iLive ISP209B User manual
USER’S GUIDE
V:1531-0913-10
For the most up-to-date version of this User’s Guide, go to www.ilive.net
ISP209B
Portable Speaker for iPod and iPhone
2
• WARNING:Lithium batteries, like all rechargeable
batteries are recyclable and should be recycled or
disposed of in normal household waste. Contact your
local government for disposal or recycling practices in
your area. They should never be incinerated since they
might explode.
• WARNING: Shock hazard - Do Not Open.
• AVIS: RISQUE DE CHOC ÉLECTRIQUE - NE PAS
OUVRIR
Mains plug is used as disconnect device and it should
remain readily operable during intended use. In order
to disconnect the apparatus from the mains completely,
the mains plug should be disconnected from the mains
socket outlet completely.
La prise du secteur est utilisé pour déconnecter le
système.
La prise du secteur ne doit pas être obstruée ou doit être
facilement accessible pendant son utilisation. Pour être
complètement déconnecté de l’alimentation d’entrée, la
prise doit être débranchée du secteur.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or
rechargeable (ni-cad, ni-mh, etc) batteries.
No mezcle baterías viejas y nuevas.
No mezcle baterías alcalinas, estándar (carbono-zinc) o
recargables (ni-cad, ni-mh, etc.).
• CAUTION: TO PREVENT ELECTRIC SHOCK,
MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
• WARNING:To reduce the risk of re or electric shock,
do not expose this apparatus to rain or moisture.
• AveRTIssemeNT: Pour réduire le risque d’incendie
ou de choc électrique, ne pas exposer cet appareil sous la
pluie et l’humidité.
• CAUTION: Use of any controls or adjustments or
performance of procedures other than those herein
specied may result in hazardous radiation exposure.
• WARNING: Changes or modications to this unit
not expressly approved by the party responsible for
compliance could void the user’s authority to operate the
equipment.
• WARNING: Do not place the unit on top of any soft,
porous, or sensitive surfaces to avoid damaging the
surface. Use a protective barrier between the unit and
surface to protect the surface.
• WARNING: Use of this unit near uorescent lighting
may cause interference regarding use of the remote. If
the unit is displaying erratic behavior move away from
any uorescent lighting, as it may be the cause.
• CAUTION:Danger of explosion if battery is incorrectly
replaced. Replace only with the same or equivalent type.
• PRÉCAUTION: Danger d’explosion si les piles sont
remplacées de façon incorrect. Remplacer les piles
seulement par le même type de pile ou l’équivalent.
• WARNING: There is a danger of explosion if you
attempt to charge standard Alkaline batteries in the unit.
Only use rechargeable NiMH batteries.
• WARNING: The remote control’s button cell battery
contains mercury. Do not put in the trash, instead recycle
or dispose of as hazardous waste
Warnings and Precautions
The lightning ash with arrowhead symbol, within
an equilateral triangle, is intended to alert the user
to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of
sufcient magnitude to constitute a risk of electric
shock to persons.
WARNING: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-
SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE
PERSONNEL.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
Customer Support: 1-888-999-4215 3
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
WARNING: Changes or modications to this unit not expressly
approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
• The apparatus shall not be exposed to dripping or splashing and
that no objects lled with liquids, such as vases, shall be placed on
apparatus.
L’appareil ne doit pas être exposé aux écoulements ou aux
éclaboussures et aucun objet ne contenant de liquide, tel qu’un vase,
ne doit être placé sur l’objet.
• Main plug is used as disconnect device and it should remain readily
operable during intended use. In order to disconnect the apparatus
from the mains completely, the mains plug should be disconnected
form the mains socket outlet completely.
La prise du secteur ne doit pas être obstruée ou doit être facilement
accessible pendant son utilisation. Pour être complètement
déconnecté de l’alimentation d’entrée, la prise doit être débranchée
du secteur.
• Battery shall not be exposed to excessive heat such as sunshine, re
or the like.
Les piles ne doivent pas être exposées à de forte chaleur, tel qu’à la
lumière du soleil, au feu ou autres choses de semblable.
• Caution marking is located at the rear or back of the apparatus.
Attention marquage est situé à l’arrière ou à l’arrière de l’appareil
• The marking information is located at the rear or back of apparatus.
Les informations de marquage est situé à l’arrière ou à l’arrière de
l’appareil.
FCC Warnings
Additional Warnings
1. Read these Instructions.
2. Keep these Instructions.
3. Heed all Warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding - type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide
blade or the third prong are provided for your safety.
When the provided plug does not t into your outlet,
consult an electrician for replacement of the obsolete
outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Only use attachments/accessories specied by the
manufacturer.
12.
Important Safety Instructions
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
Use only with a cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
4
• Made for iPod and iPhone
• Plays and charges docked iPod and
iPhone
• 3.5mm audio input
• Audio/video output
• .9” LCD display with white
backlight
• Sleep timer
• Dual alarm
• Snooze
• Gradual wake to iPod or buzzer
• Battery backup: requires 2 AAA
batteries (not included)
• Remote control: requires 1 CR2025
battery (pre-installed)
• DC power input: requires an AC/DC
power adapter (included)
• DC battery power: requires 4 AA
batteries (not included)
• AC/DC power adapter
• Docking adapters for iPod and
iPhone
• Remote control: requires 1 CR2025
battery (pre-installed)
• Carrying case
Portable Speaker for iPod and iPhone
Features
Included
Customer Support: 1-888-999-4215 5
TABLE OF CONTENTS
Warnings and Precautions . . . . . 2
Important Safety Instructions . . . . 3
• FCC Warnings
• Additional Warnings
Portable Speaker for iPod and iPhone . . 4
• Features
• Included
Introduction . . . . . . . . 6
Setup . . . . . . . . . . 8
• Power
• Battery Power
• Backup Battery Power
• Remote Power
iPod and iPhone . . . . . . . 9
• Docking an iPod and iPhone
• Playing a Docked iPod and iPhone
Clock . . . . . . . . . . 10
• Setting the Time
• Setting the Alarm
Audio and Video Input/Output . . . . 11
• 3.5mm Audio Input
• Audio/Video Output
Company Information . . . . . . 12
• Green Initiative
• International Support
• Contact Information
6
Introduction
ALARM/MENU
NAVIGATION
Press and hold, with the
unit powered o, to set
alarm 1 or 2.
Press to move up and down
through the menu of a
docked iPod.
VOLUME/BASS
Press to adjust the levels
of volume or bass output
from the unit’s speakers.
POWER/ALARM OFF
Press to power the unit o
or on, and to turn the alarm
o after it sounds.
BASS
Press to allow the levels of
bass to be adjusted.
AUDIO/VIDEO OUTPUT
TIME/MENU
Press and hold, with
the unit powered
o, to set the clock.
Press to move to
the previous menu
on a docked iPod or
iPhone.
DOCK FOR IPOD
AND IPHONE
SNOOZE
Press to delay the alarm
after it has sounded.
Press with the unit
powered on to set the
sleep timer.
BATTERY COMPARTMENT
Requires 4 AA Batteries
and 2 AAA Batteries, not
included)
UP/HOUR & DOWN/
MINUTE
Press to skip and search
through songs on a docked
iPod or iPhone. Press to
adjust the hour and minute
when setting the clock.
SOURCE
Press the Source Button to
switch between iPod Mode
and Aux Mode.
PLAY/PAUSE
Press to play or pause a
docked iPod or iPhone.
ENTER
Press to make selection on
a docked iPod or iPhone.
DC POWER INPUT
AUXILIARY INPUT
Customer Support: 1-888-999-4215 7
POWER BUTTON
Press the Power Button
to turn the unit o and
on.
RANDOM BUTTON
Press the Random
Button to activate
the Shue Mode on a
docked iPod or iPhone.
MUTE BUTTON
Press the Mute Button
to mute the volume on
the unit.
SOURCE BUTTON
Press the Source Button
to switch between iPod
Mode and Aux Mode.
PLAY/PAUSE BUTTON
Press the Play/Pause
Button to play or
pause a docked iPod or
iPhone.
BASS BUTTON
Press the Bass Button to
allow the levels of bass
to be adjusted.
SKIP/SEARCH
BUTTONS
Press the Skip/Search
Buttons to skip or
search through songs
on a docked iPod or
iPhone.
VOLUME/BASS
BUTTONS
Press the Volume/Bass
Buttons to adjust the
levels of volume or bass
output from the unit’s
speakers.
8
Plug the included AC/DC power
adapter into the DC POWER INPUT
and an AC power outlet to power the
portable speaker.
Power
Requires 4 AA batteries (not included)
Battery Power
Requires 1 CR2025 battery
(pre-installed)
Remote Power
Requires 2 AAA batteries (not included)
The backup battery is meant to retain
your portable speaker’s settings in the
event of an unexpected loss of power. The
backup batteries by themselves cannot
run the main functions of the portable
speaker.
Backup Battery Power
CR2025
Setup
Customer Support: 1-888-999-4215 9
Docking an iPod and iPhone
1. Locate the numbered bracket that
ts the iPod or iPhone model that
will be docked.
Each included bracket has a
number on it, indicating which iPod
or iPhone model that bracket is
compatible with. See the separate
bracket chart page to identify which
bracket is needed.
2. Snap the bracket into place over
the iPod and iPhone connector in
the dock.
3. Connect the iPod or iPhone to the
connector inside the Dock for iPod
and iPhone.
4. When the dock is plugged in, using
AC power, the docked iPod or
iPhone will charge.
iPod and iPhone
Playing a Docked iPod and iPhone
1. Follow the instructions for Docking
an iPod and iPhone.
2. Adjust the Source Button to
switch to iPod Mode.
3. Press the PLAY/PAUSE button to
begin playing the docked iPod or
iPhone.
10
Clock
Setting the Time Setting the Alarm
1. Press the POWER/ALARM OFF
button to turn the unit o.
2. Press and hold the TIME/MENU
button.
3. While holding the TIME/MENU
button, press the UP/HOUR &
DOWN/MINUTE buttons to adjust
the hour and minute.
4. Release the TIME/MENU button to
set the adjusted time.
1. Press the POWER/ALARM OFF
button to turn the unit o.
2. Press and hold the one of the
ALARM/MENU NAVIGATION
buttons.
3. While holding one of the ALARM/
MENU NAVIGATION buttons,
press the UP/HOUR & DOWN/
MINUTE buttons to adjust the
hour and minute.
4. Press the SOURCE button to
select the alarm source; iPod Mode,
Buzzer, or cancel the alarm.
5. Release the ALARM/MENU
NAVIGATION buttons to set the
adjusted alarm.
Customer Support: 1-888-999-4215 11
Audio and Video Input/Output
3.5mm Audio Input
Audio/Video Output
1. Connect a mini-phono 3.5mm
cable (not included) to the 3.5MM
AUDIO INPUT on the unit and the
audio output on an MP3 player.
2. Turn the unit on by pressing the
POWER/ALARM OFF button.
3. Press the SOURCE button to
switch the unit to Aux Mode.
4. Audio played through the
connected MP3 player will now be
heard through the unit.
1. Connect a mini-phono 3.5mm
to RCA cable (not included) to
the Audio/Video Output and
an external set of speakers or a
television.
2. Turn the unit on by pressing the
Power/Alarm O Button.
3. Dock an iPod or iPhone.
4. Press the Source Button to switch
to iPod Mode.
5. Audio and video played through
the docked iPod or iPhone will
now play on the connected
speakers or television.
Copyright © 2010 Digital Products International (DPI, Inc.) | All other trademarks appearing herein are the property of their respective
owners. Specications are subject to change without notice
To download this User’s Guide in
English, Spanish, or French, visit the
support section at www.ilive.net.
Para transferir esta guía de usuario
en inglés, español, o francés, visite la
sección de la ayuda en www.ilive.net.
Pour télécharger ce guide de
l’utilisateur en anglais, espagnol, ou
français, visitez la section de soutien
chez www.ilive.net.
Phone: 1-888-999-4215
Email: [email protected]
Parts Email: partsinf[email protected]
Website: www.ilive.net
International Support
Contact Information
Company Information
Other manuals for ISP209B
2
Table of contents
Other iLive Portable Speakers manuals
