IEI Technology SBOX-100-QM87i User manual

SBOX-100-QM87i Fanless Marine Computer
Page I
User Manual
Fanless Marine Computer with Intel
®
Core™ i5-4400E
Dual-Core CPU, Intel® QM87 Express Chipset, GbE LAN,
HDMI, DVI-D, VGA, CAN Bus, CFast Slot, RS-232/422/485,
USB 2.0, USB 3.0, iRIS-2400, RoHS Compliant
MODEL:
SBOX-100-QM87i
Rev. 1.00 – June 4, 2015

SBOX-100-QM87i Fanless Marine Computer
Page II
Revision
Date Version Changes
June 4, 2015 1.00 Initial release

SBOX-100-QM87i Fanless Marine Computer
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

SBOX-100-QM87i Fanless Marine Computer
Page IV
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 OVERVIEW.................................................................................................................. 2
1.2 FEATURES................................................................................................................... 2
1.3 FRONT PANEL............................................................................................................. 3
1.4 REAR PANEL............................................................................................................... 3
1.5 TECHNICAL SPECIFICATIONS ...................................................................................... 5
1.6 DIMENSIONS............................................................................................................... 7
2 UNPACKING................................................................................................................. 8
2.1ANTI-STATIC PRECAUTIONS........................................................................................ 9
2.2 UNPACKING PRECAUTIONS......................................................................................... 9
2.3 UNPACKING CHECKLIST ........................................................................................... 10
3 INSTALLATION ......................................................................................................... 12
3.1 INSTALLATION PRECAUTIONS................................................................................... 13
3.1.1 High Surface Temperature ............................................................................... 13
3.2 CFAST CARD INSTALLATION..................................................................................... 14
3.3 HDD INSTALLATION................................................................................................. 15
3.4AT/ATX MODE SELECTION...................................................................................... 17
3.5 MOUNTING THE SYSTEM .......................................................................................... 17
3.6 SERIAL DEVICE CONNECTION .................................................................................. 18
3.6.1 RS-232 Serial Port (COM1)............................................................................. 19
3.6.2 RS-232/422/485 Serial Port (COM2–COM5) ................................................. 19
3.7 CAN BUS CONNECTION AND CONFIGURATION ........................................................ 20
3.8 POWERING ON THE SYSTEM..................................................................................... 21
3.9 CLEAR CMOS.......................................................................................................... 22
3.10 DRIVER INSTALLATION........................................................................................... 22
3.11 IPMI SETUP PROCEDURE........................................................................................ 23
3.11.1 Managed System Hardware Setup.................................................................. 23
3.11.2 Using the IEI iMAN Web GUI........................................................................ 24
4 BIOS SETUP................................................................................................................ 26

SBOX-100-QM87i Fanless Marine Computer
Page V
4.1 INTRODUCTION......................................................................................................... 27
4.1.1 Starting Setup................................................................................................... 27
4.1.2 Using Setup...................................................................................................... 27
4.1.3 Getting Help..................................................................................................... 28
4.1.4 BIOS Menu Bar................................................................................................ 28
4.2 MAIN........................................................................................................................ 29
4.3ADVANCED............................................................................................................... 30
4.3.1 ACPI Settings................................................................................................... 31
4.3.2 RTC Wake Settings........................................................................................... 32
4.3.3 Trusted Computing........................................................................................... 33
4.3.4 CPU Configuration.......................................................................................... 34
4.3.5 SATA Configuration ......................................................................................... 37
4.3.6 Intel Rapid Start Technology............................................................................ 38
4.3.7 AMT Configuration.......................................................................................... 39
4.3.8 USB Configuration........................................................................................... 40
4.3.9 iWDD H/W Monitor......................................................................................... 41
4.3.10 F81866 Super IO Configuration.................................................................... 42
4.3.10.1 Serial Port n Configuration..................................................................... 43
4.3.11 Serial Port Console Redirection..................................................................... 48
4.3.12 IEI Feature..................................................................................................... 50
4.4 CHIPSET ................................................................................................................... 51
4.4.1 PCH-IO Configuration .................................................................................... 51
4.4.2 System Agent (SA) Configuration .................................................................... 53
4.4.2.1 Graphics Configuration............................................................................. 54
4.4.3 Memory Configuration..................................................................................... 56
4.5 BOOT........................................................................................................................ 56
4.6 SECURITY................................................................................................................. 58
4.7 SAVE &EXIT ............................................................................................................ 59
4.8 SERVER MANAGEMENT............................................................................................ 60
4.8.1 System Event Log............................................................................................. 61
4.8.2 BMC Network Configuration........................................................................... 63
5 MAINTENANCE......................................................................................................... 64
5.1 SYSTEM MAINTENANCE OVERVIEW......................................................................... 65
5.2 SO-DIMM REPLACEMENT PROCEDURE................................................................... 65

SBOX-100-QM87i Fanless Marine Computer
Page VI
6 INTERFACE CONNECTORS................................................................................... 68
6.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 69
6.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 71
6.2.1 Audio Connector (AUDIO1)............................................................................ 72
6.2.2 Battery Connector (BAT1) ............................................................................... 72
6.2.3 Chassis Intrusion Connector (CHASSIS1)....................................................... 72
6.2.4 Digital I/O Connector (DIO1)......................................................................... 73
6.2.5 EC Debug Connector (LPT_DB1)................................................................... 73
6.2.6 Fan Connector (CPU_FAN1)........................................................................... 73
6.2.7 Front Panel Connector (F_PANEL1)............................................................... 74
6.2.8 IPMI LED Connector (IPMI_LED1)............................................................... 74
6.2.9 LAN Active LED Connector (LAN_ACT_LED1)............................................. 74
6.2.10 PCIe Mini Slots (MINI-PCIE1, MINI-PCIE2)............................................... 74
6.2.11 Power Connector (PWR1).............................................................................. 75
6.2.12 Power Button Connector (PWR_BTN1) ........................................................ 76
6.2.13 PS_ON Connector (PS_ON1)........................................................................ 76
6.2.14 RS-232/422/485 Connector (COM2, COM3, COM4, COM5) ...................... 76
6.2.15 SATA Connector (S_ATA1)............................................................................. 76
6.2.16 SATA Connector (S_ATA2)............................................................................. 77
6.2.17 SATA Power Connector (SATA_PWR1)......................................................... 77
6.2.18 SATA Power Connector (SATA_PWR2)......................................................... 78
6.2.19 SMBus Connector, EC (SMB1)...................................................................... 78
6.2.20 SPI Flash Connector (SPI1) .......................................................................... 78
6.2.21 SPI Flash Connector, EC (CN2).................................................................... 79
6.2.22 TPM Connector (TPM1)................................................................................ 79
6.3 EXTERNAL INTERFACE PANEL CONNECTORS............................................................ 79
6.3.1 CAN Bus Connector (CAN1) ........................................................................... 80
6.3.2 DVI Connector (DVI)....................................................................................... 80
6.3.3 VGA Connector (VGA1)................................................................................... 81
6.3.4 HDMI Connector (HDMI1)............................................................................. 81
6.3.5 GbE Connectors (LAN1/2-CN1)...................................................................... 82
6.3.6 RS-232 Serial Port (COM1)............................................................................. 82
6.3.7 USB 2.0 Connectors (USB1)............................................................................ 82
6.3.8 USB 3.0 Connectors (USB3_CN1) .................................................................. 83

SBOX-100-QM87i Fanless Marine Computer
Page VII
A REGULATORY COMPLIANCE.............................................................................. 84
B SAFETY PRECAUTIONS......................................................................................... 89
B.1 SAFETY PRECAUTIONS............................................................................................. 90
B.1.1 General Safety Precautions............................................................................. 90
B.1.2 Anti-static Precautions .................................................................................... 91
B.1.3 Product Disposal............................................................................................. 92
B.2 MAINTENANCE AND CLEANING PRECAUTIONS ........................................................ 92
B.2.1 Maintenance and Cleaning.............................................................................. 92
B.2.2 Cleaning Tools................................................................................................. 93
C BIOS MENU OPTIONS............................................................................................. 94
C.1 BIOS CONFIGURATION OPTIONS ............................................................................. 95
D WATCHDOG TIMER ................................................................................................ 97
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 100
E.1 HAZARDOUS MATERIAL DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 101

SBOX-100-QM87i Fanless Marine Computer
Page VIII
List of Figures
Figure 1-1: SBOX-100-QM87i Fanless Marine Computer............................................................2
Figure 1-2: Front Panel ..................................................................................................................3
Figure 1-3: Rear Panel....................................................................................................................4
Figure 1-4: SBOX-100-QM87i Dimensions (mm) .........................................................................7
Figure 3-1: CFast Slot Cover Retention Screw..........................................................................14
Figure 3-2: CFast Card Installation.............................................................................................14
Figure 3-3: Bottom Cover Retention Screws.............................................................................15
Figure 3-4: HDD Bracket Retention Screws...............................................................................15
Figure 3-5: Inserting the HDD......................................................................................................16
Figure 3-6: Installing the HDD .....................................................................................................16
Figure 3-7: AT/ATX Mode Selection............................................................................................17
Figure 3-8: Mounting Brackets....................................................................................................17
Figure 3-9: Serial Port Locations................................................................................................18
Figure 3-10: CAN Bus Connector................................................................................................20
Figure 3-11: CAN Bus Jumper Locations ..................................................................................21
Figure 3-12: Power Input Connector Pinouts ............................................................................21
Figure 3-13: Power Connector and Power Button ....................................................................22
Figure 3-14: Clear CMOS Button Location.................................................................................22
Figure 3-15: IEI iMAN Web Address............................................................................................24
Figure 3-16: IEI iMAN Web GUI....................................................................................................25
Figure 5-1: Bottom Cover Retention Screws.............................................................................66
Figure 5-2: SO-DIMM Locations..................................................................................................66
Figure 5-3: SO-DIMM Installation................................................................................................67
Figure 6-1: Main Board Layout Diagram (Front Side)...............................................................69
Figure 6-2: Main Board Layout Diagram (Solder Side).............................................................70

SBOX-100-QM87i Fanless Marine Computer
Page IX
List of Tables
Table 1-1: Technical Specifications..............................................................................................6
Table 2-1: Package List Contents...............................................................................................11
Table 3-1: RS-232 Serial Port (COM1) Pinouts ..........................................................................19
Table 3-2: RS-232/422/485 Serial Port Pinouts..........................................................................19
Table 3-3: CAN Bus Connector Pinouts.....................................................................................20
Table 3-4: CAN Bus Jumper Settings.........................................................................................21
Table 4-1: BIOS Navigation Keys................................................................................................28
Table 6-1: Peripheral Interface Connectors...............................................................................72
Table 6-2: Audio Connector (AUDIO1) Pinouts .........................................................................72
Table 6-3: Battery Connector (BAT1) Pinouts...........................................................................72
Table 6-4: Chassis Intrusion Connector (CHASSIS1) Pinouts.................................................72
Table 6-5: Digital I/O Connector (DIO1) Pinouts........................................................................73
Table 6-6: EC Debug Connector (LPT_DB1) Pinouts................................................................73
Table 6-7: Fan Connector (CPU_FAN1) Pinouts........................................................................73
Table 6-8: Front Panel Connector (F_PANEL1) Pinouts...........................................................74
Table 6-9: IPMI LED Connector (IPMI_LED1) Pinouts...............................................................74
Table 6-10: LAN Active LED Connector (LAN_ACT_LED1)......................................................74
Table 6-11: PCIe Mini Slots (MINI-PCIE1, MINI-PCIE2) Pinouts ...............................................75
Table 6-12: Power Connector (PWR1) Pinouts..........................................................................75
Table 6-13: Power Button Connector (PWR_BTN1) Pinouts....................................................76
Table 6-14: PS_ON Connector (PS_ON1) Pinouts.....................................................................76
Table 6-15: RS-232/422/485 Connectors (COM2, COM3, COM4, COM5).................................76
Table 6-16: SATA Connector (S_ATA1) Pinouts .......................................................................77
Table 6-17: SATA Connector (S_ATA2) Pinouts .......................................................................77
Table 6-18: SATA Power Connector (SATA_PWR1) Pinouts...................................................77
Table 6-19: SATA Power Connector (SATA_PWR2) Pinouts...................................................78
Table 6-20: SMBus Connector, EC (SMB1)................................................................................78
Table 6-21: SPI Flash Connector (SPI1) Pinouts.......................................................................78
Table 6-22: SPI Flash Connector, EC (CN2)...............................................................................79
Table 6-23: TPM Connector (TPM1) Pinouts..............................................................................79
Table 6-24: Rear Panel Connectors............................................................................................80

SBOX-100-QM87i Fanless Marine Computer
Page X
Table 6-25: CAN Bus Connector (CAN1) Pinouts......................................................................80
Table 6-26: DVI Connector (DVI) Pinouts...................................................................................80
Table 6-27: VGA Connector (VGA1) Pinouts .............................................................................81
Table 6-28: HDMI Connector (HDMI1) Pinouts...........................................................................81
Table 6-29: RJ-45 GbE Connector (LAN1/2-CN1) Pinouts........................................................82
Table 6-30: RS-232 Serial Port (COM1) Pinouts ........................................................................82
Table 6-31: USB 2.0 Connector (USB1) Pinouts........................................................................82
Table 6-32: USB 3.0 Connector (USB3_CN1) Pinouts...............................................................83

SBOX-100-QM87i Fanless Marine Computer
Page XI
List of BIOS Menus
BIOS Menu 1: Main.......................................................................................................................29
BIOS Menu 2: Advanced..............................................................................................................30
BIOS Menu 3: ACPI Configuration..............................................................................................31
BIOS Menu 4: RTC Wake Settings..............................................................................................32
BIOS Menu 5: Trusted Computing..............................................................................................33
BIOS Menu 6: CPU Configuration...............................................................................................34
BIOS Menu 7: SATA Configuration.............................................................................................37
BIOS Menu 8: Intel Rapid Start Technology ..............................................................................38
BIOS Menu 9: AMT Configuration...............................................................................................39
BIOS Menu 10: USB Configuration.............................................................................................40
BIOS Menu 11: iWDD H/W Monitor .............................................................................................41
BIOS Menu 12: F81866 Super IO Configuration ........................................................................42
BIOS Menu 13: Serial Port n Configuration Menu.....................................................................43
BIOS Menu 14: Serial Port Console Redirection.......................................................................49
BIOS Menu 15: IEI Feature...........................................................................................................50
BIOS Menu 16: Chipset................................................................................................................51
BIOS Menu 17: PCH-IO Configuration........................................................................................51
BIOS Menu 18: System Agent (SA) Configuration....................................................................53
BIOS Menu 19: Graphics Configuration.....................................................................................54
BIOS Menu 20: Memory Configuration.......................................................................................56
BIOS Menu 21: Boot.....................................................................................................................56
BIOS Menu 22: Security...............................................................................................................58
BIOS Menu 23: Save & Exit..........................................................................................................59
BIOS Menu 24: Server Management...........................................................................................60
BIOS Menu 25: System Event Log..............................................................................................61
BIOS Menu 26: BMC Network Configuration.............................................................................63

SBOX-100-QM87i Fanless Marine Computer
Page 1
Chapter
1
1 Introduction

SBOX-100-QM87i Fanless Marine Computer
Page 2
1.1 Overview
Figure 1-1: SBOX-100-QM87i Fanless Marine Computer
The SBOX-100-QM87i series is a fanless marine computer with Intel® Core™ i5-4400E
processor and Intel® QM87 Express Chipset. The SBOX-100-QM87i is preinstalled 4 GB
of DDR3 SO-DIMM and can accommodate up to 16 GB of DDR3 memory. Storage in the
system is handled by two 2.5” SATA 6Gb/s SSD bays and the CFast card slot.
In addition, the SBOX-100-QM87i features Intelligent Platform Management Interface 2.0
(IPMI 2.0) that helps lower the overall costs of server management by enabling users to
maximize IT resource, save time and manage multiple systems. The SBOX-100-QM87i
supports IPMI 2.0 through the optional iRIS-2400 module.
The SBOX-100-QM87i has five serial ports, including four RS-232/422/485 serial ports on
the front panel and one RS-232 serial port on the rear panel. The HDMI, DVI-D and VGA
connectors allow the SBOX-100-QM87i to support various display devices. Other slots
and connectors include half-size and full-size PCIe Mini card slots, Gigabit Ethernet,
USB 2.0 ports, USB 3.0 ports and audio jacks (line-in, line-out and mic-in).
1.2 Features
The SBOX-100-QM87i has the following features
Fanless design
2.7 GHz Intel® Core™ i5-4400E CPU supported
Intel® QM87 chipset
Two 2.5” SATA 6Gb/s SSD bays
One CFast card supported
Two CAN bus 2.0B connectors
Two GbE LAN for high speed network applications

SBOX-100-QM87i Fanless Marine Computer
Page 3
Supports multiple display interfaces, including one HDMI connector, one
DVI-D connector and one VGA connector
Two USB 3.0 ports and two USB 2.0 ports
Four RS-232/422/485 and one RS-232 DB-9 serial ports
Three audio jacks: line-out, line-in and mic-in
RoHS compliant design
1.3 Front Panel
The front panel of the SBOX-100-QM87i provides access to the following external I/O
connectors and LED indicators:
4 x RS-232/422/485 serial port
1 x Power LED indicator (on: green; off: amber)
1 x HDD/CFast card LED indicator (active: blinking in red)
1 x IPMI LED indicator (enabled: blue; disabled: off)
2 x Knockout hole for SMA antenna connector
Figure 1-2: Front Panel
NOTE:
The default settings for COM2–COM5 are set to RS-485. To configure
the COM port mode, please change the BIOS options in Advanced 
F81866 Super IO Configuration Serial Port Configuration (refer to
Section 4.3.10.1).

SBOX-100-QM87i Fanless Marine Computer
Page 4
1.4 Rear Panel
The SBOX-100-QM87i rear panel provides access to the following external I/O
connectors:
1 x 18 V–36 V DC input terminal block
1 x Audio line-in jack
1 x Audio line-out jack
1 x Audio mic-in jack
1 x AT/ATX power mode switch
2 x CAN bus terminal block
1 x CFast card slot
1 x Clear CMOS switch
1 x DVI-D connector
2 x GbE RJ-45 connector
1 x HDMI connector
1 x Keyboard/Mouse PS/2 connector
1 x Power button
1 x RS-232 DB-9 serial port
2 x USB 2.0 port connector
2 x USB 3.0 port connector
1 x VGA connector
Figure 1-3: Rear Panel

SBOX-100-QM87i Fanless Marine Computer
Page 5
1.5 Technical Specifications
The specifications for the SBOX-100-QM87i are listed below.
SBOX-100-QM87i
CPU 22nm 4th generation dual-core Intel® Core™ i5-4400E CPU
(2.7GHz, 3M cache)
System Chipset Intel® QM87 Express Chipset
System Memory Two 1600 MHz 2 GB DDR3 SDRAM SO-DIMM preinstalled
(system max. 16 GB)
Ethernet Two GbE LAN RJ-45 connectors with teaming support and 2 kV
isolation protection:
LAN1: Intel® I217-LM with Intel® AMT 9.0 support
LAN2: Intel® I210-AT Ethernet controller
CAN Bus 2 x CAN bus 2.0B terminal block (3-pin) with 2.5 kV isolation
protection
Display 1 x DVI-D connector
1 x HDMI connector
1 x VGA connector
Serial Port 1 x RS-232 DB-9 serial port (non-isolated)
4 x RS-232/422/485 DB-9 serial port (2.5 kV isolation protection)
USB 2 x USB 2.0 port
2 x USB 3.0 port
Audio 1 x Line-in jack
1 x Line-out jack
1 x Mic-in jack

SBOX-100-QM87i Fanless Marine Computer
Page 6
Keyboard/Mouse 1 x PS/2 connector
Storage 2 x 2.5” SATA 6GB/s SSD bay with RAID 0/1 function
1 x External CFast socket (with a screwed cover)
Expansion Slot 1 x Full-size PCIe Mini slot
1 x Full-size/Half-size PCIe Mini slot
1 x iRIS-2400 (remote management module) slot
LED Indicators Power (on: green; off: orange)
HDD/CFast (active: blinking in red)
IPMI (enabled: blue; disabled: off)
Power Input Isolated 18 V–36 V DC, 8 A–4 A (max.) via 3-pin terminal block
Power Supply 150 W DC input ATX power supply module preinstalled
Chassis Construction Aluminum Alloy (top cover) with heavy duty metal
Mounting Wall mounting
Watchdog Timer Supporting 1-255 levels for time interval system reset
Operating Temperature -15ºC ~ 55ºC
Storage Temperature -20 ºC ~ 60ºC
Operating Humidity 5% ~ 95%
Color Black
Weight (Net/Gross) 4.08 kg/6.03 kg
Dimensions (W x D x H) 328 mm x 225 mm x 70 mm
Operation Vibration IEC 60945 and DNV 2.4 compliant
EMC CE, FCC
Safety DVN, IEC 60945 4th, IACS-E10, IEC 61174 compliant
Table 1-1: Technical Specifications

SBOX-100-QM87i Fanless Marine Computer
Page 7
1.6 Dimensions
The physical dimensions of the SBOX-100-QM87i are shown in 64Figure 1-4.
Figure 1-4: SBOX-100-QM87i Dimensions (mm)

SBOX-100-QM87i Fanless Marine Computer
Page 8
Chapter
2
2 Unpacking
