SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Model 682B05 Bearing Fault Detector
Operating Guide with Enclosed Warranty Information
3425 Walden Avenue, Depew, New York 14043-2495
Phone [phone]
Fax [phone]
Toll Free Line 1-800-959-4IMI
MANUAL NUMBER: 53377
MANUAL REVISION: B
ECN NUMBER: 46398

PAGE 2
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Table of Contents
Introduction...................................................................................................................... Page 3
General Features
Installation and Wiring..................................................................................................... Page 4
Configuring the 682B05................................................................................................... Page 8
ESD Sensitivity............................................................................................................... Page 10
Warranty/Servicing
Warranty, Service & Return Procedure .......................................................................... Page 11
Customer Service........................................................................................................... Page 12

PAGE 3
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Introduction
The Model 682B05 is a 4-20mA Din Rail Signal Conditioner designed to interface with IMI Sensor’s ICP®
accelerometer for bearing fault detection. Specifically, the 682B05 detects high frequency impacts related to
bearing fault/lube starvation and provides a 4-20mA signal proportional to the magnitude of vibration. From the
same sensor, the device also converts overall vibration to a 4-20mA signal, which is used for traditional machine
diagnostics and predictive maintenance such as out of balance and misalignment.
General Features
Early detection of high frequency impact faults related to bearing failure and lube starvation.
External transmitters, signal conditioners, and ICP®power supplies can be eliminated by direct
connection of the sensor to the Din Rail Signal Conditioner.
18Vdc/4mA excitation to power sensor.
Dual 4-20mA Output Signals for Bearing Fault and Overall Vibration.
Selectable High Pass filtering for Bearing Fault Detection.
Overall Output Vibration Ranges include:
Acceleration (g’s)
Velocity (in/sec)
5.00
0.50
10.00
1.00
20.00
2.00
Internal DIP switch selection for Peak or RMS on Overall Vibration.
Analog output signal connections (RV) for conducting additional frequency analysis.
Removable Terminal Blocks for easy wiring.
35mm (1.38in.) Din Rail Mount configuration.
Space saving 22.5mm (0.9in.) wide design.

PAGE 4
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Installation and Wiring
Installation
The Model 682B05 is designed to be mounted on a 35mm Din Rail. Do not install in a harsh area where it can be
exposed to cleaning fluids or machine oils. IMI Sensors recommends mounting the 682B05 in a type NEMA 4
enclosure similar to the Model 682A00 to protect the electronics from contamination.
Dimension Drawing
Inch (mm)

PAGE 5
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Connector and Pinout Diagram
The 682B05 uses plug-in type screw terminal connectors for all input and output connections.
Strip off 8mm of insulation from the connection wire ends. Using a screwdriver, remove the terminal block from
the enclosure in either the up or down direction, terminate the wire in the correct location. Do not exceed a torque
of 0.5Nm. Re-install the terminal block.
This easy to assemble connection method allows devices to be exchanged easily and the electrical connection to
be visibly isolated.
Pin Location Diagram
WARNING
AC and DC input signals and power supply voltages could be hazardous. DO NOT
connect live wires to screw terminal plugs, and DO NOT insert, remove, or handle screw
terminal plugs with live wires connected.

PAGE 6
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Pin Descriptions:
DC Power –Pins 1 through 4:
Pin 1 +Power
Pin 2 -Power/Common
Pin 3 Earth Ground
Pin 4 No Connection
ICP®Accelerometer –Pins 5 through 8:
Pin 5 + ICP®Accelerometer
Pin 6 - ICP®Accelerometer
Pin 7 Shield
Pin 8 No Connection
Raw Vibration (RV) –Pins 9 through 12, and BNC Jack:
Pin 9 + RV
Pin 10 - RV
Pin 11 No Connection
Pin 12 No Connection
4 to 20mA Fault Detector Output –Pins 13 & 14:
Pin 13 + 4 to 20mA Fault Output
Pin 14 - 4 to 20mA Fault Output
4 to 20mA Overall Vibration Output –Pins 15 & 16:
Pin 15 + 4 to 20mA Vibration Output
Pin 16 - 4 to 20mA Vibration Output
Notes:
Pins 3 and 7 are tied together but are NOT tied to the grounding tab on the back of the enclosure.
Land the accelerometer cable’s shield on Pin 7.
Tie Pin 3 to either din rail ground or Earth ground with the use of an external wire.

PAGE 7
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Typical Wiring Diagram
Note: If using the 682A01, mount the 682B05 to the left side of the power supply (as shown) with a recommended
minimum separation distance of 4” where applicable.

PAGE 8
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Configuring the 682B05
Internal PC Board Diagram
T3
T4
T1
T2
T8
T7
T5
T11
T9
T10
T12
T15
T13
T14
T16
OUTPUT1
S3S2
R28
S1
R73
R65
S456
RMS
5K
ACCEL
VEL
PK
S4
S5
PT.NO. 50831-01PCB
S6
1K
R56
R55
T6
LED1
POWER
LED
The Internal PC Board Diagram shows the location of the internal DIP and Slide switches. The switches are used
to configure the 682B05 for various sensor and vibration ranges.
The PC Board is accessible through the front of the conditioner by removing the Screw Terminal Connectors and
disengaging the tabs on the TOP and BOTTOM of the enclosure with a screwdriver. Once disengaged, the PC
Board can be slid out for configuration.
DIP Switch and Slide Switch Description:
S1: BFD High Pass Filter: 1kHz or 5kHz
S2: Overall Vibration Acceleration or Velocity Mode
S3: Overall Vibration Peak or RMS Mode
S4: Overall: 5g, 0.5ips
S5: Overall: 10g, 1ips
S6: Overall: 20g, 2ips

PAGE 9
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Warning: Do not make any adjustments to the internal potentiometers. These potentiometers are used for
factory calibration and adjusting them will require return of the 682B05 to the factory for recalibration.
Internal Switch Settings
The internal switches of the Model 682B05 must be configured for the Full Scale Output of the ICP®Sensor
connected to it. This is accomplished by removing the front cover and sliding the PC Board out of the Signal
Conditioner. Once removed, the switches should be configured per one of the conditions in the following table.
Bearing Fault Detector: Set S1 for 1kHz or 5kHz (based on running speed). Range is fixed at 50g’s Peak.
Overall Vibration:
Range Setting
S2
S3
S4
S5
S6
5g RMS
UP
UP
ON
OFF
OFF
5g Peak
UP
DOWN
ON
OFF
OFF
10g RMS
UP
UP
OFF
ON
OFF
10g Peak
UP
DOWN
OFF
ON
OFF
20g RMS
UP
UP
OFF
OFF
ON
20g Peak
UP
DOWN
OFF
OFF
ON
0.5 in/sec RMS
DOWN
UP
ON
OFF
OFF
0.5 in/sec Peak
DOWN
DOWN
ON
OFF
OFF
1.0 in/sec RMS
DOWN
UP
OFF
ON
OFF
1.0 in/sec Peak
DOWN
DOWN
OFF
ON
OFF
2.0 in/sec RMS
DOWN
UP
OFF
OFF
ON
2.0 in/sec Peak
DOWN
DOWN
OFF
OFF
ON
Note: Factory Default Setting is 1.0in/sec Peak
Recommended Alert and Alarm Settings for Fault Detector:
Although each machine will have alert and alarm settings at various levels based on its high frequency spectra,
data has been provided as a baseline to approximate what these limits should be. Note that this data is a
recommendation and levels should be adjusted according to measurements taken from a detailed vibration
analysis and/or machine history. Please contact IMI Sensors for additional information and support regarding Alert
and Alarm settings.
Recommended Fault Detector Alert and Alarm Limits
Speed Range (RPM)
Alert Limit (Peak g-level)
Alarm Limit (Peak g-level)
Less than 5
0.100
0.180
5 - 10
0.150
0.270
10 - 20
0.200
0.360
20 - 60
0.400
0.720
60 - 150
1.000
1.800
150 - 400
2.000
3.600
400 - 700
4.000
7.200
700 - 4000
5.000
9.000
4000 - 10000
7.000
12.600

PAGE 10
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Warning 1 –ESD sensitivity
The power supply/signal conditioner should not be opened by anyone other than qualified service
personnel. This product is intended for use by qualified personnel who recognize shock hazards and are familiar
with the safety precautions required to avoid injury.
Warning 2 –ESD sensitivity
This equipment is designed with user safety in mind; however, the protection provided by the equipment may be
impaired if the equipment is used in a manner not specified by PCB Piezotronics, Inc.
Caution 1 –ESD sensitivity
Cables can kill your equipment. High voltage electrostatic discharge (ESD) can damage electrical devices.
Similar to a capacitor, a cable can hold a charge caused by triboelectric transfer, such as that which occurs in the
following:
Laying on and moving across a rug,
Any movement through air,
The action of rolling out a cable, and/or
Contact with a non-grounded person.
The PCB solution for product safety:
Connect the cables only with the AC power off.
Temporarily “short” the end of the cable before attaching it to any signal input or output.
Caution 2 –ESD sensitivity

PAGE 11
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
ESD considerations should be made prior to performing any internal adjustments on the equipment. Any
piece of electronic equipment is vulnerable to ESD when opened for adjustments. Internal adjustments should
therefore be done ONLY at an ESD-safe work area. Many products have ESD protection, but the level of
protection may be exceeded by extremely high voltage.
Warranty
IMI instrumentation is warranted against defective material and workmanship for 1 year unless otherwise
expressly specified. Damage to instruments caused by incorrect power or misapplication, is not covered by
warranty. If there are any questions regarding power, intended application, or general usage, please consult with
your local sales contact or distributor. Batteries and other expendable hardware items are not covered by
warranty.
Service
Because of the sophisticated nature of IMI instrumentation, field repair is typically NOT recommended and may
void any warranty. If factory service is required, return the instrumentation according to the “Return Procedure”
stated below. A repair and/or replacement quotation will be provided prior to servicing at no charge. Before
returning the unit, please consult a factory IMI applications engineer concerning the situation as certain problems
can often be corrected with simple on-site procedures.
Return procedure
To expedite returned instrumentation, contact a factory IMI applications engineer for a RETURN MATERIAL
AUTHORIZATION (RMA) NUMBER. Please have information available such as model and serial number. Also,
to insure efficient service, provide a written description of the symptoms and problems with the equipment to a
local sales representative or distributor, or contact IMI if none are located in your area.
Customers outside the U.S. should consult their local IMI distributor for information on returning equipment. For
exceptions, please contact the International Sales department at IMI to request shipping instructions and an RMA.
For assistance, please call [phone], or fax us at [phone]. You may also receive assistance via e-
mail at [e-mail] or visit our web site at www.pcb.com.

PAGE 12
SENSORS AND INSTRUMENTATION FOR MACHINE CONDITION MONITORING
Customer Service
IMI, a division of PCB Piezotronics, guarantees Total Customer Satisfaction. If, at any time, for any reason, you
are not completely satisfied with any IMI product, IMI will repair, replace, or exchange it at no charge. You may
also choose, within the warranty period, to have your purchase price refunded.
IMI offers to all customers, at no charge, 24-hour phone support. This service makes product or application
support available to our customers, day or night, seven days a week. When unforeseen problems or emergency
situations arise, call the IMI Hot Line at [phone], and an application specialist will assist you.
3425 Walden Avenue, Depew, NY 14043-2495
Phone: [phone]  USA Fax: [phone]  INTL Fax: [phone]
ICP®is a registered trademark of PCB Group, Incorporated,
which uniquely identifies PCB sensors that incorporate built-in microelectronics.
