PRECAUTIONS................................................................................... 17
3.2 CF CARD INSTALLATION .......................................................................................... 17
3.3 HARD DISK DRIVE (HDD) INSTALLATION................................................................ 19
3.4 SYSTEM FAN INSTALLATION..................................................................................... 22
3.5 PLUGGABLE DC-IN TERMINAL BLOCK INSTALLATION ............................................. 25
3.6 MOUNTING THE SYSTEM WITH MOUNTING BRACKETS ............................................ 26
3.7 EXTERNAL PERIPHERAL INTERFACE CONNECTORS................................................... 27
3.7.1 ACC Mode Selection........................................................................................ 28
3.7.2 AT/ATX Power Mode Selection........................................................................ 28
3.7.3 Audio Connector .............................................................................................. 29
3.7.4 CompactFlash® Type II................................................................................... 29
3.7.5 Digital Input/Output Connector....................................................................... 29
3.7.6 LAN Connectors............................................................................................... 30
3.7.7 Power Input, 3-pin Terminal Block.................................................................. 32

TANK-800 Embedded System
Page vii
3.7.8 Power Input, 4-pin DIN Connector ................................................................. 32
3.7.9 RJ-45 RS-422/485 Serial Ports........................................................................ 33
3.7.10 RS-232 Serial Port Connectors...................................................................... 35
3.7.11 USB Connectors............................................................................................. 37
3.7.12 VGA Connector.............................................................................................. 38
3.8 POWERING ON/OFF THE SYSTEM ............................................................................. 40
3.9 REDUNDANT POWER ................................................................................................ 40
3.9.1 ACC ON ........................................................................................................... 41
3.9.1.1 Boot-up ..................................................................................................... 42
3.9.1.2 Switch to Backup Power........................................................................... 42
3.9.1.3 Shutdown .................................................................................................. 43
3.9.2 ACC OFF......................................................................................................... 44
3.9.2.1 Boot-up ..................................................................................................... 44
3.9.2.2 Switch to Backup Power........................................................................... 44
3.9.2.3 Shutdown .................................................................................................. 45
4 BIOS.............................................................................................................................. 46
4.1 INTRODUCTION......................................................................................................... 47
4.1.1 Starting Setup................................................................................................... 47
4.1.2 Using Setup...................................................................................................... 47
4.1.3 Getting Help..................................................................................................... 48
4.1.4 Unable to Reboot After Configuration Changes.............................................. 48
4.1.5 BIOS Menu Bar................................................................................................ 48
4.2 MAIN........................................................................................................................ 49
4.3ADVANCED............................................................................................................... 50
4.3.1 ACPI Settings................................................................................................... 51
4.3.2 CPU Configuration.......................................................................................... 52
4.3.3 IDE Configuration........................................................................................... 53
4.3.4 USB Configuration........................................................................................... 55
4.3.5 Super IO Configuration ................................................................................... 56
4.3.5.1 Serial Port n Configuration....................................................................... 57
4.3.6 H/W Monitor.................................................................................................... 63
4.3.7 Serial Port Console Redirection ...................................................................... 64
4.3.8 iEi Feature........................................................................................................ 66
4.4 CHIPSET ................................................................................................................... 67

TANK-800 Embedded System
Page viii
4.4.1 Host Bridge Configuration .............................................................................. 68
4.4.2 South Bridge Configuration............................................................................. 68
4.4.3 Intel IGD SWSCI OpRegion............................................................................. 70
4.5 BOOT........................................................................................................................ 71
4.6 SECURITY................................................................................................................. 72
4.7 EXIT......................................................................................................................... 74
A REGULATORY COMPLIANCE.............................................................................. 76
B SAFETY PRECAUTIONS......................................................................................... 81
B.1 SAFETY PRECAUTIONS............................................................................................. 82
B.1.1 General Safety Precautions............................................................................. 82
B.1.2 Anti-static Precautions .................................................................................... 83
B.1.3 Product Disposal............................................................................................. 84
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 84
B.2.1 Maintenance and Cleaning.............................................................................. 84
B.2.2 Cleaning Tools................................................................................................. 85
C DIGITAL I/O INTERFACE....................................................................................... 86
C.1 INTRODUCTION........................................................................................................ 87
C.2ASSEMBLY LANGUAGE SAMPLE 1............................................................................ 88
C.3ASSEMBLY LANGUAGE SAMPLE 2............................................................................ 88
D HAZARDOUS MATERIALS DISCLOSURE......................................................... 89
D.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ....................................... 90

TANK-800 Embedded System
Page ix
List of Figures
Figure 1-1: TANK-800.....................................................................................................................2
Figure 1-2: TANK-800 Peripheral Connectors.............................................................................6
Figure 1-3: TANK-800 LED Indicators...........................................................................................7
Figure 1-4: TANK-800-D525/1GB/2P1E-R10 Backplane (HPE-3S6) ...........................................8
Figure 1-5: TANK-800-D525/1GB/1P2E-R10 Backplane (HPE-3S7) ...........................................8
Figure 1-6: Physical Dimensions (millimeters)..........................................................................10
Figure 3-1: CF Card Slot ..............................................................................................................18
Figure 3-2: CF Card Slot Cover...................................................................................................18
Figure 3-3: CF Card Installation..................................................................................................19
Figure 3-4: Unscrew the Cover....................................................................................................20
Figure 3-5: Remove the Cover from TANK-800.........................................................................20
Figure 3-6: HDD Installation ........................................................................................................21
Figure 3-7: HDD Retention Screws.............................................................................................21
Figure 3-8: Remove the HDD Bracket from the Cover..............................................................22
Figure 3-9: Remove the Fan Bracket from the Cover ...............................................................23
Figure 3-10: Remove the Temporary Retaining Bracket ..........................................................23
Figure 3-11: Secure the System Fan to the Fan Bracket..........................................................24
Figure 3-12: Reinstall the Fan Bracket.......................................................................................24
Figure 3-13: Pluggable DC-in Terminal Block Installation .......................................................25
Figure 3-14: Mounting Bracket Retention Screws ....................................................................26
Figure 3-15: ACC Mode Switch ...................................................................................................28
Figure 3-16: AT/ATX Power Mode Switch ..................................................................................28
Figure 3-17: Audio Connector.....................................................................................................29
Figure 3-18: DIO Connector Pinout Location ............................................................................30
Figure 3-19: LAN Connection......................................................................................................31
Figure 3-20: RJ-45 Ethernet Connector......................................................................................31
Figure 3-21: 3-pin Terminal Block Pinout Location ..................................................................32
Figure 3-22: Power Input Connector...........................................................................................33
Figure 3-23: RJ-45 RS-422/485 Serial Device Connection........................................................34
Figure 3-24: RJ-45 RS-422/485 Serial Port Pinout Location.....................................................34

TANK-800 Embedded System
Page x
Figure 3-25: DB-9 Connector Pinout Location ..........................................................................35
Figure 3-26: Serial Device Connector.........................................................................................36
Figure 3-27: Serial Port Pinout Location....................................................................................36
Figure 3-28: USB Device Connection.........................................................................................37
Figure 3-29: VGA Connector .......................................................................................................39
Figure 3-30: VGA Connector .......................................................................................................39
Figure 3-31: Power Button...........................................................................................................40
Figure 3-32: Power Connectors ..................................................................................................41
Figure 3-33: ACC On: AT Mode...................................................................................................42
Figure 3-34: ACC On: ATX Mode.................................................................................................42
Figure 3-35: ACC On: Switch Between PWR1 and PWR2 ........................................................43
Figure 3-36: ACC On: Shutdown.................................................................................................43
Figure 3-37: ACC Off: AT Mode...................................................................................................44
Figure 3-38: ACC Off: ATX Mode ................................................................................................44
Figure 3-39: ACC Off: Switch Between PWR1 and PWR2........................................................45
Figure 3-40: ACC Off: Shutdown.................................................................................................45

TANK-800 Embedded System
Page xi
List of Tables
Table 1-1: TANK-800 Model Variations.........................................................................................3
Table 1-2: Technical Specifications..............................................................................................5
Table 1-3: Supported Signals........................................................................................................8
Table 1-4: Rated Voltage and Current ..........................................................................................9
Table 3-1: DIO Connector Pinouts..............................................................................................30
Table 3-2: LAN Pinouts ................................................................................................................31
Table 3-3: RJ-45 Ethernet Connector LEDs...............................................................................32
Table 3-4: Power Input Pinouts...................................................................................................33
Table 3-5: RJ-45 RS-422/485 Serial Port Pinouts ......................................................................34
Table 3-6: DB-9 Connector Pinouts............................................................................................35
Table 3-7: Serial Port Pinouts......................................................................................................36
Table 3-8: USB Port Pinouts........................................................................................................38
Table 3-9: VGA Connector Pinouts.............................................................................................39
Table 4-1: BIOS Navigation Keys................................................................................................48
TANK-800

TANK-800 Embedded System
Page 1
Chapter
1
1 Introduction

TANK-800 Embedded System
Page 2
1.1 Overview
Figure 1-1: TANK-800
The TANK-800 Series embedded system is a fanless system for wide range temperature
environments. It is powered by the Intel® AtomD525 dual core processor, uses the
Intel® ICH8M chipset and has 1.0 GB of DDR3 memory. The TANK-800 Series includes
one VGA port, two PCIe GbE LAN, four USB 2.0 ports, and six COM ports.

TANK-800 Embedded System
Page 3
1.2 Model Variations
The model variations of the TANK-800 Series are listed below.
Model No. CPU Expansion Slots
TANK-800-D525/1GB/2P1E-R10 Intel® AtomD525 1.8 GHz
dual core
Two PCI slots
One PCIe x16 slot
TANK-800-D525/1GB/1P2E-R10 Intel® AtomD525 1.8 GHz
dual core
One PCI slot
One PCIe x4 slot
One PCIe x16 slot
Table 1-1: TANK-800 Model Variations
1.3 Features
The TANK-800 features are listed below:
Intel® AtomD525 1.8 GHz dual core processor
On-board 1.0 GB DDR3 memory
Redundant dual DC input
Flexible PCI/PCIe expansion slots
Two Gigabit Ethernet ports
Four USB 2.0 ports
Four RS-232 serial ports
Two RJ-45 RS-422/485 serial ports
One VGA port
One Line-out and one Mic-in audio jacks
One CompactFlash® Type II socket
AT/ATX power mode supported
RoHS compliant

TANK-800 Embedded System
Page 4
1.4 Technical Specifications
The TANK-800 technical specifications are listed in Table 1-2.
Specifications
System
CPU 1.8 GHz Intel® AtomD525 dual core CPU
Chipset Intel® ICH8M
Memory On-board 1.0 GB DDR3 memory
1 x 204-pin DDR3 SDRAM SO-DIMM slot (system max. 3.0 GB)
Ethernet Controller Dual Realtek RTL8111E PCIe GbE controllers with ASF 2.0 support
I/O and Indicators
Ethernet 2 x RJ-45 GbE ports
RS-232 4 x RS-232 serial ports (DB-9)
RS-422/RS-485 2 x RS-422/485 serial ports (RJ-45)
USB Interfaces 4 x USB 2.0 ports
VGA 1 x VGA port (2048x1536)
Audio Connector 1 x Line-out port
1 x Mic-in port
Digital I/O 1 x DIO port (8 bits)
LED Indicators AT power mode LED
ATX power mode LED
CPU temperature alert LED
HDD LED
Power 1 LED
Power 2 LED
Storage
SATA Support one 2.5” SATA HDD
CompactFlash® One CompactFlash® Type II socket

TANK-800 Embedded System
Page 5
Specifications
Power
Power Supply Redundant dual DC input 9V~36V
Power 1 (terminal block): 9 V (+/-0.3 V) ~ 36 V
Power 2 (DC jack): 10.5 V (+/-0.3 V) ~ 36 V
Power Consumption 33 W (without add-on card)
Power Button One power button
Power Mode AT or ATX power mode (selectable by AT/ATX mode switch)
Environmental and Mechanical
Operating Temperature -20°C~70°C
Storage Temperature -30°C~80°C
Mounting Desktop, wall mount
Color Black C + Silver
Physical Dimensions 136 mm x 219 mm x 188 mm (W x D x H)
Table 1-2: Technical Specifications

TANK-800 Embedded System
Page 6
1.5 Connector Panel
All external peripheral interface connectors are located on the rear panel of the TANK-800.
The peripheral interface connectors are shown in Figure 1-2.
Figure 1-2: TANK-800 Peripheral Connectors
Connectors and buttons on the rear panel include the following.
1 x 4-pin power DC jack for 10.5V (+/-0.3V) ~ 36V power input
1 x Power terminal block for 9V (+/-0.3V) ~ 36V power input
1 x Mic-in port (pink)

TANK-800 Embedded System
Page 7
1 x Line-out port (green)
4 x RS-232 serial ports
2 x RJ-45 RS-422/485 serial ports
2 x Gigabit Ethernet ports
4 x USB ports
1 x Reset button
6 x LED indicators (Section 1.6)
1 x Power button
1 x CompactFlash® Type II socket
1 x VGA output
1 x To earth
3 x Expansion slots
1 x DIO port
1 x ACC mode switch
1 x AT/ATX power mode switch
1.6 LED Indicators
There are several indicators on the rear panel of the TANK-800 as shown in Figure 1-3.
Figure 1-3: TANK-800 LED Indicators
WARNING:
The CPU Temperature Alert LED turns red when the CPU temperature
is too high. If this situation occurs, lower the environment temperature
or close some running applications to cool down the CPU.

TANK-800 Embedded System
Page 8
1.7 Backplane Options
The backplane options of the TANK-800 are shown below.
Figure 1-4: TANK-800-D525/1GB/2P1E-R10 Backplane (HPE-3S6)
Figure 1-5: TANK-800-D525/1GB/1P2E-R10 Backplane (HPE-3S7)
The supported signals of the backplane slots are listed below.
Backplane Slot Signal
PCI PCI
HPE-3S6 (2P1E) PCIe x16 PCIe x4
PCI PCI
PCIe x4 PCIe x1
HPE-3S7 (1P2E)
PCIe x16 PCIe x2
Table 1-3: Supported Signals

TANK-800 Embedded System
Page 9
The rated voltage and current of the backplanes are listed below.
Rated Voltage Rated Current
+5 V 7 A
+12 V 3.75 A
-12 V 0.1 A
+3.3 V 8 A
Table 1-4: Rated Voltage and Current
WARNING:
The system default power is 96 W. The maximum total power of the
backplane to support expansion cards is 45 W. The power of the
selected expansion cards can not exceed the max. power (45 W),
otherwise, the system may fail.
NOTE:
When using an expansion card with high power consumption, it is
recommended to install an external power supply to the 12V power
input connector on the backplane.
The maximum dimensions of the expansion card should be 190 mm in
length and 111 mm in width.
