IEI Technology KINO-DQM871 User manual

KINO-DQM871 Mini-ITX SBC
Page i
User Manual
Mini-ITX SBC with 4th Generation 22nm Intel
®
Mobile CPU
Up to 16.0 GB DDR3, HDMI, LVDS, DisplayPort, VGA
Dual GbE, SATA 6Gb/s, USB 3.0, Dual PCIe Mini
PCIe x16, Intel® AMT 9.0, RoHS
MODEL:
KINO-DQM871
Rev. 1.00 – 30 August, 2013

KINO-DQM871 Mini-ITX SBC
Page ii
Revision
Date Version Changes
30 August, 2013 1.00 Initial release

KINO-DQM871 Mini-ITX SBC
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

KINO-DQM871 Mini-ITX SBC
Page iv
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 INTRODUCTION........................................................................................................... 2
1.2 BENEFITS ................................................................................................................... 3
1.3 FEATURES................................................................................................................... 3
1.4 CONNECTORS ............................................................................................................. 4
1.5 DIMENSIONS............................................................................................................... 5
1.6 DATA FLOW................................................................................................................ 6
1.7 TECHNICAL SPECIFICATIONS ...................................................................................... 7
2 PACKING LIST............................................................................................................. 9
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 10
2.2 UNPACKING PRECAUTIONS....................................................................................... 10
2.3 PACKING LIST............................................................................................................11
2.4 OPTIONAL ITEMS...................................................................................................... 12
3 CONNECTOR PINOUTS........................................................................................... 14
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 15
3.1.1 Layout .............................................................................................................. 15
3.1.2 Peripheral Interface Connectors ..................................................................... 16
3.1.3 External Interface Panel Connectors............................................................... 17
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 18
3.2.1 ATX Power Control Connector........................................................................ 18
3.2.2 Battery Connector............................................................................................ 19
3.2.3 Digital I/O Connector...................................................................................... 20
3.2.4 DisplayPort Connector.................................................................................... 21
3.2.5 EC Debug Port................................................................................................. 22
3.2.6 Fan Connector (CPU)...................................................................................... 23
3.2.7 Fan Connector (System) .................................................................................. 23
3.2.8 Front Panel Connector .................................................................................... 24
3.2.9 Keyboard/Mouse Connector............................................................................ 25
3.2.10 LAN Active LED Connector........................................................................... 26

KINO-DQM871 Mini-ITX SBC
Page v
3.2.11 LVDS Connector............................................................................................. 27
3.2.12 LVDS Backlight Connector............................................................................ 29
3.2.13 PCIe Mini Card Slot (Full-size)..................................................................... 29
3.2.14 PCIe Mini Card Slot (Half-size) .................................................................... 31
3.2.15 PCI Express x16 Slot...................................................................................... 32
3.2.16 Power Button (On-board).............................................................................. 35
3.2.17 Power Connector (12V)................................................................................. 35
3.2.18 RS-232 Serial Port Connectors (COM2 ~ COM5)........................................ 36
3.2.19 RS-422/485 Serial Port Connector (COM6).................................................. 37
3.2.20 SATA 6Gb/s Drive Connectors....................................................................... 38
3.2.21 SATA 3Gb/s Drive Connectors....................................................................... 39
3.2.22 SATA Power Connectors................................................................................ 40
3.2.23 SMBus Connector .......................................................................................... 41
3.2.24 SO-DIMM Connectors................................................................................... 42
3.2.25 SPI Flash Connector...................................................................................... 43
3.2.26 SPI Flash Connector (EC)............................................................................. 44
3.2.27 TPM Connector.............................................................................................. 45
3.2.28 USB 2.0 Connectors....................................................................................... 46
3.2.29 USB 3.0/2.0 Connector.................................................................................. 47
3.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 48
3.3.1 Audio Connector .............................................................................................. 48
3.3.2 Ethernet and USB 2.0 Connectors................................................................... 49
3.3.3 Ethernet and USB 3.0 Connectors................................................................... 50
3.3.4 HDMI Connectors............................................................................................ 51
3.3.5 Power Connector (12 V, Power Adapter) ........................................................ 52
3.3.6 Serial Port Connector (COM1) ....................................................................... 53
3.3.7 VGA Connector................................................................................................ 53
4 INSTALLATION ......................................................................................................... 55
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 56
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 56
4.3 COOLING KIT INSTALLATION.................................................................................... 58
4.4 SO-DIMM INSTALLATION ....................................................................................... 60
4.5 PCIE MINI CARD INSTALLATION .............................................................................. 61
4.6 JUMPER SETTINGS .................................................................................................... 62

KINO-DQM871 Mini-ITX SBC
Page vi
4.6.1 AT/ATX Mode Selection ................................................................................... 62
4.6.2 Clear CMOS..................................................................................................... 63
4.6.3 LVDS Voltage Selection.................................................................................... 64
4.6.4 LVDS Resolution Selection .............................................................................. 65
4.7 CHASSIS INSTALLATION............................................................................................ 66
4.7.1 Airflow.............................................................................................................. 66
4.7.2 Motherboard Installation................................................................................. 67
4.8 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 67
4.8.1 SATA Drive Connection ................................................................................... 67
4.8.2 Single RS-232 Cable (w/o Bracket) ................................................................. 68
4.9 EXTERNAL PERIPHERAL INTERFACE CONNECTION ................................................... 69
4.9.1 Audio Connector .............................................................................................. 69
4.9.2 HDMI Display Device Connection.................................................................. 70
4.9.3 LAN Connection (Single Connector)............................................................... 71
4.9.4 Serial Device Connection ................................................................................ 72
4.9.5 USB Connection (Dual Connector)................................................................. 73
4.9.6 VGA Monitor Connection ................................................................................ 74
4.10 INTEL®AMTSETUP PROCEDURE........................................................................... 75
5 BIOS.............................................................................................................................. 77
5.1 INTRODUCTION......................................................................................................... 78
5.1.1 Starting Setup................................................................................................... 78
5.1.2 Using Setup...................................................................................................... 78
5.1.3 Getting Help..................................................................................................... 79
5.1.4 Unable to Reboot after Configuration Changes.............................................. 79
5.1.5 BIOS Menu Bar................................................................................................ 79
5.2 MAIN........................................................................................................................ 80
5.3ADVANCED............................................................................................................... 81
5.3.1 ACPI Settings................................................................................................... 82
5.3.2 RTC Wake Settings........................................................................................... 83
5.3.3 Trusted Computing........................................................................................... 84
5.3.4 CPU Configuration.......................................................................................... 86
5.3.5 SATA Configuration ......................................................................................... 88
5.3.6 Intel(R) Rapid Start Technology....................................................................... 89
5.3.7 AMT Configuration.......................................................................................... 90

KINO-DQM871 Mini-ITX SBC
Page vii
5.3.8 USB Configuration........................................................................................... 91
5.3.9 iWDD H/W Monitor......................................................................................... 92
5.3.9.1 Smart Fan Mode Configuration................................................................ 92
5.3.10 F81866 Super IO Configuration.................................................................... 94
5.3.10.1 Serial Port n Configuration..................................................................... 94
5.3.11 F81866 H/W Monitor................................................................................... 100
5.3.11.1 Smart Fan Mode Configuration ............................................................ 101
5.3.12 Serial Port Console Redirection.................................................................. 102
5.3.13 iEi Feature ................................................................................................... 105
5.4 CHIPSET ................................................................................................................. 106
5.4.1 System Agent (SA) Configuration .................................................................. 107
5.4.1.1 Graphics Configuration........................................................................... 107
5.4.1.2 NB PCIe Configuration............................................................................110
5.4.1.3 Memory Configuration ............................................................................111
5.4.2 PCH-IO Configuration ...................................................................................112
5.4.2.1 PCI Express Configuration......................................................................113
5.5 BOOT.......................................................................................................................114
5.6 SECURITY................................................................................................................116
5.7 SAVE &EXIT...........................................................................................................117
6 SOFTWARE DRIVERS.............................................................................................119
6.1AVAILABLE SOFTWARE DRIVERS ............................................................................ 120
6.2 STARTING THE DRIVER PROGRAM .......................................................................... 120
6.3 CHIPSET DRIVER INSTALLATION............................................................................. 122
6.4 GRAPHICS DRIVER INSTALLATION.......................................................................... 125
6.5 LAN DRIVER INSTALLATION.................................................................................. 128
6.6 USB 3.0 DRIVER INSTALLATION ............................................................................ 133
6.7AUDIO DRIVER INSTALLATION ............................................................................... 136
6.8 INTEL®AMTDRIVER INSTALLATION .................................................................... 138
A BIOS OPTIONS ........................................................................................................ 141
B ONE KEY RECOVERY........................................................................................... 144
B.1 ONE KEY RECOVERY INTRODUCTION .................................................................... 145
B.1.1 System Requirement....................................................................................... 146
B.1.2 Supported Operating System......................................................................... 147

KINO-DQM871 Mini-ITX SBC
Page viii
B.2 SETUP PROCEDURE FOR WINDOWS........................................................................ 148
B.2.1 Hardware and BIOS Setup ............................................................................ 149
B.2.2 Create Partitions ........................................................................................... 149
B.2.3 Install Operating System, Drivers and Applications..................................... 153
B.2.4 Building the Recovery Partition.................................................................... 154
B.2.5 Create Factory Default Image....................................................................... 156
B.3AUTO RECOVERY SETUP PROCEDURE.................................................................... 161
B.4 SETUP PROCEDURE FOR LINUX.............................................................................. 166
B.5 RECOVERY TOOL FUNCTIONS ................................................................................ 169
B.5.1 Factory Restore ............................................................................................. 171
B.5.2 Backup System............................................................................................... 172
B.5.3 Restore Your Last Backup.............................................................................. 173
B.5.4 Manual........................................................................................................... 174
B.6 RESTORE SYSTEMS FROM A LINUX SERVER THROUGH LAN.................................. 175
B.6.1 Configure DHCP Server Settings.................................................................. 176
B.6.2 Configure TFTP Settings............................................................................... 177
B.6.3 Configure One Key Recovery Server Settings............................................... 178
B.6.4 Start the DHCP, TFTP and HTTP................................................................. 179
B.6.5 Create Shared Directory................................................................................ 179
B.6.6 Setup a Client System for Auto Recovery...................................................... 180
B.7 OTHER INFORMATION............................................................................................ 183
B.7.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller....................... 183
B.7.2 System Memory Requirement ........................................................................ 185
C TERMINOLOGY ..................................................................................................... 186
D DIGITAL I/O INTERFACE..................................................................................... 190
D.1 INTRODUCTION...................................................................................................... 191
D.2 DIO CONNECTOR PINOUTS ................................................................................... 191
D.3ASSEMBLY LANGUAGE SAMPLES........................................................................... 192
D.3.1 Enable the DIO Input Function .................................................................... 192
D.3.2 Enable the DIO Output Function.................................................................. 192
E HAZARDOUS MATERIALS DISCLOSURE ....................................................... 193
E.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY ..................................... 194

KINO-DQM871 Mini-ITX SBC
Page ix
List of Figures
Figure 1-1: KINO-DQM871..............................................................................................................2
Figure 1-2: Connectors ..................................................................................................................4
Figure 1-3: KINO-DQM871 Dimensions (mm) ..............................................................................5
Figure 1-4: Data Flow Diagram......................................................................................................6
Figure 3-1: Connector and Jumper Locations...........................................................................15
Figure 3-2: ATX Power Control Connector Location................................................................18
Figure 3-3: Battery Connector Location.....................................................................................19
Figure 3-4: Digital I/O Connector Location ................................................................................20
Figure 3-5: DisplayPort Connector Location.............................................................................21
Figure 3-6: BIOS Debug Port Location.......................................................................................22
Figure 3-7: CPU Fan Connector Location..................................................................................23
Figure 3-8: System Fan Connector Location.............................................................................24
Figure 3-9: Front Panel Connector Location .............................................................................25
Figure 3-10: Keyboard/Mouse Connector Location..................................................................26
Figure 3-11: LAN Active LED Connector Location....................................................................27
Figure 3-12: LVDS Connector Location......................................................................................28
Figure 3-13: LVDS Backlight Inverter Connector......................................................................29
Figure 3-14: PCIe Mini Card Slot Location.................................................................................30
Figure 3-15: PCIe Mini Card Slot Location.................................................................................31
Figure 3-16: PCIe x16 Slot Location ...........................................................................................33
Figure 3-17: On-board Power Button Location .........................................................................35
Figure 3-18: Power Connector Location ....................................................................................36
Figure 3-19: RS-232 Serial Port Connector Location................................................................37
Figure 3-20: RS-422/485 Serial Port Connector Location.........................................................38
Figure 3-21: SATA 6Gb/s Drive Connector Locations..............................................................39
Figure 3-22: SATA 3Gb/s Drive Connector Locations..............................................................40
Figure 3-23: SATA Power Connector Locations .......................................................................41
Figure 3-24: SMBus Connector Location...................................................................................42
Figure 3-25: SO-DIMM Connector Locations.............................................................................43
Figure 3-26: SPI Flash Connector Location...............................................................................43

KINO-DQM871 Mini-ITX SBC
Page x
Figure 3-27: EC SPI Flash Connector Location.........................................................................44
Figure 3-28: TPM Connector Location........................................................................................45
Figure 3-29: USB Connector Locations......................................................................................46
Figure 3-30: USB 3.0/2.0 Connector Location ...........................................................................47
Figure 3-31: External Interface Connectors...............................................................................48
Figure 3-32: Audio Jacks.............................................................................................................49
Figure 3-33: Ethernet Connector.................................................................................................49
Figure 3-34: Ethernet Connector.................................................................................................51
Figure 3-35: HDMI Connector......................................................................................................52
Figure 3-36: 4-pin Power Mini-DIN Connection .........................................................................52
Figure 3-37: Serial Port Pinouts..................................................................................................53
Figure 3-38: VGA Connector .......................................................................................................54
Figure 4-1: Install Support Bracket.............................................................................................58
Figure 4-2: Align the Cooling Kit.................................................................................................59
Figure 4-3: Secure the Cooling Kit..............................................................................................60
Figure 4-4: SO-DIMM Installation................................................................................................60
Figure 4-5: PCIe Mini Card Installation.......................................................................................61
Figure 4-6: AT/ATX Mode Selection Jumper Location..............................................................63
Figure 4-7: Clear CMOS Jumper Location .................................................................................64
Figure 4-8: LVDS Voltage Selection Jumper Location .............................................................65
Figure 4-9: LVDS Resolution Selection Jumper Location........................................................66
Figure 4-10: SATA Drive Cable Connection...............................................................................67
Figure 4-11: Single RS-232 Cable Installation ...........................................................................68
Figure 4-12: Audio Connector.....................................................................................................70
Figure 4-13: HDMI Connection....................................................................................................71
Figure 4-14: LAN Connection......................................................................................................72
Figure 4-15: Serial Device Connector.........................................................................................73
Figure 4-16: USB Connector........................................................................................................74
Figure 4-17: VGA Connector .......................................................................................................75
Figure 6-1: Start Up Screen ...................................................................................................... 121
Figure 6-2: Drivers..................................................................................................................... 121
Figure 6-3: Chipset Driver Welcome Screen........................................................................... 122
Figure 6-4: Chipset Driver License Agreement...................................................................... 123
Figure 6-5: Chipset Driver Read Me File ................................................................................. 123
Figure 6-6: Chipset Driver Setup Operations ......................................................................... 124

KINO-DQM871 Mini-ITX SBC
Page xi
Figure 6-7: Chipset Driver Installation Finish Screen............................................................ 125
Figure 6-8: Graphics Driver Welcome Screen ........................................................................ 126
Figure 6-9: Graphics Driver License Agreement.................................................................... 126
Figure 6-10: Graphics Driver Read Me File............................................................................. 127
Figure 6-11: Graphics Driver Setup Operations..................................................................... 127
Figure 6-12: Graphics Driver Installation Finish Screen ....................................................... 128
Figure 6-13: Windows Control Panel....................................................................................... 129
Figure 6-14: System Control Panel.......................................................................................... 129
Figure 6-15: Device Manager List ............................................................................................ 130
Figure 6-16: Update Driver Software Window ........................................................................ 131
Figure 6-17: Locate Driver Files............................................................................................... 131
Figure 6-18: LAN Driver Installation ........................................................................................ 132
Figure 6-19: LAN Driver Installation Complete....................................................................... 132
Figure 6-20: USB 3.0 Driver Welcome Screen........................................................................ 133
Figure 6-21: USB 3.0 Driver License Agreement.................................................................... 134
Figure 6-22: USB 3.0 Driver Read Me File............................................................................... 134
Figure 6-23: USB 3.0 Driver Setup Operations....................................................................... 135
Figure 6-24: USB 3.0 Driver Installation Finish Screen ......................................................... 135
Figure 6-25: Audio Driver Welcome Screen............................................................................ 136
Figure 6-26: Audio Driver Installation...................................................................................... 137
Figure 6-27: Audio Driver Installation Complete.................................................................... 137
Figure 6-28: Intel® ME Driver Welcome Screen ..................................................................... 138
Figure 6-29: Intel® ME Driver License Agreement................................................................. 139
Figure 6-30: Intel® ME Driver Setup Operations.................................................................... 139
Figure 6-31: Intel® ME Driver Installation Finish Screen ...................................................... 140
Figure B-1: IEI One Key Recovery Tool Menu ........................................................................ 145
Figure B-2: Launching the Recovery Tool.............................................................................. 150
Figure B-3: Recovery Tool Setup Menu .................................................................................. 150
Figure B-4: Command Prompt ................................................................................................. 151
Figure B-5: Partition Creation Commands.............................................................................. 152
Figure B-6: Launching the Recovery Tool.............................................................................. 154
Figure B-7: Manual Recovery Environment for Windows..................................................... 154
Figure B-8: Building the Recovery Partition........................................................................... 155
Figure B-9: Press Any Key to Continue .................................................................................. 155
Figure B-10: Press F3 to Boot into Recovery Mode............................................................... 156

KINO-DQM871 Mini-ITX SBC
Page xii
Figure B-11: Recovery Tool Menu ........................................................................................... 156
Figure B-12: About Symantec Ghost Window........................................................................ 157
Figure B-13: Symantec Ghost Path ......................................................................................... 157
Figure B-14: Select a Local Source Drive ............................................................................... 158
Figure B-15: Select a Source Partition from Basic Drive ...................................................... 158
Figure B-16: File Name to Copy Image to ............................................................................... 159
Figure B-17: Compress Image.................................................................................................. 159
Figure B-18: Image Creation Confirmation............................................................................. 160
Figure B-19: Image Creation Complete................................................................................... 160
Figure B-20: Image Creation Complete................................................................................... 160
Figure B-21: Press Any Key to Continue ................................................................................ 161
Figure B-22: Auto Recovery Utility.......................................................................................... 162
Figure B-23: Disable Automatically Restart............................................................................ 162
Figure B-24: Launching the Recovery Tool............................................................................ 163
Figure B-25: Auto Recovery Environment for Windows ....................................................... 163
Figure B-26: Building the Auto Recovery Partition................................................................ 164
Figure B-27: Factory Default Image Confirmation ................................................................. 164
Figure B-28: Image Creation Complete................................................................................... 165
Figure B-29: Press any key to continue.................................................................................. 165
Figure B-30: IEI Feature ............................................................................................................ 166
Figure B-31: Partitions for Linux.............................................................................................. 167
Figure B-32: Manual Recovery Environment for Linux ......................................................... 168
Figure B-33: Access menu.lst in Linux (Text Mode).............................................................. 168
Figure B-34: Recovery Tool Menu ........................................................................................... 169
Figure B-35: Recovery Tool Main Menu.................................................................................. 170
Figure B-36: Restore Factory Default...................................................................................... 171
Figure B-37: Recovery Complete Window.............................................................................. 171
Figure B-38: Backup System.................................................................................................... 172
Figure B-39: System Backup Complete Window ................................................................... 172
Figure B-40: Restore Backup ................................................................................................... 173
Figure B-41: Restore System Backup Complete Window..................................................... 173
Figure B-42: Symantec Ghost Window ................................................................................... 174
Figure B-43: Disable Automatically Restart............................................................................ 181

KINO-DQM871 Mini-ITX SBC
Page xiii
List of Tables
Table 1-1: Technical Specifications..............................................................................................8
Table 2-1: Packing List.................................................................................................................12
Table 2-2: Optional Items.............................................................................................................13
Table 3-1: Peripheral Interface Connectors...............................................................................17
Table 3-2: Rear Panel Connectors..............................................................................................17
Table 3-3: ATX Power Control Connector Pinouts....................................................................18
Table 3-4: Battery Connector Pinouts........................................................................................20
Table 3-5: Digital I/O Connector Pinouts....................................................................................20
Table 3-6: DisplayPort Connector Pinouts ................................................................................21
Table 3-7: EC Debug Port Pinouts..............................................................................................22
Table 3-8: CPU Fan Connector Pinouts......................................................................................23
Table 3-9: System Fan Connector Pinouts ................................................................................24
Table 3-10: Front Panel Connector Pinouts...............................................................................25
Table 3-11: Keyboard/Mouse Connector Pinouts .....................................................................26
Table 3-12: LAN Active LED Connector Pinouts.......................................................................27
Table 3-13: LVDS Connector Pinouts.........................................................................................28
Table 3-14: Backlight Inverter Connector Pinouts....................................................................29
Table 3-15: PCIe Mini Card Slot Pinouts ....................................................................................31
Table 3-16: PCIe Mini Card Slot Pinouts ....................................................................................32
Table 3-17: PCIe x16 Side A Pinouts ..........................................................................................34
Table 3-18: PCIe x16 Side B Pinouts ..........................................................................................35
Table 3-19: Power Connector Pinouts........................................................................................36
Table 3-20: Serial Port Connector Pinouts ................................................................................37
Table 3-21: RS-422/485 Serial Port Connector Pinouts............................................................38
Table 3-22: DB-9 RS-422/485 Pinouts.........................................................................................38
Table 3-23: SATA 6Gb/s Drive Connector Pinouts....................................................................39
Table 3-24: SATA 3Gb/s Drive Connector Pinouts....................................................................40
Table 3-25: SATA Power Connector Pinouts.............................................................................41
Table 3-26: SMBus Connector Pinouts ......................................................................................42
Table 3-27: SPI Flash Connector Pinouts ..................................................................................44

KINO-DQM871 Mini-ITX SBC
Page xiv
Table 3-28: EC SPI Flash Connector Pinouts ............................................................................45
Table 3-29: TPM Connector Pinouts...........................................................................................46
Table 3-30: USB Port Connector Pinouts...................................................................................47
Table 3-31: USB 3.0/2.0 Connector Pinouts...............................................................................48
Table 3-32: LAN Pinouts ..............................................................................................................49
Table 3-33: Connector LEDs........................................................................................................50
Table 3-34: External USB 2.0 Port Pinouts ................................................................................50
Table 3-35: LAN Pinouts ..............................................................................................................50
Table 3-36: Connector LEDs........................................................................................................51
Table 3-37: External USB 3.0 Port Pinouts ................................................................................51
Table 3-38: HDMI Connector Pinouts .........................................................................................52
Table 3-39: Serial Port Pinouts....................................................................................................53
Table 3-40: VGA Connector Pinouts...........................................................................................54
Table 4-1: Jumpers.......................................................................................................................62
Table 4-2: LVDS Voltage Selection Jumper Settings................................................................64
Table 4-3: LVDS Resolution Selection Jumper Settings..........................................................66
Table 5-1: BIOS Navigation Keys................................................................................................79
Table 6-1: Digital I/O Connector Pinouts................................................................................. 191

KINO-DQM871 Mini-ITX SBC
Page xv
BIOS Menus
BIOS Menu 1: Main.......................................................................................................................80
BIOS Menu 2: Advanced..............................................................................................................82
BIOS Menu 3: ACPI Settings .......................................................................................................82
BIOS Menu 4: RTC Wake Settings..............................................................................................83
BIOS Menu 5: Trusted Computing..............................................................................................85
BIOS Menu 6: CPU Configuration...............................................................................................86
BIOS Menu 7: SATA Configuration.............................................................................................88
BIOS Menu 8: Intel(R) Rapid Start Technology .........................................................................89
BIOS Menu 9: AMT Configuration...............................................................................................90
BIOS Menu 10: USB Configuration.............................................................................................91
BIOS Menu 11: iWDD H/W Monitor .............................................................................................92
BIOS Menu 12: Smar Fan Mode Configuration..........................................................................93
BIOS Menu 13: F81866 Super IO Configuration........................................................................94
BIOS Menu 14: Serial Port n Configuration Menu.....................................................................94
BIOS Menu 15: F81866 H/W Monitor........................................................................................ 100
BIOS Menu 16: Smart Fan Mode Configuration ..................................................................... 101
BIOS Menu 17: Serial Port Console Redirection.................................................................... 102
BIOS Menu 18: iEi Feature........................................................................................................ 105
BIOS Menu 19: Chipset............................................................................................................. 106
BIOS Menu 20: System Agent (SA) Configuration................................................................. 107
BIOS Menu 21: Graphics Configuration.................................................................................. 108
BIOS Menu 22: NB PCIe Configuration ................................................................................... 110
BIOS Menu 23: Memory Configuration.................................................................................... 111
BIOS Menu 24: PCH-IO Configuration..................................................................................... 112
BIOS Menu 25: PCI Express Configuration ............................................................................ 113
BIOS Menu 26: Boot.................................................................................................................. 114
BIOS Menu 27: Security............................................................................................................ 116
BIOS Menu 28: Save & Exit.......................................................................................................117
KINO-DQM871

KINO-DQM871 Mini-ITX SBC
Page 1
Chapter
1
1 Introduction

KINO-DQM871 Mini-ITX SBC
Page 2
1.1 Introduction
Figure 1-1: KINO-DQM871
The KINO-DQM871 is a Mini-ITX SBC with a 4th generation 22nm Intel® mobile CPU and
Intel® QM87 Express Chipset. Storage on the board is handled by two SATA 6Gb/s ports,
two SATA 3Gb/s ports and one PCIe Mini socket for connecting a hard drive, optical drive
or SSD.
The board has four types of graphics outputs that support triple independent display. A
VGA output connects to a VGA monitor. One LVDS connector supports 18/24-bit
dual-channel display. Two HDMI connectors support HDMI 1080p display and an internal
DisplayPort connector supports DisplayPort displays.
Other slots and connectors include RS-232 ports, RS-422/485 port, Gigabit Ethernet, USB
3.0 ports, USB 2.0 ports, TPM, SMBus and digital I/O.

KINO-DQM871 Mini-ITX SBC
Page 3
1.2 Benefits
Some of the KINO-DQM871 motherboard benefits include:
Low power consumption
Wide range of I/O interfaces
Triple independent display support
1.3 Features
Some of the KINO-DQM871 motherboard features are listed below:
Mini-ITX form factor
RoHS compliant
4th generation 22mm Intel® Core™ mobile processor
1066/1333/1600MHz dual-channel DDR3 SDRAM
Intel® AMT 9.0 support
Dual GbE
Supports VGA, HDMI, LVDS and DisplayPort interface for triple independent
display (HDMI V1.4a compliant)
14 USB ports (ten USB 2.0, four USB 3.0)
Five RS-232 serial ports and one RS-422/485 serial port
Two PCIe Mini card slots
One PCIe x16 slot

KINO-DQM871 Mini-ITX SBC
Page 4
1.4 Connectors
The connectors on the KINO-DQM871 are shown in the figure below.
Figure 1-2: Connectors

KINO-DQM871 Mini-ITX SBC
Page 5
1.5 Dimensions
The main dimensions of the KINO-DQM871 are shown in the diagram below.
Figure 1-3: KINO-DQM871 Dimensions (mm)
