IMP De Mayo Hip Positioner SystemOBESE Manual

De Mayo Hip Positioner® System
OBESE (Large Patient) Set Up Instructions
1. Leave OR table pads in place, then place OR bedsheet on top.
2. Pre-Assemble the Positioner. Assemble at bar into bottom groove of Lumbar Support Base. Assemble
washer and locking knob.
3. Roll the patient on their side.
4. Attach Bariatric Extension Plate (1101-BE).
)
.
5. Attach Contoured Lumbar Pad for left or right hip application.
o
n.

De Mayo Hip Positioner® System
OBESE (Large Patient) Set Up Instructions page 2
6. Assemble Lumbar Support Base into the imp® Rail Clamp at a position even with the patient’s iliac crest.
Use the Vertical Bar in a straight and upright position as a guide to aim at the patient’s iliac crest.
Lock Flat Bar Knob in center groove
of Support Base.
nob
in
cente
r
r
gr
gr
oo
oo
ve
ve
e.
7. Angle the Vertical Support Bar towards the head of the patient. Assemble the Horizontal Crossover
Large Bar #1 onto the Vertical Bar #1. Allow 2 ngerbreadths between the patient and the bar.
readths
between
the
pa
tient
and
the
bar
.
Large
* Anterior Support Assembly (includes Anterior Support, Anterior Vertical Support -Large, Anterior Pelvic Support)
Attach Anterior Rotation Bar #3 to round end
of Horizontal Bar #3/2.
--Large
Attach Anterior Pelvic Support
#4 to Anterior Vertical Bar #4.
Finished Assembly
pp
y
Attach AnteriorRotation Bar #3to
CAUTION: Make sure the
threaded knob ts into
groove on #3
4

De Mayo Hip Positioner®System
OBESE (Large Patient) Set Up Instructions page 3
8. Place Anterior Patient Protector Pad onto the Anterior Support Assembly.
9. Slide the “Large” Anterior Support Assembly over Crossover Bar #2. Rotate Anterior Vertical Bar #3,
and adjust Anterior Pelvic Support #4, so that the Anterior Patient Protector Pad contacts the superior
iliac crest.
st Anterior Pelvic S
up
p
po
p
rt #
4,
so that the Anterior Pa
t
t.
10. Compress Anterior Support Assembly pushing toward Lumbar Support.
Lock Anterior Support Knob #2.
If any readjustments are required,
release Compression Knob #2, then adjust
any other knobs to achieve greatest stability.
TIGHTEN ALL KNOBS FOR SECURITY
2
.

De Mayo Hip Positioner®System
OBESE (Large Patient) Set Up Instructions page 4
De Mayo Hip Positioner® is a registered trademark of Innovative Medical Products, Inc.
De Mayo Hip Positioner® US Patent #6,820,621
imp® Rail Clamp is a trademark of Innovative Medical Products, Inc.
© 2011 Innovative Medical Products, Inc.
All Rights Reserved
OPTION - Stabilizer Bar may be inserted into the Anterior Support Assembly with an additional
imp® Rail Clamp (note: maintain 2 ngerbreadths at the rib cage and Horizontal Crossover Bar).
Add the Stabilizing Bar Tube by sliding it from the anterior side of the patient into the opening of
the Anterior Support Assembly.
Slide the Stabilizing Bar Hook into the imp® Rail Clamp. Attach to the threads of the Stabilizing Bar Tube,
and tighten both knobs.
In the event (while utilizing the Stabilizing Bar) you
cannot seat the Adjustable Support Assembly,
loosen compression and rotate plate. With the
Anterior Pelvic Support out of the way, seat the
Adjustable Lateral Support and re-engage the
Anterior Pelvic Support.
A
nter
i
or
P
e
l
v
i
c
S
u
pp
pp
pp
pp
ort
.
