IFM Electronic Elector 600 User manual

Operating instructions
Temperature transmitter with display
TDxxxx
80234348 / 00 12 / 2015
UK

2
Contents
1 Preliminary note���������������������������������������������������������������������������������������������������3
1�1 Explanation of symbols����������������������������������������������������������������������������������3
2 Safety instructions �����������������������������������������������������������������������������������������������3
3 Functions and features ����������������������������������������������������������������������������������������3
4 Function���������������������������������������������������������������������������������������������������������������4
5 Installation������������������������������������������������������������������������������������������������������������5
5�1 Units with G½ sealing cone (type TD25xx)����������������������������������������������������5
6 Electrical connection��������������������������������������������������������������������������������������������6
7 Operating and display elements ��������������������������������������������������������������������������7
8 Parameter setting ������������������������������������������������������������������������������������������������7
8�1 IO-Link �����������������������������������������������������������������������������������������������������������7
8�1�1 General information ������������������������������������������������������������������������������7
8�1�2 Device-specific information�������������������������������������������������������������������7
8�1�3 Parameter setting tools�������������������������������������������������������������������������8
8�2 Adjustable parameters�����������������������������������������������������������������������������������8
9 Operation�������������������������������������������������������������������������������������������������������������8
10 Technical data����������������������������������������������������������������������������������������������������9
10�1 Temperature resistance �������������������������������������������������������������������������������9
11 Factory setting ���������������������������������������������������������������������������������������������������9

3
UK
1 Preliminary note
1.1 Explanation of symbols
►Instruction
> Reaction, result
[…] Designation of keys, buttons or indications
→Cross-reference
Important note
Non-compliance can result in malfunction or interference�
Information
Supplementary note�
2 Safety instructions
• Please read this document prior to set-up of the unit� Ensure that the product is
suitable for your application without any restrictions�
• If the operating instructions or the technical data are not adhered to, personal
injury and/or damage to property can occur�
• Improper or non-intended use may lead to malfunctions of the unit or to un-
wanted effects in your application� That is why installation, electrical connec-
tion, set-up, operation and maintenance of the unit must only be carried out by
qualified personnel authorised by the machine operator�
• In order to guarantee the correct condition of the device for the operating time
the device must only be used in media to which the wetted parts are sufficiently
resistant (→ Technical data).
• The responsibility whether the measurement devices are suitable for the
respective application lies with the operator� The manufacturer assumes no
liability for consequences of misuse by the operator� Improper installation and
use of the devices result in a loss of the warranty claims�
3 Functions and features
The unit detects the medium temperature and converts it into an analogue output
signal (4 ��� 20 mA)�

4
4 Function
• The unit converts the measured signal into a temperature-proportional ana-
logue signal� Depending on the parameter setting (→ 8) the output signal is at:
4���20 mA with setting [OU] = [I] or
20���4 mA with setting [OU] = [Ineg]�
• The analogue signal can be scaled. Factory setting → see Technical data at
www�ifm�com�
Minimum distance between ASP and AEP = 5 °C or 9 °F�
Maximum measuring range at [OU] = [I] Measuring range scaled at [OU] = [I]
MAW MEW
20.6
20
4
3.7
T [°C/°F]
I [mA]
I [mA]
T [°C/°F]MEWMAW AEPASP
20.6
20
4
3.7
MAW = initial value of the measuring range
MEW = final value of the measuring range
ASP = analogue start point
AEP = analogue end point
Within the measuring range the output signal is between 4 and 20 mA� If the tem-
perature value is outside the limits of the measuring range, the following output
signal is provided:
Output signal at
[OU] = [I]
Output signal at
[OU] = (Ineg]
Temperature > AEP 20���20�6 mA 4���3�7 mA
Temperature > MEW 20�6 mA 3�7 mA
Temperature < ASP 4���3�7 mA 20���20�6 mA
Temperature < MAW 3�7 mA 20�6 mA

5
UK
In case of internal fault, the output signal behaves according to the parameter set
in [FOU] (3�5 mA or 21�1 mA) → 8 Parameter setting�
5 Installation
►Connect the unit to the process using a fixing element (Triclamp, adapter)�
Information about the available adapters at www�ifm�com�
►Observe the instructions of the adapter�
►Use a lubricating paste which is suitable and approved for the
application�
Use in hygienic areas to 3A requirements:
►Make sure that the sensors are integrated into the system in accordance with
3A�
5.1 Units with G½ sealing cone (type TD25xx)
Tightening torque 30���50 Nm�
About sensor installation conforming to 3A:
►Insert PEEK sealing ring E43911�
►Carry out installation according to separate installation instructions of
the sealing ring�
The PEEK sealing ring is not supplied with the unit� It must be ordered separately�
Order no�: E43911�

6
6 Electrical connection
The unit must be connected by a qualified electrician�
The national and international regulations for the installation of electrical
equipment must be adhered to�
Voltage supply according to EN 50178, SELV, PELV�
►Disconnect power�
►Connect the unit as follows:
43
2 1 L+
L
3
1
4
2
IO-Link
L+
L
1
2
12
Operation as 2-wire unit (1):
Pin 1 L+
Pin 2 Analogue signal for temperature
Operation as 4-wire unit (2):
Pin 1 L+
Pin 2 Analogue signal for temperature
Pin 3 L-
pin 4 IO-Link

7
UK
7 Operating and display elements
12
3
1: Current temperature in °C
2: Current temperature in °F
3: 7-segment LED display (4 digits)
8 Parameter setting
Using an IO-Link capable parameter setting tool, the following options are avail-
able:
- Reading current process values�
- Reading, changing and saving current parameter settings and transmitting
them to other units of the same type�
8.1 IO-Link
8.1.1 General information
This unit has an IO-Link communication interface which requires an IO-Link-capa-
ble module (IO-Link master) for operation�
The IO-Link interface enables direct access to the process and diagnostic data
and provides the possibility to set the parameters of the unit during operation�
In addition communication is possible via a point-to-point connection with a USB
adapter cable�
You will find more detailed information about IO-Link at www�ifm�com/gb/io-link�
8.1.2 Device-specific information
You will find the IODDs necessary for the configuration of the IO-Link unit and
detailed information about process data structure, diagnostic information and
parameter addresses at www�ifm�com/gb/io-link�

8
8.1.3 Parameter setting tools
You will find all necessary information about the required IO-Link hardware and
software at www�ifm�com/gb/io-link�
8.2 Adjustable parameters
OU2 Output function:
Analogue signal: 4���20 mA [I] or 20���4 mA [Ineg]�
ASP2
Analogue start value for temperature�
Measured value at which the output signal is 4 mA (20 mA if
[OU2] = [Ineg])�
AEP2
Analogue end value for temperature�
Measured value at which the output signal is 20 mA (4 mA if
[OU2] = [Ineg])�
Minimum distance between ASP2 and AEP2 = 5 °C or 9 °F�
COF
Zero-point calibration�
Setting range: ± 10 °C in steps of 0�1 °C� The internal measured
value "0" is shifted by this value�
FOU2
Behaviour of the output in case of an internal fault�
- [ON] = the analogue signal goes to the upper end stop value
(21�1 mA)�
- [OFF] = the analogue signal goes to the lower end stop value
(3�5 mA)�
Uni Unit of measurement for system temperature: °C or °F�
Update rate of display
[d1] = update of the measured values every 50 ms�
[d2] = update of the measured values every 200 ms�
[d3] = update of the measured values every 600 ms�
Orientation of display [rd] = display rotated by 180°�
9 Operation
After power on, the unit is in the Run mode (= normal operating mode)�
The current temperature value is shown in the display� The analogue output pro-
vides a temperature-proportional signal → 4 Function�
If the temperature value is outside the limits of the measuring range, [OL]
or [UL] is displayed�

9
UK
10 Technical data
10.1 Temperature resistance
Maximum operation time depending on the medium temperature
Further technical data and scale drawing at www�ifm�com�
11 Factory setting
Factory setting User setting
OU I
COF 0.0
FOU OFF
Factory settings for the parameters ASP2, AEP2 and Uni → technical data sheet
at www�ifm�com�
More information at www�ifm�com
