IEI Technology NANO-6613 User manual

0-1
NANO-6613 Motherboard
1

0-2
2
IEI®Technology, Corp.
REVISION HISTORY
Title NANO-6613Intel Pentium M/Celeron M Motherbard
Revision Number Description Date of Issue
1.0 Initial release July 2006
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event is the manufacturer liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
IBM PC is a registered trademark of International Business Machines Corporation. INTEL
is a registered trademark of INTEL Corporation. AMI is registered trademarks of American
Megatrends Inc. Other product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

0-3
NANO-6613 Motherboard
3
Table of Contents
1INTRODUCTION................................................................................................... 15
1.1 NANO-6613 OVERVIEW ......................................................................................... 16
1.1.1 NANO-6613 Applications ................................................................................ 16
1.1.2 NANO-6613 Benefits........................................................................................ 16
1.1.3 NANO-6613 Features ...................................................................................... 16
1.2 NANO-6613 BOARD OVERVIEW............................................................................. 17
1.2.1 NANO-6613 Connectors.................................................................................. 18
1.2.2 Technical Specifications................................................................................... 19
2DETAILED SPECIFICATIONS ........................................................................... 21
2.1 CPU SUPPORT.......................................................................................................... 22
2.2 ONBOARD CHIPSETS ................................................................................................ 22
2.2.1 Northbridge and Southbridge Chipsets ........................................................... 22
2.2.2 SiS661CX Northbridge Chipset ....................................................................... 22
2.2.3 SiS964 Southbridge Chipset............................................................................. 23
2.3 GRAPHICS SUPPORT ................................................................................................. 24
2.4 MEMORY SUPPORT................................................................................................... 24
2.5 PCI BUS INTERFACE SUPPORT ................................................................................. 25
2.6 GBE ETHERNET ....................................................................................................... 25
2.7 DRIVE INTERFACES .................................................................................................. 25
2.7.1 SATA Drives ..................................................................................................... 26
2.7.2 IDE HDD Interfaces ........................................................................................ 26
2.7.3 Floppy Disk Drive (FDD)................................................................................ 26
2.7.4 Compact Flash Support ................................................................................... 26
2.8 SERIAL PORTS .......................................................................................................... 26
2.9 REAL TIME CLOCK................................................................................................... 27
2.10 INFRARED DATA ASSOCIATION (IRDA) INTERFACE................................................ 27
2.11 USB INTERFACES................................................................................................... 27
2.12 BIOS ..................................................................................................................... 27
2.13 OPERATING TEMPERATURE AND TEMPERATURE CONTROL..................................... 27
2.14 AUDIO CODEC........................................................................................................ 28
2.15 POWER CONSUMPTION........................................................................................... 29

0-4
4
IEI®Technology, Corp.
2.16 PACKAGED CONTENTS AND OPTIONALACCESSORY ITEMS..................................... 29
2.16.1 Package Contents........................................................................................... 29
2.16.2 Optional Accessory Items............................................................................... 30
3CONNECTORS AND JUMPERS......................................................................... 31
3.1 PERIPHERAL INTERFACE CONNECTORS .................................................................... 32
3.1.1 NANO-6613 Layout ......................................................................................... 32
3.1.2 Peripheral Interface Connectors ..................................................................... 33
3.1.3 Rear Panel Connectors.................................................................................... 34
3.1.4 Onboard Jumpers............................................................................................. 34
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 35
3.2.1 ATX Power Connector ..................................................................................... 35
3.2.2 Audio Connector .............................................................................................. 36
3.2.3 Compact Flash Connector............................................................................... 37
3.2.4 Fan Connectors................................................................................................ 38
3.2.5 GPIO Connector.............................................................................................. 39
3.2.6 IDE Connector................................................................................................. 40
3.2.7 Inverter Power Connector ............................................................................... 42
3.2.8 IR Interface Connector .................................................................................... 43
3.2.9 LCD LVDS Interface Connector...................................................................... 44
3.2.10 Parallel Port Connector ................................................................................ 45
3.2.11 PCI-104 Connector........................................................................................ 46
3.2.12 RS-232 Serial Port Connectors...................................................................... 48
3.2.13 RS-232/485 Serial Port Connector................................................................ 49
3.2.14 SATA Drive Connectors ................................................................................. 51
3.2.15 System Front Panel Connector...................................................................... 52
3.2.16 Power Connector........................................................................................... 53
3.2.17 TV Out Connector.......................................................................................... 53
3.2.18 Internal USB Connectors............................................................................... 54
3.3 EXTERNAL (REAR PANEL) CONNECTORS ................................................................. 56
3.3.1 CRT Connector ................................................................................................ 56
3.3.2 Ethernet Connectors ........................................................................................ 57
3.3.3 Keyboard/Mouse Connector ............................................................................ 58
3.3.4 Serial Port Connectors .................................................................................... 58
3.3.5 USB Connector ................................................................................................ 59
3.4 ONBOARD JUMPERS ................................................................................................. 60

0-5
NANO-6613 Motherboard
5
3.4.1 Clear CMOS Jumper........................................................................................ 60
3.4.2 CPU FSB Settings Jumper............................................................................... 62
3.4.3 CPU Frequency Setting Jumper ...................................................................... 63
3.4.4 LCD Voltage Setup Jumper.............................................................................. 64
3.4.5 COM2 Setup Jumper........................................................................................ 66
4INSTALLATION AND CONFIGURATION ....................................................... 67
4.1 INSTALLATION CONSIDERATIONS ............................................................................. 68
4.1.1 Installation Notices.......................................................................................... 68
4.2 UNPACKING.............................................................................................................. 69
4.2.1 Unpacking Precautions.................................................................................... 69
4.2.2 Checklist........................................................................................................... 69
4.3 NANO-6613 MOTHERBOARD INSTALLATION........................................................... 70
4.3.1 CPU Installation.............................................................................................. 71
4.3.2 Cooling Kit (CF-479B-RS ) Installation.......................................................... 73
4.3.3 Mounting the NANO-6613 Embedded Module................................................ 74
4.3.4 DIMM Module Installation.............................................................................. 75
4.3.4.1 Purchasing the Memory Module............................................................... 75
4.3.4.2 SODIMM Module Installation.................................................................. 75
4.3.5 Peripheral Device Connection......................................................................... 76
4.3.5.1 IDE Disk Drive Connector (IDE1)........................................................... 77
4.3.5.2 Compact Flash Disk.................................................................................. 78
4.3.5.3 Parallel Port Connector (LPT1) ................................................................ 78
4.3.5.4 Audio Interface ......................................................................................... 78
4.3.5.5 COM Port Connectors [COM1, COM2, COM3 and COM4]................... 78
4.4 CHASSIS INSTALLATION ........................................................................................... 78
4.5 REAR PANEL CONNECTORS ...................................................................................... 79
4.5.1 LCD Panel Connection.................................................................................... 79
4.5.2 Ethernet Connection ........................................................................................ 79
4.5.3 USB Connection............................................................................................... 79
4.5.4 Serial Connection............................................................................................. 79
4.5.5 Keyboard and Mouse Connection.................................................................... 79
5AMI BIOS SETUP.................................................................................................. 81
5.1 INTRODUCTION ........................................................................................................ 82
5.1.1 Starting Setup................................................................................................... 82
5.1.2 Using Setup...................................................................................................... 82

0-6
6
IEI®Technology, Corp.
5.1.3 Getting Help..................................................................................................... 83
5.1.4 Unable to Reboot after Configuration Changes.............................................. 83
5.1.5 BIOS Menu Bar................................................................................................ 83
5.2 MAIN ....................................................................................................................... 83
5.3 ADVANCED............................................................................................................... 85
5.3.1 CPU Configuration.......................................................................................... 86
5.3.2 IDE Configuration ........................................................................................... 87
5.3.2.1 IDE Master, IDE Slave ............................................................................. 90
5.3.3 Super IO Configuration.................................................................................... 94
5.3.4 Hardware Health Configuration...................................................................... 99
5.3.5 ACPI Configuration ....................................................................................... 100
5.3.6 MPS Configuration ........................................................................................ 101
5.3.7 Power Configuration ..................................................................................... 102
5.3.8 USB Configuration......................................................................................... 104
5.4 PCI/PNP ................................................................................................................ 106
5.5 CHIPSET ..................................................................................................................111
5.5.1 NorthBridge Configuration.............................................................................112
5.5.1.1 Internal VGA Settings..............................................................................113
5.5.2 SouthBridge Configuration.............................................................................116
5.6 BOOT ......................................................................................................................117
5.6.1 Boot Settings Configuration............................................................................118
5.6.2 Boot Device Priority ...................................................................................... 121
5.6.3 Hard Disk Drives........................................................................................... 122
5.7 SECURITY............................................................................................................... 123
5.8 EXIT....................................................................................................................... 124
6SOFTWARE DRIVERS....................................................................................... 127
6.1 AVAILABLE SOFTWARE DRIVERS ............................................................................ 128
6.2 REALTEK AUDIO DRIVER (ALC655) INSTALLATION.............................................. 128
6.3 REALTEK LAN DRIVER (FOR GBE LAN) INSTALLATION....................................... 132
6.4 SIS AGP DRIVER INSTALLATION............................................................................ 135
6.5 SIS IDE DRIVER INSTALLATION ............................................................................ 137
6.6 SIS VGA UTILITIES DRIVER.................................................................................. 139
ABIOS CONFIGURATION OPTIONS ................................................................ 143
A.1 BIOS CONFIGURATION OPTIONS........................................................................... 144

0-7
NANO-6613 Motherboard
7
BWATCHDOG TIMER .......................................................................................... 147
CADDRESS MAPPING.......................................................................................... 151
C.1 IO ADDRESS MAP ................................................................................................. 152
C.2 1ST MB MEMORYADDRESS MAP ......................................................................... 152
C.3 IRQ MAPPING TABLE............................................................................................ 153
C.4 DMA CHANNELASSIGNMENTS............................................................................. 153
DEXTERNALAC’97 AUDIO CODEC................................................................. 155
D.1 INTRODUCTION ..................................................................................................... 156
D.1.1 Accessing the AC’97 CODEC....................................................................... 156
D.1.2 Driver Installation......................................................................................... 156
D.2 SOUND EFFECT CONFIGURATION........................................................................... 157
D.2.1 Accessing the Sound Effects Manager .......................................................... 157
D.2.2 Sound Effect Manager Configuration Options ............................................. 158
ERAID SETUP ........................................................................................................ 161
E.1 INTRODUCTION...................................................................................................... 162
E.1.1 RAID Support ................................................................................................ 162
E.1.2 What is RAID................................................................................................. 162
E.2 RAID SETUP ......................................................................................................... 162
E.2.1 Introduction ................................................................................................... 162
E.2.2 Copy the RAID Driver................................................................................... 163
E.2.3 Install SATA Drives........................................................................................ 164
E.2.4 Configure the SATA Controller in BIOS........................................................ 164
E.2.5 Configure the RAID BIOS ............................................................................. 165
E.2.6 Install the OS................................................................................................. 169
FINDEX.................................................................................................................... 171

0-8
8
IEI®Technology, Corp.
List of Figures
Figure 1-1: NANO-6613 Board Overview (Top View)...............................................17
Figure 1-2: NANO-6613 Board Overview (Bottom View).........................................17
Figure 3-1: Connector and Jumper Locations .........................................................32
Figure 3-2: ATX Power Connector Location.............................................................35
Figure 3-3: Audio Connector Location......................................................................36
Figure 3-4: CFII Socket Location...............................................................................37
Figure 3-5: Fan Connector Locations .......................................................................39
Figure 3-6: GPIO Connector Location.......................................................................40
Figure 3-7: IDE Device Connector Location.............................................................41
Figure 3-8: Inverter Power Connector Location.......................................................42
Figure 3-9: IR Connector Location............................................................................43
Figure 3-10: LCD LVDS Connector Locations..........................................................44
Figure 3-11: Parallel Port Connector Location.........................................................46
Figure 3-12: PCI-104 Connector Location ................................................................47
Figure 3-13: Serial Port Connector Locations..........................................................49
Figure 3-14: RS-232/485 Serial Port Connector Location .......................................50
Figure 3-15: SATA Drive Connector Locations........................................................51
Figure 3-16: System Front Panel Connector Location............................................52
Figure 3-17: Power Connector Location...................................................................53
Figure 3-18: TV Out Connector Location..................................................................54
Figure 3-19: Internal USB Connector Locations......................................................55
Figure 3-20: NANO-6613 Board Rear Panel..............................................................56
Figure 3-21: RJ-45 Ethernet Connector ....................................................................58
Figure 3-22 Jumper ....................................................................................................60
Figure 3-23: Clear CMOS Jumper Location..............................................................62
Figure 3-24: J5 Location.............................................................................................63
Figure 3-25: J4 Location.............................................................................................64
Figure 3-26: J2 Location.............................................................................................65
Figure 3-27: J1 Location.............................................................................................66

0-9
NANO-6613 Motherboard
9
Figure 4-1: Make sure the CPU socket retention screw is unlocked.....................71
Figure 4-2: Lock the CPU Socket Retention Screw .................................................72
Figure 4-3: IEI CF-479B-RS Cooling Kit ....................................................................73
Figure 4-4: Securing the Cooling Kit.........................................................................74
Figure 4-5: Connect the cooling fan cable ...............................................................74
Figure 4-6: SODIMM Module Installation ..................................................................76
Figure 4-7: Connection of IDE Connector ................................................................77
Figure 6-1: InstallShield Wizard Extracting Files.................................................. 129
Figure 6-2: Audio Driver Install Shield Wizard Starting ....................................... 129
Figure 6-3: Audio Driver Setup Preparation.......................................................... 130
Figure 6-4: Audio Driver Digital Signal .................................................................. 130
Figure 6-5: Audio Driver Installation Continues ................................................... 131
Figure 6-6: Audio Driver Installation Complete..................................................... 131
Figure 6-7: Realtek LAN Driver InstallShield Wizard............................................ 132
Figure 6-8: Realtek LAN Driver Welcome .............................................................. 133
Figure 6-9: Realtek LAN Driver Ready to Install ................................................... 133
Figure 6-10: Realtek LAN Driver Setup Status...................................................... 134
Figure 6-11: Realtek LAN Driver Installation Complete........................................ 134
Figure 6-12: Starting Install Shield Wizard Screen............................................... 135
Figure 6-13: Preparing Setup Screen..................................................................... 135
Figure 6-14: Install Shield Screen........................................................................... 136
Figure 6-15: Installing Screen................................................................................. 136
Figure 6-16: Restart the Computer......................................................................... 137
Figure 6-17: Select a Language.............................................................................. 137
Figure 6-18: Welcome Screen................................................................................. 138
Figure 6-19: Chipset Driver Readme File Information.......................................... 138
Figure 6-20: Chipset Driver Installation Complete................................................ 139
Figure 6-21: VGA Utilities Welcome Screen.......................................................... 140
Figure 6-22: Select Setup Installation Type........................................................... 140
Figure 6-23: Select Folders to Copy Files ............................................................. 141
Figure 6-24: Review Settings .................................................................................. 141
Figure 6-25: Read ReadMe File............................................................................... 142
Figure 6-26: Restart the Computer......................................................................... 142

0-10
10
IEI®Technology, Corp.
List of Tables
Table 1-1: Technical Specifications ..........................................................................20
Table-2-1: Supported CPUs........................................................................................22
Table 2-2: Power Consumption .................................................................................29
Table 3-1: Peripheral Interface Connectors..............................................................34
Table 3-2: Rear Panel Connectors.............................................................................34
Table 3-3: Onboard Jumpers .....................................................................................35
Table 3-4: ATX Power Connector Pinouts................................................................36
Table 3-5: Audio Connector Pinouts.........................................................................37
Table 3-6: CFII Socket Pinouts...................................................................................38
Table 3-7: Fan Connector Pinouts.............................................................................39
Table 3-8: GPIO Connector Pinouts..........................................................................40
Table 3-9: IDE Connector Pinouts.............................................................................42
Table 3-10: Inverter Power Connector Pinouts........................................................43
Table 3-11: IR Connector Pinouts..............................................................................44
Table 3-12: LCD LVDS Connector Pinouts...............................................................45
Table 3-13: Parallel Port Connector Pinouts............................................................46
Table 3-14: PCI-104 Connector Pinouts....................................................................48
Table 3-15: COM3 Pinouts..........................................................................................49
Table 3-16: COM4 Pinouts..........................................................................................49
Table 3-17: RS-232/485 Serial Port Connector Pinouts...........................................50
Table 3-18: SATA Drive Connector Pinouts .............................................................51
Table 3-19: System Front Panel Connector Pinouts ...............................................53
Table 3-20: Power Connector Pinouts ......................................................................53
Table 3-21: TV Out Connector Pinouts .....................................................................54
Table 3-22: USB2 Pinouts...........................................................................................55
Table 3-23: USB3 Pinouts...........................................................................................55
Table 3-24: VGA Connector Pinouts .........................................................................57
Table 3-25: LAN1 and LAN2 Pinouts.........................................................................57
Table 3-26: RJ-45 Ethernet Connector LEDs............................................................58

0-11
NANO-6613 Motherboard
11
Table 3-27: Serial Port Pinouts..................................................................................59
Table 3-28: USB1 Connector Pinouts........................................................................59
Table 3-29: Onboard Jumpers ...................................................................................60
Table 3-30: Clear CMOS Jumper Settings ................................................................61
Table 3-31: J5 FSB Selection Jumper Settings........................................................62
Table 3-32: CPU Frequency Jumper Settings..........................................................63
Table 3-33: J2 Jumper Settings.................................................................................65
Table 3-34: J1 Jumper Settings.................................................................................66
Table 4-1: IEI Provided Cables...................................................................................76
Table 5-1: BIOS Navigation Keys...............................................................................83

0-12
12
IEI®Technology, Corp.
List of BIOS Menus
Menu 1: Main ....................................................................................................84
Menu 2: Advanced ....................................................................................................86
Menu 3: CPU Configuration .......................................................................................87
Menu 4: IDE Configuration .........................................................................................88
Menu 5: IDE Master and IDE Slave Configuration ...................................................90
Menu 6: Super IO Configuration................................................................................94
Menu 7: Hardware Health Configuration ..................................................................99
Menu 8: ACPI Configuration ................................................................................... 100
Menu 9: MPS Configuration .................................................................................... 101
Menu 10: Power Configuration............................................................................... 102
Menu 11: USB Configuration .................................................................................. 105
Menu 12: PCI/PnP Configuration............................................................................ 107
Menu 13: Chipset ................................................................................................. 112
Menu 14: NorthBridge Chipset Configuration....................................................... 113
Menu 15: SouthBridge Chipset Configuration...................................................... 116
Menu 16: Boot ................................................................................................. 118
Menu 17: Boot Settings Configuration................................................................... 119
Menu 18: Boot Device Priority Settings................................................................. 121
Menu 19: Removable Drives ................................................................................... 122
Menu 20: Security ................................................................................................. 123
Menu 21: Exit ................................................................................................. 124

0-13
NANO-6613 Motherboard
13
Glossary
AC ’97 Audio Codec 97
ACPI Advanced Configuration and
Power Interface
APM Advanced Power Management
ARMD ATAPI Removable Media Device
ASKIR Shift Keyed Infrared
ATA Advanced Technology
Attachments
BIOS Basic Input/Output System
CFII Compact Flash Type 2
CMOS Complementary Metal Oxide
Semiconductor
CPU Central Processing Unit
Codec Compressor/Decompressor
COM Serial Port
DAC Digital to Analog Converter
DDR Double Data Rate
DIMM Dual Inline Memory Module
DIO Digital Input/Output
DMA Direct Memory Access
EIDE Enhanced IDE
EIST Enhanced Intel SpeedStep
Technology
FDD Floppy Disk Drive
FDC Floppy Disk Connector
FFIO Flexible File Input/Output
FIFO First In/First Out
FSB Front Side Bus
IrDA Infrared Data Association
HDD Hard Disk Drive
IDE Integrated Data Electronics
I/O Input/Output
ICH4 I/O Controller Hub 4
L1 Cache Level 1 Cache
L2 Cache Level 2 Cache
LCD Liquid Crystal Display
LPT Parallel Port Connector
LVDS Low Voltage Differential Signaling
MAC Media Access Controller
OS Operating System
PCI Peripheral Connect Interface
PIO Programmed Input Output
PnP Plug and Play
POST Power On Self Test
RAM Random Access Memory
SATA Serial ATA
S.M.A.R.T Self Monitoring Analysis and
Reporting Technology
SPD Serial Presence Detect
S/PDI Sony/Philips Digital Interface
SDRAM Synchronous Dynamic Random
Access Memory
SIR Serial Infrared
UART Universal Asynchronous
Receiver-transmitter
USB Universal Serial Bus
VGA Video Graphics Adapter

0-14
14
IEI®Technology, Corp.
THIS PAGE IS INTENTIONALLY LEFT BLANK

1-15
NANO-6613 Motherboard
15
1 Introduction
Chapter
1

1-16
16
IEI®Technology, Corp.
1.1 NANO-6613 Overview
The EPIC form factor NANO-6613 socket 479 Pentium M / Celeron M CPU platform is
fully equipped with advanced multi-mode I/Os. The NANO-6613 is designed for system
manufacturers, integrators, and VARs that want performance, reliability, and quality at a
reasonable price.
1.1.1 NANO-6613 Applications
The NANO-6613 is designed for applications in the following areas:
 Industrial PC applications
 Human Machine Interface (HMI) applications
 Marine, GPS and transportation applications
 Financial, retail and kiosk applications
1.1.2 NANO-6613 Benefits
Some of the NANO-6613 benefits include:
 Low power, high performance
 Dual GbE design supports multi network embedded applications such as
redundant network or multi-subnet working environment
 Multiple storage option integration including
o 44 Pin IFM or 2.5＂HDD
o Dual SATA ports support
o CFII support
 PCI-104 extension support
 Data security SATA RAID support
 Flexible dual display options
1.1.3 NANO-6613 Features
Some of the NANO-6613 features are listed below:
 Complies with RoHS
 Supports socket 479 Intel® Pentium M / Celeron M CPUs
 Supports a maximum front side bus (FSB) speed up to 533MHz

1-17
NANO-6613 Motherboard
17
 Supports up to 1GB of 333MHz or 400MHz of DDR memory
 Comes with two high performance gigabit Ethernet (GbE) controller
 Supports two SATA channels with transfer rates up to 150MB/s
 Supports six USB 2.0 devices
1.2 NANO-6613 Board Overview
Figure 1-1: NANO-6613 Board Overview (Top View)
Figure 1-2: NANO-6613 Board Overview (Bottom View)

1-18
18
IEI®Technology, Corp.
1.2.1 NANO-6613 Connectors
The NANO-6613 has the following connectors onboard:
 1 x ATX PSON connector
 1 x Audio connector
 1 x Compact Flash (CF) connector (solder side)
 1 x DDR SODIMM socket
 2 x Fan connectors
 1 x GPIO connector
 1 x IDE Interface connector
 1 x Inverter power connector
 1 x IR interface connector
 1 x LCD LVDS interface connector
 1 x Parallel port connector
 1 x PCI-104 connector
 2 x Serial port connectors
 1 x RS-232/485 serial port connector
 2 x Serial ATA connectors
 1 x System front panel connector
 1 x Power connector
 1 x TV out connector
 2 x USB connectors
The NANO-6613 has the following connectors on the board rear panel:
 1 x CRT connector
 2 x Ethernet connectors
 1 x Keyboard/Mouse connector
 1 x Serial port connector
 2 x USB 2.0 ports
The NANO-6613 has the following onboard jumpers:
 Clear CMOS
 CPU FSB setting
 CPU frequency setting

1-19
NANO-6613 Motherboard
19
 LCD voltage setup
 COM2 setup (RS-232/485)
The location of these connectors on the motherboard can be seen in Figure 1-1. These
connectors are fully described in Chapter 3.
1.2.2 Technical Specifications
NANO-6613 technical specifications are listed in Table 1-1. Detailed descriptions of each
specification can be found in Chapter 2 Detailed Specifications.
SPECIFICATION
CPUs Supported Intel®Pentium®M / Celeron®M FSB 400/533MHz
Chipsets Northbridge: SIS 661CX
Southbridge: SIS 964
I/O Controller SIS 964
Graphics Support SiS Mirage™ Graphic Engine
Display CRT; LVDS; TV-out
Memory One DDR memory modules (Max. 1GB)
PCI Bus Interface 33MHz, Revision 2.3
Serial ATA (SATA) Two SATA channels with 150MB/s transfer rates
HDD Interface One IDE channels support two Ultra ATA 100/133 devices
USB Interfaces Six USB 2.0 connectors supported
Serial Ports Four COM ports
Super I/O W83697HG
IrDA By super I/O
Digital I/O 4 input / 4 output by super I/O
Audio Interfaces One Audio Codec ’97 (AC’97) version 2.3 connector

1-20
20
IEI®Technology, Corp.
Ethernet Two Gigabit Ethernet (GbE) connectors
BIOS AMI flash BIOS
Power +12V, AT/ATX supported
Physical Dimensions 165mm x 115mm (width x length)
Operating Temperature Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Table 1-1: Technical Specifications
