iGenix IG9022 User manual

IG9022
2kW Fan Heater
USER MANUAL
Please read these instructions carefully before use and retain for future reference
Before switching on your appliance,
always check for any damage which may have been caused in transit
PO Number:
IMPORTANT: THIS PRODUCT IS ONLY SUITABLE
FOR WELL INSULATED SPACES OR OCCASIONAL USE

2
CONTENTS
Safefty instructions..................................................................3-5
Technical Specication ........................................................ 6 - 7
Appliance Overview...................................................................8
Operating Instructions........................................................ 8 - 9
Cleaning & Maintenance ............................................................9
Troubleshooting........................................................................ 10
Mains Plug Fuse Replacement ............................................... 11
Product disposal and recycling.............................................. 11
Igenix Warranty ................................................................12 - 13

3
SAFETY INSTRUCTIONS
Important: Read and follow all of the instructions even if you
feel you are familiar with the product, and nd a place to keep this
manual handy for future reference.
1. This appliance can be used by children aged from 8 years and
above if they have been given supervision or instruction
concerning the use of the appliance in a safe way and understand
the hazards involved.
2. Cleaning and user maintenance shall not be made by children
unless they are older than 8 years and supervised.
3. Keep the appliance and its cord out of reach of children aged
less than 8 years.
4. Children shall not play with the appliance.
5. Appliances can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand the
hazards involved.
6. This product is intended for domestic use only.
7. The heater is not designed for use as the main form of heating.
8. This product is for indoor use only. Do not use the heater
outdoors.
9. Ensure that the electricity supply in your home is rated at
220-240 volts before operating the appliance.
10. If the mains lead of this appliance becomes damaged then it
must be replaced by the manufacturer’s service agent or a
suitably qualied person using the same rated cable in order to
avoid a hazard.
11. There are no user serviceable parts inside this heater.
12. Children should be supervised to ensure that they do not play
with the appliance.
13. Always turn off and unplug the appliance before attempting
to move.
14. Do not store the appliance while it is still hot.

4
15. Always turn off and unplug the appliance when not in use.
16. Do not use the heater in the immediate surroundings of a bath,
shower or swimming pool.
17. Do not reach for an appliance that has fallen into water.
Switch of at supply and unplug immediately
18. Never place the heater where it may fall into water, or stand
on a damp oor.
19. Do not cover or obstruct any of the heat outlet grilles or air
intake openings of the heater.
20. Do not insert any objects through the heat outlet of air
intakes grilles.
21. Attention: the front grille gets hot during use.
22. Do not place the heater on carpets with a deep pile.
23. Do not place the heater directly below a socket outlet.
24. Ensure that the heater is not positioned close to curtains or
furniture as this may create a re hazard.
25. Do not use the heater in areas where ammable liquids are
stored or ammable fumes may be present.
26. To protect against re, electric shock or injury do not immerse
the heater, power cord or plug in water or any other liquid.
27. Do not twist, kink or wrap the cord around the appliance, this
may cause the insulation to weaken and split.
28. Do not run the cord under carpeting, rugs or runners. Arrange
cord away from trafc so that it will not be tripped over.
Keep the cord a safe distance from the inlet and outlet grilles.
29. Avoid the use of an extension cord.
30. Do not operate with the cord coiled as a build up of heat
could be sufcient to become a hazard.
26. Do not remove plug from power socket by pulling the supply
cord. Always grip the plug.
27. Do not remove the plug socket until the appliance is
switched off.
28. Do not use the appliance to dry clothes.
29. Do not operate appliance with wet hands.

5
30. The most common cause of overheating is deposits of dust or
uff in the appliance. Ensure these deposits are removed
regularly by unplugging the appliance and vacuum cleaning
the grilles.
31. Use this appliance only as described in the manual. Any other
use is not recommended by the manufacturer and may case re,
electric shock or injury.
WARNING: In order to avoid overheating, do not cover
the heater.

6
TECHNICAL SPECIFICATION
Item Symbol Value Unit Item Unit
Heat output
Nominal heat output Pnom 2.000 kW
Minimum heat output Pmin 1.200 kW
(indicative)
Minimum continuous Pmax,c 2.000 kW
heat output
Auxiliary electricity consumption
At nominal heat output elmax 1.926 kW
At minimum heat output elmin 1.148 kW
In standby mode elSB 0.000 kW
Type of heat input, for electric storage local
space heaters only (select one)
manual heat charge control, with No
integrated thermostat
manual heat charge control with No
room and/or outdoor temperature
feedback
electronic heat charge control with No
room and/or outdoor temperature
feedback
fan assisted heat output No
Type of heat output/room temperature
control (select one)
single stage heat output and no room No
temperature control
Two or more manual stages, no room No
temperature control
with mechanic thermostat room Yes
temperature control
with electronic room temperature No
control
electronic room temperature control No
plus day timer
electronic room temperature control No
plus week timer
Other control options (multiple selections
possible)
room temperature control, with No
presence detection
room temperature control, with open No
window detection
with distance control option No
with adaptive start control No
with working time limitation No
with black bulb sensor No

7
Mode Ecodesign requirements , from 7 January 2013 Result - Remark Verdict
Off mode Power consumption in ‘off mode’:
Power consumption of equipment in any off-
mode condition shall not exceed 0.50 W
0 W P
Standby mode Power consumption in ‘standby mode(s)’:
The power consumption of equipment in
any condition providing only a reactivation
function, or providing only a reactivation
function and a mere indication of enabled
reactivation function, shall not exceed 0.50 W
N/A
The power consumption of equipment in any
condition providing only information or status
display, or providing only a combination of
reactivation function and information or status
display shall not exceed 1.00W
N/A
Test Data
Commission Regulation (EC) No 1275/2008 Requirement
Seasonal space heating energy efciency
Description Value
Seasonal space heating energy efciency in active mode-ηs,on 40%
For electric local space heaters-ηth 100%
The electric to primary energy ‘conversion coefcient-CC 2.5
correction factor accounting for a positive contribution to the seasonal space 0%
correction factor accounting for a positive contribution to the seasonal space 6.00%
correction factor accounting for a positive contribution to the seasonal space 0%
correction factor accounting for a negative contribution to the seasonal space 0%
correction factor accounting for a negative contribution to the seasonal space 0%
Seasonal space heating energy efciency-ηs36.00%
Verdict P

8
APPLIANCE OVERVIEW
OPERATING INSTRUCTIONS
Before turning on the machine ensure that the following has been checked:
1. Check that the power cord is not damaged.
2. This product uses a 220-240V AC power supply. Before use, ensure the rated current of the power
socket meets the local requirements.
Place the machine on a at surface. This product has a tip-over switch safety feature. If placed on an
uneven surface the heater may not turn on.
Temperature Control Knob
Insert the plug into the power socket, then turn the temperature control knob clockwise. A click sound
indicates the temperature control is on, then adjust the temperature to the desired level.
Power Selection Knob
Turn the power selection knob to select between 3 functions: Fan only, Low 1200W (LOW), High
2000W(HIGH).
Turn off the Heater
1. Turn the power selection knob to OFF position.
2. Turn the temperature control knob anticlockwise to the initial position.
3. Remove the power plug, store the heater after the entire machine has cooled down.
Safety Protection
1. Overheat protection:
When the temperature in the heater is too high (wrong environment, improper use etc.), the
thermostat device can automatically cut off the power to the unit.After the heater has cooled
sufciently it can be used as normal after rectifying the cause.
2. Tip-over protection:
When the whole heater is tipped over, the safety system will automatically cut off the power, and will
return to the previous setting once the body is placed upright.
Temperature
control knob Power indicator light
Power selection knob
Safety grill

9
Safety Control
Your heater is tted with a safety device “Double Protector” that (1) switches off the heater by thermal
cut-off in the event of overheating or malfunction and it will reset while the temperature reduces to
a normal level. (2) Shuts off the heater by thermal fuse in the event of overheating or malfunction and
prevents operation by some other accidental reason.
If overheating or malfunctions continue, return the heater to an Approved Service Agent for examination.
The most common cause of overheating is deposits of dust or uff entering the heater, therefore it
is important to ensure that these deposits are removed regularly by unplugging the unit and vacuum
cleaning air vents and front grille.
Power Indicator Light
This fan heater is equipped with a power indicator light that glows whenever the heater is plugged in
and turned on. It will continue to glow even if the thermostat has cycled through the heating elements.
This feature is to prevent you from being unaware that the heater is operating and maintaining the
temperature of the room.
When you do not wish the heater to control the room temperature, turn the control switch to O (off)
and remove the plug from the electrical outlet.
CLEANING & MAINTENANCE
1. Light accumulated dust may be removed from the heater with a soft cloth.Wipe the exterior
surfaces of the heater occasionally with a lightly damp cloth (not dripping wet) with a solution of mild
detergent and water. Dry the case thoroughly with a soft dry cloth before operating the heater.
2. The fan motor is lubricated by the factory and will require no further lubrication
3. No other user maintenance is required or recommended. If service is required, send your heater to
the nearest authorised service depot.
4. Store heater in a clean and dry place when not in use. REMEMBER - portable electric heaters are
designed for spot heating, or as a supplementary heat source.They are not intended to be main
sources of heat during the normal heating season.
Note: There may be trace of smoke or odour when unit is rst operated. This is caused by protective
residue left on the heating coil during the manufacturing process. It will quickly evaporate, and should not
re-occur.
Warning: This heater cannot achieve accurate temperature control of the environment, and thus
cannot be used as an insulation device for storage environment, items, animals and plants.

10
TROUBLESHOOTING GUIDE
Please refer to the trouble shooting guide when experiencing an issue with your heater. If you still cannot
determine the fault then please call our Customer Service number 01473 271272.
Problem Possible Cause Possible Solution
After the power is engaged, the
power indicator light does not
illuminate and the machine does
not work
The plug may not be plugged
correctly
Check whether the plug is
properly inserted into the
power socket
The temperature control knob
is not in the correct position
Check whether the temperature
control knob is turned to the
ON position
The machine stops suddenly
during heating
The temperature exceeds the
threshold of the thermal cut-off
Cool the machine before use

MAINS PLUG FUSE REPLACEMENT
(Class II)
Remove the central screw on the plug and open the shell.
Take out the fuse and replace with a new fuse of the same
Amp. Install the shell again and tighten the screws.
11
DISPOSAL INFORMATION
The European Directive 2012/19/EU on Waste Electrical and
Electronic Equipment (WEEE), requires that old household
electrical appliances must not be disposed of in normal unsorted
municipal waste.
Old appliances must be collected separately in order to optimise
the recovery and recycling of the materials they contain and reduce the impact
on human health and the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation, that when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer for information
concerning the correct disposal of their old appliance.

12
Igenix Warranty Terms & Conditions
This product is guaranteed for a period of 12 months as standard from the date of purchase
against mechanical and electrical defects.You can extend your warranty for a further 12 months by
registering your product.
Upon registration we will cover your product for a period of 24 months from the original purchase
date against any mechanical or electrical defects.
To qualify for the warranty, the product must be used for domestic household use only and in
accordance with the instructions in the user manual.Any misuse of the product will result in the
warranty being void.
The warranty does not cover accidental damage, misuse, neglect, tampering or incorrect adjustment
or installation.
The warranty will be rendered invalid if the product is resold, has had its serial number removed
(or has an invalid serial number), or if an unauthorised person has carried out any repairs or
alterations.
The warranty does not cover accessories or consumable parts that require replacement under
normal use. This includes shelving, dials, lters, belts and trays etc.
In the unlikely event of a breakdown please refer to the Troubleshooting guide in your user manual
and check all plugs, fuses and the electricity supply.
If you still require assistance please contact our Customer Service department on
01473 271 272 or write to us at the following address:
Customer Service Department
38 Bluestem Road, Ransomes Europark
Ipswich, IP3 9RR
Please quote the Product Code which begins ‘IG’ or ‘DF’ and the PO Number on the front of the
manual, and give details of the exact fault.We will then decide whether to repair or replace the
item.
Before we arrange the repair or replacement you will be required to return a copy of your proof
of purchase. Please retain your original.
If an item is replaced within the agreed warranty period, the warranty for the replacement item will
be calculated from the purchase date of the original.
In the event that the product is inspected and no fault is found or the product is not within the
warranty period you will be charged for the repair and any carriage costs.

13
Thank you for choosing lgenix
As a valued customer we would like to offer you a FREE 2 year warranty to cover your product
against any electrical or mechanical defects.
This means that in the unlikely event you develop a fault or problem with your product we will
happily repair or replace the item free of charge.
To qualify for the 2 year warranty you must register your product within 30 days of purchase.The
full Terms & Conditions of our warranty policy are shown on the opposite page.They are also
available on our website. www.igenix.co.uk
