iGenix IG9042 User manual

Please read these instructions carefully before use and retain for future reference
Before switching on your appliance,
always check for any damage which may have been caused in transit
IG9042
Batch code:
2kW Wall PTC Fan Heater
USER MANUAL

2
CONTENTS
Important Safety Instructions...............................................3-4
Specication .................................................................................5
Appliance Overview...................................................................6
Control Panel...............................................................................6
Remote Control..........................................................................6
Mounting Instructions................................................................7
Operating Instructions...........................................................8-9
Using the Control Panel ............................................................8
Using the Remote Control .......................................................9
Overheat Protection ............................................................... 10
Cleaning and Maintenance ..................................................... 10
Trouble Shooting Guide.......................................................... 11
Fuse Replacement.................................................................... 12
Disposal Information............................................................... 12
Terms and Conditions and Warranty Information...... 14-15

3
IMPORTANT SAFETY INSTRUCTIONS
Read and follow all of the instructions even if you feel you are familiar
with the product, and nd a place to keep this manual handy for future
reference.
Important: This appliance is intended for use in a domestic
environment only.Any other use is not recommended by the manufacturer
and may cause re, electrical shocks or other injury to user or property.
When using electrical appliances, basic safety precautions should always be
followed:
• Please read all instructions carefully before using the appliance for the
rst time.
• Before using the appliance, check the voltage indicated on the rating
label corresponds with the main voltage in your home.
• If the supply cord is damaged, it must be replaced before further use
by a service agent or similarly qualied persons in order to avoid a
hazard.
• In order to prevent overheating, do not cover the appliance.
• This appliance can be used by children aged from 8 years and above if
they have been given supervision or instruction concerning the use of
the appliance in a safe way and understand the hazards involved.
• Cleaning and user maintenance shall not be made by children unless
they are older than 8 years and supervised.
• Keep the appliance and its cord out of reach of children aged less than
8 years
• Children shall not play with the appliance.
• This appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Caution: Some parts of this product can become very hot and cause
burns. Particular attention has to be given where children and vulnerable
people are present.
• Do not immerse the appliance or cord in water or any other liquid.
Do not use it in a bathroom, near water, or outdoors.

4
• Do not use the appliance for anything other than its intended use.
• Do not leave the appliance unattended whilst in use.
• Ensure the appliance is installed at least 2m above the oor.
• Do not remove the plug from the socket by pulling the cable. Always
remove it by pulling the plug itself.
• Do not use the appliance if the power cord or plug is damaged. Do
not replace the power cord or any other parts yourself.
• This appliance is for household indoor use only. Never use it outdoors.
• Before moving or attempting to clean the appliance, unplug and allow
it to cool down completely.
• The appliance should not be placed directly under a xed power
socket.
• The use of an extension lead is not recommended, as overheating of
the extension lead may occur during appliance operation.
• This appliance has been designed to be wall-mounted, and as such
should never be attempted to be used as a free-standing unit.
• When mounting the appliance, ensure the wind outlet is facing
downwards.
• Do not use the appliance in areas where ammable liquids are stored
or where ammable fumes may be present.
• Before drilling holes for installation of this appliance, check that there
are no pipes or cables hidden behind the wall.
• When mounting this appliance, ensure that the unit is securely xed to
a strong wall and it safely connected to a mains socket.
• Do not touch the appliance with wet hands.
• Turn off the appliance immediately if the motor stops working.
• In order for this appliance to work at optimum efciency, ensure all
external doors and windows are closed securely during operation.
• When the appliance has been switched off, the fan will continue to run
for 30 seconds in order to cool the unit. Do not disconnect the plug
until the fan has stopped.
• Before disposing of the appliance, ensure that the battery has
been removed from the remote control and has been disposed of
appropriately.

5
Model IG9042
Brand Igenix
Wattage (W) 2000W
Frequency (Hz) 50/60Hz
Voltage (V) 220-240V
Thermostatic Cut Off Ye s
Auto Shut Off Ye s
Overheating Protection Ye s
Remote Control Ye s
Power Settings
1
2
1000W
2000W
Product Dimensions (mm) (H)220 x (W)610 x (D)139
Net Weight (kg) 3.6
Class II
SPECIFICATION

6
MOUNTING INSTRUCTIONS
Mounting the Appliance:
Note: Before mounting the appliance, remove the protective plastic from the
screen.
1) Select a spot on the wall to mount the appliance; ensure there is a minimum of
1.8m clearance from the bottom of the unit to the oor
2) Drill 2 holes , at least 20mm inwards from either side of the unit, using the
measurements from g.1 as a guide.
Note: Before drilling any holes, make sure the wall does not have any hidden
cables or pipes behind it
3) Insert a plastic raw plug into each of the drilled holes before drilling a screw
into each plug. Make sure to leave each screw sticking out of the wall by 10mm
(g.2)
g.1:
g.2:
4) Hang the appliance onto the screws (g.3)
g.3:
572mm
1.8m
Edge of unit
Edge of unit
20mm 20mm

7
APPLIANCE OVERVIEW
Louvre
Control Panel:
Control Panel
Remote Control:
Power
Button
Heat
Button
Oscillation
Button
Timer
Button
High Heat
Indicator
Low Heat
Indicator
Temperature
Indicator
Oscillation
Indicator
- Temperature
Button
+ Temperature
Button
On / Off
Button
Cancel
Button
Timer
Button
Heat/Mode
Button Oscillation
Button

8
Ensure the unit has been installed correctly before operation (following the
instructions on page 6)
OPERATING INSTRUCTIONS
OPERATING THE APPLIANCE USING THE CONTROL PANEL
• Plug the appliance into a suitable power socket. The appliance will beep and
enter standby mode and the LED display will show the ambient temperature
of the room.
• Press the Power button on the control panel; the louvre will open and
the fan will begin to blow without heat.
To Heat:
• Press the Heat button once to set the appliance to low heat mode.
• Press the Heat button twice to set the appliance to high heat mode.
• Press the Heat button again to switch off heat mode and blow air at
room temperature.
To Use Oscillation Function:
• Press the Oscillation button to activate the oscillation of the louvre.
• Press the Oscillation button once more to switch off oscillation mode.
To Set the Timer:
• Press the Timer button to increase the run time by 1 hour till a maximum
of 8 hours.
• Both timer indicator lights will illuminate after the timer has been set and the
LED display will revert back to showing the ambient temperature.
• The appliance will automatically switch off after the desired time.To cancel
the timer, press the Timer button till “00” is displayed.
To Turn Off:
• Press the Power button to switch off the appliance.
• The fan will continue to blow without heat for 30 seconds after the appliance
has been switched off and then the louvre will close; this will enable the
appliance to cool down inside.

9
OPERATING THE APPLIANCE USING THE REMOTE CONTROL
• Plug the appliance into a suitable power socket. The appliance will beep and
enter standby mode and the LED display will show the ambient temperature
of the room.
• Press the On/Off button to switch on the appliance; the louvre will open and
the fan will begin to blow without heat.
To Heat:
• Press the Mode button once to set the appliance to low heat mode.
• Press the Mode button twice to set the appliance to high heat mode.
• Press the up or down buttons to set the desired temperature, which will be
shown on the LED display on the appliance.
• Press the Mode button again to switch off heat mode and blow air at room
temperature.
Note: If the set temperature is equal to or lower than the ambient
temperature, the appliance will not heat. Ensure the set temperature is at least
3°C higher than the ambient temperature of the room, in order for the appliance
to function.
To Use Oscillation Function:
• Press the Oscillation button to activate the oscillation of the louvre.
• Press the Oscillation button once more to switch off oscillation mode.
To Set the Timer:
• Press the Timer button to increase the run time by 1 hour till a maximum of
8 hours.
• Both timer indicator lights will illuminate after the timer has been set and the
LED display will revert back to showing the ambient temperature.
• The appliance will automatically switch off after the desired time.To cancel
the timer, press the Timer button till “00” is displayed.
To Turn Off:
• Press the On/Off button to switch off the appliance.
• The fan will continue to blow without heat for 30 seconds after the appliance
has been switched off and then the louvre will close; this will enable the
appliance to cool down inside.

10
CLEANING AND MAINTENANCE
Before attempting any cleaning or maintenance on the appliance, allow it to cool
completely and ensure that it is switched off and disconnected from the power
supply.
Wipe the outside of the unit with a soft, damp cloth.A mild detergent may be
used if necessary. Dry with a cloth. Do not use any harsh abrasives or solvents.
Never immerse this appliance in water or any other liquid.
If the appliance is not going to be used for a long period of time, safely
disconnect from the power socket and store the appliance in a dry place.
Note: Storing the appliance in a damp environment could cause the unit to rust
and/or could effect the electronics in the appliance.
OVERHEAT PROTECTION
This appliance is tted with a Thermostatic Cut Off that automatically switches
off the unit in case of overheating (e.g due to the appliance being covered or
obstructed). Should the appliance switch off due to overheating, the following
steps should be taken immediately:
• Switch the appliance to standby mode and safely disconnect from the power
socket.
Note: Take care in not touching the appliance, as it will be hot and may cause
injury.
• Remove anything that may be obstructing the unit.
• Wait at least 30 minutes for the appliance to cool down completely.
• Reconnect the unit to the power source and turn the appliance back on.

11
TROUBLE SHOOTING GUIDE
If you experience difculties with the appliance, please check the suggestions below
before contacting customer services on 01473 271272:
Problem Possible Cause Possible Solution
The appliance does not
work.
There is no power to the
appliance.
Ensure the appliance is
properly connected to the
power supply and is set to
‘On.’
No electricity in the mains wall
socket.
Check fuse or breaker.
The Thermal Safety Cut Out
has been activated
Disconnect the appliance
from the power, remove
anything covering the
unit, allow to cool down
completely and then
reconnect to power.
Timer is not set correctly. Check the timer is set
correctly.
The room is too cold
or too hot.
Temperature is set too low or
too high.
Check the temperature
setting.
Draft from windows or door. Block up any drafts and
ensure all external windows
and doors are closed.

12
DISPOSAL INFORMATION
The European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in normal unsorted
municipal waste.
Old appliances must be collected separately in order to optimise
the recovery and recycling of the materials they contain and reduce the impact
on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.
MAINS PLUG FUSE REPLACEMENT
Fuse Replacement (Class II)
Remove the central screw on the plug and
open the shell. Take out the fuse and replace
with a new fuse of the same Amp. Install the
shell again and tighten the screws.

13

14
lgenix Warranty Terms & Conditions
This product is guaranteed for a period of 12 months as standard from the date of purchase
against mechanical and electrical defects. You can extend your warranty for a further 12 months by
registering your product.
Upon registration we will cover your product for a period of 24 months from the original purchase
date against any mechanical or electrical defects.
To qualify for the guarantee, the product must be used for domestic household use only and in
accordance with the instructions in the user manual.Any misuse of the product will result in the
warranty being void.
The guarantee does not cover accidental damage, misuse, neglect, tampering or incorrect
adjustment or installation.
The guarantee will be rendered invalid if the product is resold, has had its serial number removed
(or has an invalid serial number), or if an unauthorised person has carried out any repairs or
alterations.
The warranty does not cover accessories or consumable parts that require replacement under
normal use. This includes shelving, dials, lters, belts and trays etc.
In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual
and check all plugs, fuses and the electricity supply.
If you still require assistance please contact our Customer Service department on
01473 271 272 or write to us at the following address:
Customer Service Department
38 Bluestem Road, Ransomes Europark
Ipswich, IP3 9RR
Please quote the Product Code which begins ‘IG’ or ‘DF’ and the Batch Coder beginning ‘5’ and give
details of the exact fault. We will then decide whether to repair or replace the item.
Before we arrange the repair or replacement you will be required to return a copy of your proof
of purchase. Please retain your original.
If an item is replaced within the agreed guarantee period, the guarantee for the replacement item
will be calculated from the purchase date of the original.
In the event that the product is inspected and no fault is found or the product is not within the
guarantee period you will be charged for the repair and any carriage costs.

15
Thank you for choosing lgenix
As a valued customer we would like to offer you a FREE 2 year warranty to cover your product
against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will
happily repair or replace the item free of charge.
To qualify for the 2 year warranty you must register your product within 30 days of purchase.The
full Terms & Conditions of our warranty policy are shown on the opposite page.They are also
available on our website. www.igenix.co.uk
To register your product, please complete all sections of the form below and return to us at the
following address: lgenix, 38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR.
Alternatively you can visit the lgenix website and complete the form online.
Customer Details:
Title: First Name Surname:
Address:
Post Code:
Email:
Telephone:
Product Information:
Product Code (Beginning IG or DF): Product Description:
Batch Number (Beginning 5): Serial Number (If applicable):
Date of Purchase:
Retailer Name:
Retailer Location:
Please tick here to conrm you have read and accept our Terms & Conditions
Please tick here if you DO NOT wish to receive marketing information from us
Customer Signature: Date:

38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR
Tel. [phone]
Disclaimer: Igenix operate a policy of continual improvement and development.
We therefore reserve the right to change/alter the specication and appearance of our appliances without prior notice.
All diagrams and images shown in this manual are for illustration purposes only.
