IKEA Rytmisk User manual

AA-2118952-1
© Inter IKEA Systems B.V. 2019 23199
991.0xxx.xxx_01 - 190116
D0000xxxx_00

ENGLISH 4
4
2
1345
Please refer to the last
page of this manual for the
full list of IKEA appointed
Authorized Service Centre
and relative national phone
number
2
1345

4 ENGLISH
For your safety and correct operation of the appliance,
read this manual carefully before installation and use.
Always keep these instructions with the appliance even if
you move or sell it. Users must fully know the operation
and safety features of the appliance.
The wire connection has to be done by specialized
technician.
• The manufacturer will not be held liable for any
damages resulting from incorrect or improper
installation.
• The minimum safety distance between the cooker top
and the extractor hood is: for electrical hob 500mm and
for gas hob 650mm.
• If the instructions for installation for the gas hob specify
a greater distance, this must be respected.
• Check that the mains voltage corresponds to that
indicated on the rating plate fixed to the inside of the
hood.
• Means for disconnection must be incorporated in the
fixed wiring in accordance with the wiring rules.
• For Class I appliances, check that the domestic power
supply guarantees adequate earthing.
• Connect the extractor to the exhaust flue through a pipe
of minimum diameter 120 mm. The route of the flue
must be as short as possible.
• Do not connect the extractor hood to exhaust ducts
Contents
Safety information 4
Product description 8
Care and cleaning 9
What to do if... 11
Technical Data 12
Energy efficiency 13
Environment concerns 14
IKEA GUARANTEE 14
Safety information

5 ENGLISH
carrying combustion fumes (boilers, fireplaces, etc.).
• If the extractor is used in conjunction with non-electrical
appliances (e.g. gas burning appliances), a sufficient
degree of aeration must be guaranteed in the room in
order to prevent the backflow of exhaust gas. When
the cooker hood is used in conjunction with appliances
supplied with energy other than electric, the negative
pressure in the room must not exceed 0,04 mbar to
prevent fumes being drawn back into the room by the
cooker hood.
• The air must not be discharged into a flue that is used
for exhausting fumes from appliances burning gas or
other fuels.
• If the supply cord is damaged, it must be replaced from
the manufacturer or its service agent.
• Connect the plug to a socket complying with current
regulations, located in an accessible place.
• With regards to the technical and safety measures to
be adopted for fume discharging it is importat to closely
follow the regulations provided by the local authorities.
WARNING: Before installing the Hood, remove the
protective films.
• Use only screws and small parts in support of the hood.
WARNING: Failure to install the screws or fixing
device in accordance with these instructions may
result in electrical hazards.
• Connect the hood to the power net by using a bipolar
switch having a contact gap of at least 3 mm.
• Do not look directly at the light through optical devices
(binoculars, magnifying glasses…).
• Do not flambè under the range hood; risk of fire.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,

6 ENGLISH
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
• Children should be supervised to ensure that they do
not play with the appliance.
• The appliance is not to be used by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
Accessible parts may become hot when used with
cooking appliances.
• Clean and/or replace the Filters after the specified time
period (Fire hazard).
• There shall be adequate ventilation of the room when
the range hood is used at the same time as appliances
burning gas or other fuels (not applicable to appliances
that only discharge the air back into the room).

7 ENGLISH
Use
• Switch off or unplug the appliance
from the mains supply before
carrying out any maintenance
work.
• The top of the hood must not to be
used as a shelf.
• The extractor hood has been
designed exclusively for domestic
use to eliminate kitchen smells.
• Never use the hood for purposes
other than for which it has been
designed.
• Never leave high naked flames
under the hood when it is in
operation.
• Adjust the flame intensity to direct
it onto the bottom of the pan
only, making sure that it does not
engulf the sides.
Deep fat fryers must be continuously
monitored during use: overheated oil
can burst into flames.
Installation modes
The hood has been designed to be
installed and used either as a “Exhaust
mode”, or as a “Recirculation mode”.
9
min 471 mm
max 861 mm
min 569 mm
max 861 mm
min 471 mm
max 861 mm
min 569 mm
max 861 mm
Exhaust mode (see symbol
in installation booklet)
Cooking steam is sucked and
channelled outside the house
through a discharge duct (not
supplied), fitted to the hood steam
outlet.
Ensure that the discharge duct is
correctly fitted to the air outlet, unit
using an appropriate connection
system.
9
min 471 mm
max 861 mm
min 569 mm
max 861 mm
min 471 mm
max 861 mm
min 569 mm
max 861 mm
Recirculation mode (see
symbol in installation booklet)
The air is filtered through one or
more the charcoal filters, and then
resent into room.
Important: Ensure appropriate air
circulation around the hood.
Important: If the hood is supplied
without charcoal filters and installed
on recirculation mode, these must be
fitted before the hood can be used.
Filters are available in shops.
The hood should be installed away
from particularly dirty areas,
windows, doors and heat sources.
The accessories for wall fixing are
not included because wall made of
different materials require different
types of fixing accessories. Use
fixing systems suitable for the walls
of your home and the weight of the
appliance. For more details, contact
a specialized dealer.
Keep this booklet for future
consultation.

8 ENGLISH
Product description
Upper Chimney
Lower Chimney
Hood body
LED Lighting
Grease filters
Control Pannel
Lights
To turn the lights
on, press the dial
and release it so
that it pops out of
its housing.
To turn the lights
o, push the dial
back inwards,
returning it to the
o position.
Motor
Speed
Adjustment
Press the dial and
release it so that
it pops out of its
housing, then turn
the dial to select
one of the available
suction speeds.
Control Panel

9 ENGLISH
Care and cleaning
Switch off or unplug the appliance
from the mains supply before carrying
out any maintenance work.
IMPORTANT Clean the hood using a
damp cloth and a neutral liquid deter-
gent.
Long Life Charcoal Filter
The anti-odour filter can be washed and
regenerated every 3-4 months (or more
frequently if the hood is subject to inten-
sive use), up to a Max. of 8 regeneration
cycles (in case of particularly intensive
use it is recommended that you do not
exceed 5 cycles).
General hints
Regeneration procedure:
• Wash in the dishwasher at a MAX
temperature of 70° or hand wash
in hot water without using abrasive
sponges (do not use detergents!).
• Dry in the oven at a MAX
temperature of 70° for 2 hours (it
is recommended to read carefully
the user manual and the assembly
instruction of the oven of your own).
• Switch ON the hood at minimum speed when you start cooking and keep it run-
ning for few minutes after cooking is finished.
• Increase the speed only in case of large amount of smoke and vapour and use
boost speed(s) only in extreme situations.
• Replace the charcoal filter(s) when necessary to maintain a good odour reduction
efficiency.
• Clean the grease filter(s) when necessary to maintain a good grease filter ef-
ficiency.
• Use the maximum diameter of the ducting system indicated in this manual to
optimize efficiency and minimize noise.

10 ENGLISH
Grease Filters
Clean or replace the filters continuously
according to below time intervals, to
maintain good performance of the hood
and to prevent a potential fire hazard,
caused by excessive grease build-up.
The grease filters must be cleaned
every 2 months of operation, or more
frequently for particularly heavy usage,
and can be washed in a dishwasher.
[
Replacing the lamps
For Replacement please contact an Au-
thorized Service Center.

11 ENGLISH
What to do if...
If there is a fault, first try to find a
solution to the problem yourself. If you
cannot find a solution to the problem
yourself, contact an authorized service
center.
If you operated the appliance
wrongly, or the installation was not
carried out according to the Assembly
instructions, the visit from the Author-
ized Service Centre technician may not
take place free of charge, even during
the warranty period.
Before contacting the Authorized Service Centre:
Switch the appliance on again to see if the problem has disappeared. If not, switch
it off again and repeat the operation after an hour.
If your appliance still does not work properly after carrying out the checks listed in
the troubleshooting guide and switching the appliance on again, contact the Author-
ized Service Centre, clearly explaining the problem and specifying:
• the type of fault;
• the model;
• the type and serial number of the appliance (given on the rating plate).
PROBLEM POSSIBLE CAUSE SOLUTION
Appliance not stable The appliance is not correctly
installed Follow the Installation instruction enclosed to the appliance.
Appliance is not in horizontal
position The appliance is not correctly installed Follow the Installation instruction enclosed to the appliance.
Performance in terms of oil
capture are not satisfying Oil and grease on metal filters or charcoal filters.
Follow the cleaning frequency of
filters as described in the user
manual
Appliance does not work The appliance is not correctly
connected
Verify that the main cable is con-
nected to the motor group or the
plug is connected to the socket
The light does not work The LED is broken You can replace the lamp without contact the Authorized Service
Centre.
Noise of hood is higher than
customer expectation.
Air outlet diameter in the wall is
too small, causing a pressure drop
and an increase in motor speed.
Follow the Installation instruction
enclosed to the appliance.
Product is installed in recirculation
mode.
Product in recirculation mode(and
using a charcoal filter) will generate
an higher noise than a product in
extration mode.
More than one bend in the venti-
lation duct.
If the exhaust system in the build-
ing has multiple bend in or a long
distance, this can increase the noise
of the product.

12 ENGLISH
Technical Data
This appliance has been designed,
manufactured and marketed in
compliance with the E.E.C. Directives.
The technical information is situated in
the rating plate on the internal side of
the appliance.
* Maximum speed (boost excluded).
Unit Value
Product Type Wall mounted hood
Dimensions
Width mm 898
Depth mm 471
Exhaust Height min/max mm 630/995
Recirculating Height min/max mm 715/995
Airow max* - Exhaust m3/h 400
Noise max* - Exhaust dBA 65
Airow max* - Recirculating m3/h 190
Noise max* - Recirculating dBA 70
Total Power W116
Lamps info
Type LED BAR
Number & Power 2 x 3W
Socket N/A
Installation minimum height - gas hob mm 650
Installation minimum height - elec hob mm 500
Net Weight Kg 8,3

13 ENGLISH
Energy efficiency
Normative references:
EN/IEC 61591
EN/IEC 60704-1
EN/IEC 60704-2-13
EN/IEC 60704-3
EN 50564
Energy saving
The appliance contains features which
help you save energy during everyday
cooking.
Product Information according
to EU n°66/2014 Unit Value
Model identifier
RYTMISK
904.432.15
204.432.14
Annual Energy Consumption kWh/a 39,5
Time increase factor 1,3
Fluid Dynamic Eciency 18,2
Energy Eciency Index 66,6
Measured air ow rate at best eciency point m3/h 223,0
Measured air pressure at best eciency point Pa 217
Maximum air ow m3/h 400,0
Measured electric power input at best eciency
point W 74,0
Nominal power of the lighting system W 6,0
Average illumination of the lighting system on
the cooking surface lux 220
Measured power consumption in standby mode W N/A
Measured power consumption o mode W 0,00
Sound power level at maximum speed (boost
excluded) dBA 65

14 ENGLISH
Environment concerns
IKEA GUARANTEE
Maintenance
• The symbol on the product
or on its packaging indicates that
this product may not be treated as
household waste. Instead it shall
be handed over to the applicable
collection point for the recycling of
electrical and electronic equipment.
By ensuring this product is disposed
of correctly, you will help prevent
potential negative consequences for
the environment and human health,
which could otherwise be caused
by inappropriate waste handling
of this product. For more detailed
How long is the IKEA guarantee
valid?
This guarantee is valid for five (5)
years – two (2) years if the appliance
is named LAGAN or TILLREDA - from
the original date of purchase of your
appliance at IKEA or from the installa-
tion date with maximum limit of three
months from the purchase date.
The original sales receipt, is required as
proof of purchase.
If service work is carried out under
guarantee, this will not extend the guar-
antee period for the appliance.
Once a warranted product has been
replaced, the replaced product warranty
will be valid for the balance period from
date of original purchase invoice
Who will execute the service?
IKEA service provider will provide the
service through its own service op-
erations or authorized service partner
network.
information about recycling of this
product, please contact your local
city office, your household waste
disposal service or the shop where
you purchased the product.
Packaging materials
The materials with the symbol are
recyclable. Dispose the packaging in
suitable collection containers to recycle
it.
What does this guarantee cover?
• The guarantee covers faults of the
appliance, which have been caused
by faulty construction or material
faults from the date of purchase from
IKEA or from the installation date with
maximum limit of three months from
the purchase date.
• This guarantee applies to domestic
use only.
• The exceptions are specified under
the headline “What is not covered
under this guarantee?” Within the
guarantee period,
• The costs to remedy the fault e.g. re-
pairs, parts, labour and travel will be
covered, provided that the appliance
is accessible for repair without special
expenditure. On these conditions the
respective local regulations are ap-
plicable.
• Replaced parts become the property
of IKEA.
• In case of non-repairable product, the
retail value of the replacement will not

15 ENGLISH
exceed the purchase price that was
paid by the customer
What will IKEA do to correct the
problem?
• IKEA appointed Service Provider will
examine the product and decide,
at its sole discretion, if it is covered
under this guarantee. If considered
covered, IKEA Service Provider or its
authorized service partner through
its own service operations, will then,
at its sole discretion, either repair the
defective product or replace it with
the same or a comparable product.
What is not covered under this
guarantee?
• Normal wear and tear.
• Deliberate or negligent damage,
damage caused by failure to observe
operating instructions, incorrect instal-
lation or by connection to the wrong
voltage, damage caused by chemi-
cal or electrochemical reaction, rust,
corrosion or water damage including
but not limited to damage caused by
excessive lime in the water supply,
damage caused by abnormal environ-
mental conditions.
• Consumable parts including batteries
and lamps.
• Non-functional and decorative parts
which do not affect normal use of the
appliance, including any scratches and
possible colour differences.
• Accidental damage caused by foreign
objects or substances and cleaning or
unblocking of filters, drainage systems
or soap drawers.
• Damage to the following parts: ce-
ramic glass, accessories, crockery and
cutlery baskets, feed and drainage
pipes, seals, lamps and lamp covers,
screens, knobs, casings and parts of
casings. Unless such damages can
be proved to have been caused by
production faults.
• Cases where no fault could be found
during a technician’s visit.
• Repairs not carried out by our ap-
pointed service providers and/or an
authorized service contractual partner
or where non-original parts have been
used.
• Repairs caused by installation which is
faulty or not according to specification
• The use of the appliance in a non-do-
mestic environment i.e. professional
use.
• Transportation damages. If a cus-
tomer transports the product to his
home or another address, IKEA is not
liable for any damage that may occur
during transport. However, if IKEA
delivers the product to the customer’s
delivery address, then damage to the
product that occurs during this deliv-
ery will be covered by IKEA.
• Damage resulting from power outage,
power surges or dips, fluctuating volt-
age or improper voltage All workout
parts are not covered by the guaran-
tee e.g.: filters and cleanliness.
• Cost for carrying out the initial instal-
lation of the IKEA appliance. However,
if an IKEA appointed Service Pro-
vider or its authorized service partner
repairs or replaces the appliance
under the terms of this guarantee, the
appointed Service Provider or its au-
thorized service partner will reinstall
the repaired appliance or install the
replacement, if necessary.
• All plumping and electrical installation,
are not the responsibility of IKEA, and
customer must complete these work
before the execution work.

16 ENGLISH
How country law applies
The IKEA guarantee gives you specific
legal rights, which cover or exceed
all the local legal demands. However
these conditions do not limit in any way
consumer rights described in the local
legislation.
Area of validity
This warranty is valid only in the country
where the product has been purchased;
the services will be provided in the
framework of the guarantee conditions.
An obligation to carry out services in the
framework of the guarantee exists only
if the appliance complies and is installed
in accordance with:
- the technical specifications of the
country in which the guarantee claim
is made;
- the Assembly Instructions and User
Manual Safety Information.
The dedicated AFTER SALES for
IKEA appliances
Please don’t hesitate to contact IKEA
appointed After Sales Service Provider
to:
• make a service request under this
guarantee;
• ask for clarifications on installation of
the IKEA appliance in the dedicated
IKEA kitchen furniture;
• ask for clarification on functions of
IKEA appliances.
To ensure that we provide you with the
best assistance, please read carefully
the Assembly Instructions and/or the
User Manual before contacting us.
How to reach us if You need our
service
Please refer to the last page of this
manual for the full list of IKEA appointed
contacts and relative national phone
numbers.
In order to provide you a quicker
service, we recommend to use the
specific phone numbers listed on
this manual. Always refer to the
numbers listed in the booklet of the
specific appliance you need an as-
sistance for.
Please also always refer to the
IKEA article number (8 digit code)
placed on the rating plate of your
appliance.
SAVE THE SALES RECEIPT!
It is your proof of purchase and required
for the guarantee to apply. The sales
receipt also reports the IKEA name and
article number (8 digit code) for each of
the appliances you have purchased.
UNITED ARAB EMIRATES
Toll free:
Web:
800 4532
www.IKEA.com
: 
: 
QATAR
Toll free:
Web:
e-mail:
800 4532
www.IKEA.qa
[e-mail]
: 
: 
: 
EGYPT
Hotline:
Web:
e-mail:
16576
www.IKEA.eg
[e-mail]
: 
: 
: 
STATE OF KUWAIT
Contact centre:
Web:
e-mail:
[phone]
www.IKEA.com.kw
[email protected]om.kw
: 
: 
: 
JORDAN
Contact centre:
Web:
[phone]
www.IKEA.jo
: 
: 
KINGDOM OF SAUDI ARABIA
Contact centre:
Our phone lines are open:
Saturday - Thursday
Friday
92000-4532
09:00 AM - 10:00 PM
2:00 PM - 10:00 PM
: 
: 


BAHRAIN
Contact centre:
Our telephone lines are open
all day
80001120
09:00 AM - 10:00 PM
: 


UNITED ARAB EMIRATES
Toll free:
Web:
800 4532
www.IKEA.com
: 
: 
QATAR
Toll free:
Web:
e-mail:
800 4532
www.IKEA.qa
[e-mail]
: 
: 
: 
EGYPT
Hotline:
Web:
e-mail:
16576
www.IKEA.eg
IkeaCairo.customerser[email protected]om
: 
: 
: 
STATE OF KUWAIT
Contact centre:
Web:
e-mail:
[phone]
www.IKEA.com.kw
[email protected]
: 
: 
: 
JORDAN
Contact centre:
Web:
[phone]
www.IKEA.jo
: 
: 
KINGDOM OF SAUDI ARABIA
Contact centre:
Our phone lines are open:
Saturday - Thursday
Friday
92000-4532
09:00 AM - 10:00 PM
2:00 PM - 10:00 PM
: 
: 


BAHRAIN
Contact centre:
Our telephone lines are open
all day
80001120
09:00 AM - 10:00 PM
: 


16
ةيبرعلا

15
ةيبرعلا
