IEI Technology NANO-GX2 User manual

NANO-GX2 EPIC NANO Motherboard
Page i

NANO-GX2 EPIC NANO Motherboard
Page ii
Revision
Date Version Changes
May, 2008 1.00 Initial release

NANO-GX2 EPIC NANO Motherboard
Page iii
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

NANO-GX2 EPIC NANO Motherboard
Page iv
Manual Conventions
WARNING!
Warnings appear where overlooked details may cause damage to the equipment or result
in personal injury. Warnings should be taken seriously. Warnings are easy to recognize.
The word “warning” is written as “WARNING,” both capitalized and bold and is followed by
text. The text is the warning message. A warning message is shown below:
WARNING:
This is an example of a warning message. Failure to adhere to warning
messages may result in permanent damage to the NANO-GX2 or
personal injury to the user. Please take warning messages seriously.
CAUTION!
Cautionary messages should also be heeded to help reduce the chance of losing data or
damaging the NANO-GX2. Cautions are easy to recognize. The word “caution” is written
as “CAUTION,” both capitalized and bold and is followed. The text is the cautionary
message. A caution message is shown below:
CAUTION:
This is an example of a caution message. Failure to adhere to cautions
messages may result in permanent damage to the NANO-GX2. Please
take caution messages seriously.

NANO-GX2 EPIC NANO Motherboard
Page v
NOTE:
These messages inform the reader of essential but non-critical information. These
messages should be read carefully as any directions or instructions contained therein can
help avoid making mistakes. Notes are easy to recognize. The word “note” is written as
“NOTE,” both capitalized and bold and is followed by text. The text is the cautionary
message. A note message is shown below:
NOTE:
This is an example of a note message. Notes should always be read.
Notes contain critical information about the NANO-GX2. Please take
note messages seriously.

NANO-GX2 EPIC NANO Motherboard
Page vi
Packing List
NOTE:
If any of the components listed in the checklist below are missing,
please do not proceed with the installation. Contact the IEI reseller or
vendor you purchased the NANO-GX2 from or contact an IEI sales
representative directly. To contact an IEI sales representative, please
send an email to [email protected].
The items listed below should all be included in the NANO-GX2 package.
 1 x NANO-GX2 single board computer
 1 x 44-pin IDE cable
 1 x Audio cable
 1 x Dual port USB cable
 1 x Mini jumper pack
 1 x Utility CD
 1 x QIG (quick installation guide)
Images of the above items are shown in Chapter 3.

NANO-GX2 EPIC NANO Motherboard
Page vii
Table of Contents
1 INTRODUCTION.......................................................................................................... 1
1.1 CPU BOARD OVERVIEW ............................................................................................ 2
1.1.1 Applications ....................................................................................................... 2
1.1.2 Benefits............................................................................................................... 2
1.1.3 Features ............................................................................................................. 3
1.2 GENERAL OVERVIEW ................................................................................................. 4
1.2.1 CPU Board Connectors..................................................................................... 5
1.2.2 Technical Specifications..................................................................................... 6
2 DETAILED SPECIFICATIONS.................................................................................. 9
2.1 OVERVIEW ............................................................................................................... 10
2.2 DIMENSIONS ............................................................................................................ 10
2.2.1 Board Dimensions............................................................................................ 10
2.2.2 External Interface Panel Dimensions.............................................................. 10
2.3 DATA FLOW.............................................................................................................. 12
2.4 EMBEDDED AMD GEODE™ GX 466 CPU.............................................................. 13
2.5 GRAPHICS SUPPORT ................................................................................................. 14
2.6 MEMORY SUPPORT................................................................................................... 15
2.7 GEODELINK™ PCI BRIDGE..................................................................................... 16
2.7.1 GeodeLink™.................................................................................................... 16
2.7.2 10/100 Mb/s Ethernet....................................................................................... 17
2.7.3 Mini PCI Expansion Slot ................................................................................. 18
2.8 AMD GEODE™ CS5536 SYSTEM CHIPSET ............................................................. 19
2.8.1 GeodeLink™ Interface Unit............................................................................. 20
2.8.2 ATA-6 Controller.............................................................................................. 21
2.8.3 AC’97 Controller ............................................................................................. 22
2.8.4 Flash Interface................................................................................................. 24
2.8.5 USB Controller ................................................................................................ 25
2.8.6 Serial Communications.................................................................................... 26
2.8.7 Real Time Clock ............................................................................................... 26
2.8.8 BIOS................................................................................................................. 27

NANO-GX2 EPIC NANO Motherboard
Page viii
2.9 ENVIRONMENTALAND POWER SPECIFICATIONS ....................................................... 27
2.9.1 System Monitoring ........................................................................................... 27
2.9.2 Operating Temperature and Temperature Control........................................... 27
2.9.3 Power Consumption......................................................................................... 28
3 UNPACKING............................................................................................................... 29
3.1 ANTI-STATIC PRECAUTIONS...................................................................................... 30
3.2 UNPACKING.............................................................................................................. 30
3.2.1 Unpacking Precautions.................................................................................... 30
3.3 UNPACKING CHECKLIST........................................................................................... 31
3.3.1 Package Contents............................................................................................. 31
4 PINOUTS...................................................................................................................... 33
4.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 34
4.1.1 NANO-GX2 Layout.......................................................................................... 34
4.1.2 Peripheral Interface Connectors ..................................................................... 35
4.1.3 External Interface Panel Connectors............................................................... 36
4.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 36
4.2.1 Audio Connector .............................................................................................. 36
4.2.2 CD In Connector.............................................................................................. 37
4.2.3 CompactFlash®Socket..................................................................................... 38
4.2.4 Digital I/O Connector...................................................................................... 40
4.2.5 Fan Connector................................................................................................. 41
4.2.6 IDE Connector................................................................................................. 42
4.2.7 Mini PCI Slot ................................................................................................... 44
4.2.8 Power and HDD LED Connector.................................................................... 48
4.2.9 Power Button Connector.................................................................................. 49
4.2.10 Reset Button Connector ................................................................................. 50
4.2.11 USB Connectors............................................................................................. 50
4.3 EXTERNAL INTERFACE CONNECTORS....................................................................... 51
4.3.1 Ethernet Connector.......................................................................................... 52
4.3.2 Keyboard and Mouse Connector ..................................................................... 53
4.3.3 Power Input Connector.................................................................................... 54
4.3.4 RS-232 Serial Port Connectors........................................................................ 55
4.3.5 USB Ports......................................................................................................... 56

NANO-GX2 EPIC NANO Motherboard
Page ix
4.3.6 VGA Connector................................................................................................ 56
5 INSTALLATION ......................................................................................................... 59
5.1 ANTI-STATIC PRECAUTIONS...................................................................................... 60
5.2 INSTALLATION CONSIDERATIONS ............................................................................. 61
5.2.1 Installation Notices.......................................................................................... 61
5.2.2 Installation Checklist....................................................................................... 62
5.2.3 CF Card Installation........................................................................................ 63
5.3 JUMPER SETTINGS.................................................................................................... 64
5.3.1 AT/ATX Power Mode ....................................................................................... 65
5.3.2 Board ID .......................................................................................................... 66
5.3.3 CompactFlash®Master/Slave.......................................................................... 66
5.4 CHASSIS INSTALLATION ........................................................................................... 67
5.4.1 Airflow.............................................................................................................. 67
5.4.2 NANO-GX2 Installation................................................................................... 68
5.5 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 68
5.5.1 ATA Flat Cable Connection ............................................................................. 68
5.5.2 USB Cable........................................................................................................ 69
5.5.3 Audio Kit Installation....................................................................................... 70
5.6 EXTERNAL PERIPHERAL INTERFACE CONNECTION................................................... 71
5.6.1 Keyboard and Mouse ....................................................................................... 72
5.6.2 LAN.................................................................................................................. 73
5.6.3 Serial Device.................................................................................................... 74
5.6.4 USB.................................................................................................................. 75
5.6.5 VGA Monitor.................................................................................................... 76
6 BIOS SETUP................................................................................................................ 79
6.1 INTRODUCTION ........................................................................................................ 80
6.1.1 Starting Setup................................................................................................... 80
6.1.2 Using Setup...................................................................................................... 80
6.1.3 Getting Help..................................................................................................... 81
6.1.4 Unable to Reboot After Configuration Changes.............................................. 81
6.1.5 Main BIOS Menu ............................................................................................. 81
6.2 STANDARD CMOS FEATURES.................................................................................. 84
6.2.1 IDE Primary Master/Slave .............................................................................. 86

NANO-GX2 EPIC NANO Motherboard
Page x
6.3 ADVANCED BIOS FEATURES.................................................................................... 89
6.4 ADVANCED CHIPSET FEATURES................................................................................ 93
6.5 INTEGRATED PERIPHERALS ...................................................................................... 95
6.6 POWER MANAGEMENT SETUP.................................................................................. 98
6.7 PNP/PCI CONFIGURATIONS ................................................................................... 100
6.8 PC HEALTH STATUS ............................................................................................... 104
7 SOFTWARE DRIVERS............................................................................................ 107
7.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 108
7.2 VGA DRIVER......................................................................................................... 108
7.3 AUDIO DRIVER........................................................................................................112
7.4 LAN DRIVER..........................................................................................................116
A BIOS OPTIONS........................................................................................................ 121
B TERMINOLOGY...................................................................................................... 125
C DIGITAL I/O INTERFACE..................................................................................... 129
C.1 INTRODUCTION...................................................................................................... 130
C.2 DIO CONNECTOR PINOUTS ................................................................................... 130
C.3 ASSEMBLY LANGUAGE SAMPLES........................................................................... 131
C.3.1 Enable the DIO Input Function..................................................................... 131
C.3.2 Enable the DIO Output Function.................................................................. 131
D WATCHDOG TIMER .............................................................................................. 133
E ADDRESS MAPPING .............................................................................................. 137
E.1 IO ADDRESS MAP.................................................................................................. 138
E.2 1ST MB MEMORYADDRESS MAP........................................................................... 139
E.3 IRQ MAPPING TABLE ............................................................................................ 139
E.4 DMA CHANNELASSIGNMENTS ............................................................................. 140
F COMPATIBILITY..................................................................................................... 141
F.1 COMPATIBLE OPERATING SYSTEMS........................................................................ 142
F.2 COMPATIBLE PROCESSORS ..................................................................................... 142
F.3 COMPATIBLE MEMORY MODULES .......................................................................... 142
G HAZARDOUS MATERIALS DISCLOSURE....................................................... 143

NANO-GX2 EPIC NANO Motherboard
Page xi
G.1 HAZARDOUS MATERIALS DISCLOSURE TABLE FOR IPB PRODUCTS CERTIFIED AS
ROHS COMPLIANT UNDER 2002/95/EC WITHOUT MERCURY..................................... 144
H AC'97 AUDIO CODEC ............................................................................................ 147
H.1 INTRODUCTION ..................................................................................................... 148
H.1.1 Accessing the AC’97 CODEC....................................................................... 148
H.1.2 Driver Installation......................................................................................... 148
H.2 SOUND EFFECT CONFIGURATION........................................................................... 149
H.2.1 Accessing the Sound Effects Manager .......................................................... 149
H.2.2 Sound Effect Manager Configuration Options ............................................. 150

NANO-GX2 EPIC NANO Motherboard
Page xii
List of Figures
Figure 1-1: NANO-GX2 ...................................................................................................................2
Figure 1-2: Overview (Front Side).................................................................................................4
Figure 1-3: Overview (Solder Side)...............................................................................................5
Figure 2-1: NANO-GX2 Dimensions (mm)..................................................................................10
Figure 2-2: External Interface Panel Dimensions (mm)............................................................11
Figure 2-3: Data Flow Block Diagram.........................................................................................12
Figure 2-4: AMD Geode GX..........................................................................................................13
Figure 2-5: Graphics Support......................................................................................................14
Figure 2-6: Onboard DDR RAM ...................................................................................................16
Figure 2-7: GeodeLink™..............................................................................................................16
Figure 2-8: 10/100 Mb/s Ethernet ................................................................................................17
Figure 2-9: Mini PCI Slot ..............................................................................................................18
Figure 2-10: System Chipset.......................................................................................................19
Figure 2-11: IDE Interface ............................................................................................................21
Figure 2-12: Onboard Audio........................................................................................................22
Figure 2-13: CompactFlash® Slot...............................................................................................24
Figure 2-14: USB Ports ................................................................................................................25
Figure 2-15: Serial Communications..........................................................................................26
Figure 2-16: BIOS..........................................................................................................................27
Figure 4-1: Connector and Jumper Locations...........................................................................34
Figure 4-2: Connector and Jumper Locations (Solder Side) ...................................................35
Figure 4-3: Audio Connector Location.......................................................................................37
Figure 4-4: Audio CD In Connector Location ............................................................................38
Figure 4-5: CF Card Socket Location .........................................................................................39
Figure 4-6: Digital I/O Connector Locations ..............................................................................41
Figure 4-7: Fan Connector Location...........................................................................................42
Figure 4-8: IDE Connector Location...........................................................................................43
Figure 4-9: Mini PCI Slot Location..............................................................................................45
Figure 4-10: Power and HDD LED Connector Location............................................................48
Figure 4-11: Power Button Connector Location........................................................................49

NANO-GX2 EPIC NANO Motherboard
Page xiii
Figure 4-12: Reset Button Connector Locations.......................................................................50
Figure 4-13: USB Connector Pinout Locations.........................................................................51
Figure 4-14: NANO-GX2 On-board External Interface Connectors .........................................52
Figure 4-15: Ethernet Connector.................................................................................................53
Figure 4-16: PS/2 Connector .......................................................................................................54
Figure 4-17: Serial Port Pinout Locations..................................................................................56
Figure 4-18: VGA1 Connector .....................................................................................................57
Figure 5-1: CF Card Installation..................................................................................................64
Figure 5-2: Power Mode Jumper Pinout Location.....................................................................65
Figure 5-3: Board ID Jumper Pinout Location...........................................................................66
Figure 5-4: CompactFlash® Master/Slave Jumper Pinout Location.......................................67
Figure 5-5: IDE Cable Connection...............................................................................................69
Figure 5-6: Dual USB Cable Connection....................................................................................70
Figure 5-7: Audio Kit Connection ...............................................................................................71
Figure 5-8: PS/2 Keyboard/Mouse Connector ...........................................................................73
Figure 5-9: LAN Connection........................................................................................................74
Figure 5-10: Serial Device Connector.........................................................................................75
Figure 5-11: USB Connector........................................................................................................76
Figure 5-12: VGA Connector .......................................................................................................77
Figure 7-1: VGA Driver Start Up Screen.................................................................................. 109
Figure 7-2: Select the Installation Method .............................................................................. 110
Figure 7-3: VGA Driver Installation.......................................................................................... 111
Figure 7-4: VGA Driver Installation.......................................................................................... 111
Figure 7-5: Close the VGA Driver Installation Wizard............................................................ 112
Figure 7-6: Audio Driver Start Up Screen ............................................................................... 113
Figure 7-7: Select the Installation Method .............................................................................. 114
Figure 7-8: Audio Driver Installation........................................................................................ 115
Figure 7-9: Close the Audio Driver Installation Wizard ......................................................... 116
Figure 7-10: CD Main Menu ...................................................................................................... 117
Figure 7-11: AMD LX/GX CD Driver Menu............................................................................... 118
Figure 7-12: Locate the Setup Program Icon.......................................................................... 118
Figure 7-13: Preparing Setup Screen ...................................................................................... 119
Figure 7-14: Install Wizard Welcome Screen.......................................................................... 119
Figure 7-15: Installing Screen ..................................................................................................120

NANO-GX2 EPIC NANO Motherboard
Page xiv
List of Tables
Table 1-1: Technical Specifications..............................................................................................7
Table 2-1: Geode™ GX Graphics Processor Features .............................................................15
Table 2-2: Supported HDD Specifications..................................................................................22
Table 2-3: Power Consumption...................................................................................................28
Table 3-1: Package List Contents...............................................................................................32
Table 4-1: Peripheral Interface Connectors...............................................................................36
Table 4-2: Rear Panel Connectors..............................................................................................36
Table 4-3: Audio Connector Pinouts ..........................................................................................37
Table 4-4: Audio CD In Connector Pinouts................................................................................38
Table 4-5: CF Card Socket Pinouts.............................................................................................40
Table 4-6: Digital I/O Connector Pinouts....................................................................................41
Table 4-7: Fan Connector Pinouts..............................................................................................42
Table 4-8: IDE Connector Pinouts...............................................................................................44
Table 4-9: Mini PCI Slot Pinouts..................................................................................................48
Table 4-10: Power and HDD LED Connector Pinouts...............................................................49
Table 4-11: Power Button Connector Pinouts...........................................................................49
Table 4-12: Reset Button Connector Pinouts............................................................................50
Table 4-13: USB Port Connector Pinouts...................................................................................51
Table 4-14: Ethernet Connector Pinouts....................................................................................52
Table 4-15: Connector LEDs........................................................................................................53
Table 4-16: PS/2 Connectors.......................................................................................................54
Table 4-17: Power Input Connector Pinouts..............................................................................55
Table 4-18: Serial Port Pinouts....................................................................................................55
Table 4-19: USB Connector Pinouts...........................................................................................56
Table 4-20: VGA1 Connector Pinouts.........................................................................................57
Table 5-1: Jumpers.......................................................................................................................65
Table 5-2: Power Mode Jumper Settings ...................................................................................65
Table 5-3: Board ID Jumper Settings..........................................................................................66
Table 5-4: CompactFlash® Master/Slave Jumper Settings......................................................67
Table 5-5: IEI Provided Cables....................................................................................................68

NANO-GX2 EPIC NANO Motherboard
Page xv
Table 6-1: BIOS Navigation Keys................................................................................................81

NANO-GX2 EPIC NANO Motherboard
Page xvi
BIOS Menus
BIOS Menu 1: Award BIOS CMOS Setup Utility ........................................................................82
BIOS Menu 2: Standard CMOS Features....................................................................................84
BIOS Menu 3: IDE Channel Master .............................................................................................86
BIOS Menu 4: Advanced BIOS Features....................................................................................89
BIOS Menu 5: Advanced Chipset Features................................................................................93
BIOS Menu 6: Integrated Peripherals.........................................................................................95
BIOS Menu 7: Power Management Setup ..................................................................................99
BIOS Menu 8: PnP/PCI Configurations.................................................................................... 101
BIOS Menu 9: IRQ Resources .................................................................................................. 102
BIOS Menu 10: DMA Resources............................................................................................... 103
BIOS Menu 11: PC Health Status............................................................................................. 104

NANO-GX2 EPIC NANO Motherboard
Page 1
Chapter
1
1 Introduction

NANO-GX2 EPIC NANO Motherboard
Page 2
1.1 CPU Board Overview
Figure 1-1: NANO-GX2
The EPIC form factor NANO-GX2 is a highly integrated CPU card for embedded
computers, specifically optimized for multi-media applications requiring minimum
installation space. The NANO-GX2 is particularly suitable for low power and fan-less
applications. The NANO-GX2 supports a full range of functionality for an
AT/ATX-compatible industrial computer in a space-saving 3.5” profile. The NANO-GX2 is
equipped with an on board low-power consumption and high performance AMD Geode™
GX 466 processor. The NANO-GX2 also includes 128 MB of DDR memory onboard.
1.1.1 Applications
The NANO-GX2 motherboard has been designed for thin client applications. The low
power consumption and embedded processor provide adequate computing power for
these applications. The fanless design ensures a quiet and more reliable computer setup.
1.1.2 Benefits
Some of the NANO-GX2 motherboard benefits include,

NANO-GX2 EPIC NANO Motherboard
Page 3
 operating reliably in harsh industrial environments with ambient temperatures
as high as 60°C
 rebooting automatically if the BIOS watchdog timer detects that the system is
no longer operating
 small form factor ideally suited for thin client applications
1.1.3 Features
Some of the NANO-GX2 motherboard features are listed below:
 EPIC form factor
 RoHS compliant
 Embedded AMD Geode™ GX 466 CPU
 Mini PCI expansion slot
 128 MB DDR memory
 One high performance Ethernet (10/100M) controller
 Supports up to four USB 2.0 devices
 Integrated audio

NANO-GX2 EPIC NANO Motherboard
Page 4
1.2 General Overview
Figure 1-2: Overview (Front Side)
