Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
1 8200-1456-02 E0
Illustra Flex Series 3MP Indoor Dome Camera
This chapter provides product features, installation procedures, and connection information regarding
the Illustra Flex Series 3MP Indoor Dome camera.
Product features
Len cases require special care when handling and cleaning to avoid scratches. For information on
bubble handling and cleaning, see 8200-1174-01 Bubble Clearing Procedure Application Note.
Go to https://illustracameras.com/products.
From the Products page, select your camera product range and then select your camera model. Click
Downloads and search for Bubble Handling and Cleaning Procedure.
Product overview
This chapter explains the features and installation of the Flex Indoor Dome camera. Product code
and description of the camera is provided in the table below.
Table 1 Product code and description of the Flex Indoor Dome camera
Product Code Description
IFS03D1ICWTT Illustra Flex 3MP Mini-dome, 2.8-12mm, indoor, vandal, clear, white, TDN, TWDR
Figure 2 Physical dimensions of the Indoor Dome camera (mm)

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 2
Figure 3 Physical dimensions of the Indoor Dome camera
Figure 4 Pictorial index of the camera

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
3 8200-1456-02 E0
Table 5 Pictorial index descriptions
Index number Description
1 Camera bottom case
2 Tilt adjustment bracket
3 Loosen the screw to take off camera housing
4 Camera housing
5 Dome cover
Figure 6 Pin definitions of the unit

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 4
Table 7 Interior button descriptions
Interior button Description
Resets to factory default by pressing and holding the button for five seconds.
Reboots the unit.
Analog out port.
Power over Ethernet (PoE) port.
Figure 8 Connectors of the camera
NOTE Connectors and field wiring terminals for external Class 2 circuits provided with marking indicating
minimum Class of wiring to be used. Class 2 shall be marked adjacent to the field wiring terminals.
Figure 9 Audio and alarm pin definitions

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
5 8200-1456-02 E0
Installation
In the box
Check everything in the packing box matches to the order form and the packing slip. In addition to
this guide, items below are included in the packing box:
• 1 Network Indoor Dome Camera
• 1 printed Quick Start Guide
• 1 printed Regulatory document
• 1 NTSC/PAL output female BNC cable
• 1 adapter plate (for pendant cap
• 3 7mm adapter plate screws
• 1 Torx 10 Security L-Key
• 3 18mm plastic anchors and screws
• 1 installation template sticker
• 2 8mm pendant cap screws
Contact your dealer if any item is missing.
Note:The adapter plate is for an installation with a ADCi6DPCAPI (W/B) pendant cap and can also
be used to mount to a standard dual gang electrical box.
Installation tools
The following tools assist with installation:
• a drill
• screwdrivers
• wire cutters

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 6
Checking appearance
When first unboxing, check whether if there is any visible damage to the appearance of the unit and
its accessories. The protective materials used for the packaging should be able to protect the unit
from most types of accidents during transportation.
Remove the protective part of the unit when every item is checked in accordance with the list in In
the box on page 5.
Procedure 1 Disassembling the camera
Refer to Figure 10 on page 6 for a pictorial index of disassembling the camera.
Step Action
1 Remove the screws (5) to take off camera housing.
2 Gently remove the camera housing (4) and dome cover (6) and set aside.
Figure 10 Disassembling the camera
- End -
Procedure 2 Connecting the wires
Step Action
This unit supports one of the following options as power supply:
1 AC 24V:
a Connect 24V (～) cables to terminals ～AC 24V
2 PoE:

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
7 8200-1456-02 E0
a Connect the RJ-45 jack to a PoE compatible network device that supplied power
through the Ethernet cable.
3 Insert Audio cable and alarm cable to the unit, and connect the network cable to the RJ-45
terminal of a switch.
Note:The power source needs to be NEC Class 2 or LPS. The PoE connection should be provided
by a UL Listed product and the connections shall be made in accordance with Article 800 of the NEC
or local regulations.
- End -
Procedure 3 Mounting the camera
Step Action
1 Mark holes that correspond to the camera base on the mounting surface
2 Drill holes.
3 Fasten the anchors to the mounting surface with screws.
4 Connect the Safety Wire (fall prevention wire, not supplied) with one end to the ceiling and
the other to the safety-cord screw of the unit.
5 Secure the unit bottom case to the wall or ceiling with tapping screws.
6 Adjust the viewing angle. Refer to Adjusting the Position on page 7 for information regarding
how to adjust the viewing angle.
WARNING
Depending on the material of your mounting surface, you may require different screws and
anchors than those as supplied. To prevent the unit from falling off, ensure that it is secured to a
firm place (ceiling slab or channel) with a safety wire (not supplied) strong enough to sustain the
total weight of the unit. Pay attention to the finishing at the end of the wire. Never turn the lens
more than 360°, which should disconnect or break internal cables.
CAUTION Safety wire must be connected with one end to the ceiling and the other to the safety-cord screw of
the unit.
- End -
Procedure 4 Adjusting the Position
The unit has three axes for positioning, refer to Figure 11 on page 8. While monitoring, adjust the
position as below:
Step Action
1 Pan Adjustment (A). For Wall Mount and Tilted Ceilings
a Rotate the lens base (maximum 375°) until you are satisfied with the field of view.
2 Horizontal Rotation (B)
a Rotate 3D assembly in the base. Do not turn assembly more than 360° as this
assembly may cause the internal cables to twist and disconnect or break.
3 Tilt Adjustment (C):
a Tilt the lens base (maximum 90°) until you are satisfied with the field of view.

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 8
CAUTION
Limitation for three axes position:
• Pan range: 375°
• Tilt range: 90°
• Rotate range: Motorize Lens 356°
Figure 11 Adjusting the position of the camera
- End -
Procedure 5 Locking the Camera
Step Action
1 Use a soft, lint-free cloth to wipe the dome cover and remove fingerprints.
2 Attach the inner liner and camera housing.
3 Turn the power on after you have install the unit.
- End -

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
9 8200-1456-02 E0
Illustra Flex Series 3MP Outdoor Dome Camera
This chapter provides product features, installation procedures, and connection information regarding
the Illustra Flex Series 3MP Outdoor Dome camera.
Product features
Len cases require special care when handling and cleaning to avoid scratches. For information on
bubble handling and cleaning, see 8200-1174-01 Bubble Clearing Procedure Application Note.
Go to https://illustracameras.com/products.
From the Products page, select your camera product range and then select your camera model. Click
Downloads and search for Bubble Handling and Cleaning Procedure.
Product overview
This chapter explains the features and installation of the Flex Outdoor Dome camera. Product code
and description of the camera is provided in the table below.
Table 12 Product code and description of the Flex Outdoor camera
Product Code Description
IFS03D1OCWIT Illustra Flex 3MP Mini-dome, 2.8-12mm, outdoor, vandal, clear, white, TDN w/IR, TWDR
Figure 13 Physical dimensions of the Outdoor Dome camera (mm)

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 10
Figure 14 Physical dimensions of the Outdoor Dome camera
Figure 15 Pictorial index of the Outdoor Dome camera

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
11 8200-1456-02 E0
Table 16 Pictorial index descriptions
Index number Description
1 Camera bottom case
2 IR board
3 Tilt adjustment bracket
4 Camera top case
5 Loosen the screw to take off camera housing
6 Dome cover
Figure 17 Pin definitions of the unit

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 12
Table 18 Interior button descriptions
Interior button Description
Resets to factory default by pressing and holding the button for five seconds.
Reboots the unit.
Analog out port.
Power over Ethernet (PoE) port.
Note:The connector cable of the Outdoor Dome Camera should be contained in a conduit suitable for
outdoor use.
Figure 19 Connectors of the unit
NOTE Connectors and field wiring terminals for external Class 2 circuits provided with marking indicating
minimum Class of wiring to be used. Class 2 shall be marked adjacent to the field wiring terminals.
Figure 20 Audio and alarm pin definitions

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
13 8200-1456-02 E0
Installation
In the box
Check everything in the packing box matches to the order form and the packing slip. In addition to
this guide, items below are included in the packing box.
• 1 Network Outdoor Dome Camera
• 1 printed Quick Start Guide
• 1 printed Regulatory document
• 1 NTSC/PAL output female BNC cable
• 1 adapter plate (for pendant cap)
• 3 7mm adapter plate screws
• Desiccant
• 1 Torx 10 Security L-Key
• 3 18mm plastic anchors and screws
• 1 installation template sticker
• 2 8mm pendant cap screws
Contact your dealer if any item is missing.
Note:The adapter plate is for an installation with a ADCi6DPCAPI (W/B) pendant cap and can also
be used to mount to a standard dual gang electrical box.
Installation tools
The following tools assist with installation:
• a drill
• screwdrivers
• wire cutters

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 14
Checking appearance
When first unboxing, check whether if there is any visible damage to the appearance of the unit and
its accessories. The protective materials used for the packaging should be able to protect the unit
from most types of accidents during transportation.
Remove the protective part of the unit when every item is checked in accordance with the list in In
the box on page 13.
Procedure 6 Disassembling the Camera
Step Action
1 Remove the screws (4).
2 Gently remove the camera housing (3) and dome cover (5).
3 Set the camera housing aside.
Figure 21 Disassembling the outdoor camera
- End -
Procedure 7 Connecting the wires
Connect the power cable to the power plugs with one of the following options:
Step Action
1 AC 24V:
a Insert the power cable for AC 24V.
b Connect 24 V (~) cables to terminals ~AC 24V.
2 PoE:

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
15 8200-1456-02 E0
a Connect the RJ-45 jack to a PoE compatible network device that supplies power
through the Ethernet cable.
Note:The power source needs to be NEC Class 2 or LPS. The PoE connection should be provided
by a UL Listed product and the connections shall be made in accordance with Article 800 of the NEC
or local regulations.
- End -
Procedure 8 Mounting the camera
Step Action
1 Mark holes that correspond to the camera base on the mounting surface
2 Drill holes.
3 Fasten the anchors to the mounting surface with screws.
4 Connect the Safety Wire (fall prevention wire, not supplied) with one end to the ceiling and
the other to the safety-cord screw of the unit.
5 Secure the unit bottom case to the wall or ceiling with tapping screws.
6 Adjust the viewing angle.
WARNING
Depending on the material of your mounting surface, you may require different screws and
anchors than those as supplied. To prevent the unit from falling off, ensure that it is secured to a
firm place (ceiling slab or channel) with a safety wire (not supplied) strong enough to sustain the
total weight of the unit. Pay also attention to the finishing at the end of the wire. Never turn the lens
more than 360°, which should disconnect or break internal cables.
CAUTION Safety wire must be connected with one end to the ceiling and the other to the safety-cord screw of
the unit.
- End -
Procedure 9 Optional - 4S Electrical Junction Box
Step Action
1 Secure the mounting kit (optional) to 4S Electrical box using 2 appropriate screws.
2 Secure the unit case to mounting kit using 2 appropriate screws.
3 Tuck the cables in the 4S Electrical box.
4 Adjust the view angles.
5 Attach the unit housing.
6 Turn the power on after you install the unit.

Illustra Flex 3MP Indoor and Outdoor Dome Cameras Quick Start Guide
8200-1456-02 E0 16
Figure 22 Mounting the camera with the junction box
NOTE
The mounting kit called out in Figure 22 on page 16 is not supplied with the unit.
Keeping tilt angle over 25 degrees is recommended when IR-LED light is used. If tilt angel is below 25
degrees from the horizontal, the image would be flashed by the reflection of IR-LED light.
- End -
Procedure 10 Adjusting the Position
The unit has three axes for positioning, refer to Figure 23 on page 17. While monitoring, adjust the
position as below.
Step Action
1 Pan Adjustment (A) For Wall Mount and Tilted Ceilings:
a Rotate the lens base (maximum 375°) until you are satisfied with the field of view.
2 Horizontal Rotation (B):
a Rotate 3D assembly in the base. Do not turn assembly more than 360° as this
assembly may cause the internal cables to twist and disconnect or break.
3 Tilt Adjustment (C):
a Tilt the lens base (maximum 90°) until you are satisfied with the field of view.
CAUTION
Limitation for three axes position:
• Pan range: 375°
• Tilt range: 75°
• Rotate range: Motorize Lens 356°
