IKEA VALGRUNDAD User manual

VÄLGRUNDAD FR
ES

ENGLISH
Please refer to the last page of this manual for the full list of IKEA
appointed After Sales Service Provider and relative national phone
numbers.
Please record your model and serial numbers
below for reference.
Purchase Date
Model Number
Serial Number
Please attach sales receipt here for future
reference.
Installation checklist
Door
Door seals completely to cabinet on all sides
Door is level
Levelling
Refrigerator is level, side-to-side and
tilted ¼ in. (6mm) front-to-back
Cabinet is setting solid on all corners
Distance holder (anti-tip bracket) set
Electrical power
House power turned on
Refrigerator plugged in
Final Checks
Shipping material removed
Refrigerator and freezer temperatures set
Crisper humidity control set
Refer to the separate Assembly
Instructions for detailed installation

FRANÇAIS
Veuillez vous reporter à la dernière page du présent manuel pour la liste
complète des prestataires de service après-vente désignés par IKEA et les
numéros de téléphone nationaux correspondants.
Veuillez enregistrer vos numéros de modèle et
de série ci-dessous à titre informatif.
Date d’achat
Numéro de modèle
Numéro de série
Veuillez brocher votre reçu ici pour vous y
référer ultérieurement.
Porte
La porte se ferme complètement sur
l’armoire de tous les côtés
La porte est de niveau
Mise à niveau
Le réfrigérateur est de niveau d’un côté à
l’autre et incliné de 6 mm (¼ po) de l’avant à
l’arrière
L’armoire a un appui solide aux quatre coins
Le support de distanciation (anti-
basculement) est installé
Alimentation électrique
L’alimentation électrique de la maison est
sous tension
Le réfrigérateur est branché
Matériel d’expédition retiré
Réglage de la température du réfrigérateur
et du congélateur
Réglage d’humidité du bac à légumes
Reportez-vous aux instructions de
montage à part pour une installation
détaillée.

ESPAÑOL
Por favor, consulte la última página de este manual donde encontrará la
lista completa de los proveedores de servicios posventa designados por
IKEA y sus respectivos números de teléfono.
Por favor, registre su modelo y los números de
serie que aparecen debajo para referencia.
Fecha de compra
Número del modelo
Número de serie
Por favor, adjunte su recibo de compra
aquí para futura referencia.
Lista de control de la instalación
Puerta
La puerta sella por completo el gabinete
La puerta está nivelada
Nivelador
El refrigerador está nivelado, de lado a lado,
y tiene una inclinación de ¼ de pulgada
(6 mm) hacia atrás.
El gabinete descansa sólidamente en las
cuatro esquinas.
Dispositivo distanciador (soporte anti-vuelco)
Corriente eléctrica
Corriente doméstica encendida
Refrigerador enchufado
Material de embalaje retirado
del congelador
Consulte las Instrucciones de Montaje
separadas para los detalles de la
instalación.

ENGLISH 6
FRANÇAIS 23
ESPAÑOL 42

6ENGLISH
Contents
IMPORTANT SAFETY INFORMATION 6
Installation 9
First use 10
Product description 11
Operation 12
Daily use 14
Hints and tips 15
Care and cleaning 16
Troubleshooting 18
Technical information 20
Environmental concerns 21
IKEA limited guarantee 21
Subject to change without notice.
IMPORTANT SAFETY INFORMATION
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Retain all documents for subsequent use
or for the next owner.
•The manufacturer is not liable if you
disregard the instructions and warnings
in the operating and installation
instructions.
•Know these safety symbols.
This is the attention symbol, pertaining to
safety, which alerts users to potential risks
to themselves and others.
All safety warnings are preceded by the
attention symbol and the following terms:
Warning:indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
Caution: indicates a potentially hazardous
situation which, if not avoided, may result in
minor ormoderate injury.
Child safety
• Keep children away from packaging and its
cartons and cling wrap!
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
• Do not allow children to play with the
appliance!
• Destroy or recycle the carton, plastic
bags, and any exterior wrapping material
immediately after the refrigerator is
unpacked. Children should never use
these items to play. Cartons covered with
rugs,bedspreads, plastic sheets or stretch
wrap may become airtight chambers, and
General Safety
• This appliance is intended to be used in
household and similar applications such as:
- eas in
environments;
- By clients in hotels, motels, bed and
breakfast and other residential type
environments;
• If the power cord is damaged, it must be
replaced by the manufacturer, its Authorised
in order to avoid a hazard.
• Only original parts supplied by the
manufacturer should be used. Only original
parts satisfy safety requirements.
• Do not use electrical appliances inside the
appliance (e.g. heater, electric ice maker,
etc.). Risk of explosion!
• Do not use water spray and steam to clean
the appliance. The steam may penetrate
electrical parts and cause a short–circuit.
Risk of electric shock!

7ENGLISH
• Do not use pointed and sharp–edged
implements to remove frost or layers of
ice. You could damage sensitive internal
components, including the refrigerant
tubes. Leaking refrigerant may ignite or
cause eye injuries.
• Do not use other means to accelerate
the defrosting process other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not store products which contain
explosive substances in the appliance. Risk
of explosion!
• Only store high-proof alcohol tightly closed
and standing up.
• Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• Never cover or block the ventilation
openings for the appliance.
•
• Clean the appliance with a moist soft cloth.
Only use neutral detergents. Do not use
abrasive products, abrasive cleaning pads,
solvents or metal objects.
• Keep plastic parts and the refrigerator seal
free of oil and grease. Otherwise, parts and
the refrigerator seal will become porous.
• Do not stand on or lean heavily against the
base of the appliance, door, shelves etc.
Transportation
The appliance is heavy and must be handled
with caution during transportation and
installation. Because of the weight and
dimensions of the appliance, at least two
persons are necessary to move the appliance
into position securely and avoid injuries to
people or damage to the appliance.
Installation
Warning!
install this appliance.
• Remove all the packaging and the transit
bolts.
• Do not install oruse a damaged appliance.
• Follow the installation instruction supplied
with the appliance.
• Always take care when moving the
appliance as it is heavy. Always use safety
gloves and enclosed footwear.
• Make sure the air can circulate around the
appliance.
• Do not tilt the refrigerator for more than 45°
form upright during moving it.
• eversing the
door wait at least 4 hours before connecting
the appliance to the power supply. This is to
• Before carrying out any operations on the
appliance (e.g. reversing the door), remove
the plug from the power socket.
• Do not install the appliance close to
radiators or cookers, oven or hobs.
• The rear of the appliance must stand
against the wall.
• Do not install the appliance where there is
direct sunlight.
• Do not install this appliance in areas that
are too humid or too colds, such as the
construction appendices, garages or wine
cellars.
• When you move the appliance, lift it by the
Electrical connection
Warning!
Warning!When positioning the appliance,
ensure the power cord is not trapped or
damaged.
Warning!Do not use multi-plug adapters
and extension cords.
Warning! Do not, under any
circumstances, cut, remove, or bypass the
grounding prong.
3-prong plug
3-prong receptacle
Grounding pin
Ground receptacle box

8ENGLISH
• The appliance must be earthed. The
appliance must be plugged into its own
dedicated 115 Volt, 60 Hz.,15 Amp, AC
only electrical outlet. The power cord of
the appliance is equipped with a 3-prong
grounding plug for your protection
against electrical shock hazards. It must be
plugged directly into a properly grounded
3-prong receptacle. The receptacle must be
installed in accordance with local codes and
Avoid connecting refrigerator to a Ground
Fault Interrupter (GFI) circuit.
• If there is a 2-prong standard wall socket,
it is the responsibility of the customer to
have this socket replaced with a correctly
grounded 3-prong wall socket.
• Never unplug the appliance by pulling on
and pull straight out from the receptacle to
prevent damaging the power cord.
•
voltage varies by 10% or more. Operating
damage the compressor. Such damage is
not covered under your warranty.
• Do not plug the appliance into an electrical
outlet controlled by a wall switch or pull
cord to prevent the appliance from being
• Make sure that the parameters on the rating
plate are compatible with the electrical
ratings of the mains power supply.
• Always use a correctly installed shockproof
socket.
• Make sure not to cause damage to the
electrical components (e.g. mains plug, power
cord, compressor). Contact the Authorised
Service Centre or an electrician to change the
electrical components.
• The power cord must stay below the level of
the mains plug.
• Connect the mains plug to the mains socket
only at the end of the installation. Make sure
that there is access to the mains plug after
the installation.
Use
Warning! Risk of injury, burns, electrical
isobutane (R600a), a natural gas with a high
level of environmental compatibility. Be careful
not to cause damage to the refrigerant circuit
containing isobutane.
• The surface of the compressor becomes hot:
The surface of the compressor may become
hot under normal operation. Do not touch it
with hands.
•
appliance.
• Do not put electrical appliances (e.g. ice
cream makers) in the appliance unless they
are stated applicable by the manufacturer.
• If damage occurs to the refrigerant circuit,
sources of ignition in the room. Ventilate
the room.
• Do not let hot items to touch the plastic
parts of the appliance.
• Do not put soft drinks in the freezer
compartment. This will create pressure on
the drink container.
• Do
appliance.
•
near or on the appliance.
• Do not touch the compressor or the
condenser. They are hot.
• Do not remove or touch items from the
freezer compartment if your hands are wet
or damp.
• Do not freeze again food that has been
thawed.
• Follow the storage instructions on the
packaging of frozen food.
Internal lighting
Warning! Risk of electric shock.
• The lamp is only for interior lighting of the
appliance. Do not use it for house lighting.
Care and cleaning
Warning! Risk of injury or damage to the
appliance.
• Before maintenance, deactivate the
appliance and disconnect the mains plug
from the mains socket.

9ENGLISH
• This appliance contains hydrocarbons in the
the maintenance and the recharging of the
unit.
• Regularly examine the drain of the
appliance and if necessary, clean it. If the
drain is blocked, defrosted water collects in
the bottom of the appliance.
Service
• To repair the appliance contact the
Authorised Service Centre listed at the end
of this manual.
• Use original spare parts only.
• Please note that self-repair or non-
professional repair can have safety
consequences and might void the
guarantee.
Proper disposal of your appliance
Warning! Risk of child entrapment.
problems of the past. Junked or abandoned
appliances are still dangerous – even if they will
sit for “just a few days”. If you are getting rid of
your old, please follow the instructions below to
help prevent accidents.
• Disconnect the appliance from the mains
supply.
• wer cord and discard it.
• Remove the door to prevent children and
pets to be closed inside of the appliance.
• The refrigerant circuit and the insulation
materials of this appliance are ozone-
friendly.
• gas. Contact your municipal authority for
information on how to discard the appliance
correctly.
• Do not cause damage to the part of the
cooling unit that is near the heat exchanger.
• We strongly encourage responsible
appliance recycling/disposal methods.
Check with your utility company or visit
www.energystar.gov/recycle for more
information on recycling your old unit.
CFC/HCFC Disposal
Your old refrigerator may have a cooling system
are believed to harm stratospheric ozone if
released to the atmosphere. Other refrigerants
may also cause harm to the environment if
released to the atmosphere.
If you are throwing away your old refrigerator,
make sure the refrigerant is removed for
you intentionally release refrigerant, you may
provisions of environmental legislation.
State of California Proposition 65 Warnings
Warning! This product can expose you
to chemicals including vinyl chloride,
which is known to the State of California
to cause cancer and birth defects or other
reproductive harm. For more information
go to www.P65Warnings.ca.gov.
Installation
Warning! Refer to Safety chapters.
Positioning
• Follow the separate Assembly Instructions to
install this appliance.
• This appliance should be installed in a dry,
well ventilated indoor.
• Do not install this appliance:
- Outdoors;
- In an environment with dripping water;
- In rooms where there is a risk of frost.
Location
• To ensure best performance, install the
appliance well away from sources of heat
such as radiators, boilers, direct sunlight
etc. Make sure that air can circulate freely
around the back of the cabinet.
• Leave a space of at least 3.94" between the
appliance and the wall, and at least 11.81"
between the top of the appliance and the
ceiling.
• Leave enough space to access and open the
door easily (W x D ≥50.20" × 53.15").

10ENGLISH
W
D
Levelling feet
If the appliance tilts in some way, adjust the
height of the left/right foot of the appliance to
be in a horizontal level. Refer to the separate
Assembly Instructions for detailed installation.
1. Disconnect the mains plug of the appliance
from the power socket.
2. Turn the foot clockwise to raise the
appliance; turn the foot counter clockwise to
lower the appliance.
Reversing doors (optional)
Based on the location of the appliance, you
may need to reverse the doors to allow for easy
access to the appliance contents.
A suitable screwdriver and/or wrench is needed
for door re-installation.
Refer to the separate Assembly Instructions for
detailed installation.
Installing distance holder
Warning! Serious or fatal crushing injuries
can occur from appliance tip-over. ALWAYS
secure this appliance to the wall using tip-
over restraints.
the appliance to the wall for the following
advantages. You must follow the separate
Assembly Instructions to correctly install this
distance holder/anti-tip bracket.
• Allow enough space for air circulation
between the appliance and the walls.
• Secure the appliance to the wall for tip-over
prevention.
Electrical connection
Caution! Any electrical work required to
install this appliance should be carried
person.
Warning! This appliance must be earthed.
Failure to follow these instructions can
The manufacturer declines any liability should
these safety measures not be observed.
First use
Cleaning the interior
time,wash the interior and all internal
accessories with lukewarm water and same
neutral soap so as to remove the typical smell of
a brand new product, then dry thoroughly.
Important! Do not use detergents or abrasive

11ENGLISH
Product description
Product overview
1
2
3
9
10
4
5
6
7
8
1Door gasket
2Door balconies
3Bottle balcony
4Door for freezer drawers
5Vegetable drawers
6Freezing-humidity control slider
7Glass shelves
8LED lamp and temperature control panel
9Upper freezer drawer
10 Lower freezer drawer
Least cold zone
Intermediate temperature zone
Coldest zone

12ENGLISH
Operation
Control panel
1 2 3 4 5
1
2Refrigerator temperature button
3Refrigerator temperature indicators
4Freezer temperature button
5Freezer temperature indicators
Switching on
Warning! Refer to "Electrical connection"
section of the Safety chapter.
• Connect the mains plug to the power socket.
The display on the control panel turns on.
The temperature indicators show the set
default temperatures for the refrigerator
and the freezer compartments respectively.
• To change temperature, refer to the section
for temperature regulation.
set the appliance at a colder temperature and
run it without loading any food until it auto
stops at the set temperature. Usually it takes
2 or 3 hours, then set a desired temperature and
put food in the appliance.
• T
the 1seconds. The
• To switch the appliance on, press and hold
the 1seconds
To disconnect the appliance from the power
supply, disconnect the mains plug from the
power socket.
Temperature regulation for refrigerator
compartment
• Press the 2Refrigerator temperature
button to toggle the 3refrigerator
46˚F (8˚C)39˚F (4˚C) 36˚F (2˚C)
• One ( ) on indicates 46°F (8°C) is set.
• Two ( ) on indicate 39°F (4°C) is set.
• Three ( ) on indicate 36°F (2°C) is
set.
Temperature regulation for freezer
compartment
• Press the 4Freezer temperature button
to toggle the 5freezer temperature
temperatures.
3˚F (-16˚C)-2˚F (-19˚C)-11˚F (-24˚C)
• One ( ) on indicates 3°F (-16°C) is set.
• Two ( ) on indicate -2°F (-19°C) is set.
• Three ( ) on indicate -11°F (-24°C)
is set.

13ENGLISH
Adjust the temperature setting by keeping in
mind that the temperature inside the appliance
depends on:
• room temperature
• how often the door is opened
• the quantity of food stored
• the location of the appliance
Important! If the ambient temperature is
high or the appliance is fully loaded, and the
appliance is set to the lowest temperatures, it
may run continuously causing frost to form on
the rear wall. In this case a higher temperature
must be set to allow automatic defrosting and
therefore reduced energy consumption.
Deactivate/activate freezing function
The freezing-humidity control is available on the
rear wall of the refrigerator compartment.
You can deactivate or activate freezing function
in the freezer compartment.
Freezing-humidity
control slider
• To deactivate the freezing function, adjust
the freezing-humidity control slider to the
right end.
• To activate the freezing function, adjust the
freezing-humidity control slider to the left
end.
When the freezing function is deactivated,
you can use the freezer compartment for
food refrigeration.
Humidity adjustment
You can use the freezing-humidity control
slider to adjust humidity inside the refrigerator
compartment.
Freezing-humidity
control slider
Door open alarm
If the door of the appliance is left open for two
minutes, the buzzer will sound continuously
close the door or press the 1
Connect to an ice maker
• The appliance is equipped with an ice maker
connector through which you can connect
an ice maker (not included).
• To purchase an ice maker, contact the
Authorised Service Centre listed at the end
of this manual.

14ENGLISH
Daily use
Freezing calendar
1-2
10-12
3-4
10-12
3-6
10-12
3-6
10-12
3-6
• The symbols sho
goods.
• The numbers indicate storage times in
months for the appropriate types of frozen
goods. Whether the upper or lower value of
the indicated storage time is valid depends
on the quality of the foods and treating
before freezing.
Freezing fresh food
To freeze food in the freezer compartment,
make sure the freezing function is
activated. Refer to "Deactivate/activate
freezing function" section.
• The freezer compartment is suitable for
freezing fresh food and storing frozen and
deep-frozen food for a long time.
• The freezing process lasts 24 hours: during
this period do not add other food to be
frozen.
Storage of frozen food
•
of use, before putting the products in the
compartment let the appliance run at least
2 hours on the colder setting.
• Successful freezing depends on the correct
packaging. When you close and seal the
package you must not allow air or moisture
in or out. If you do, you could have food
odour and taste transfer throughout the
refrigerator, and also dry out frozen food.
•Note: Never put bottled food or drinks in
the freezer compartment.
• For best performance, leave enough
space in the freezer compartment for air
to circulate around the packages. Also let
enough room at the front so the door can
close tightly.
Warning! In the event of accidental
defrosting, for example due to a power
failure, the defrosted food must be
consumed quickly or cooked immediately,
cooled and then re-frozen.
Thawing
Deep-frozen or frozen food, prior to being used,
can be thawed in the refrigerator compartment
or at room temperature, depending on the time
available for this operation.
Small pieces may even be cooked still frozen,
directly from the freezer: in this case, cooking
will take longer.
Storage of food in the refrigerator
compartment
• Cover or wrap the food, particularly if it has
• Position the food so that air can circulate
freely around it.
• For best performance, leave enough space
in the refrigerator compartment for air
to circulate around the packages. Also let
enough room at the front so the door can
close tightly.
Positioning the door balconies
Picture for reference only
1
1
2
• To permit storage of food packages of
various sizes, the door balconies can be
• To remove the door balcony, compress on
both sides of the door balcony then pull it
upward to remove.

15ENGLISH
Movable shelves
• The walls of the refrigerator are equipped
with a series of runners so that the safety
glass shelves can be positioned as desired.
• To remove a glass shelf, lift it up then pull
it out.
Caution! Donot move the glass shelf above
thevegetable drawer to ensure correct air
circulation.
Vegetable drawer
1
2
• The drawers are suitable for storing fruit
and vegetables.
• To remove a drawer, pull it towards yourself
until reaching the end point then tilt its front
upwards to remove.
• To clean the grooves in which the drawer
rollers sit, remove the roller (after removing
the drawer) in the arrow direction as shown
accessible for cleaning.
Roller
Groove
Hints and tips
Normal operating sounds
The following sounds are normal during
operation:
• A faint gurgling and bubbling sound from
coils sound when refrigerant is pumped.
• A whirring and pulsating sound from the
compressor when refrigerant is pumped.
• A sudden cracking noise from inside
appliance caused by thermic dilatation
(a natural and not dangerous physical
phenomenon).
Hints for energy saving
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• If the ambient temperature is high and very
low internal temperature is set and the
appliance is fully loaded, the compressor
may run continuously, causing frost or ice
on the evaporator. If this happens, set the
internal temperature toward warmer one to
allow automatic defrosting and so a saving
in electricity consumption.
Hints for fresh food refrigeration
• Do not store warm food or evaporating
liquids in the refrigerator.
• Cover or wrap the food, particularly if it has
• Position food so that air can circulate freely
around it.
Hints for refrigeration
Useful hints:
• Meat (all types): wrap in a suitable
packaging and place it on the glass shelf
above the vegetable drawer. Store meat for
at most 1-2 days.

16ENGLISH
• Cooked foods, cold dishes: cover and place
on any shelf.
• Fruit and vegetables: clean thoroughly and
place in a special drawer. Bananas, potatoes,
onions and garlic must not be kept in the
refrigerator if not packed.
• Butter and cheese: place in a special airtight
container or wrap in an aluminium foil or
a polythene bag to exclude as much air as
possible.
• Bottles: close with a cap and place on the
door bottle shelf, or (if available) on the
bottle rack.
Cautions for Use
• The mor
the longer for once the door is opened, the
more it needs electric consumption, which
even leads malfunction.
• Re-plug in the power plug at the interval of
over ten minutes.
• Do not store bottled drink in the freezer,
so as to prevent from being broken and
damaging the refrigerator.
• Open the door as less as possible during
power-cut.
• When defrosting, never use any sharp or
metallic objects to remove the frost on the
surface of the evaporator as it will damage
the evaporator.
• Do not touch foods and containers in the
freezing compartment with your wet hands
so as to prevent from being frostbitten.
Hints for freezing
To help you make the most of the freezing
process, here are some important hints:
• The freezing process takes 24 hours. No
further food to be frozen should be added
during this period.
• Freeze only top quality, fresh and
• Prepare food in small portions to enable it
to be rapidly and completely frozen and to
make it possible subsequently to thaw only
the quantity required.
• Wrap up the food in aluminium foil or
polythene and make sure that the packages
are airtight.
• Do not allow fresh, unfrozen food to touch
food which is already frozen, thus avoiding a
rise in temperature of the latter.
• Lean foods store better and longer than
fatty ones; salt reduces the storage life of
food.
• Water ices, if consumed immediately after
removal from the freezer compartment, can
possibly cause the skin to be freeze burnt.
• It is advisable to show the freezing in date
on each individual pack to enable you to
keep tab of the storage time.
Hints for storage of frozen food
To obtain the best performance from this
appliance, you should:
• Make sure that the commercially frozen
retailer.
• Make sur
transferred from the food store to the
freezer in the shortest possible time.
• Do not open the door frequently or leave it
open longer than absolutely necessary.
• Once defrosted, food deteriorates rapidly
and cannot be refrozen;
• Do not exceed the storage period indicated
by the food manufacturer.
Care and cleaning
Warning! Refer to Safety chapters.
General warnings
Caution! Unplug the appliance before
carrying out any maintenance operation.
This appliance contains hydrocarbons in its
cooling unit; maintenance and recharging
must therefore only be carried out by
authorized technicians.
The accessories and parts of the
appliance are not suitable for washing in a
dishwasher.
Cleaning the interior
interior and all internal accessories should be
washed with lukewarm water and some neutral
soap to remove the typical smell of a brand-new
product, then dried thoroughly.

17ENGLISH
Caution! Do not use detergents or
abrasive powders, as these will damage
Initial power on
Caution! Before inserting the power
plug in to the outlet and switching on
appliance standing upright for at least
4
amount of time for the oil to return to the
compressor. Otherwise the compressor
or electronic components may sustain
damage.
Periodic cleaning
Caution! Do not pull, move or damage any
pipes and/orcables inside thecabinet.
Caution! Do not damage the cooling
system.
Caution! When moving the cabinet, lift it
by the front edge to avoid scratching the
The equipment has to be cleaned regularly:
1. Clean the inside and accessories with
lukewarm water and some neutral soap.
2. Regularly check the door seals and wipe
clean to ensure they are clean and free from
debris.
3. Rinse and dry thoroughly.
4. If accessible, clean the condenser and the
compressor at the back of the appliance
with a brush. This operation will improve
the performance of the appliance and save
electricity consumption.
Periods of non-operation
When the appliance is not in use for long
periods, take the following precautions:
1. Disconnect the appliance from electricity
supply.
2. Remove all food.
3. Defrost (if necessary) and clean the
appliance and all accessories.
4. Clean the appliance and all accessories.
5. Leave the door/doors open to prevent
unpleasant smells.
Caution! If you want to keep the appliance
switched on, ask somebody to check it
once in a while to prevent the food inside
from spoiling in case of a power failure.
Defrosting refrigerator compartment
Frost is automatically eliminated from the
evaporator of the refrigerator compartment
every time the motor compressor stops,
during normal use. The defrost water drains
out through a trough into a special container
at the back of the appliance, over the motor
compressor, where it evaporates.
It is important to periodically clean the defrost
water drain hole at the back of the refrigerator
and dripping onto the food inside.
For this purpose use the tube cleaner provided
in the accessory bag.
Defrosting freezer compartment
The freezer compartment has automatic
defrosting function.
Due to seasonal changes, a thick layer of frost
may form. To defrost manually, observe the
followings.
• Disconnect the appliance from the power
supply, and leave open the freezer door.
• Remove all foods, ice cube tray and shelf or
transfer to refrigerator compartment.
• Clean and wipe out the melted frost with a
cloth.
• After defrosting, connect the appliance to
the power supply.
Caution! To avoid damaging the freezer
compartment wall, do not use any sharp
objects to remove the frost or separate the
frozen food.

18ENGLISH
Troubleshooting
Warning! Refer to Safety chapters.
What to do if...
Problem Possible Cause Solution
The appliance does not operate.
Switch on the appliance.
The mains plug is not connected to the
mains socket correctly.
Connect the mains plug to the
mains socket correctly. Refer to
"Electrical connection" section of
the safety chapter.
There is no voltage in the mains socket. appliance to the mains socket.
The appliance is noisy. The appliance is not placed stably.
Level the feet of the appliance
to stabilize it. Refer to "Levelling
feet", or the separate Assembly
Instructions.
The lamp does not work. The lamp is defective. Refer to “Replacing the lamp”.
The freezer compartment cannot
freeze food. Freezing function is deactivated.
Activate freezing function. Refer
to "Deactivate/activate freezing
function".
The compressor operates
continually.
Temperature is set incorrectly. Refer to “Operation” chapter.
Many food products were inserted at the
same time.
Wait some hours and then check
the temperature again.
The room temperature is too high. Refer to climate class chart on the
rating plate.
Food products placed in the appliance
were too warm.
Allow food products to cool to
room temperature before storing.
The door is not closed correctly. Refer to “Closing the door”.
The temperature in the appliance
is too low/too high.
The temperature is not set correctly. Set a higher/lower temperature.
The door is not closed correctly. Refer to “Closing the door”.
The food products temperature is too
high.
Let the food products temperature
decrease to room temperature
before storage.
Many food products are inserted at the
same time.
Insert less food products at the
same time.
The thickness of the frost is greater than
0.16"-0.20". Defrost the appliance.
The door has been opened often. Open the door only if necessary.
There is no cold air circulation in the
appliance.
Make sure that there is cold air
circulation in the appliance.

19ENGLISH
Problem Possible Cause Solution
There is too much condensed
water on the rear wall of the
refrigerator.
Door was opened too frequently. Open the door only when
necessary.
Door was not closed completely. Make sure the door is closed
completely.
Stored food was not wrapped. Wrap food in suitable packaging
before storing it in the appliance.
refrigerator.
The drain hole at the back of the
appliance is clogged.
Clean the drain hole with a piece
of wire.
Food products prevent water from Make sure that food products do
not touch the rear plate.
The door is not closed well.
Refer to "Closing the door", or
refer to the troubleshooting item
below ("The door does not close
completely").
The appliance tilts forward.
Tilt the appliance slightly backward
(a quarter-inch lower in the back).
Refer to the separate Assembly
Instructions for appliance level
adjustment.
The drip pan cracks. Contact Authorised Service Centre
listed at the end of this manual.
The defrost water drain is clogged. Clean the drain hole with a piece
of wire.
The door does not close
completely.
The shelves are out of position.
Make sure the shelves are in
correct position. Refer to "Movable
shelves".
The door gaskets are dirty. Clean the door gaskets. Refer to
"Care and cleaning".
The appliance is not level.
Make sure the appliances
is installed in level. Refer to
"Levelling feet", or the separate
Assembly Instructions.
Malfunction alarm
If the appliance malfunctions, the LED indicators
fault and the buzzer will sound. To switch the
1button on the
control panel.
• and Temperature sensor failure
of the refrigerator chamber
• and Temperature sensor failure
of the freezer chamber
• and Defrosting sensor failure of
the freezer chamber
• and Communication failure
• and Failure of ambient
temperature sensor
If your appliance still is not working
properly after making the above checks,
contact the Authorised Service Centre. You
Closing the door
1. Clean the door gaskets.
2. If necessary, adjust the door. Refer to the
separate Assembly Instructions.
3. If necessary, replace the defective door
gaskets. Contact the After Sales Service.

20ENGLISH
Replacing the lamp
The appliance is equipped with a lamp for
interior lighting.
Only service is allowed to replace the lighting
device. Contact your Authorised Service Centre.
For quick solution, always refer to the full list
of Authorised Service Centre located at the
end of this manual and call your relative phone
number.
Technical information
Product category
Product type Refrigerator
Installation type Freestanding
Product dimensions
Height 66.61"
Width 29.53"
Depth 30.91"
Net volume
Fridge 13.07 cu.ft.
Freezer 5.62 cu.ft.
Defrost system
Fridge auto
Freezer auto
Energy consumption 466 kWh/y
Noise level 43 dB
Energy class E-star
Voltage 115 V
Frequency 60 Hz
Picture for reference only
XXX.XXX.XX
Article Number
(8-digitcode)
Serial Number (start
with SN, 22-digit code)
The article number and the serial number
are situated in the rating plate on the
internal left side of the appliance.
