iGenix IG9021 User manual

Please read these instructions carefully before use and retain for future reference
Before switching on your appliance
Always check for any damage which may have been caused in transit
IG9021
2kW Oscillating Fan Heater
USER MANUAL
Batch code:
IMPORTANT: THIS PRODUCT IS ONLY SUITABLE
FOR WELL INSULATED SPACES OR OCCASIONAL USE

2
CONTENTS
Important Safety Instructions...............................................2-4
Appliance Overview...................................................................4
Technical Specication ...............................................................5
Operating Instructions...............................................................6
Cleaning and Maintenance ........................................................6
Fuse Replacement.......................................................................7
Trouble Shooting Guide.............................................................7
Terms and Conditions and Warranty Information...........8-9
Disposal Information............................................................... 12
SAFETY INSTRUCTIONS
Important: Read and follow all of the instructions even if you
feel you are familiar with the product and nd a place to keep this
manual handy for future reference.
• Make sure the unit is connected to an earthed power supply
of the correct rating (refer to the rating label located on the
unit). Ensure that the electricity supply in your home is rated at
220-240 volts before operating the appliance.
• This appliance should only be used by adults.
• Cleaning and user maintenance shall not be made by children.
• Keep the appliance and its cord out of reach of children.
• Children shall not play with the appliance.
• The appliances cannot be used by persons with reduced
physical, sensory or mental capabilities.
• This product is intended for domestic use only.
• The heater is not designed for use as the main form of heating.
• This product has been designed for household and indoor use
only. Do not use the heater outdoors.
• If the mains lead of this appliance becomes damaged then it
must be replaced by the manufacturer’s service agent or a
suitably qualied person using the same rated cable in order to
avoid a hazard.
• Keep the mains lead away from the hot body of the appliance
and always unroll lead completely to avoid dangerous
overheating.

3
• Always turn off the appliance and unplug when not in use or
before carrying out cleaning, maintenance or moving locations.
• Ensure the appliance is used on a at, even surface, positioned
away from curtains and furniture which could cause a re hazard.
• There are no user serviceable parts inside this heater.
• Do not remove plug from power socket until and appliance is
switched off and never remove by pulling the supply cord.
Always grip the plug.
• Do not cover or obstruct any of the heat outlet grilles or air
intake openings of the heater.
• Do not insert any objects through the heat outlet of air
intakes grilles.
• Do not place the heater directly below a socket outlet.
• Ensure that the heater is not positioned close to curtains or
furniture as this may create a re hazard.
• Do not use the heater in areas where ammable liquids are
stored or ammable fumes may be present.
• Do not twist, kink or wrap the cord around the appliance as this
may cause the insulation to weaken and split.
• Do not place the heater on carpets with a deep pile. Do not
run the cord under carpeting, rugs or runners.Arrange cord
away from trafc so that it will not be tripped over. Keep the
cord a safe distance from the inlet and outlet grilles.
• Use of an extension cord is not recommended with this
appliance.
• Do not use the appliance to dry clothes.
• Do not store the appliance while it is still hot.
• Do not operate with the cord coiled as a build-up of heat could
be sufcient to become a hazard.
• Attention: the front grille gets hot during use.
• The most common cause of overheating is deposits of dust or
uff in the appliance. Ensure these deposits are removed
regularly by unplugging the appliance and vacuum cleaning the
grilles.

4
• Do not reach for an appliance that has fallen into water. Switch
off at supply and unplug immediately
• Never place the heater where it may fall into water, or stand on
a damp oor.
• Do not use the unit in a wet room, such as a bathroom or
laundry room or in areas where the unit is likely to get splashed.
• To protect against re, electric shock or injury do not immerse
the heater, power cord or plug in water or any other liquid.
• Do not operate appliance with wet hands.
• Use this appliance only as describe in the manual.Any other use
is not recommended by the manufacturer and may case re,
electric shock or injury.
APPLIANCE OVERVIEW
1. Temperature Control
2. Mode Selector Control
3. Power Indicator Light
4. Oscillation Switch
5. Tip Over Switch (underneath)
5
2
3
4
5
Fig. 1
Fig. 2 Fig. 3

5
Technical specication
Item Symbol Value Unit Item Unit
Heat output
Nominal heat output Pnom 2 kW
Minimum heat output Pmin 1 kW
(indicative)
Minimum continuous Pmax,c 2 kW
heat output
Auxiliary electricity consumption
At nominal heat output elmax 0 kW
At minimum heat output elmin 0 kW
In standby mode elsb 0 kW
Type of heat input, for electric storage local
space heaters only (select one)
manual heat charge control, with N/A
integrated thermostat
manual heat charge control with N/A
room and/or outdoor temperature
feedback
electronic heat charge control with N/A
room and/or outdoor temperature
feedback
fan assisted heat output N/A
Type of heat output/room temperature
control (select one)
single stage heat output and no room [no]
temperature control
Two or more manual stages, no room [no]
temperature control
with mechanic thermostat room [yes]
temperature control
with electronic room temperature [no]
control
electronic room temperature control [no]
plus day timer
electronic room temperature control [no]
plus week timer
Other control options (multiple selections
possible)
room temperature control, with [no]
presence detection
room temperature control, with open [no]
window detection
with distance control option [no]
with adaptive start control [no]
with working time limitation [no]
with black bulb sensor [no]

6
OPERATING INSTRUCTIONS
Choose a suitable location for the heater ensuring you have taken account of the safety instructions
NOTE: It is normal that when the heater is turned on for the rst time or after not being used for a
long period of time that it may emit a slight smell and fumes.These will disappear when the heater has
been on a short while.
• Take out the heater from its box carefully. Please save the box to store
the heater when not in use.
• Plug the unit into a power socket. Do not to use the same electrical socket
as another high wattage electrical appliance in order to avoid overloading
the circuit.
Selecting Mode:
• Use the Mode Selector Control (Fig 3) to choose the required mode.
• Setting (Fig 3) indicates the fan function only, this will produce no heat.
• l Setting (Fig 3) indicates the low heating function 1kW power.
• II Setting (Fig 3) indicates the high heating function 2kW power.
• 0 Setting (Fig 3) indicates off.
Selecting temperature:
• Gradually turn the Temperature Control (Fig 2) in a clockwise direction until the
required temperature is reached.
• The Temperature Control can then be turned in either direction to decrease or increase
the temperature.
• The thermostat can be adjusted between 0 - 40°C.
Oscillation Function
• The unit is supplied with an oscillation function; this will allow air to be distributed over a larger area.
• To switch the oscillation function on, press the Oscillation Switch (Fig 1 [4]) to the ‘on’ position, to
switch off repeat this function.
Overheat Protection
• The unit is tted with a safeguard that will automatically shut the power off should any part of the
heater begin to overheat. Once the unit has cooled down it will automatically switch back on.
Check that there is nothing surrounding the unit that may have caused it to overheat.
Tip Over Switch
• The unit is tted with a tip over switch, this will automatically shut the power off should the unit
fall or be knocked over. To reset unit, stand upright on a at even surface.
Cleaning and Maintenance
• Ensure the heater is switched off and unplugged from the mains socket and allowed to cool down.
Once cool wipe the exterior of the unit with a damp (not wet) clean cloth. It is not recommended to
use detergents or abrasive materials as this may damage the housing. Important: Do not allow water
to enter the heater.
• To remove dust and debris for the grilles it is recommended that you use a vacuum cleaner.
• Ensure that the heater and plug are dry before plugging back into the mains socket.
Storing
• When the unit is not in use for long periods of time it is recommended that the unit be placed back
in the original box and stored out of reach of children.

7
MAINS PLUG FUSE REPLACEMENT
(Class II)
Remove the central screw on the plug and open the shell.
Take out the fuse and replace with a new fuse of the same
Amp. Install the shell again and tighten the screws.
TROUBLE SHOOTING
Please refer to the trouble shooting guide when experiencing an issue with your heater. If you still cannot
determine the fault then please call our Customer Services number 01473 271272
Problem Possible Cause Solution
The heater does
not work.
1. Not properly plugged into the
mains wall socket.
Push plug rmly in.
2. Not switched on.
The heater is
getting too hot.
Conrm the unit is switched on.
3. Power cut.
Adjust the temperature control.
The heater is
not heating up.
1.Temperature control set too low.
Check the fuse or breaker.
1. Inadequate air ow.
2.Temperature control set to high.
3. Power cut.
Make sure there is air circulating
in the room.
Make sure that nothing is blocking
the air ow.
Adjust the temperature control
to a higher setting.
2.The Mode selector is on
the wrong mode.
Turn the Mode selector to
ll high mode.

8
lgenix Warranty Terms & Conditions
This product is guaranteed for a period of 12 months as standard from the date of purchase
against mechanical and electrical defects.You can extend your warranty for a further 12 months by
registering your product.
Upon registration we will cover your product for a period of 24 months from the original purchase
date against any mechanical or electrical defects.
To qualify for the warranty, the product must be used for domestic household use only and in
accordance with the instructions in the user manual.Any misuse of the product will result in the
warranty being void.
The warranty does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment
or installation.
The warranty will be rendered invalid if the product is resold, has had its serial number removed
(or has an invalid serial number), or if an unauthorised person has carried out any repairs or
alterations.
The warranty does not cover accessories or consumable parts that require replacement under
normal use. This includes shelving, dials, lters, belts and trays etc.
In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual
and check all plugs, fuses and the electricity supply.
If you still require assistance please contact our Customer Service department on
01473 271 272 or write to us at the following address:
Customer Service Department
38 Bluestem Road, Ransomes Europark
Ipswich, IP3 9RR
Please quote the Product Code which begins ‘IG’ or ‘DF’ and the Batch Coder beginning ‘5’ and give
details of the exact fault.We will then decide whether to repair or replace the item.
Before we arrange the repair or replacement you will be required to return a copy of your proof
of purchase. Please retain your original.
If an item is replaced within the agreed warranty period, the warranty for the replacement item will
be calculated from the purchase date of the original.
In the event that the product is inspected and no fault is found or the product is not within the
warranty period you will be charged for the repair and any carriage costs.

99
Thank you for choosing lgenix
As a valued customer we would like to offer you a FREE 2 year warranty to cover your product
against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will
happily repair or replace the item free of charge.
To qualify for the 2 year warranty you must register your product within 30 days of purchase.The
full Terms & Conditions of our warranty policy are shown on the opposite page.They are also
available on our website. www.igenix.co.uk
To register your product, please complete all sections of the form below and return to us at the
following address: lgenix, 38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR.
Alternatively you can visit the lgenix website and complete the form online.
Customer Details:
Title: First Name Surname:
Address:
Post Code:
Email:
Telephone:
Product Information:
Product Code (Beginning IG or DF): Product Description:
Batch Number (Beginning 5): Serial Number (If applicable):
Date of Purchase:
Retailer Name:
Retailer Location:
Please tick here to conrm you have read and accept our Terms & Conditions
Please tick here if you DO NOT wish to receive marketing information from us
Customer Signature: Date:

10

11

38 Bluestem Road, Ransomes Europark, Ipswich, IP3 9RR
Tel. [phone]
Disclaimer: Igenix operate a policy of continual improvement and development.
We therefore reserve the right to change/alter the specication and appearance of our appliances without prior notice.
All diagrams and images shown in this manual are for illustration purposes only.
DISPOSAL INFORMATION
The European Directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances
must not be disposed of in normal unsorted municipal waste.
Old appliances must be collected separately in order to optimise the
recovery and recycling of the materials they contain and reduce the
impact on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your obligation,
that when you dispose of the appliance it must be separately collected. Consumers
should contact their local authority or retailer for information concerning the correct
disposal of their old appliance.
