iLight SCMR1232 User manual

Mounting & Installation Technical Data
Typical Schematic
Electrical & Mechanical
Control: Via iLight network connection
iCANnet™ output current: 100mA Max @ nominal 15V
Rating: 32A* per channel @ 40ºC
Protection: Provided by installer
Output channel current: Maximum 12 x 32A*
(Total unit load not to exceed 192A)
Note: Fully loaded channels should be spaced every other channel to prevent heat buildup
Relay outputs: Volt free capable of switching inductive and resistive loads
Terminal Sizes: Loads - maximum cable size: 1 x 10mm2per circuit
Ambient temperature: 2°C – 40°C
Relative humidity: 5% - 95% max, non-condensing
IP rating: IP20
Installation: Installation must be carried out by a suitably qualied electrician and installed
in a suitable DINrail enclosure.
Dimensions: 212mm (w) x 90mm (h) x 58mm (d)
Weight: 0.8kg
Software
For programming SCMR1232, Device Editor V2.11.1 is required
(Packaged with iCANsoft V3.1.7 or later)
* 32A resistive per channel @ 400C - 20A capacitive per channel @ 400C
SCMR1232
12 x 32A Relay Controller
Doc No: 9850-000782-03
SCMR1232 must be mounted in a suitable enclosure to provide regulatory
protection from electric shock hazard as well as protecting the iCANnet
data network from tampering that could lead to reduced network security.
Ensure selected enclosure provides adequate cooling ventilation.
Fixing to DIN rail
1. Fix top clips over DIN rail.
2. Pull down bottom clip using screwdriver.
3. Close module towards DIN rail.
4. Push up bottom clip to x securely to DIN rail.
Removing from DIN rail
1. Pull down bottom clip with screwdriver.
2. Lift module away from DIN rail.
1
2
3
4
1
2
E&OE. iLight reserve the right to make
changes to the equipment without
prior notice.
© Signify Holding
iLight
Usk House, Lakeside
Llantarnam Park,
Cwmbran,
NP44 3HD, UK
t: [phone]
e: [email protected]
www. iLight.co.uk
EU Authorised Representative
Cooper Lighting Netherlands B.V.
High Tech Campus
HTC 48
Eindhoven
5656 AE
Installation Guide
Dimensions
90mm
212mm
SCMR1232 Control Plate Network Sensor
Control Plate
iCANnet

99850-000782-03. E&OE.
Status LED
Green LED ashes – device OK
Data LED
Red LED ashes when messages sent on network.
Alarm LED
Red LED solid on for local initiated alarm
Red LED ashes for network initiated alarm
RS485 / DMX LED
Green LED ashes when DMX or RS485 messages are sent or
received
Device Identication
Press and release switch.
Sending a message to identify the device on the network
(red Data LED ashes).
Device LEDs and Buttons
Typical Connection Diagram
SCMR1232
12 x 32A Relay Controller
230V
N
L
DMX Start Address
1 - 512
To set non-sequential
channel addresses,
use iCANsoft and set
rotary encoders to start
address: 0-0-0
RS485 / DMX
termination
RS485 / DMX
Connection
Incoming Supply
Supply: 100-230V 50Hz 0.33A MAX
0.33A MAX
Auxilary Volt Free Contacts
2 x Volt free inputs
iLight Network
Termination
Connection
to the iLight
Network
DALI IN
Device
Identication
Switch
32A Max
Function iCANnet Cable Colours
0V Black
CAN L Blue
Shield Silver
CAN H White
+VDC Red
Maximum segment distance: 500m (1640 ft)
Devices per segment: 100 (without bridge or repeater)
Consult iLight for information on alternative cable types.
IMPORTANT NOTE: Connecting a mains potential cable to the
iCAN Network terminals is likley to damage the unit and other
devices connected, and invalidate warranty.
iCAN Network Connections
IMPORTANT NOTE: Connecting a mains potential cable to the
iCAN Network terminals is likley to damage the unit and other
devices connected, and invalidate warranty.
