Handicare SystemRoMedic MiniLift160EE User manual

Manual nr: 450 ver. 10 151210
MiniLift160EE/MiniLift160EM
SystemRoMedicTM
SWL: 160 kg/350 lbs
REVISION HISTORY
REV. DESCRIPTION DATE APPROVED
D
E
F
C
1 2 3 4
B
A
3 2 1 5
C
D
4 6 7 8
A
B
This drawing and any information or descriptive matter set out hereon are the confidential and copyright property of Handicare
and must not be disclosed, loaned, copied or used for manufacturing, tendering or any other purpose without their written permission.
01
SCALE PROJECTION
Material <not specified>
MATERIAL SPECIFICATION:
A3
2015-03-13
38130.55 g
90003418
MiniLift 160EE
Released
SIZE
MATERIAL:
TITLE
STATUS
WEIGHT:
SHEET 1 OF 1
CREATED
DATE NAME
REV. DWG. NO.
1:20
60300010
60300011
60300012
60300013

3
MANUAL
SystemRoMedicTM
English
MiniLift160 is a mobile sit-to-stand lift which has been developed to, as gently as possible, assist the user when rising
from a sitting to a standing position. When MiniLift160 is combined with the appropriate lifting accessories, the user gets
support under the feet, for the front of the lower legs and behind the back, which provides for a safe and secure
sit-to-stand procedure. The construction safely moves the user forwards and upwards in a natural movement pattern
and, at the same time, the leg muscles and balance is exercised. MiniLift160 is available in four variants with electrical
(EE) or manual (EM) base widening and with standard height or low legs for use with lower beds. All variants are
manufactured in steel for stability and strength and are suitable for users weighing up to 160 kg/350 lbs.
1. Lift arm
2. Hooks for lift vest/sling
3. Hand control
4. Leg support
5. Footplate
6. Rear castos with brakes
7. Battery
8. Emergency stop
9. Adjustment of leg support
10. Electrical emergency lowering
11. Charging lamp
12. Front castors
13. Locking mechanism for adjustment of lift arm
14. Base-width adjustment
REVISION HISTORY
REV. DESCRIPTION DATE APPROVED
D
E
F
C
1 2 3 4
B
A
3 2 1 5
C
D
4 6 7 8
A
B
This drawing and any information or descriptive matter set out hereon are the confidential and copyright property of Handicare
and must not be disclosed, loaned, copied or used for manufacturing, tendering or any other purpose without their written permission.
01
SCALE PROJECTION
Material <not specified>
MATERIAL SPECIFICATION:
A3
2015-03-13
38130.55 g
90003418
MiniLift 160EE
Released
SIZE
MATERIAL:
TITLE
STATUS
WEIGHT:
SHEET 1 OF 1
CREATED
DATE NAME
REV. DWG. NO.
1:20
1
2
3
4
5
7
9
12
13
810
11
6
14
MiniLift160EE/MiniLift160EM
SystemRoMedicTM
Visual inspection
Inspect lift functions regularly. Check to ensure that material is free from damage.
Before use
Make certain the lift is properly assembled.
Check sling bar connection and safety latch function.
Check lifting function and base-width adjustment.
Check to ensure that the actuator is correctly installed.
Always read the user manuals for all assistive devices used during a transfer.
Keep the user manual where it is accessible to users of the product.
Always make sure that you have the right version of the user manual.
Under no circumstances may the lift be used by persons who have not received instruction in the operation of the lift.
It is strongly prohibited to modify the original product.
Safety information
Always read the user manual
English

4MANUAL SystemRoMedicTM
Assembly
Check to ensure that all components are included:
Lift unit, control box and battery pack, undercarriage, footplate, leg support, hand control and cord, user manual and
charger.
The lift is collapsed when delivered. Set up the lift, according to the following instructions
(no tools required):
1. Lock castor brakes.
2. Place the mast in the base
3. Mount the lockninghandles at the base of the mast.
4. Tighten locking handle (1).
5. Check all mounting fixtures and locking handles.
6. Deactivate the emergency stop function and perform a final inspection (see Final
inspection).
Connect cables: Hand control cord in HS, cable to lift unit on mast in outlet M1, and
cable to base-width motor in outlet M2. (EE)
To collapse the lift, follow the instructions below.
1. Lock castor brakes.
2. Change the base width pedal to horizontal.
3. Remove legsupport and footplate.
4. Run the lift arm to the lowest position, and then activate in the emergency stop button.
5. Push the lift arm in as far as possible.
6. Loosen the locking handle at the base of the mast (1). You need not remove the locking handle.
7. Lift up on the mast and lower it towards the undercarriage.
Warning, risk of pinching (between base and mast)
8. Pull the mast back and tighten the locking handle (1).
1
HS M1 M2

5
MANUAL
SystemRoMedicTM
Final inspection
Inspect the lift for signs of wear and damage. Check all castors and castor brakes.
Check all connections and fixtures including screws and bolts. Check the packaging to
ensure that there are no loose parts.
Check the emergency stop function by activating the emergency stop button, and
then pressing either the up or down button. If nothing happens when the up or down
buttons are pressed, the emergency stop is functioning properly.
Grasp the hand control, press the up button and run the lift arm all the way up. Then,
press the down button and run the liftarm all the way down.
Test base-width adjustment function by pushing down on the respective pedals for
widening and narrowing the base. For EE use the buttons on the hand control.
Test lift function by lifting a person (not a user) using an approved sling. At the same
time, check the emergency lowering function with someone in the lift, see section on
Emergency lowering.
If the lift is functioning correctly, connect the charger and check to ensure that the
charging lamp on the control box lights up.
NOTE!
Before the lift is used for the first time:
• it must be charged for at least 4 hours. See section on charging batteries.
• the control box service counter needs to be reset. To reset the service counters
press both lift buttons on the hand control at the same time for 5 seconds.
An audio signal will indicate that the timer has been reset.
Keep the user manual where it is accessible to users of the product.
EE
EM
English

6MANUAL SystemRoMedicTM
• The lift must be assembled according to the assembly instructions provided with the lift.
• The lift may only be used indoors and on a level floor.
• Lifting accessories must be properly trial fitted and tested in relation to the user’s needs and functional ability.
• Do not leave the user unattended during a transfer situation.
• Under no circumstances may max. load be exceeded. See section on Safe working load.
• The lift arm must be loaded throughout the entire lowering procedure to ensure a soft and smooth experience.
• Ensure that the user’s feet do not get caught between the footplate and the floor. Ensure that the user’s feet do not get
caught between the footplate and the base when adjusting the base width.
• MiniLift160 is not intended for transporting users. It may only be used for short transfers.
• Never move the lift by pulling on the actuator!
• The lift must not be used or immersed in or under water including showering.
• The lift should not be left / stored in a high humidity environment.
• The lift must not be charged in a wet room.
• To ensure optimal function, the lift must be inspected regularly. See section on Maintenance.
• Warranty applies only if repairs or alterations are done by an authorized technician.
• Using lifting accessories other than those approved by Handicare can entail a risk.
• Note the risk of pinching between base and mast when collapsing the lift.
Do not push
Important Information
Safe working load
Different products on the same lift system (lift unit, sling bar, sling, scales and other lifting accessories) may have different
allowable safe working loads. The lowest allowable safe working load always determines the safe working load of the
assembled system. Always check the safe working loads for the lift and accessories before use. Contact your dealer if
you have any questions.
Using the product
To transfer with MiniLift160, the user must be able to:
• support weight while standing
• understand instructions

7
MANUAL
SystemRoMedicTM
Charging batteries
A tone sounding when using the lift indicates that the battery need recharging.
Charge the lift after use to ensure that the battery is always fully charged.
Lock the castor wheels when charging the battery.
1. Connect the charging cable to a power outlet and in the connection for charger cable.
The symbol for charging is shown on the display.
2. Check to ensure that the lamps on the control box light up. The green LED lamp
indicates that the charger is receiving power and the yellow LED lamp indicates that the
battery is charging.
3. Charging stops automatically when the battery is fully charged.
Wall-mounted charger.
1. Remove the battery pack from the lift and place it in the wall-mounted charger.
2. Check to ensure that the LED lamp on the front of the charger lights up.
NOTE!
Before the lift is used for the first time, it must be charged for at least 4 hours.
For maximum battery life, charge batteries regularly. We recommend daily charging when
the lift is used daily.
The emergency stop must be deactivated during charging.
The control box and battery have the following features
1. Emergency stop
2. Charging lamps
3. Display showing battery charge level
4. Connection for charger cable
5. Connection for base-width adjustment motor
6. Connection for lift arm actuator
7. Connection for hand control
8. Electrical emergency lowering
9. Handle for lifting battery
1
7
65
4
3
2
2
9
8
English

8MANUAL SystemRoMedicTM
Service information read-out
Basic service information can be read out on the display. To get the service information on the
display please press the lifting arm up button for half a second. The information will be shown
for ½ minute or until other buttons are activated.
• Total cycles done by the actuator
• Total work done by the actuator (ampere usage times seconds in use)
• Total number of overloads
• Days since last service/Days between services
Battery information on the display
The battery discharging will be shown in four stages:
Battery state 1: The battery is ok, no need for charging (100 - 50 %).
Battery state 2: Battery needs charging. (50 - 25 %)
Battery state 3: Battery needs charging. (Less than 25 %) A tone sounds when a button is pressed in
this battery state.
Battery state 4: The battery needs charging (17V or lower). At this stage some of the functionality of
the lift is lost. At this battery stage it is only possible to drive the lifting arm down. Furthermore an
audio signal will sound when a control button is activated. The symbol will switch between the two
pictures for 10 seconds.
The battery symbol is shown when the box is active until power down (2 minutes after use).
It is not possible to use other batttery types than BAJ1/BAJ2.
The battery level is measured via voltage level. This means that it is possible to experience e.g. that
the battery switches from state 1 to state 2 and back to state 1.

9
MANUAL
SystemRoMedicTM
Hand control
Raising/lowering the lift arm
Symbol indicate direction of travel.
Motion stops as soon as the button is released.
Electrical base-width adjustment (EE)
Markings on the buttons of the hand control indicate function.
Motion stops as soon as the buttons are released.
Manual base-width adjustment (EM)
Push down on the respective pedals at the back of
the lift to widen and narrow the base.
Emergency stop
To activate emergency stop
Activate the red emergency stop button on the control box.
Resetting
Turn the button in the direction of the arrows until the button pops out.
Emergency lowering
Manual emergency lowering
For manual emergency lowering, turn the round plastic knob
on the actuator clockwise.
Electrical emergency lowering
For electrical emergency lowering, use the down button on
the control box. Use a narrow object such as a pen.
Eva450EEL Eva600EEL
Eva450EML
REVISION HISTORY
REV. DESCRIPTION DATE APPROVED
D
E
F
C
1 2 3 4
B
A
3 2 1 5
C
D
4 6 7 8
A
B
SCALE:1:10
DWG. NO. REV.
NAME DATE
DRAWN
APPROVED BY
SHEET 1 OF 1
WEIGHT:
COMMENTS:
STATUS: TITLE
MATERIAL:
SIZE
Released
EVA EEL 450 base
90001288 02
g
2011-05-20
A3
Unless otherwise stated, general
tolerances according to ISO 2768-m
hc-jope
This drawing and any information or descriptive matter set out hereon are the confidential and copyright property of Handicare
and must not be disclosed, loaned, copied or used for manufacturing, tendering or any other purpose without their written permission.
EM
EE
EM
Electrical emergency
lowering
Manual emergency
lowering
English

10 MANUAL SystemRoMedicTM
Instructions for use
These instructions must be followed for correct use of MiniLift160.
Caution
The actuator does not lower the lift arm when the lift is being lowered. This reduces the risk of the user being pinched by
the lift arm. To prevent the lift arm from at first catching, and then suddenly fal the lift arm must be loaded throughout the
entire lowering procedure, so that it is always supported by the actuator.
Hand control functions
The hand control has four functions: up and down (lift arm), out and in (base width).
Two functions cannot be used at the same time.
NOTE: The hand control functions do not operate if the emergency stop button is activated
NOTE: MiniLift160 is not intended for transporting users. It may only be used for short transfers.
Caution Never move the lift by pulling on the actuator.
Caution Ensure that the user’s feet do not get caught between the footplate and the floor. Ensure that the user’s feet do
not get caught between the footplate and the base when adjusting the base width.

11
MANUAL
SystemRoMedicTM
Using MiniLift160
Place an appropriately sized ThoraxSling behind and below the user’s hips,
(see user manual for ThoraxSling). (1)
When the user has placed his/her feet on the footplate, move the lift forward
towards the user. Place the lift as close as possible to the user. Take care to
ensure that the user’s shins are resting securely against the leg support, and
then adjust (2) the leg support so that it does not press against the user’s
kneecaps (about 2 cm lower). (3)
Raise the locking handle (4) on the lift arm and pull the lift arm out as far as
possible towards the user.
Select the sling loop that reaches the hook on the boom (shortest loop
alternative). Hook the lift loops to the underside of the sling bar. (5)
1
2
3
4
5
English

12 MANUAL SystemRoMedicTM
Instruct the user to lean back and allow himself/herself to be supported behind the
back during raising. Raise the lift to the desired height and ensure that the user is
standing with both feet on the footplate and is grasping the sling bar handles with
both hands to avoid being pinched between the slingbar and lift loops. (7)
6
7
Helpful hint:
Use a longer loop alternative for short users and for users that cannot be fully raised.
Use a shorter loop alternative for taller users, and pull the lift arm out to allow the user to rise to a standing position.
Raise the locking handle and draw the boom back, so that the lift straps on the sling are stretched, and then lower the
locking handle back into position. (6)

13
MANUAL
SystemRoMedicTM
Trouble-shooting
If the lift adjustment cannot be activated, check the following:
- That the emergency stop button is not activated.
- That all cables are properly and securely connected. Pull out the contact and plug it in again firmly.
- That battery charging is not in progress.
- That the battery is charged.
If the lift is not working properly, contact your dealer.
If the lift makes unusual noises:
- Try to determine the source of the sound. Take the lift out of operation and contact your dealer.
Accessories
ThoraxSling, polyester, XS-XXL, article no.: 45500003-009
ThoraxSling, wipeable, S-XXL, article no.: 45500004-009
ThoraxSling, with seat support, polyester, S-XL, article no.: 45600004-008
ThoraxSling, with seat support, disposable, non-woven, S-XL,
article no.: 45690004-008
CalfStrap, article no.:70200033
SlingBarWrap MiniLift, wipeable, article no.: 70200012
Hand control
Hand control HB33-6, 6 buttons, with service, battery status and overload
indicators, article no.: 70200089
English

14 MANUAL SystemRoMedicTM
Maintenance
The lift must undergo thorough inspection at least once per year. Inspection must be performed by authorized personnel
and in accordance with Handicare’s service manual.
Repairs and maintenance may only be done by authorized personnel using original spare parts.
Used batteries are to be left at the nearest recycling station. Used batteries can also be returned to
Handicare or a Handicare dealer for recycling.
+50 ºC
-10 ºC
Cleaning/disinfection
If necessary, clean the lift with warm water or a soap solution and check that the castors are free from dirt and hair. Do
not use cleaning agents containing phenol or chlorine, as this could damage the aluminium and the plastic materials. If
disinfection is needed, 70 % ethanol, 45 % isopropanol or similar should be used.
Storage and transportation
If the lift is not to be used for some time or e.g., during transport, we recommend that the emergency stop button be
pressed in. The lift should be transported and stored in -10 ° C to + 50 ° C and in normal humidity, 30% -75 %. The air
pressure should be between 700 and 1060 hPa. Let the lift reach room temperature before the batteries are charged or
the lift is used.
Service agreements
Handicare offers the possibility of service agreements for maintenance and regular testing of your mobile lift. Contact
your local Handicare representative.
106 kPa
70 kPa
75%
30%
1060 hPa
700 hPa
+50 °C
-10 °C
75%
30%

15
MANUAL
SystemRoMedicTM
Symbols
Read user manual
May not be discarded in domestic waste
The product fulfills the demands stated in the MDD 93/42/EEC
Type B, according to the degree of protection against electric shock.
The device is intended for indoor use.
Class lI equipment
Always Read The User Manual
This equipment/system is intended for use by healthcare professionals only. This equipment/system may cause radio
interference or may disrupt the operation of nearby equipment. It may be necessary to take mitigation measures, such
as reorienting or relocating the equipment/system or shielding the location.
EMC
English

16 MANUAL SystemRoMedicTM
Lifting speed: 1.4“ /s, 35 mm/s without load.
Batteries: Two 12V, 2.9 Ah valve-regulated, sealed, lead accumulator (gel-type batteries)
Charger: 400 m A
Motor: DC 24V, 5,5 Amp. IP X4. Operationtime: 10% at maximum continous operation of 2
minutes, maximum 5 cycles per minute. Push: 4 000N.
Sound level: With load: upwards: 74.7 dB(A) downwards: 52.6 dB(A).
Material Steel
Emergency lowering: Mechanical and electrical
Castors: Front 3.9”, 100 mm, back 3.9”, 100mm
Weight: 89.3 lbs, 40,5 kg
Turning diameter: 43,6”, 1109 mm
IP class: IP X4
Expected lifetime: 10 years
Operating forces buttons on
hand controll:
4 N
Max. load: 160kg/350 lbs
Technical Information
Medical Device Class I. The product complies with the requirements of the Medical Devices Directive 93/42/EEC.
